Prowlarr on GKE Autopilot
Prowlarr is the central indexer manager for the *arr media-automation suite — Sonarr, Radarr, Lidarr, and Readarr all point at Prowlarr instead of configuring indexers separately in each app; Prowlarr syncs indexer configuration out to every connected app's own API. It is written in .NET, part of the same Servarr codebase lineage as Sonarr/Radarr, and GPL-3.0 licensed. This module deploys Prowlarr on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.
This is the only platform variant of Prowlarr in this catalogue. A
Prowlarr_CloudRun module was built, deployed, and diagnosed, then removed
entirely — see §3 for the full finding. There is no Cloud Run alternative to
fall back to; GKE is the only supported target.
This guide focuses on the cloud services Prowlarr uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.
1. Overview
Prowlarr runs as a single .NET process pod backed by an embedded SQLite database. The deployment wires together a small, focused set of Google Cloud services:
| Capability | Google Cloud service | Notes |
|---|---|---|
| Compute | GKE Autopilot | Single .NET process pod, 1 vCPU / 1 GiB by default |
| Database | none | Prowlarr manages indexer/app-sync config in an embedded SQLite database (WAL mode) — no Cloud SQL instance is created |
| Object storage | a block PVC (default), or Cloud Storage | stateful_pvc_enabled = true by default — a real block PVC mounted at /config; a storage GCS bucket exists but is unused as a mount unless the PVC is disabled |
| Cache & queue | none | Prowlarr has no Redis or queue dependency (enable_redis hardcoded false) |
| Secrets | Secret Manager | None generated — Prowlarr has no built-in admin account and no encryption key to protect |
| Ingress | Cloud Load Balancing | External LoadBalancer once service_type = "LoadBalancer" is set; optional custom domain + managed certificate |
Sensible defaults worth knowing up front:
- No database of any kind.
Prowlarr_Commonfixesdatabase_type = "NONE"— Prowlarr's only persistent state is its own embedded SQLite file. - Official image, unmodified.
container_image_source = "prebuilt"deployslscr.io/linuxserver/prowlarrdirectly — no Dockerfile, no custom build, no entrypoint translation. - Block-storage PVC by default, not GCS FUSE.
stateful_pvc_enabled = trueruns Prowlarr as a StatefulSet with a per-pod PVC mounted at/config. This is deliberate, not incidental — WAL-mode SQLite needs real POSIX file locking, which GCS FUSE does not reliably provide, and this catalogue has a documented history of GCS FUSE corrupting other WAL-mode SQLite apps (see UptimeKuma).stateful_pvc_storage_classdefaults tostandard(HDDpd-standard), not SSD — Prowlarr's config state is tiny with no high-IOPS need, so it draws from the much largerDISKS_TOTAL_GBregional quota instead of the tightSSD_TOTAL_GBquota. - Single instance, non-negotiable.
min_instance_count = 1andmax_instance_count = 1— the embedded SQLite database is a single writer. service_typeneeds an explicit override. The variable's inherited Foundation default is"ClusterIP"; Prowlarr has a real web UI operators need to reach, so setservice_type = "LoadBalancer"at deploy time.- No default login. There is no generated secret and no built-in admin account — configure authentication (if wanted) from the web UI's Settings → General → Security after first deploy.
2. Google Cloud Services & How to Explore Them
All commands assume you have run
gcloud container clusters get-credentials <cluster> --region <region> --project <project>
and that PROJECT, REGION, and NAMESPACE are set.
A. GKE Autopilot — the Prowlarr workload
- Console: GKE → Workloads → select the
prowlarrStatefulSet for pod status, resource usage, and logs. - CLI:
kubectl get pods,svc -n "$NAMESPACE"
kubectl get statefulset -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" statefulset/<service-name> --tail=100
B. Storage — a block PVC (default) or Cloud Storage
- Console: Kubernetes Engine → Storage, or Cloud Storage → Buckets (filter by the tenant prefix).
- CLI:
kubectl get pvc -n "$NAMESPACE" # stateful_pvc_enabled = true (default)
gcloud storage buckets list --project "$PROJECT" --filter="name~prowlarr" # only mounted if the PVC is disabled
C. Secret Manager
Prowlarr creates no secrets of its own, but the workload's Secret Manager
footprint (shared platform secrets, Workload Identity bindings) is still
worth checking if you add custom secret_environment_variables:
- CLI:
gcloud secrets list --project "$PROJECT" --filter="name~prowlarr"
D. Networking & ingress
- CLI:
kubectl get svc -n "$NAMESPACE" -o wide
EXTERNAL_IP=$(kubectl get svc <service-name> -n "$NAMESPACE" -o jsonpath='{.status.loadBalancer.ingress[0].ip}')
echo "$EXTERNAL_IP"
E. Cloud Logging & Monitoring
- Console: Logging → Logs Explorer, filter
resource.type="k8s_container" resource.labels.namespace_name="<namespace>". - CLI:
kubectl logs -n "$NAMESPACE" statefulset/<service-name> --tail=100 -f
3. Prowlarr Application Behaviour
- No first-deploy database setup. There is no
db-initjob — Prowlarr creates and migrates its own SQLite schema (prowlarr.db, WAL mode) at/configon first boot. - No default admin account. Authentication is off until you enable it in the web UI (Settings → General → Security); there is no "admin/admin" or well-known first-login credential to change.
- Health path. Both the startup and liveness probes target
GET /ping, which returns200 {"status":"OK"}unauthenticated. This is a real fix over this module's original clone source, which pointed both probes at/api/health(a path that does not exist on Prowlarr). - Inspect job execution (only relevant if you supply custom
initialization_jobs— none run by default):kubectl get jobs -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" job/<job-name>
⚠ Why there is no Cloud Run variant: s6-overlay vs. gVisor
This is the most consequential platform-specific finding for this module — the result of three separate, systematic live diagnostic deploys that ruled out storage and resources before concluding the root cause was the container's own init system.
The problem. The official lscr.io/linuxserver/prowlarr image, like
every LinuxServer.io image, uses s6-overlay as PID 1 — a supervision
system that itself execs the application process after running its own
init sequence (permission fixups, service bootstrap, etc.). Cloud Run
executes containers inside gVisor, a user-space sandbox that intercepts
and emulates Linux syscalls. On Cloud Run, the Prowlarr container produced
zero output — not even the s6-overlay startup banner that normally
prints within milliseconds on any other platform — and Cloud Run reported
"Application exec likely failed" every time.
How it was isolated. Three live diagnostic deploys, changing one variable at a time:
- Default configuration — fails identically: no output, exec failure.
- With an added GCS volume (in case the mount itself was the blocker) — fails identically.
- With increased CPU/memory (in case s6-overlay's init sequence was simply timing out under tight resources) — fails identically.
All three attempts produced the exact same symptom with no variation, ruling out storage and resource sizing as the cause and isolating the failure to the init process itself being incompatible with the gVisor sandbox — not a configuration mistake that could be fixed with different inputs.
The outcome. Prowlarr_CloudRun was built, deployed, diagnosed, and
then removed from the catalogue entirely — the same disposition already
applied to Kopia, RocketChat, and LobeChat, each removed for its own
platform-level incompatibility rather than left in a permanently-broken
state. Prowlarr_GKE has no such restriction: GKE runs containers on real
Linux nodes (Autopilot's managed nodes), so s6-overlay execs exactly as it
does on any standard Docker host — confirmed live, pod reports 1/1 Running and /ping returns 200 both internally
(kubectl exec ... wget) and externally once the LoadBalancer IP
provisions.
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Prowlarr are listed; every other input is inherited from App_GKE with its standard behaviour.
Group 3 — Application Identity
| Variable | Default | Description |
|---|---|---|
application_name | prowlarr | Base name for resources. |
application_display_name | Prowlarr | Human-readable name shown in the platform UI. |
application_version | latest | Passed straight through as the official image's tag — no custom build, so no version-pin build ARG exists. |
Group 4 — Runtime & Scaling
| Variable | Default | Description |
|---|---|---|
container_image_source | prebuilt | Deploys lscr.io/linuxserver/prowlarr directly. Correctly forwarded to App_GKE (unlike some prebuilt modules where this variable is inert). |
container_port | 9696 | Fixed via Prowlarr_Common; not forwarded to App_GKE directly. |
min_instance_count / max_instance_count | 1 / 1 | Both pinned at 1 — the embedded SQLite database is a single writer. |
enable_image_mirroring | true | Mirrors the official image into Artifact Registry to avoid Docker Hub rate limits, even though the image itself is unmodified. |
Group 6 — GKE Backend Configuration
| Variable | Default | Description |
|---|---|---|
service_type | ClusterIP | Override to LoadBalancer. The inherited default is written with internal/database-style workloads in mind; Prowlarr has a real web UI that needs external reachability. |
workload_type | null | Auto-resolves to StatefulSet when stateful_pvc_enabled = true (the default) — no need to set both. |
Group 7 — StatefulSet
| Variable | Default | Description |
|---|---|---|
stateful_pvc_enabled | true | Deliberate default — gives the embedded WAL-mode SQLite database real POSIX file locking, which GCS FUSE does not reliably provide. |
stateful_pvc_mount_path | /config | Where Prowlarr keeps prowlarr.db and all other app state. |
stateful_pvc_storage_class | standard | HDD pd-standard, not SSD — Prowlarr's config/SQLite state is small with no high-IOPS need; avoids the tight SSD_TOTAL_GB quota in favor of the much larger DISKS_TOTAL_GB quota. |
stateful_fs_group | 3000 | Makes the PVC group-writable; Prowlarr runs as UID 1000 / GID 2000. |
Group 10 — Observability & Health
| Variable | Default | Description |
|---|---|---|
startup_probe / liveness_probe | HTTP /ping | The probes actually applied to the Pod (forwarded through Prowlarr_Common). Confirmed live: 200 {"status":"OK"}, unauthenticated. |
startup_probe_config / health_check_config | HTTP /api/health (stale) | Inert for Prowlarr — App_GKE always prefers the per-app startup_probe/liveness_probe above when a module supplies one, so these top-level variables never reach the Pod spec despite their stale-looking default. |
uptime_check_config | { enabled = false, path = "/api/health" } | Not inert. Disabled by default, but if you enable the Cloud Monitoring uptime check, override path = "/ping" — this variable is applied as-is, unlike the two above. |
Group 14 — Cloud Storage & Artifact Registry
| Variable | Default | Description |
|---|---|---|
storage_buckets | one storage bucket | Provisioned but unused as a mount while stateful_pvc_enabled = true (the default) — the block PVC takes over /config instead. |
Group 16 — Database
| Variable | Default | Description |
|---|---|---|
database_type | NONE | Fixed by Prowlarr_Common — Prowlarr has no SQL database. |
Group 19 — Custom Domain & Networking
| Variable | Default | Description |
|---|---|---|
reserve_static_ip | true | The tested/reference deployment used false (ephemeral IP) after hitting the project's global static-IP quota ceiling — safe to leave false for Prowlarr, which bakes no self-referencing URL into its own configuration at boot. |
All other inputs follow standard App_GKE behaviour.
5. Outputs
| Output | Description |
|---|---|
service_name / service_url / service_external_ip | Kubernetes Service identity and address. |
storage_buckets | The storage bucket (unused as a mount while stateful_pvc_enabled = true). |
statefulset_name | Name of the StatefulSet (the default workload type). |
kubernetes_ready | Whether the workload reached Ready state. |
container_image / container_registry | The deployed image reference and Artifact Registry repository. |
6. Configuration Pitfalls & Sensible Defaults
Plan-time validation catches the min/max scaling conflict, the IAP
credential requirement, and the StatefulSet/workload_type conflict before
apply — but several settings that pass validation still have a wrong-looking
or unsafe default worth knowing before you deploy.
Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).
| Setting | Sensible value | Risk | Consequence if wrong |
|---|---|---|---|
service_type | LoadBalancer | High | The inherited default is ClusterIP — Prowlarr's web UI is unreachable from outside the cluster until this is set explicitly. |
| Deploying on Cloud Run | Don't — use Prowlarr_GKE (the only supported variant) | Critical | The image's s6-overlay init process cannot exec inside Cloud Run's gVisor sandbox — confirmed via 3 diagnostic deploys, all failing identically with zero container output. There is no configuration fix; a Prowlarr_CloudRun module was built, tested, and removed for exactly this reason. |
stateful_pvc_enabled | true (the default) | High | Disabling it falls back to a GCS FUSE mount at /config, which does not reliably support the POSIX file locking Prowlarr's WAL-mode SQLite database needs — this catalogue has a documented history of GCS FUSE corrupting other WAL-mode SQLite apps. |
stateful_pvc_storage_class | Leave at standard (HDD) | Low–Medium | Switching to standard-rwo/premium-rwo (SSD) draws from the far tighter SSD_TOTAL_GB quota for no real benefit — Prowlarr's config-file I/O pattern doesn't need SSD IOPS. |
max_instance_count | Leave at 1 | Critical | The embedded SQLite database is a single writer; raising this risks database corruption. |
uptime_check_config.path | Override to /ping if enabling uptime checks | Medium | The variable's default path is a stale /api/health left over from this module's clone source — unlike startup_probe/liveness_probe, this one is not overridden elsewhere, so an uptime check enabled with the default path will fail against a path that doesn't exist. |
| Authentication | Enable it from the web UI's Settings → General → Security after first deploy | High | Prowlarr ships with no built-in admin account and no generated secret — an internet-reachable, unauthenticated instance is exposed by default until you configure it. |
For the foundation behaviour referenced throughout — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Prowlarr-specific application configuration is described in Prowlarr_Common.
