Homebox on GKE Autopilot
Homebox is an open-source, self-hosted home inventory and organization system with a Go REST API backend (Echo-style, Ent ORM) and a Vue 3/Nuxt frontend served embedded from the same binary — track items, attach photos, and organize by location. This module deploys Homebox on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.
This guide focuses on the cloud services Homebox uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.
1. Overview
Homebox runs as a single Go binary (API + embedded frontend) — one pod, no sidecars beyond the Cloud SQL Auth Proxy. The deployment wires together a small, focused set of Google Cloud services:
| Capability | Google Cloud service | Notes |
|---|---|---|
| Compute | GKE Autopilot | Go/Echo pod, 1 vCPU / 512 MiB by default |
| Database | Cloud SQL for PostgreSQL 15 | Homebox reads discrete HBOX_DATABASE_* env vars, not a constructed DSN |
| Object storage | Cloud Storage | A data bucket is created for item photos/attachments, but not auto-mounted |
| Cache & queue | none | Homebox has no Redis or queue dependency |
| Secrets | Secret Manager | Database password plus HBOX_AUTH_API_KEY_PEPPER (a real, app-consumed secret) |
| Ingress | Cloud Load Balancing | External LoadBalancer, optional custom domain + managed certificate |
Sensible defaults worth knowing up front:
- PostgreSQL is the standardized engine.
Homebox_Commonfixesdatabase_type = "POSTGRES_15"and setsHBOX_DATABASE_DRIVER=postgresexplicitly. - No custom container build. The official prebuilt image
(
ghcr.io/sysadminsmedia/homebox) is used directly. - Open self-registration, not a default admin account. Homebox does not
ship a hardcoded credential: the first person to submit the "Register"
form on a fresh instance becomes the initial admin user. See the
Common guide for detail. Operators should set
HBOX_OPTIONS_ALLOW_REGISTRATION=falseafter completing registration. workload_type = "Deployment", notStatefulSet. Homebox keeps no local state beyond what's already in Cloud SQL — no PVC, no NFS mount required.- Item photos are not persisted by default. A GCS bucket is created but
not auto-mounted — add a
gcs_volumesentry if uploaded item photos and attachments need to survive a pod restart.
2. Google Cloud Services & How to Explore Them
All commands assume you have run
gcloud container clusters get-credentials <cluster> --region <region> --project <project>
and that PROJECT, REGION, and NAMESPACE are set.
A. GKE Autopilot — the Homebox workload
- CLI:
kubectl get pods,svc -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100
B. Cloud SQL for PostgreSQL 15
Pods reach the database privately through the cloud-sql-proxy sidecar over
127.0.0.1.
- CLI:
gcloud sql instances list --project "$PROJECT"
gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"
C. Cloud Storage
- CLI:
gcloud storage buckets list --project "$PROJECT" --filter="name~homebox"
D. Secret Manager
- CLI:
gcloud secrets list --project "$PROJECT" --filter="name~homebox"
gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"
E. Networking & ingress
- CLI:
kubectl get svc -n "$NAMESPACE" -o wide
F. Cloud Logging & Monitoring
- CLI:
kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100 -f
3. Homebox Application Behaviour
- First-deploy database setup. An initialization Job runs
create-db-and-user.sh, idempotently creating the application role and database. - Schema migrations on start. Homebox's Ent ORM applies its own internal migrations automatically on every pod start.
- Open self-registration — no default admin credential. The first
visitor to complete the "Register" form becomes the admin. There is no
credential to retrieve, reset, or rotate — set
HBOX_OPTIONS_ALLOW_REGISTRATION=falseonce the admin account exists to close public signups. - Health path. Startup and liveness probes target
/api/v1/status— Homebox's real, unauthenticated status endpoint. - Inspect job execution:
kubectl get jobs -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" job/<job-name>
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Homebox are listed; every other input is inherited from App_GKE with its standard behaviour.
Group 3 — Application Identity
| Variable | Default | Description |
|---|---|---|
application_name | homebox | Base name for resources. |
application_version | latest | Homebox publishes a genuine latest tag. |
Group 4 — Runtime & Scaling
| Variable | Default | Description |
|---|---|---|
container_image_source | prebuilt | No custom build needed. |
container_port | 7745 | Homebox's native default port. |
min_instance_count / max_instance_count | 0 / 1 | HPA scaling bounds. |
Group 11 — Storage & Filesystem
| Variable | Default | Description |
|---|---|---|
storage_buckets | one data bucket | Created but not auto-mounted. |
stateful_pvc_enabled | false | Not used — Homebox is stateless at the pod level. |
Group 12 (16) — Database Backend
| Variable | Default | Description |
|---|---|---|
database_type | POSTGRES_15 | Fixed by Homebox_Common. |
db_host_env_var_name | HBOX_DATABASE_HOST | Aliases the platform DB_HOST onto Homebox's expected name. |
db_user_env_var_name | HBOX_DATABASE_USERNAME | Aliases DB_USER. |
db_password_env_var_name | HBOX_DATABASE_PASSWORD | Aliases DB_PASSWORD. |
db_name_env_var_name | HBOX_DATABASE_DATABASE | Aliases DB_NAME. |
db_port_env_var_name | HBOX_DATABASE_PORT | Aliases DB_PORT. |
Group 14 — Observability & Health
| Variable | Default | Description |
|---|---|---|
startup_probe_config / health_check_config | HTTP /api/v1/status | Probes target Homebox's real status endpoint. |
5. Outputs
| Output | Description |
|---|---|
service_name / service_url / service_external_ip | Kubernetes Service identity and address. |
database_instance_name / database_name / database_user / database_host / database_port | Cloud SQL connection details. |
storage_buckets | The data bucket for item photos and attachments. |
kubernetes_ready | Whether the workload reached Ready state. |
6. Configuration Pitfalls & Sensible Defaults
Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).
| Setting | Sensible value | Risk | Consequence if wrong |
|---|---|---|---|
application_database_name / application_database_user | Set once | Critical | Immutable after first deploy; renaming recreates the DB/user and destroys all data. |
container_image_source | prebuilt (default) | High | "custom" triggers an unnecessary Cloud Build with no Dockerfile in this module. |
| First registration | Complete promptly after deploy | Medium | The first person to register on a fresh, publicly reachable instance becomes the admin — until you register and set HBOX_OPTIONS_ALLOW_REGISTRATION=false, anyone who discovers the URL can claim the admin account. |
gcs_volumes for item photos | Add explicitly before real use | High | Without it, uploaded item photos and attachments live on the pod's ephemeral filesystem and do not survive a restart — this is a bigger deal for Homebox than for apps where images are optional, since photo attachments are core to a home-inventory workflow. |
db_*_env_var_name variables | Leave at their Homebox-specific defaults | Critical | Changing/clearing these breaks Homebox's Postgres connection — it reads HBOX_DATABASE_*, not DB_*. |
HBOX_DATABASE_SSL_MODE | disable (already set by this module) | Critical | On GKE, DB_HOST resolves to 127.0.0.1 (the cloud-sql-proxy sidecar), which terminates TLS itself and serves plaintext on loopback. Homebox's Postgres client defaults HBOX_DATABASE_SSL_MODE to require and panics on boot (tls error: server refused TLS connection) unless told the local connection is unencrypted. Homebox_GKE sets this via module_env_vars — do not clear it. Not needed on Cloud Run, which connects over a Unix socket (no TLS negotiation applies there regardless of this setting). |
For the foundation behaviour referenced throughout — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Homebox-specific application configuration shared with the Cloud Run variant is described in Homebox_Common.
