Kavita on GKE Autopilot

Kavita is a fast, feature-rich, self-hosted digital library and reading server for comics, manga, and e-books — a clean web reading UI, OPDS feeds, collections, reading lists, and full-text search over your library, built on .NET with an internal SQLite database. This module deploys Kavita on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services Kavita uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

1. Overview

Kavita runs as a single .NET web workload with no external database or cache — everything it needs (settings, its internal SQLite database, and the library index) lives on disk under /kavita/config.

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	.NET web pod on port 5000, 1000m CPU / 1Gi memory by default
Database	None — internal SQLite	database_type is fixed to NONE by Kavita_Common; no Cloud SQL instance is created
State persistence	Per-pod block PVC (StatefulSet)	/kavita/config holds the SQLite database (kavita.db) and app settings; on by default (stateful_pvc_enabled = true)
Object storage	Cloud Storage	A storage bucket is provisioned by Kavita_Common, but is only mounted at /kavita/config when the block PVC is disabled
Secrets	Secret Manager	None generated — the first-run setup wizard creates the admin account; secret_ids/secret_values are empty
Ingress	Kubernetes Gateway API	ClusterIP Service by default, exposed through the Gateway with a reserved static IP; custom domain supported

Sensible defaults worth knowing up front:

• SQLite lives on a real block PVC, not GCS FUSE. stateful_pvc_enabled defaults to true, so Kavita runs as a StatefulSet with a per-pod block PVC mounted at /kavita/config. This is deliberate: gcsfuse corrupts SQLite/media indexes, so the GCS FUSE mount (enable_gcs_storage_volume) is only used as a fallback when the block PVC is turned off. If you ever set stateful_pvc_enabled = false, Kavita's SQLite database and library metadata move onto the GCS FUSE-backed storage bucket instead — do this only if you understand the SQLite-on-gcsfuse risk.
• The storage GCS bucket is created either way but only mounted conditionally. Kavita_Common always declares a storage bucket output, but the GKE wrapper sets enable_gcs_storage_volume = !stateful_pvc_enabled, so with the default block PVC in place that bucket exists but is not mounted into the pod.
• Single replica by default, and it should stay that way. min_instance_count = 1, max_instance_count = 1. Kavita serves one shared SQLite library from one volume — there is no clustering or shared-storage coordination, so running more than one replica against the same PVC is unsafe.
• NFS is off by default (enable_nfs = false) — persistence is handled entirely by the StatefulSet PVC, not Filestore.
• No first-boot database setup job. Kavita has no db-init/migration job; initialization_jobs defaults to an empty list and only custom jobs you supply are run.
• No auto-generated secrets. Unlike most application modules, Kavita has no admin password or API key created in Secret Manager — the admin account is created through the web UI's first-run setup wizard the first time you open the service.
• session_affinity is None and service_type is ClusterIP — external access goes through the Gateway API (enable_custom_domain = true by default) rather than a directly exposed LoadBalancer Service.
• Redis is forced off. App_GKE's foundation default for enable_redis is true, but Kavita_GKE's main.tf hardcodes enable_redis = false — Kavita has no use for Redis and this cannot be overridden through the module's variables.

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the Kavita workload

Kavita runs as a StatefulSet by default (auto-selected because stateful_pvc_enabled = true), giving each pod a stable identity and its own PVC. Because it is a single-replica, single-writer SQLite app, do not scale it horizontally.

• Console: Kubernetes Engine → Workloads → select the Kavita workload for pods, revisions, and events.
• CLI:

  kubectl get pods,svc -n "$NAMESPACE" --selector app.kubernetes.io/name~kavita 2>/dev/null || \
    kubectl get pods,svc -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" statefulset/<service-name> --tail=100
  kubectl describe pod -n "$NAMESPACE" -l app=<service-name>

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. Persistent storage — block PVC (SQLite + library metadata)

Kavita's config, its internal SQLite database (kavita.db), and library metadata all live under /kavita/config, which by default is a per-pod block Persistent Volume Claim (stateful_pvc_enabled = true, stateful_pvc_size = "20Gi", stateful_pvc_storage_class = "standard-rwo"). This is real block storage — not a GCS FUSE mount — because gcsfuse corrupts SQLite and media index files.

• Console: Kubernetes Engine → Storage for the PVC; Compute Engine → Disks for the underlying persistent disk.
• CLI:

  kubectl get pvc -n "$NAMESPACE"
  kubectl describe pvc -n "$NAMESPACE" <pvc-name>
  gcloud compute disks list --project "$PROJECT" --filter="name~kavita"

standard-rwo is SSD-backed (Balanced PD) and draws the project's SSD_TOTAL_GB quota — see App_GKE and the repository's storage-class guidance for how to move to HDD (stateful_pvc_storage_class = "standard") if SSD quota is tight. Losing this PVC loses the entire Kavita library index, settings, and reading progress.

C. Cloud Storage (the unmounted storage bucket)

Kavita_Common provisions a Cloud Storage bucket (suffix storage) regardless of the storage layout in use. With the default block-PVC layout it is created but not mounted; it is only mounted at /kavita/config via GCS FUSE when stateful_pvc_enabled = false.

• Console: Cloud Storage → Buckets.
• CLI:

  gcloud storage buckets list --project "$PROJECT" --filter="name~kavita"

See App_GKE for CMEK options and GCS Fuse CSI driver mounts.

D. Secret Manager

Kavita has no generated secrets — no admin password, API key, or signing key is created by this module. Any custom secrets you configure via secret_environment_variables still flow through Secret Manager and the Secret Store CSI driver like any other GKE application module.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~kavita"

See App_GKE for the Secret Store CSI integration and rotation.

E. Networking & ingress

By default the workload uses a ClusterIP Service (service_type = "ClusterIP") exposed externally through the Kubernetes Gateway API (enable_custom_domain = true) with a reserved static IP (reserve_static_ip = true).

• Console: Network services → Load balancing; VPC network → IP addresses.
• CLI:

  kubectl get svc,gateway,httproute -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

F. Cloud Logging & Monitoring

Pod stdout/stderr flow to Cloud Logging; GKE metrics flow to Cloud Monitoring. Optional uptime checks and alert policies are available (uptime_check_config is disabled by default for this module).

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. Kavita Application Behaviour

• No database bootstrap job. Kavita manages its own SQLite storage entirely at runtime; Kavita_Common injects no db-init/migration job, and initialization_jobs defaults to [].
• First-boot setup wizard. There is no seeded admin account or generated credential. Open the service URL — the first-run setup wizard walks through creating the initial administrator account and adding your first library.
• Storage layout is controlled by stateful_pvc_enabled. With the default true, Kavita runs as a StatefulSet and /kavita/config (config + SQLite kavita.db) is a block PVC (stateful_pvc_size = "20Gi", storage class standard-rwo, stateful_fs_group = 3000 so the volume is group-writable). If you disable it, Kavita_Common instead mounts the storage GCS bucket at the same path via GCS FUSE (enable_gcs_storage_volume = true in that case). stateful_pod_management_policy defaults to null (App_GKE's OrderedReady default), which is the safe setting for Kavita's single-writer restarts.
• Single-writer, single replica. min_instance_count = 1 and max_instance_count = 1 by default — Kavita has no distributed/clustering mode, so do not raise max_instance_count while a single PVC/SQLite database backs the workload.
• Health probe paths. Both the startup probe (startup_probe / startup_probe_config) and the liveness probe (liveness_probe / health_check_config) are HTTP GET /api/health, unauthenticated. The startup probe uses a longer failure budget (initial_delay_seconds = 15, period_seconds = 10, failure_threshold = 10) to tolerate slower first-boot library indexing before the liveness probe (initial_delay_seconds = 30, period_seconds = 30, failure_threshold = 3) takes over.
• Redis is force-disabled. Kavita_GKE's main.tf sets enable_redis = false unconditionally when calling App_GKE, overriding the foundation's own enable_redis = true default — no REDIS_HOST/REDIS_PORT are ever injected.
• Custom image build. The container is built from a thin wrapper Dockerfile (FROM jvmilazz0/kavita:${KAVITA_VERSION}); application_version = "latest" resolves to the pinned KAVITA_VERSION = 0.8.7 build argument (a version bump requires editing the pinned value in Kavita_Common, not just redeploying).
• Verify the workload and PVC after deploy:

  kubectl get statefulset,pvc,pods -n "$NAMESPACE"
  kubectl exec -n "$NAMESPACE" <pod-name> -- ls -la /kavita/config
  kubectl port-forward -n "$NAMESPACE" svc/<service-name> 5000:5000
  curl -s http://127.0.0.1:5000/api/health

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Kavita are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 3 — Application Identity

Variable	Default	Description
application_name	kavita	Base name for resources. Do not change after first deploy.
application_display_name	Kavita	Human-readable name shown in the platform UI.
application_version	latest	Kavita image tag; latest builds the pinned KAVITA_VERSION = 0.8.7.

Group 4 — Runtime & Scaling

Variable	Default	Description
cpu_limit	1000m	CPU limit for the Kavita container.
memory_limit	1Gi	Memory limit; Kavita is a lightweight .NET server, comfortable for large libraries.
min_instance_count	1	Kept at 1 to avoid cold starts during index loading.
max_instance_count	1	Keep at 1 — Kavita has no clustering/shared-write support.
container_port	5000 (fixed by Kavita_Common)	Not forwarded to App_GKE; the container always listens on 5000.
enable_cloudsql_volume	false	Kavita has no Cloud SQL — leave false.

Group 6 — GKE Backend & Cluster

Variable	Default	Description
service_type	ClusterIP	External access goes through the Gateway API, not a direct LoadBalancer.
workload_type	null → StatefulSet	Auto-resolves to StatefulSet because stateful_pvc_enabled = true.
session_affinity	None	No sticky routing needed with a single replica.

Group 7 — StatefulSet / Block PVC

Variable	Default	Description
stateful_pvc_enabled	true	On by default. Provisions the per-pod block PVC that holds Kavita's config + SQLite database.
stateful_pvc_size	20Gi	Size for the config/library/SQLite volume; increase for large collections.
stateful_pvc_mount_path	/kavita/config	Must remain Kavita's data dir (config + kavita.db).
stateful_pvc_storage_class	standard-rwo	SSD-backed Balanced PD; draws the SSD_TOTAL_GB quota.
stateful_fs_group	3000	Makes the PVC group-writable for Kavita's UID 1000 / GID 2000 process.
stateful_pod_management_policy	null → OrderedReady	Required for safe restarts of the single-writer SQLite workload.

Group 15 — Redis (inert for Kavita)

Variable	Default	Description
enable_redis	true (variable default)	Overridden to false in Kavita_GKE's main.tf regardless of this value — Kavita never uses Redis.
redis_host / redis_port / redis_auth	—	Forwarded to the foundation for compatibility only; not applicable to Kavita.

Group 16 — Database (not applicable)

Variable	Default	Description
database_type	NONE	Fixed by Kavita_Common — Kavita stores everything in internal SQLite, no Cloud SQL instance is created.

Group 19 — Custom Domain, Static IP & Networking

Variable	Default	Description
enable_custom_domain	true	Gateway API ingress is on by default for Kavita.
reserve_static_ip	true	Stable external IP across redeploys.
application_domains	[]	Custom hostnames + managed certificate.
enable_nfs	false	Off by default — persistence is via the block PVC, not Filestore.

All other inputs follow standard App_GKE behaviour.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip	In-cluster ClusterIP.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific services.
service_external_ip	External LoadBalancer IP (when a static IP is reserved).
service_url	URL to reach Kavita.
storage_buckets	Created Cloud Storage buckets (includes the storage bucket, mounted only when stateful_pvc_enabled = false).
network_name / network_exists / regions	VPC network, presence, available regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
initialization_jobs	Names of any custom initialization jobs you supplied (none by default).
statefulset_name	Name of the StatefulSet (present since Kavita defaults to the StatefulSet workload type).
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / cicd_configuration	CI/CD status and details (repo, trigger, registry).
github_repository_url / github_repository_owner / github_repository_name	CI/CD GitHub details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time — a StatefulSet forced alongside a stateless setting, IAP with no authorized identities, quota_memory_* given as bare integers, an out-of-range container_port/backup_retention_days. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Setting	Sensible value	Risk	Consequence if wrong
stateful_pvc_enabled	true (default)	Critical	Disabling it moves Kavita's SQLite database onto a GCS FUSE mount, which risks corrupting the SQLite file/library index under concurrent writes.
stateful_pvc_mount_path	/kavita/config	Critical	Must match Kavita's fixed data directory; changing it separates the app from its config/SQLite state.
max_instance_count	1	Critical	Kavita has no clustering or shared-write coordination; more than one replica against the same PVC risks SQLite corruption.
stateful_pvc_storage_class	standard-rwo (SSD)	Medium	SSD draws the tight SSD_TOTAL_GB quota; on a quota-constrained project, switch to HDD (standard) since Kavita's I/O needs don't require SSD IOPS.
enable_nfs	false	Low	NFS is unnecessary — persistence is via the block PVC; enabling it adds cost with no benefit for this module's default layout.
enable_redis	forced false in main.tf	Low	Setting this variable has no effect — Kavita never uses Redis regardless of the value passed.
stateful_fs_group	3000	High	Kavita runs as UID 1000/GID 2000; an incorrect or unset fsGroup can leave the PVC unwritable by the container at boot.
memory_limit	1Gi	Medium	Comfortable for large libraries; too low risks OOM during library scans or full-text indexing.
quota_memory_requests / _limits	binary units (4Gi, 8192Mi)	Critical	Bare integers are treated as bytes and block all pod scheduling in the namespace.
First-run admin account	Complete the setup wizard promptly after deploy	Medium	Until the wizard runs, the service is reachable but has no admin account and no libraries configured.
reserve_static_ip	true	Medium	Without it, the external IP can change across redeploys, breaking DNS and bookmarked OPDS URLs.
backup_retention_days	7 (raise for prod)	Medium	Too short for compliance retention; Kavita has no separate database backup path since its state is entirely on the PVC.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Kavita-specific application configuration shared with the Cloud Run variant is described in Kavita_Common.
