Audiobookshelf on GKE Autopilot

Audiobookshelf is a self-hosted audiobook and podcast server — it organises your audio library, streams to the web UI and the official mobile apps, and keeps per-user listening progress in sync. This module deploys Audiobookshelf on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services Audiobookshelf uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

1. Overview

Audiobookshelf runs as a single Node.js workload on GKE Autopilot. Unusually for this catalogue, it needs no external database, no Redis, and no application secrets — the deployment footprint is deliberately small:

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	Node.js pod, 1 vCPU / 1 GiB by default, single replica
Database	None	Audiobookshelf embeds its own SQLite database under CONFIG_PATH — no Cloud SQL
Persistent state	Persistent Volume Claim (block storage)	A StatefulSet PVC mounted at /data, backing both CONFIG_PATH and METADATA_PATH
Container image	Cloud Build + Artifact Registry	Thin wrapper built FROM ghcr.io/advplyr/audiobookshelf and mirrored into your registry
Secrets	Secret Manager	No application secrets — the admin user is created in the first-run web UI
Ingress	Cloud Load Balancing	External LoadBalancer with a reserved static IP; optional custom domain

Sensible defaults worth knowing up front:

• No external database. database_type = "NONE" and enable_cloudsql_volume = false are fixed by Audiobookshelf_Common; Audiobookshelf creates and migrates its internal SQLite database on first boot. No db-init job runs.
• A real block PVC, not GCS FUSE, backs /data. stateful_pvc_enabled = true by default — gcsfuse corrupts SQLite and the media file index, so Audiobookshelf requires a genuine block device. When the PVC is enabled, the variant automatically disables the GCS-FUSE storage volume at the same path (enable_gcs_storage_volume = !stateful_pvc_enabled) to avoid a double-mount conflict at /data. This is the key difference from Audiobookshelf_CloudRun, which has no PVC option and uses GCS FUSE instead.
• stateful_pvc_enabled = true with no explicit workload_type resolves to StatefulSet. One PVC per pod, provisioned from the standard-rwo (SSD, Balanced PD) StorageClass by default — see §6 for the SSD-quota implication.
• One persistent mount covers everything. CONFIG_PATH = /data/config (SQLite DB + app config) and METADATA_PATH = /data/metadata (cover art, cached metadata) are both redirected under the single stateful_pvc_mount_path (/data). Losing this PVC loses all Audiobookshelf state.
• Single replica. min_instance_count = 1 and max_instance_count = 1 — one shared SQLite library must be served by exactly one writer. Do not raise the maximum without verifying multi-writer safety (there is none).
• Custom (thin-wrapper) image. Cloud Build wraps the upstream ghcr.io/advplyr/audiobookshelf image so it is mirrored into Artifact Registry. The Dockerfile reads the app-specific AUDIOBOOKSHELF_VERSION build ARG (not the generic APP_VERSION the foundation injects); application_version = "latest" resolves to the pinned 2.17.0.
• No generated secrets. The initial root user is created interactively in the first-run web UI, and API tokens are minted in the UI afterwards — Audiobookshelf_Common exposes empty secret_ids/secret_values.
• Health probes target /healthcheck, Audiobookshelf's unauthenticated 200 endpoint (startup: 15 s initial delay, 10-second period, 10 failures allowed; liveness: 30 s delay, 30-second period, 3 failures).
• No Redis. The variant's main.tf overrides the foundation's enable_redis default to false for this module.
• Custom domain enabled by default. enable_custom_domain = true (unlike most other GKE modules, which default this off) — supply application_domains to attach a hostname, or it falls back to the LoadBalancer IP.

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the Audiobookshelf StatefulSet

Audiobookshelf runs as a single-pod StatefulSet (the default resolved workload type when stateful_pvc_enabled = true), giving it a stable pod identity and an ordered restart — appropriate for a single-writer SQLite workload.

• Console: Kubernetes Engine → Workloads → select the Audiobookshelf workload for pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
• CLI:

  kubectl get pods,svc -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" statefulset/<service-name> --tail=100
  kubectl describe pod -n "$NAMESPACE" -l app=<service-name>

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. Persistent Volume Claim — the /data block storage

All Audiobookshelf state — the SQLite database, application config, cover art, and cached metadata — lives under /data, backed by a block Persistent Volume Claim provisioned per-pod by the StatefulSet. gcsfuse is explicitly avoided here because it corrupts SQLite and the media file index. Additional media libraries (for example a read-only audiobook bucket) can still be attached through gcs_volumes at a different mount path.

• Console: Kubernetes Engine → Workloads → select the workload → the Volumes/Storage tab. Compute Engine → Disks also lists the underlying Persistent Disk.
• CLI:

  kubectl get pvc -n "$NAMESPACE"
  kubectl describe pvc -n "$NAMESPACE" -l app=<service-name>
  gcloud compute disks list --project "$PROJECT" --filter="name~<service-name>"

See App_GKE §7 (StatefulSet / PVC) for StorageClass options, and §6 below for the SSD-quota pitfall.

C. Cloud Build & Artifact Registry — the container image

The module builds a thin wrapper image FROM ghcr.io/advplyr/audiobookshelf:${AUDIOBOOKSHELF_VERSION} via Cloud Build and stores it in the tenant's Artifact Registry, insulating deploys from upstream registry rate limits and pinning the version.

• Console: Cloud Build → History; Artifact Registry → Repositories.
• CLI:

  gcloud builds list --project "$PROJECT" --limit 5
  gcloud artifacts docker images list \
    "$REGION-docker.pkg.dev/$PROJECT/<repo>/audiobookshelf" --project "$PROJECT"

D. Secret Manager

Audiobookshelf itself needs no injected secrets — there is no database password, master key, or JWT secret. Secret Manager remains available for any custom secret_environment_variables you add. On GKE, secrets are projected into pods via the Secret Store CSI driver.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~audiobookshelf"

See App_GKE for the Secret Store CSI integration and rotation.

E. Networking & ingress

By default the workload is exposed through an external Cloud Load Balancing IP (service_type = ClusterIP by default at the foundation level, but Audiobookshelf's ingress is normally reached via enable_custom_domain = true and a reserved static IP; set service_type = LoadBalancer for a direct external IP without a custom domain). A custom domain with a Google-managed certificate is enabled by default for this module.

• Console: Network services → Load balancing; VPC network → IP addresses.
• CLI:

  kubectl get svc,ingress -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

F. Cloud Logging & Monitoring

Pod stdout/stderr flow to Cloud Logging; GKE metrics flow to Cloud Monitoring. Optional uptime checks and alert policies are available (uptime checks are disabled by default and only pass against a publicly reachable endpoint).

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. Audiobookshelf Application Behaviour

• Self-contained first boot, no init job. On first start Audiobookshelf creates its SQLite database and directory layout under CONFIG_PATH/METADATA_PATH — no init job, migration job, or database provisioning is involved. Because both paths sit under the persistent PVC mount, the database survives pod restarts and application-version upgrades. Audiobookshelf_Common injects no default initialization_jobs; custom jobs can still be supplied for one-off data loads.
• First-run setup wizard. Open the service URL (/) — Audiobookshelf prompts you to create the initial root user interactively. There is no environment-based admin bootstrap; API tokens are minted in the web UI afterwards (Settings → Users).
• Single writer, single replica. SQLite over a block PVC tolerates exactly one writer. The module pins min_instance_count = 1 / max_instance_count = 1; a StatefulSet with stateful_pod_management_policy = OrderedReady further ensures pods are not started concurrently during scaling events.
• Health endpoint. /healthcheck returns HTTP 200 unauthenticated once the server is ready; it backs the HTTP startup probe (15 s initial delay, 10-second period, up to 10 failures ≈ 115 s of first-boot grace) and the HTTP liveness probe (30 s initial delay, 30-second period, 3 failures). The web UI is at /.
• Scaling constraints. As a StatefulSet with a single-writer SQLite backend, do not scale beyond 1 replica. The default stateful_update_strategy and stateful_pod_management_policy (both null → foundation defaults of RollingUpdate/OrderedReady) are adequate at replica count 1; they only matter if you experiment with more than one pod, which is not supported by the application.
• Verification CLI:

  kubectl get pods,pvc -n "$NAMESPACE"
  SERVICE=$(kubectl get svc -n "$NAMESPACE" -o jsonpath='{.items[?(@.metadata.labels.application=="audiobookshelf")].metadata.name}')
  kubectl exec -n "$NAMESPACE" statefulset/<service-name> -- wget -qO- http://localhost:80/healthcheck
  kubectl port-forward -n "$NAMESPACE" svc/<service-name> 8080:80
  curl -s -o /dev/null -w "%{http_code}\n" http://localhost:8080/healthcheck   # expect 200

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Audiobookshelf are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 3 — Application Identity

Variable	Default	Description
application_name	audiobookshelf	Base name for resources. Do not change after first deploy.
application_version	latest	ghcr.io/advplyr/audiobookshelf image tag used as the custom-build base; latest resolves to the pinned 2.17.0 via the app-specific AUDIOBOOKSHELF_VERSION build ARG.
application_display_name	Audiobookshelf Vector Database	Human-readable display name.
description	Audiobookshelf Vector Database — high-performance similarity search for AI applications	Workload description.

Group 4 — Runtime & Scaling

Variable	Default	Description
cpu_limit	1000m	CPU per pod. Library scans are CPU-bound — size up for large imports.
memory_limit	1Gi	Memory per pod; size up for large libraries.
min_instance_count	1	Keep at 1 to avoid cold starts during library/index loading.
max_instance_count	1	Keep at 1 — one SQLite library, one writer.
container_port	80	Audiobookshelf's HTTP port (fixed by Audiobookshelf_Common; this variable is not itself forwarded to App_GKE).
enable_cloudsql_volume	false	No Cloud SQL — keep false; Audiobookshelf does not use it.
enable_image_mirroring	true	Mirror the upstream image into Artifact Registry.

Group 6 — GKE Backend & Cluster

Variable	Default	Description
service_type	ClusterIP	Kubernetes Service type; set LoadBalancer for a direct external IP.
workload_type	null → StatefulSet (via stateful_pvc_enabled = true)	Recommended for Audiobookshelf's stable pod identity and ordered restarts.
session_affinity	None	Single-replica deployment, so sticky sessions are not required.
network_tags	["nfsserver"]	Foundation-inherited default; Audiobookshelf does not use NFS, so this tag has no practical effect unless enable_nfs is also enabled.

Group 7 — StatefulSet / PVC

Variable	Default	Description
stateful_pvc_enabled	true	Required — gcsfuse corrupts Audiobookshelf's SQLite database and media file index, so a real block PVC backs /data.
stateful_pvc_size	20Gi	Size to hold the full audio library index plus overhead (the PVC holds config/metadata, not necessarily raw audio files if those are mounted separately via gcs_volumes).
stateful_pvc_mount_path	/data	Both CONFIG_PATH (/data/config) and METADATA_PATH (/data/metadata) live under this mount.
stateful_pvc_storage_class	standard-rwo (SSD, Balanced PD)	See §6 — consider standard (HDD) to avoid exhausting the SSD_TOTAL_GB quota; Audiobookshelf's SQLite/media workload does not need SSD IOPS.
stateful_pod_management_policy	null → OrderedReady	Required for safe restarts of a single-writer workload.
stateful_update_strategy	null → RollingUpdate	Only matters if replica count is (unsupportedly) raised above 1.
stateful_fs_group	3000	Matches the Audiobookshelf Helm chart's fsGroup convention (the app runs as UID 1000/GID 2000) so the PVC is group-writable.

Group 13 — Filesystem (NFS)

Variable	Default	Description
enable_nfs	false	Not used by default — Audiobookshelf's state lives on the block PVC, not NFS.

Group 14 — Cloud Storage

Variable	Default	Description
create_cloud_storage	true	Provisions the Common module's storage bucket; unused for the primary /data mount when stateful_pvc_enabled = true (the PVC replaces GCS FUSE at that path), but still created and available for gcs_volumes overrides.
gcs_volumes	[]	Additional GCS FUSE mounts, e.g. a read-only media library bucket at a separate path.

Group 15 — Redis Cache

Variable	Default	Description
enable_redis	true (foundation default) → forced to false by main.tf	Audiobookshelf does not use Redis; the variant hardcodes enable_redis = false in its App_GKE call regardless of this variable's value.

Group 16 — Database Backend

Variable	Default	Description
database_type	NONE	Fixed — Audiobookshelf has no SQL database; all other database inputs are forwarded for foundation compatibility only and have no effect.

Group 19 — Custom Domain, Static IP & Networking

Variable	Default	Description
enable_custom_domain	true	Enabled by default for this module (unlike most GKE modules, which default this off).
application_domains	[]	Custom hostnames + managed certificate; supply one to use the custom domain.
reserve_static_ip	true	Stable external IP across redeploys.

Group 22 — VPC Service Controls & Audit Logging

Variable	Default	Description
enable_vpc_sc	false	Enforce a VPC-SC perimeter (requires org-level permissions).
enable_audit_logging	false	Detailed Cloud Audit Logs.

All other inputs follow standard App_GKE behaviour.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip	In-cluster ClusterIP.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific services.
service_external_ip	External LoadBalancer IP (when a static IP is reserved).
service_url	URL to reach Audiobookshelf.
statefulset_name	Name of the StatefulSet.
storage_buckets	Created Cloud Storage buckets.
network_name / network_exists / regions	VPC network, presence, available regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
initialization_jobs	Names of any custom setup jobs (none by default).
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / cicd_configuration	CI/CD status and details (repo, trigger, registry).
github_repository_url / github_repository_owner / github_repository_name	CI/CD GitHub details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time — a StatefulSet forced alongside a stateless setting, IAP with no authorized identities, quota_memory_* given as bare integers, an out-of-range container_port/backup_retention_days. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Setting	Sensible value	Risk	Consequence if wrong
max_instance_count	1	Critical	Multiple pods write the same SQLite database over the shared PVC — database corruption.
stateful_pvc_enabled	true	Critical	Disabling it falls back toward a GCS-FUSE-style mount for /data; gcsfuse corrupts Audiobookshelf's SQLite database and media file index.
CONFIG_PATH / METADATA_PATH (via environment_variables)	leave defaults	Critical	Changing them after first boot orphans the existing SQLite database and cached metadata.
stateful_pvc_mount_path	/data	Critical	Must stay in sync with CONFIG_PATH/METADATA_PATH; a mismatch means the SQLite DB is never actually persisted to the PVC.
stateful_pvc_storage_class	standard (HDD) recommended over the standard-rwo (SSD) default	High	This module currently defaults to standard-rwo, which draws the tight SSD_TOTAL_GB regional quota (e.g. only 500 GB on Qwiklabs); Audiobookshelf's SQLite/media workload does not need SSD IOPS. A campaign of several SSD-backed stateful apps can exhaust the quota — pass -var stateful_pvc_storage_class=standard to use HDD (pd-standard) instead. Scaling the workload to zero does not release the PVC; only deleting it does.
container_port	80	Critical	Audiobookshelf listens on 80 (PORT=80 injected by Audiobookshelf_Common); a mismatch fails every health probe.
quota_memory_requests / _limits	binary units (4Gi, 8192Mi)	Critical	Bare integers are treated as bytes and block all pod scheduling in the namespace (only relevant if enable_resource_quota = true).
enable_redis	forced false regardless of input	Low	Audiobookshelf has no use for Redis; the variant ignores this variable and always passes false to the foundation.
application_version	pinned tag	Medium	latest silently resolves to the pinned 2.17.0; pin explicitly to control upgrades.
enable_custom_domain / application_domains	true / set a hostname	Medium	Left true with no application_domains, the module falls back to the internal cluster URL or LoadBalancer IP rather than a stable hostname.
enable_cloudsql_volume	false	Low	No Cloud SQL exists; enabling wastes a sidecar.
backup_retention_days	7 (raise for prod)	Medium	Too short for compliance retention.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Audiobookshelf-specific application configuration shared with the Cloud Run variant is described in Audiobookshelf_Common.
