Jellystat on Google Cloud Run
Jellystat is an open-source statistics and analytics dashboard for Jellyfin media servers, tracking playback history, active sessions, user activity, library growth, and viewing trends. This module deploys Jellystat on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure.
This guide focuses on the cloud services Jellystat uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.
1. Overview
Jellystat runs as a single Node.js/Express container (with a bundled React frontend) on Cloud Run v2. The deployment wires together a focused set of Google Cloud services:
| Capability | Google Cloud service | Notes |
|---|---|---|
| Compute | Cloud Run v2 | Node.js service, 1 vCPU / 512 MiB by default, serverless autoscaling; scale-to-zero supported |
| Database | Cloud SQL for PostgreSQL 15 | Required — non-standard POSTGRES_* env var names |
| Object storage | Cloud Storage | A small optional backups bucket for database export archives |
| Secrets | Secret Manager | Auto-generated JWT_SECRET; database password |
| Ingress | Cloud Run URL | Default run.app URL; optional external HTTPS load balancer + custom domain |
Sensible defaults worth knowing up front:
- PostgreSQL 15 is mandatory. The database engine is fixed by the shared application layer.
- Non-standard database env var names. Jellystat reads
POSTGRES_IP,POSTGRES_PORT,POSTGRES_USER,POSTGRES_PASSWORD, andPOSTGRES_DATABASE— notPOSTGRES_DB** (community-confirmed that name does not work), and not the platform's genericDB_names. Both sets are injected side by side viamain.tf'sdb__env_var_name` aliasing. container_port = 3000is fixed. Jellystat's server hardcodes this port; it is not configurable via environment variable (see upstream issue #314). The variable exists for Foundation convention parity only.JWT_SECRETis generated automatically and stored in Secret Manager. It signs Jellystat's session/auth tokens.- No Redis support. Jellystat has no native Redis integration;
enable_redisand related variables are inert. - Scale-to-zero is enabled by default (
min_instance_count = 0). Cold starts add a few seconds of latency to the first request after idle. - No environment variable pairs Jellystat with a Jellyfin server. This is the single most important operational fact about this module: Jellystat's Jellyfin connection (server URL + API key) is entered entirely through its own web UI after first boot, and has no Terraform-automatable equivalent. See §3 below.
2. Google Cloud Services & How to Explore Them
All commands assume PROJECT and REGION are set. Service and resource names
are reported in the deployment Outputs.
A. Cloud Run — the Jellystat service
Jellystat runs as a Cloud Run v2 service that autoscales by request load between the minimum and maximum instance counts.
- Console: Cloud Run → select the service for revisions, traffic, logs, and metrics.
- CLI:
gcloud run services list --project "$PROJECT" --region "$REGION"
gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"
See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.
B. Cloud SQL for PostgreSQL 15
Jellystat stores all playback/analytics data in a managed Cloud SQL for PostgreSQL 15 instance. The service connects privately through the Cloud SQL Auth Proxy over a Unix socket. On first deploy an initialization Job creates the application database and user. Jellystat then applies its own schema migrations automatically on startup.
- Console: SQL → select the instance for connections, backups, flags, metrics.
- CLI:
gcloud sql instances list --project "$PROJECT"
gcloud sql instances describe <instance-name> --project "$PROJECT"
gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"
The instance name, database, user, and password secret are in the Outputs. See App_CloudRun for the connection model, backups, and password rotation.
C. Cloud Storage
An optional, small Cloud Storage bucket (backups) is provisioned for
Jellystat's own database export/backup archive feature.
- Console: Cloud Storage → Buckets.
- CLI:
gcloud storage buckets list --project "$PROJECT"
D. Secret Manager
One cryptographic secret is generated automatically and stored in Secret
Manager: JWT_SECRET (used to sign Jellystat session/auth tokens). The
database password is managed separately by the foundation.
- Console: Security → Secret Manager.
- CLI:
gcloud secrets list --project "$PROJECT"
gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"
See App_CloudRun for injection and rotation details.
E. Networking & ingress
The service is reachable at its run.app URL by default. An external HTTPS
load balancer with a custom domain, Cloud CDN, and Cloud Armor can be layered
on.
- Console: Cloud Run (service URL); Network services → Load balancing.
- CLI:
gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'
See App_CloudRun.
F. Cloud Logging & Monitoring
Container logs flow to Cloud Logging; Cloud Run and Cloud SQL metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.
- Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
- CLI:
gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50
3. Jellystat Application Behaviour
- First-deploy database setup. An initialization Job runs
db-init.shusingpostgres:15-alpine. It connects through the Cloud SQL Auth Proxy and idempotently creates the application role and database. The job is safe to re-run. - Database migrations on start. Jellystat applies its own schema migrations automatically on every startup — no separate migrate job exists in this module.
JWT_SECRETis generated once and stored in Secret Manager. Rotating it invalidates all active user sessions (users must log back in) but causes no data loss.- Health path. Startup, liveness, and uptime probes target
GET /auth/isConfigured— a public, unauthenticated endpoint that returns 200 as soon as the server is up. - Manual Jellyfin pairing is required after first boot — this cannot be
automated by Terraform. Jellystat has no environment variable for the
companion Jellyfin server's URL or API key; the pairing is entirely
UI-driven:
- Open the deployed Jellystat URL and create the first admin account.
- In your Jellyfin server's own Dashboard → API Keys, generate a new API key for Jellystat.
- In Jellystat's settings, enter your Jellyfin server's URL and paste in that API key. If you don't already have a Jellyfin server deployed, deploy one first with the sibling Jellyfin_CloudRun module (or Jellyfin_GKE) — see its own configuration guide.
- Inspect job execution:
gcloud run jobs list --project "$PROJECT" --region "$REGION"
gcloud run jobs executions list --job <job-name> --project "$PROJECT" --region "$REGION"
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Jellystat are listed; every other input is inherited from App_CloudRun with its standard behaviour.
Group 3 — Application Identity
| Variable | Default | Description |
|---|---|---|
application_name | jellystat | Base name for resources. Do not change after first deploy. |
application_display_name | Jellystat | Human-readable name shown in the Console. |
application_version | latest | Container image version tag — passed through to the cyfershepard/jellystat image tag. |
Group 4 — Runtime & Scaling
| Variable | Default | Description |
|---|---|---|
container_image_source | prebuilt | Deploys the official cyfershepard/jellystat image directly. Do not set custom — there is no Dockerfile for this app. |
container_image | "" | Leave blank to use the default image. |
container_port | 3000 | Fixed — matches Jellystat's hardcoded internal port. Changing this variable has no effect on the app. |
cpu_limit / memory_limit | 1000m / 512Mi | Container resources. |
min_instance_count / max_instance_count | 0 / 1 | Scale-to-zero by default. |
enable_cloudsql_volume | true | Cloud SQL Auth Proxy for socket connections. |
Group 11 — Storage & Filesystem
| Variable | Default | Description |
|---|---|---|
enable_nfs | false | Off — Jellystat has no shared-file storage need. |
create_cloud_storage | true | Creates the small backups bucket. |
gcs_volumes | [] | Not used by default. |
Group 12 — Database Backend
| Variable | Default | Description |
|---|---|---|
database_type | POSTGRES_15 | Fixed. |
application_database_name | jellystat_db | Injected as both DB_NAME and POSTGRES_DATABASE. Immutable after first deploy. |
application_database_user | jellystat_user | Injected as both DB_USER and POSTGRES_USER. |
initialization_jobs | [] | Leave empty to use the built-in db-init job. |
Group 14 — Observability & Health
| Variable | Default | Description |
|---|---|---|
startup_probe / liveness_probe | HTTP /auth/isConfigured | Public, unauthenticated health endpoint. |
uptime_check_config | { enabled = false, path = "/auth/isConfigured" } | Enable explicitly to activate. |
Group 21 — Redis (not consumed)
| Variable | Default | Description |
|---|---|---|
enable_redis / redis_host / redis_port / redis_auth | off / empty | Not consumed. Jellystat has no native Redis integration. |
All other inputs are inherited from App_CloudRun.md with standard behaviour.
5. Outputs
| Output | Description |
|---|---|
service_name | Cloud Run service name. |
service_url | Default run.app URL of the service. |
service_location | Region the service runs in. |
load_balancer_ip / load_balancer_url | External HTTPS load balancer IP / URL (when enabled). |
database_instance_name | Cloud SQL instance name. |
database_name / database_user | Application database name / user. |
database_password_secret | Secret Manager secret holding the DB password. |
database_host / database_port | DB endpoint / port. |
storage_buckets | Created Cloud Storage buckets (backups). |
container_image / container_registry | Deployed image and Artifact Registry repo. |
monitoring_enabled / uptime_check_names | Monitoring status and uptime checks. |
initialization_jobs | Names of the setup jobs (db-init). |
deployment_id / tenant_id / resource_prefix | Naming identifiers. |
project_id / project_number | Project identifiers. |
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode | VPC-SC status. |
6. Configuration Pitfalls & Sensible Defaults
Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).
| Setting | Sensible value | Risk | Consequence if wrong |
|---|---|---|---|
application_database_name / application_database_user | Set once | Critical | Immutable after first deploy; renaming recreates the DB/user and destroys all data. |
JWT_SECRET (auto-generated) | Only rotate deliberately | Medium | Rotating it invalidates all active sessions — users must log back in — but causes no data loss. |
container_image_source | prebuilt | Critical | Setting custom fails the Cloud Build step — there is no Dockerfile for Jellystat in this catalogue. |
container_port | 3000 (informational) | Low | Jellystat's server hardcodes port 3000 regardless of this variable's value. |
| Jellyfin URL/API key pairing | Manual, post-deploy | High | There is no environment variable for this — skipping the manual UI step leaves Jellystat showing no data even though the deployment is healthy. |
enable_redis | leave false | Low | Jellystat has no Redis integration; setting true has no effect. |
startup_probe/liveness_probe path | /auth/isConfigured | High | Pointing probes at an authenticated endpoint causes 401/403 and the revision never becomes Ready. |
min_instance_count | 0 (default) is fine | Low | Jellystat is a request/response dashboard with no background scheduler — no need for always-on CPU. |
For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_CloudRun. Jellystat-specific application configuration shared with the GKE variant is described in Jellystat_Common.
