Spoolman on GKE Autopilot
Spoolman is a free, open-source inventory and usage tracker for 3D-printing filament spools — vendors, materials, remaining weight, cost per spool, and per-print consumption. It ships as a single-process Python/FastAPI backend with a bundled static Vue/Quasar frontend. This module deploys Spoolman on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.
This guide focuses on the cloud services Spoolman uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.
1. Overview
Spoolman runs as a single Python/FastAPI pod — there is no separate frontend workload; the Vue/Quasar UI is bundled and served from the same process. The deployment wires together a minimal set of Google Cloud services:
| Capability | Google Cloud service | Notes |
|---|---|---|
| Compute | GKE Autopilot | Prebuilt ghcr.io/donkie/spoolman image, 1 vCPU / 512Mi by default |
| Database | Cloud SQL for PostgreSQL 15 | Required — this module standardises on Postgres (Spoolman upstream also supports MySQL/SQLite/CockroachDB) |
| Object storage | None | Spoolman keeps all state in Postgres; no GCS bucket is provisioned |
| Cache | None | Spoolman has no Redis/cache integration |
| Secrets | Secret Manager | Only the auto-generated database password — Spoolman has no admin/API-key bootstrap secret of its own |
| Ingress | Cloud Load Balancing | External LoadBalancer by default |
Sensible defaults worth knowing up front:
- PostgreSQL 15 is the only supported engine in this module.
database_typeis fixed bySpoolman_Common; Spoolman upstream also supports MySQL and CockroachDB via env vars, but this module does not expose that choice. - No custom build.
container_image_source = "prebuilt"deploysghcr.io/donkie/spoolmandirectly — there is no Dockerfile, no Cloud Build step. - No init job. The Foundation auto-creates the Postgres role and database; Spoolman runs its own Alembic migrations automatically on every container start.
- No application secrets. Spoolman ships with no authentication at all —
whoever can reach the Service has full read/write access to the inventory.
There is no login gate to bootstrap and nothing generated in Secret Manager
beyond the database password. If that is not acceptable, put the service
behind IAP (
enable_iap = true) or a Cloud Armor IP allowlist. service_type = "LoadBalancer"by default. Spoolman is a browser-driven web UI, so the Service is externally reachable out of the box.reserve_static_ip = falseby default. Spoolman bakes no self-referencing URL into boot-time config (onlySPOOLMAN_CORS_ORIGINmatters, and only for cross-domain access), so this module conserves the project's often-tight static-IP quota by not reserving one.- Connections use the cloud-sql-proxy sidecar's loopback, not TCP.
Spoolman's SQLAlchemy layer builds its connection via
URL.create()(a structured object, not string concatenation), so127.0.0.1passes through cleanly with no URL-parsing issue and no TLS/sslmodeconfiguration needed.
2. Google Cloud Services & How to Explore Them
All commands assume you have run
gcloud container clusters get-credentials <cluster> --region <region> --project <project>
and that PROJECT, REGION, and NAMESPACE are set. The namespace and other
identifiers are reported in the deployment Outputs.
A. GKE Autopilot — the Spoolman workload
Spoolman runs as a single Deployment/pod on Autopilot, which bills for the CPU/memory the pod actually requests.
- Console: Kubernetes Engine → Workloads → select the Spoolman workload for pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
- CLI:
kubectl get pods,svc -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100
See App_GKE for how Autopilot and scaling are managed.
B. Cloud SQL for PostgreSQL 15
Spoolman stores all inventory data (spools, filaments, vendors, usage history) in a managed Cloud SQL for PostgreSQL 15 instance. The pod reaches it privately through the Cloud SQL Auth Proxy sidecar over loopback; no public IP is exposed. There is no initialization job — Spoolman applies its own schema migrations on every boot.
- Console: SQL → select the instance for connections, backups, flags, and metrics.
- CLI:
gcloud sql instances list --project "$PROJECT"
gcloud sql instances describe <instance-name> --project "$PROJECT"
gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"
The instance name, database, user, and password secret are in the Outputs. See App_GKE for the connection model, backups, and password rotation.
C. Secret Manager
Only the auto-generated database password lives in Secret Manager — Spoolman has no admin account or API key of its own to bootstrap.
- Console: Security → Secret Manager.
- CLI:
gcloud secrets list --project "$PROJECT" --filter="name~spoolman"
gcloud secrets versions access latest --secret=<db-password-secret> --project "$PROJECT"
D. Networking & ingress
The Service is reachable at its external LoadBalancer IP by default
(service_type = "LoadBalancer", reserve_static_ip = false so the IP is
ephemeral unless changed).
- Console: Kubernetes Engine → Services & Ingress.
- CLI:
kubectl get svc -n "$NAMESPACE" -o wide
See App_GKE for custom domains, CDN, and Cloud Armor.
E. Cloud Logging & Monitoring
Container logs flow to Cloud Logging; GKE and Cloud SQL metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.
- Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
- CLI:
kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100
3. Spoolman Application Behaviour
- No first-deploy database setup job. Unlike most application modules in
this catalogue, Spoolman needs no
db-initjob — the Foundation creates the Postgres role and database, and Spoolman's own Alembic migrations run automatically on every container start (including the very first boot). - No authentication. There is no login page, no admin account, and no API key gate. Anyone who can reach the Service can view and modify the entire inventory. Decide your access-control approach (IAP, Cloud Armor allowlist, or accept public read/write) before exposing the LoadBalancer IP.
- Health path.
/api/healthis public and unauthenticated, returning a 200/OK JSON status once the server (and its DB connection) is up. Both the startup and liveness probes target this path. - Database engine locked to Postgres. Spoolman's own
SPOOLMAN_DB_TYPEenvironment variable selects the engine; this module always sets it topostgres. Never unset it viaenvironment_variables— without it, Spoolman silently falls back to a throwaway container-local SQLite file with no error at all. - Inspect Cloud SQL connectivity:
kubectl exec -n "$NAMESPACE" deploy/<service-name> -- env | grep -i spoolman_db
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Spoolman are listed; every other input is inherited from App_GKE with its standard behaviour.
Group 3 — Application Identity
| Variable | Default | Description |
|---|---|---|
application_name | spoolman | Base name for resources. Do not change after first deploy. |
application_display_name | Spoolman | Human-readable name. |
application_version | latest | Image tag pulled from ghcr.io/donkie/spoolman. Genuinely prebuilt — no Dockerfile/build-arg pinning concerns. |
Group 4 — Container & Scale
| Variable | Default | Description |
|---|---|---|
deploy_application | true | Set false to provision infrastructure only. |
container_image_source | prebuilt | Forwarded to the Foundation — required, or the default "custom" silently triggers a Kaniko build attempt with no Dockerfile. |
container_port | 8000 | Spoolman's default listen port. |
container_resources | { cpu_limit = "1000m", memory_limit = "512Mi" } | Ample for a single-tenant filament tracker. |
min_instance_count / max_instance_count | 0 / 1 | Scale-to-zero is safe — Spoolman has no background work. |
Group 16 — Database
| Variable | Default | Description |
|---|---|---|
db_host_env_var_name | SPOOLMAN_DB_HOST | Aliases the Foundation's DB_HOST (127.0.0.1 via the cloud-sql-proxy sidecar on GKE). |
db_user_env_var_name | SPOOLMAN_DB_USERNAME | Aliases DB_USER. |
db_password_env_var_name | SPOOLMAN_DB_PASSWORD | Aliases DB_PASSWORD. |
db_name_env_var_name | SPOOLMAN_DB_NAME | Aliases DB_NAME. |
db_port_env_var_name | SPOOLMAN_DB_PORT | Aliases DB_PORT. |
application_database_name / application_database_user | spoolman / spoolman | Immutable after first deploy. |
Group 14 — Storage & Filesystem
| Variable | Default | Description |
|---|---|---|
create_cloud_storage | false | No GCS bucket needed — all state lives in Cloud SQL. |
enable_nfs | false | No shared filesystem needed. |
Group 19 — Networking
| Variable | Default | Description |
|---|---|---|
service_type | LoadBalancer | Spoolman is a browser-driven web UI, exposed externally by default. |
reserve_static_ip | false | Conserves the project's static-IP quota; Spoolman bakes no self-referencing URL into boot-time config. |
Group 10 — Probes & Lifecycle
| Variable | Default | Description |
|---|---|---|
startup_probe_config | HTTP /api/health, 10s delay | Public, unauthenticated. |
health_check_config | HTTP /api/health, 30s period | Public, unauthenticated. |
All other inputs (CI/CD, backups, VPC-SC, Cloud Armor, IAP, Redis, stateful PVCs) are inherited from App_GKE with standard behaviour — Spoolman uses none of them by default.
5. Outputs
| Output | Description |
|---|---|
service_name | Kubernetes Service name. |
namespace | Kubernetes namespace. |
service_cluster_ip | Internal ClusterIP. |
service_external_ip | External LoadBalancer IP. |
service_url | Full URL of the deployed workload. |
database_instance_name | Cloud SQL instance name. |
database_name / database_user | Application database name / user. |
database_password_secret | Secret Manager secret holding the DB password. |
database_host / database_port | DB endpoint / port. |
storage_buckets | Always empty — Spoolman needs no GCS bucket. |
container_image / container_registry | Deployed image and Artifact Registry repo (when mirroring is enabled). |
monitoring_enabled | Monitoring status. |
initialization_jobs | Always empty — Spoolman needs no init job. |
kubernetes_ready | Whether the workload reports ready. |
deployment_id / tenant_id / resource_prefix | Naming identifiers. |
project_id / project_number | Project identifiers. |
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode | VPC-SC status. |
audit_logging_enabled / artifact_registry_cmek_enabled | Audit logging and CMEK status. |
6. Configuration Pitfalls & Sensible Defaults
Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).
| Setting | Sensible value | Risk | Consequence if wrong |
|---|---|---|---|
| No authentication (built-in) | Front with IAP or Cloud Armor if needed | Critical | Anyone who can reach the Service can read and modify the entire filament inventory — there is no login gate to disable. |
SPOOLMAN_DB_TYPE (auto-injected postgres) | Never unset via environment_variables | Critical | Unsetting it silently falls back to a throwaway container-local SQLite file — no error, and all data is lost on every pod restart. |
application_database_name / application_database_user | Set once | Critical | Immutable after first deploy; renaming recreates the DB/user and destroys all data. |
container_image_source | prebuilt (do not override to custom) | Critical | Setting "custom" triggers a Kaniko build attempt against a module with no Dockerfile — the build fails outright. |
service_type | LoadBalancer (default) | High | Switching to ClusterIP makes the service unreachable from a browser without kubectl port-forward or a separate ingress. |
SPOOLMAN_DB_QUERY | Leave empty unless troubleshooting | Medium | Escape hatch for a TCP + sslmode fallback — only needed if the loopback connection path is ever found unreliable; not required for normal operation. |
reserve_static_ip | false (default) | Low | Set true only if you need a stable IP for DNS/firewall allowlisting — the project's static-IP quota is limited and shared across the tenant. |
min_instance_count | 0 (default) | Low | Spoolman has no background work, so scale-to-zero is safe. |
For the foundation behaviour referenced throughout — Workload Identity, scaling, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Spoolman-specific application configuration shared with the Cloud Run variant is described in Spoolman_Common.
