Trilium on Google Cloud Run

Trilium Notes (the actively maintained TriliumNext fork — not the archived zadam/trilium) is an open-source, hierarchical, self-hosted note-taking application with an embedded SQLite database. This module deploys Trilium on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure.

This guide focuses on the cloud services Trilium uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.

---

1. Overview

Trilium runs as a single Node.js/Express container on Cloud Run v2. The deployment wires together a deliberately small set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	Cloud Run v2	Node.js service, 1 vCPU / 1 GiB by default, serverless autoscaling — but see scaling notes below
Database	None (embedded SQLite)	Trilium's entire document store is a single SQLite file, document.db, on the persistent volume
Object storage	Cloud Storage	A dedicated data bucket, mounted via GCS FUSE at /home/node/trilium-data
Secrets	Secret Manager	None generated — Trilium has no env-var-driven credential
Ingress	Cloud Run URL	Default run.app URL; optional external HTTPS load balancer + custom domain

Sensible defaults worth knowing up front:

• No database engine to manage. database_type = "NONE" — there is no Cloud SQL instance, no connection string, and nothing to back up separately from the data bucket.
• Single-instance only. min_instance_count = max_instance_count = 1. Trilium's embedded SQLite database has no multi-writer support — running more than one instance risks database corruption from concurrent writes.
• No seeded credential. Unlike apps with a Secret Manager-backed password, Trilium has no env-var-driven auth bootstrap. On first visit, the app itself presents a "Set Password" screen; complete it before sharing the URL.
• Health probe is /api/health-check, not /. The root path (/) returns a 302 redirect to the setup/login screen. Only /api/health-check returns an unauthenticated 200 {"status":"ok"} — confirmed live via local container testing.
• The data directory is everything. /home/node/trilium-data holds the SQLite database, all attachments, revision history, and settings. Losing this volume loses everything; it is persisted via a GCS FUSE-mounted bucket by default.
• mount_options set uid=1000,gid=1000. Trilium's container runs as the node user (confirmed via docker run ... id node); without matching mount options, GCS FUSE mounts the directory root-owned and the app fails to boot.

---

2. Google Cloud Services & How to Explore Them

All commands assume PROJECT and REGION are set. Service and resource names are reported in the deployment Outputs.

A. Cloud Run — the Trilium service

Trilium runs as a single Cloud Run v2 service. Because it must stay at exactly one instance, there is no meaningful autoscaling to observe — the interesting signal is revision health and cold-start behaviour.

• Console: Cloud Run → select the service for revisions, traffic, logs, and metrics.
• CLI:

  gcloud run services list --project "$PROJECT" --region "$REGION"
  gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
  gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"

See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.

B. Cloud Storage — the Trilium data directory

The entire application state (SQLite document.db, attachments, revision history, settings) lives in a dedicated Cloud Storage bucket, mounted via GCS FUSE at /home/node/trilium-data.

• Console: Cloud Storage → Buckets.
• CLI:

  gcloud storage buckets list --project "$PROJECT"
  gcloud storage ls gs://<data-bucket>/          # bucket name is in the Outputs

See App_CloudRun for GCS Fuse mount options and CMEK.

C. Networking & ingress

The service is reachable at its run.app URL by default. An external HTTPS load balancer with a custom domain, Cloud CDN, and Cloud Armor can be layered on.

• Console: Cloud Run (service URL); Network services → Load balancing.
• CLI:

  gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'

See App_CloudRun.

D. Cloud Logging & Monitoring

Container logs flow to Cloud Logging; Cloud Run metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50

---

3. Trilium Application Behaviour

• No first-deploy database setup job. Trilium creates and migrates its own SQLite schema on first web visit, via its own setup wizard — there is no Terraform-managed db-init job to inspect.
• First-run "Set Password" screen. Navigating to the root URL for the first time presents a password-setup form (no default admin/username — Trilium is a single-user app). There is no pre-seeded credential in Secret Manager to look up.
• Health path. Startup and liveness probes target /api/health-check, which returns 200 {"status":"ok"} once the HTTP server is listening — regardless of whether the SQLite database has been initialized yet (that only happens after the operator completes the Set Password step).
• Single-writer constraint. Never raise max_instance_count above 1 — the embedded SQLite database is not safe for concurrent writers from multiple instances.
• Inspect the running revision:

  gcloud run services describe <service-name> \
    --region "$REGION" --project "$PROJECT" \
    --format='value(status.url)'

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Trilium are listed; every other input is inherited from App_CloudRun with its standard behaviour.

Group 1 — Project & Identity

Variable	Default	Description
project_id	(required)	Target Google Cloud project.
region	us-central1	Region for the service and regional resources.

Group 2 — Deployment Environment

Variable	Default	Description
tenant_deployment_id	demo	Short suffix that makes resource names unique per environment.
support_users	[]	Emails granted project access and monitoring alerts.
resource_labels	{}	Labels applied to all resources.

Group 3 — Application Identity

Variable	Default	Description
application_name	trilium	Base name for resources. Do not change after first deploy.
application_display_name	Trilium Notes	Human-readable name shown in the Console.
application_version	latest	Docker image version tag; mapped to a pinned build ARG (TRILIUM_VERSION) internally, not passed through as latest to the Dockerfile.
enable_password	false	Reserved for parity with other single-user editor modules. No effect — Trilium has no env-var-driven password bootstrap.

Group 4 — Runtime & Scaling

Variable	Default	Description
deploy_application	true	Set false to provision infrastructure only.
cpu_limit	1000m	CPU per instance.
memory_limit	1Gi	Memory per instance; Trilium is lightweight, raise only for very large note collections.
min_instance_count / max_instance_count	1 / 1	Keep both at 1 — no multi-writer support on the embedded SQLite database.
container_port	8080	Trilium's default HTTP port.
execution_environment	gen2	Gen2 required for GCS Fuse mounts.
enable_image_mirroring	true	Mirror the Trilium image into Artifact Registry.

Group 5 — Access & Ingress Control

Variable	Default	Description
ingress_settings	all	Public by default; restrict to internal for a private deployment.
vpc_egress_setting	PRIVATE_RANGES_ONLY	Route only RFC 1918 traffic via VPC.
enable_iap	false	Require Google sign-in in front of Trilium.

Group 11 — Storage & Filesystem

Variable	Default	Description
create_cloud_storage	true	Create the Trilium data bucket.
gcs_volumes	[]	Additional GCS Fuse volumes beyond the auto-mounted data bucket.

Group 12 — Database Backend

Variable	Default	Description
database_type	NONE	Not referenced — Trilium has no SQL database (embedded SQLite only).

Group 14 — Observability & Health

Variable	Default	Description
startup_probe	HTTP /api/health-check, 15s delay	Startup probe.
liveness_probe	HTTP /api/health-check, 30s delay	Liveness probe.
uptime_check_config	disabled	Optional Cloud Monitoring uptime check on /api/health-check.

---

5. Outputs

Output	Description
service_name	Cloud Run service name.
trilium_url	Default run.app URL of the service.
service_location	Region the service runs in.
load_balancer_ip / load_balancer_url	External HTTPS load balancer IP / URL (when enabled).
storage_buckets	Created Cloud Storage buckets.
container_image / container_registry	Deployed image and Artifact Registry repo.
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Setting	Sensible value	Risk	Consequence if wrong
max_instance_count	1	Critical	Raising it risks concurrent writers corrupting the embedded SQLite database — there is no query-layer protection against this.
Data bucket / gcs_volumes mount_options	uid=1000,gid=1000	Critical	Wrong uid/gid mounts the data directory root-owned; the non-root Trilium process fails to boot with a permission error.
First-visit "Set Password" step	Complete immediately	Critical	An un-set-password Trilium instance left on a public URL is reachable by anyone until the password is set.
startup_probe / liveness_probe path	/api/health-check	High	Pointing probes at / gets a 302 redirect, which most HTTP health checks treat as a failure, blocking the revision from ever becoming Ready.
ingress_settings	internal for private use	Medium	all (default) makes the (initially unauthenticated, pre-Set-Password) instance reachable from the public internet.
memory_limit	1Gi	Low	Trilium is lightweight; only raise for very large note/attachment collections.

---

For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_CloudRun. Trilium-specific application configuration shared with the GKE variant is described in Trilium_Common.
