SparkyFitness on Google Cloud Run
SparkyFitness is a self-hosted, AI-assisted family food, fitness, water, and health
tracker built as a Node.js/Express backend (codewithcj/sparkyfitness_server) with a
separate React frontend served by nginx (codewithcj/sparkyfitness). This module
deploys SparkyFitness on Cloud Run v2 on top of the
App_CloudRun foundation, which provisions and manages the shared
Google Cloud infrastructure.
This guide focuses on the cloud services SparkyFitness uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.
1. Overview
SparkyFitness runs as two prebuilt containers in a single multi-container Cloud Run
service — a real platform constraint, not a stylistic choice. The upstream frontend
image's nginx config hardcodes a plain http:// reverse-proxy target
(proxy_pass http://${SPARKY_FITNESS_SERVER_HOST}:${SPARKY_FITNESS_SERVER_PORT}),
which cannot reach a separate Cloud Run service's HTTPS-only public URL. So:
- The frontend (nginx, port 80) is the main (ingress) container — it receives
all public browser traffic and reverse-proxies
/api,/uploads,/mcp, and/health-datarequests. - The backend (Node.js, port 3010) runs as an in-pod
additional_containerssidecar, reachable by the frontend only athttp://127.0.0.1:3010— plain loopback HTTP, exactly what the vendor nginx config expects.
| Capability | Google Cloud service | Notes |
|---|---|---|
| Compute | Cloud Run v2 (multi-container revision) | Frontend (ingress, ~0.5 vCPU/512Mi) + backend (in-pod sidecar, 1 vCPU/1Gi by default) |
| Database | Cloud SQL for PostgreSQL 15 | Required — no other engine is supported |
| Secrets | Secret Manager | Auto-generated SPARKY_FITNESS_API_ENCRYPTION_KEY, BETTER_AUTH_SECRET, SPARKY_FITNESS_APP_DB_PASSWORD; database password |
| Ingress | Cloud Run URL | Default run.app URL on the frontend container; optional external HTTPS load balancer + custom domain |
Sensible defaults worth knowing up front:
- PostgreSQL 15 is mandatory. No other engine is supported.
- Two database roles, one Terraform-managed.
db_user(defaultsparky) is the admin/migration role created by thedb-initjob;app_db_user(defaultsparky_app) is a limited-privilege role the backend creates and maintains itself at every boot, usingdb_user's credentials — there is no Terraform resource for it. - No separate migrate job. Unlike many apps in this catalogue, SparkyFitness's backend runs its own database migrations on every container start.
- Both images are prebuilt —
container_image_source = "prebuilt"for the whole module; no Cloud Build step runs for the application itself. - Scale-to-zero by default (
cpu_always_allocated = false,min_instance_count = 0) — a plain request/response app with no background scheduler. - Health probes are real, not guessed.
GET /api/healthon port 3010 is confirmed via the backend's own DockerfileHEALTHCHECKdirective.
2. Google Cloud Services & How to Explore Them
All commands assume PROJECT and REGION are set. Service and resource names are
reported in the deployment Outputs.
A. Cloud Run — the SparkyFitness service
A single Cloud Run v2 service runs both containers in one revision. The frontend
container is the one that receives ingress traffic and appears in
status.url; the backend is only visible via the revision's container spec.
- Console: Cloud Run → select the service for revisions, traffic, logs, and
metrics. Expand the revision to see both containers (
sparkyfitness/ frontend andbackend). - CLI:
gcloud run services list --project "$PROJECT" --region "$REGION"
gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
gcloud run revisions describe <revision-name> --project "$PROJECT" --region "$REGION" \
--format='value(spec.containers[].name)'
See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.
B. Cloud SQL for PostgreSQL 15
SparkyFitness stores all application data in a managed Cloud SQL for PostgreSQL 15
instance. The backend sidecar receives the connection details via the
SPARKY_FITNESS_DB_HOST/_PORT/_NAME/_USER/_PASSWORD env vars (renamed from
the Foundation's standard DB_* names).
- Console: SQL → select the instance for connections, backups, flags, metrics.
- CLI:
gcloud sql instances list --project "$PROJECT"
gcloud sql instances describe <instance-name> --project "$PROJECT"
gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"
The instance name, database, user, and password secret are in the Outputs. See App_CloudRun for the connection model, backups, and password rotation.
C. Secret Manager
Three cryptographic secrets are generated automatically:
SPARKY_FITNESS_API_ENCRYPTION_KEY— 64-char hex, encrypts stored external data-source credentials.BETTER_AUTH_SECRET— signs sessions and encrypts 2FA/TOTP data.SPARKY_FITNESS_APP_DB_PASSWORD— password for the self-healing, limited-privilegeapp_db_userrole.
gcloud secrets list --project "$PROJECT" --filter="name~sparkyfitness"
gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"
D. Networking & ingress
The frontend container is reachable at the service's run.app URL by default. An
external HTTPS load balancer with a custom domain, Cloud CDN, and Cloud Armor can be
layered on.
gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'
E. Cloud Logging & Monitoring
gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50
The backend sidecar's logs appear in the same Cloud Logging stream, tagged with its
container name — filter on resource.labels.container_name="backend" to isolate them.
3. SparkyFitness Application Behaviour
- First-deploy database setup. A single
db-initinitialization Job (usingpostgres:15-alpine) creates the admin role (db_user) and database (db_name). It does not createapp_db_user— the backend does that itself. - Migrations run on every boot. The backend applies its own schema migrations at
startup using the admin
db_usercredentials — there is no separate migrate job to monitor. app_db_useris self-healing. The backend creates or updates this limited-privilege role at every start, so it survives a full container recreation with no manual intervention.- First-run account creation. Sign up via the web UI to create the first user
account. Set
admin_emailto that user's email and redeploy to grant admin privileges —SPARKY_FITNESS_ADMIN_EMAILonly elevates an existing account, it does not create one. - Disable signup after first use. Set
disable_signup = trueonce the admin account exists, to prevent unauthenticated users from self-registering. - Health path.
GET /api/healthon port 3010 (backend) — confirmed via the upstream Dockerfile's ownHEALTHCHECKdirective, not guessed. - Immutable secrets.
BETTER_AUTH_SECRETmust never change after users enable 2FA (it locks them out);SPARKY_FITNESS_API_ENCRYPTION_KEYmust never change after external data sources are connected (it invalidates the encrypted credentials). - Cloud SQL TLS caveat (verify on first live deploy). The backend sidecar's
SPARKY_FITNESS_DB_HOSTalways resolves to the raw Cloud SQL private IP on Cloud Run (this Foundation'sadditional_containers/inherit_app_envmechanism always uses the raw IP, regardless ofenable_cloudsql_volume). Confirm the backend's Postgres client (pg/node-postgres) connects successfully against that IP — if the Cloud SQL instance enforces SSL, this may need a follow-up fix. - Inspect job execution:
gcloud run jobs list --project "$PROJECT" --region "$REGION"
gcloud run jobs executions list --job db-init --project "$PROJECT" --region "$REGION"
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for SparkyFitness are listed; every other input is inherited from App_CloudRun with its standard behaviour.
Group 3 — Application Identity
| Variable | Default | Description |
|---|---|---|
application_name | sparkyfitness | Base name for resources. Do not change after first deploy. |
application_version | latest | Tags BOTH the frontend and backend images identically. Use latest or a v-prefixed tag exactly as published upstream (e.g. v0.17.3 — a bare 0.17.3 does not exist). |
Group 4 — Runtime & Scaling
| Variable | Default | Description |
|---|---|---|
cpu_limit / memory_limit | 1000m / 1Gi | Resource limits for the backend sidecar. |
min_instance_count / max_instance_count | 0 / 2 | Instance scaling bounds. |
container_port | 3010 | Backend's listening port inside its sidecar. |
cpu_always_allocated | false | Request-based billing — no background work needed at steady state. |
enable_cloudsql_volume | true | See the TLS caveat in §3 — the backend sidecar always gets the raw private IP regardless of this flag on Cloud Run. |
Group 5 — SparkyFitness Application Config
| Variable | Default | Description |
|---|---|---|
app_db_user | sparky_app | Limited-privilege runtime role name, self-created by the backend. |
disable_signup | false | Disable new self-registration. |
admin_email | "" | Grants admin to an EXISTING user on startup; does not create the account. |
public_api_docs | false | Expose Swagger docs publicly. |
allow_private_network_cors | false | Only enable on a private network. |
log_level | ERROR | Backend log verbosity. |
timezone | Etc/UTC | Backend TZ. |
Group 7 — SMTP (optional)
| Variable | Default | Description |
|---|---|---|
smtp_enabled | false | Enable password-reset/notification email. |
smtp_host / smtp_port / smtp_user / smtp_from / smtp_secure | see variables.tf | Set all fields together when enabling SMTP; supply the password via secret_environment_variables (SPARKY_FITNESS_EMAIL_PASS). |
Group 13 — Database
| Variable | Default | Description |
|---|---|---|
database_type | POSTGRES_15 | Fixed — no other engine supported. |
db_name | sparkyfitness_db | Database name. Immutable after first deploy. |
db_user | sparky | Admin/migration role — the backend runs its own migrations with this role. |
Group 15 — Jobs & Scheduled Tasks
| Variable | Default | Description |
|---|---|---|
initialization_jobs | [] | Leave empty to use the built-in db-init job (admin role + database only). |
Group 16 — Observability & Health
| Variable | Default | Description |
|---|---|---|
startup_probe / liveness_probe | HTTP /api/health, port 3010 | Targets the backend; the frontend main container gets its own plain TCP probe (hardcoded in the wiring file, not user-configurable). |
Group 17 — Redis (not used natively)
| Variable | Default | Description |
|---|---|---|
enable_redis | false | SparkyFitness does not use Redis; left available as a generic Foundation capability. |
5. Outputs
| Output | Description |
|---|---|
service_name | Cloud Run service name. |
app_url | URL of the application (frontend/ingress container) — open this in a browser. |
backend_url | Internal loopback address of the backend sidecar (http://127.0.0.1:3010). |
database_instance_name / database_name / database_user | Cloud SQL identifiers. |
database_password_secret | Secret Manager secret holding the admin DB password. |
storage_buckets | Created Cloud Storage buckets (none by default). |
container_image | Deployed frontend image. |
deployment_id / tenant_id / resource_prefix | Naming identifiers. |
6. Configuration Pitfalls & Sensible Defaults
Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).
| Setting | Sensible value | Risk | Consequence if wrong |
|---|---|---|---|
BETTER_AUTH_SECRET (auto-generated) | Never rotate after users enable 2FA | Critical | Rotating it locks out every user with 2FA enabled. |
SPARKY_FITNESS_API_ENCRYPTION_KEY (auto-generated) | Never rotate after first connection | Critical | Rotating it invalidates all stored external-data-source credentials. |
db_name / db_user | Set once | Critical | Immutable after first deploy; changing recreates the DB and destroys all data. |
application_version | Use upstream's exact tag (v0.17.3) | High | A bare 0.17.3 (no v prefix) does not exist upstream — pull fails. |
admin_email | Set only after the account exists | Medium | Setting it before signup has no effect — it elevates an existing account, never creates one. |
enable_cloudsql_volume | Verify TLS during first live deploy | High | The Cloud Run backend sidecar always receives the raw Cloud SQL private IP (not the socket) — confirm the backend's Postgres client connects successfully. |
disable_signup | true after first admin | Medium | Leaving signup open lets anyone with the URL create an account. |
smtp_enabled | Set ALL smtp_* fields together | Medium | A partially-configured SMTP block can leave password-reset email non-functional. |
For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_CloudRun. SparkyFitness-specific application configuration shared with the GKE variant is described in SparkyFitness_Common.
