Linkwarden on Google Cloud Run
Linkwarden is an open-source, self-hosted bookmark manager that goes beyond simple link-saving: every bookmark can be automatically archived as a full-page screenshot, PDF, and single-file "monolith" snapshot using a bundled headless Chrome, so your links keep working even after the source page changes or disappears. This module deploys Linkwarden on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure.
This guide focuses on the cloud services Linkwarden uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.
1. Overview
Linkwarden runs as a single Node.js/Next.js container on Cloud Run v2. The web
server and a background archiving worker run side by side in the SAME
container (via concurrently) — there is no separate worker service. The
deployment wires together a focused set of Google Cloud services:
| Capability | Google Cloud service | Notes |
|---|---|---|
| Compute | Cloud Run v2 | Next.js + headless Chrome container, 2 vCPU / 2 GiB by default, min_instance_count = 1 (background worker needs to keep running) |
| Database | Cloud SQL for PostgreSQL 15 | Required — Linkwarden's Prisma schema is Postgres-only |
| Object storage | Cloud Storage (GCS Fuse volume) | Mounted at /data/data by default for archived screenshots/PDFs/monoliths |
| Cache & queue | None | The archiving worker polls PostgreSQL directly; no Redis/BullMQ dependency |
| Secrets | Secret Manager | Auto-generated NEXTAUTH_SECRET; database password |
| Ingress | Cloud Run URL / Cloud Load Balancing | Default run.app URL; optional external HTTPS load balancer + custom domain |
Sensible defaults worth knowing up front:
- PostgreSQL 15 is mandatory. Linkwarden's Prisma schema hardcodes the
postgresqlprovider; selecting any other engine breaks the first-boot migration. DATABASE_URLconnects over the private IP, not the socket. A Cloud SQL Unix-socket directory path contains colons that break Prisma's URL-authority DSN parsing, so the cloud entrypoint always uses the injectedDB_IP(the real Cloud SQL private IP on Cloud Run) withsslmode=require.NEXTAUTH_URLis derived automatically, appending the required/api/v1/authsuffix to the computed Cloud Run service URL — never set it manually with a literal$(VAR)template (Cloud Run passes that through unexpanded).min_instance_count = 1andcpu_always_allocated = trueby default. The in-container background archiving worker must keep processing the queue between requests; scale-to-zero would stop archiving.- Headless Chrome runs in-process with the web server. Unlike Crawl4AI (a
separate supervisord service), Linkwarden's screenshot/PDF/monolith
archiving shares the same container/process as the Next.js server — size
memory_limit/cpu_limitfor the whole container's peak, not just the web server. Default: 2 vCPU / 2Gi; bump memory to 4Gi for heavy archiving loads. - A GCS volume is mounted automatically at
/data/data. This is the absolute path Linkwarden's storage code resolvesSTORAGE_FOLDERto (verified against the built image), so archived content persists across restarts with no NFS required (enable_nfs = falseby default). - No seeded superuser. The first user to register through the standard NextAuth registration flow becomes the instance owner.
DISABLE_BROWSERis a documented fallback, not a default. If Cloud Run's gVisor sandbox has trouble launching the bundled headless Chrome (a similar risk class to the documented Prowlarr s6-overlay/gVisor incompatibility elsewhere in this catalogue), setdisable_browser = trueto skip all browser-dependent archiving tasks while keeping link metadata/tag/collection features working. Verify live before assuming this is needed.
2. Google Cloud Services & How to Explore Them
All commands assume PROJECT and REGION are set. Service and resource names
are reported in the deployment Outputs.
A. Cloud Run — the Linkwarden service
Linkwarden runs as a Cloud Run v2 service that autoscales by request load between the minimum and maximum instance counts. Each deployment creates an immutable revision; traffic can be split across revisions for safe rollouts.
- Console: Cloud Run → select the service for revisions, traffic, logs, and metrics.
- CLI:
gcloud run services list --project "$PROJECT" --region "$REGION"
gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"
See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.
B. Cloud SQL for PostgreSQL 15
Linkwarden stores all application data (bookmarks, collections, tags, users,
archive metadata) in a managed Cloud SQL for PostgreSQL 15 instance. The cloud
entrypoint connects over the Cloud SQL private IP directly (DB_IP), not the
Auth Proxy Unix socket — a Prisma-specific requirement, since a socket
directory path breaks URL-authority DSN parsing. On first deploy an
initialization Job creates the application database and user; Linkwarden then
runs its own prisma migrate deploy on every container start.
- Console: SQL → select the instance for connections, backups, flags, metrics.
- CLI:
gcloud sql instances list --project "$PROJECT"
gcloud sql instances describe <instance-name> --project "$PROJECT"
gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"
The instance name, database, user, and password secret are in the Outputs. See App_CloudRun for the connection model, backups, and password rotation.
C. Cloud Storage (archived content)
A dedicated Cloud Storage bucket is provisioned automatically and mounted
via GCS Fuse at /data/data by default — the absolute path Linkwarden's
storage code resolves STORAGE_FOLDER to at runtime. Both the web and worker
processes resolve to this same path despite running from different working
directories inside the container.
- Console: Cloud Storage → Buckets.
- CLI:
gcloud storage buckets list --project "$PROJECT"
gcloud storage ls gs://<data-bucket>/ # bucket name is in the Outputs
See App_CloudRun for GCS Fuse and CMEK options.
D. Secret Manager
One secret is generated automatically and stored in Secret Manager:
NEXTAUTH_SECRET (signs NextAuth session JWTs). The database password is
managed separately by the foundation.
- Console: Security → Secret Manager.
- CLI:
gcloud secrets list --project "$PROJECT"
gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"
See App_CloudRun for injection and rotation details.
E. Networking & ingress
The service is reachable at its run.app URL by default. An external HTTPS
load balancer with a custom domain, Cloud CDN, and Cloud Armor can be layered
on; ingress settings and VPC egress control connectivity.
- Console: Cloud Run (service URL); Network services → Load balancing.
- CLI:
gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'
gcloud compute addresses list --project "$PROJECT"
See App_CloudRun.
F. Cloud Logging & Monitoring
Container logs flow to Cloud Logging; Cloud Run and Cloud SQL metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.
- Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
- CLI:
gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50
3. Linkwarden Application Behaviour
- First-deploy database setup. An initialization Job runs
db-init.shusingpostgres:15-alpine. It connects through the Cloud SQL private IP and idempotently creates the application database and user and grants privileges. The job is safe to re-run. - Schema migrations run on every boot. Linkwarden's base image
CMDrunsprisma migrate deploybefore starting the web and worker processes, so upgrading the application version applies schema changes automatically — there is no separate migration job. NEXTAUTH_SECRETis immutable after first boot. Generated once and written to Secret Manager. Rotating it invalidates every active session, forcing all users to log in again.- No pre-seeded admin account. The first user to register through the standard NextAuth registration flow becomes the instance owner — there is no default credential to retrieve.
- Background archiving worker. A separate process (
worker.ts, run viaconcurrentlyalongside the web server in the same container) polls PostgreSQL directly and processes queued links in batches (ARCHIVE_TAKE_COUNT, default5). Each batch launches headless Chrome instances for screenshot/PDF/monolith capture — CPU/memory spike briefly during each batch. - Health path. Startup and liveness probes default to
/— Linkwarden has no confirmed dedicated health endpoint. The startup probe allows a generous window (60s initial delay, 30 failure threshold) to absorb Next.js cold start plus headless Chrome/Playwright initialization. - Inspect job execution:
gcloud run jobs list --project "$PROJECT" --region "$REGION"
gcloud run jobs executions list --job <job-name> --project "$PROJECT" --region "$REGION"
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Linkwarden are listed; every other input is inherited from App_CloudRun with its standard behaviour.
Group 1 / 2 — Project & Identity
| Variable | Default | Description |
|---|---|---|
project_id | (required) | Target Google Cloud project. |
region | us-central1 | Region for the service and regional resources. |
tenant_deployment_id | demo | Short suffix that makes resource names unique per environment. |
Group 3 — Application Identity
| Variable | Default | Description |
|---|---|---|
application_name | linkwarden | Base name for resources. Do not change after first deploy. |
display_name | Linkwarden | Human-readable name shown in the Console. |
application_version | latest | Linkwarden publishes a genuine latest tag upstream — this pins/tracks the real upstream release, unlike some other custom-build modules. |
Group 4 — Runtime & Scaling
| Variable | Default | Description |
|---|---|---|
deploy_application | true | Set false to provision infrastructure only. |
cpu_limit | 2000m | 2 vCPU — headless Chrome archiving runs in-process with the web server. |
memory_limit | 2Gi | Minimum for bundled headless Chromium; bump to 4Gi for heavy PDF/screenshot workloads. |
cpu_always_allocated | true | Keeps the background archiving worker processing between requests. |
min_instance_count | 1 | Keeps the archiving worker alive; scale-to-zero would stop background archiving. |
max_instance_count | 5 | Autoscaling upper bound. |
container_port | 3000 | Linkwarden (Next.js) listens on port 3000. |
execution_environment | gen2 | Required for GCS Fuse mounts. |
enable_cloudsql_volume | true | Kept for parity; the entrypoint connects over DB_IP directly, not the socket. |
enable_image_mirroring | true | Mirror the Linkwarden image into Artifact Registry. |
Group 5 — Access & Ingress Control
Standard ingress_settings, vpc_egress_setting, enable_iap — see
App_CloudRun.
Group 6 — Environment Variables & Secrets
| Variable | Default | Description |
|---|---|---|
environment_variables | {} | Extra non-secret settings. DATABASE_URL, NEXTAUTH_URL, PORT, and HOSTNAME are set automatically — do not set them here. |
disable_browser | false | Sets DISABLE_BROWSER — skips all headless-Chrome archiving tasks. Fallback if Cloud Run's sandbox misbehaves with Chrome. |
archive_take_count | 5 | Links processed per background-worker batch (ARCHIVE_TAKE_COUNT). |
secret_environment_variables | {} | Map of env var → Secret Manager secret name. |
Group 11 — Storage & Filesystem
| Variable | Default | Description |
|---|---|---|
enable_nfs | false | Off by default — Linkwarden uses a GCS volume instead for simplicity. |
gcs_volumes | [] (falls back to a built-in default) | A default "storage" volume mounted at /data/data is wired automatically unless you supply your own list, which fully replaces it. |
Group 12 — Database Backend
| Variable | Default | Description |
|---|---|---|
database_type | POSTGRES_15 | Fixed — Linkwarden's Prisma schema is Postgres-only. |
db_name | linkwarden | PostgreSQL database name. Immutable after first deploy. |
db_user | linkwarden | Application database user. Password auto-generated in Secret Manager. |
Group 13 — Jobs & Scheduled Tasks
| Variable | Default | Description |
|---|---|---|
initialization_jobs | [] | Leave empty to use the built-in db-init job. Linkwarden runs its own Prisma migrations on boot — no separate migrate job is needed. |
cron_jobs | [] | Not used by default. |
Group 14 — Observability & Health
| Variable | Default | Description |
|---|---|---|
startup_probe / liveness_probe | HTTP / | Linkwarden has no confirmed dedicated health endpoint; generous timing window for cold start + Chrome init. |
uptime_check_config | { enabled=false, path="/" } | Cloud Monitoring uptime check; disabled by default. |
Group 21 — Redis
| Variable | Default | Description |
|---|---|---|
enable_redis | false | Not used by Linkwarden — its archiving worker polls PostgreSQL directly. Kept for Foundation-variable parity. |
5. Outputs
Returned on a successful deployment — the quickest way to locate and explore the running resources.
| Output | Description |
|---|---|
service_name | Cloud Run service name. |
service_url | Default run.app URL of the service. |
service_location | Region the service runs in. |
load_balancer_ip / load_balancer_url | External HTTPS load balancer IP / URL (when enabled). |
database_instance_name | Cloud SQL instance name. |
database_name / database_user | Application database name / user. |
database_password_secret | Secret Manager secret holding the DB password. |
database_host / database_port | DB endpoint / port. |
storage_buckets | Created Cloud Storage buckets. |
container_image / container_registry | Deployed image and Artifact Registry repo. |
initialization_jobs | Names of the setup jobs. |
deployment_id / tenant_id / resource_prefix | Naming identifiers. |
project_id / project_number | Project identifiers. |
6. Configuration Pitfalls & Sensible Defaults
Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).
Inherited plan-time validation. This module passes its configuration through the App_CloudRun foundation engine, which validates values and combinations at plan time. Most mistakes below are caught up front rather than at apply or runtime.
| Setting | Sensible value | Risk | Consequence if wrong |
|---|---|---|---|
NEXTAUTH_SECRET (auto-generated) | Never rotate after first boot | Critical | Rotating it invalidates every active session, forcing all users to log in again. |
db_name / db_user | Set once | Critical | Immutable after first deploy; renaming recreates the DB/user and destroys all data. |
database_type | POSTGRES_15 (fixed) | Critical | Any other engine breaks the first-boot Prisma migration entirely. |
min_instance_count | 1 | High | Scale-to-zero stops the background archiving worker between requests — queued links never get archived. |
memory_limit | 2Gi minimum | High | Headless Chrome archiving OOMs below this floor; the web server may still respond while archiving silently fails. |
enable_nfs + gcs_volumes | Leave enable_nfs=false, use the default GCS volume | Medium | Enabling NFS without also disabling the default GCS volume wiring can leave archived content split across two storage backends. |
disable_browser | false unless Chrome fails on Cloud Run's sandbox | Medium | Leaving it true unnecessarily disables all screenshot/PDF/monolith archiving — Linkwarden becomes a plain link list. |
archive_take_count | 5 (default) | Low | Large values spike CPU/memory sharply during each batch (concurrent headless Chrome instances). |
ingress_settings | all for normal use | Medium | Restricting to internal blocks the public login/registration flow needed for the first-run owner account. |
For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_CloudRun. Linkwarden-specific application configuration shared with the GKE variant is described in Linkwarden_Common.
