Grocy on Google Cloud Run

Grocy on Google Cloud Run

Grocy is a self-hosted grocery and household ERP: inventory tracking with barcode scanning, chore/task management, shopping lists, and meal planning. It is distinct from this catalogue's Mealie module, which covers recipe/meal-planning only — Grocy is the broader household-ERP tool. This module deploys Grocy on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure; Grocy_CloudRun is a thin wrapper that supplies Grocy's own configuration (image, port, probes, storage wiring) and forwards everything else straight through.

This guide focuses on the cloud services Grocy uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.

1. Overview​

Grocy runs as an nginx + php-fpm container (the upstream LinuxServer.io grocy image, unmodified) on Cloud Run v2. The deployment wires together a focused set of Google Cloud services:

CapabilityGoogle Cloud serviceNotes
ComputeCloud Run v21 vCPU / 1 GiB by default, min=max=1 (no autoscaling — single-writer SQLite)
DatabaseNoneGrocy uses an embedded SQLite database — no Cloud SQL instance is created
Persistent stateCloud Filestore (NFS)/config (SQLite database, config, uploads, backups) is mounted over NFS, not GCS FUSE — see §4
Object storageCloud StorageA storage bucket is provisioned but unused by default (see §4)
SecretsSecret ManagerNone generated for Grocy — no injectable admin credential exists
IngressCloud Run URL / Cloud Load BalancingDefault run.app URL; optional external HTTPS load balancer + custom domain

Sensible defaults worth knowing up front:

  • SQLite is the only database Grocy supports. Confirmed by reading Grocy's own upstream source (services/DatabaseService.php) — there is no MySQL/Postgres driver branching at all. database_type is fixed to NONE.
  • /config is persisted over NFS, not GCS FUSE — a deliberate fix, not the catalogue's usual default. Grocy writes to data/grocy.db-journal every 1–2 seconds; GCS FUSE's object-storage translation layer cannot sustain that write pattern. A GCS-FUSE-backed /config crash-looped in production (confirmed live over 12 boot cycles / 20+ minutes — repeated BufferedWriteHandler.OutOfOrderError, HTTP 429 rate-limiting, stale-file-handle errors). Grocy_CloudRun instead sets enable_nfs = true, nfs_mount_path = "/config". See §4 for the full story.
  • This is a genuinely different bug class than UptimeKuma's SQLite-on-NFS incident. UptimeKuma's problem was WAL-mode lock incompatibility. Grocy never enables WAL mode at all (no journal_mode PRAGMA anywhere in its source) — its problem is write frequency, not lock semantics. Together they show "gcsfuse breaks SQLite" is a broader lesson than just WAL locking.
  • Single instance only. min_instance_count = 1, max_instance_count = 1. Grocy's SQLite database is single-writer with no clustering support — running multiple replicas against the same volume is unsafe.
  • No injectable admin credential. The upstream image ships default admin / admin credentials, changed via the web UI on first login. No Secret Manager secret is created for Grocy.
  • Health probes hit /, not /health. Grocy has no dedicated health endpoint; the login page (200, unauthenticated) is used for both startup and liveness probes.

2. Google Cloud Services & How to Explore Them​

All commands assume PROJECT and REGION are set. Service and resource names are reported in the deployment Outputs.

A. Cloud Run — the Grocy service​

Grocy runs as a single-instance Cloud Run v2 service. Each deployment creates an immutable revision; traffic can be split across revisions for safe rollouts.

  • Console: Cloud Run → select the service for revisions, traffic, logs, and metrics.
  • CLI:
    gcloud run services list --project "$PROJECT" --region "$REGION"
    gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
    gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"

See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.

B. Cloud Filestore (NFS) — the /config volume​

All of Grocy's state — the embedded SQLite database (grocy.db), config.php, uploaded images/attachments, and backups — lives under /config, mounted over a Cloud Filestore (NFS) instance rather than GCS FUSE. This is the load-bearing storage decision for this module (see §4); losing or misconfiguring this mount loses all Grocy data.

  • Console: Filestore → Instances.
  • CLI:
    gcloud filestore instances list --project "$PROJECT" --zone "$REGION-a"
    gcloud filestore instances describe <instance-name> --project "$PROJECT" --zone "$REGION-a"

See App_CloudRun for NFS auto-discovery and provisioning behaviour.

C. Cloud Storage​

A dedicated Cloud Storage storage bucket is provisioned automatically, but by default it is not used to back /config — that mount goes through NFS instead (see §4). It remains available for any custom gcs_volumes an operator adds.

  • Console: Cloud Storage → Buckets.
  • CLI:
    gcloud storage buckets list --project "$PROJECT"

See App_CloudRun for GCS Fuse and CMEK options.

D. Networking & ingress​

The service is reachable at its run.app URL by default. An external HTTPS load balancer with a custom domain, Cloud CDN, and Cloud Armor can be layered on; ingress settings and VPC egress control connectivity.

  • Console: Cloud Run (service URL); Network services → Load balancing.
  • CLI:
    gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'
    gcloud compute addresses list --project "$PROJECT"

See App_CloudRun.

E. Cloud Logging & Monitoring​

Container logs flow to Cloud Logging; Cloud Run metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.

  • Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
  • CLI:
    gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50

3. Grocy Application Behaviour​

  • No first-deploy database setup. Grocy has no external database and no db-init job — it creates and migrates its own embedded SQLite schema under /config on first boot.
  • /config durability depends on the NFS mount, not a managed database. Because Grocy's entire state (database, config, uploads, backups) lives in files on /config, the correctness of the NFS mount is the correctness of the deployment. Confirm the mount is healthy before trusting any data written to it.
  • No admin credential is generated or injectable. The upstream image ships default admin / admin credentials. Log in with those on first access and change the password immediately via Users → admin → Edit in the Grocy UI — there is no environment variable or Secret Manager value that sets this for you.
  • Health path. Both the startup and liveness probes issue HTTP GET /, which returns Grocy's login page (200) with no authentication required. This is not a dedicated health endpoint — Grocy has none — but it reliably indicates the nginx + php-fpm stack is serving.
  • Single-writer constraint is architectural, not a scaling knob. Because Grocy's SQLite database has no MySQL/Postgres equivalent and no clustering support, max_instance_count must stay at 1. There is no configuration that safely enables horizontal scaling for this module.
  • Verified live. https://grocycr31ffe08b-kj6qcu2rxa-uc.a.run.app — 16 curl samples over ~5 minutes against a single stable revision (grocycr31ffe08b-00003-h4w), consistently serving <title>Login | Grocy</title>, with zero corruption-signature log entries (OutOfOrderError / 429 / stale file / database is locked / disk I/O error all absent) after the NFS fix described in §4.

4. Why /config Uses NFS Instead of GCS FUSE — the Real Story​

This module's persistent-storage wiring is not this catalogue's usual default, and the reason is worth understanding before changing it.

Grocy writes to data/grocy.db-journal on every database transaction — confirmed live, roughly every 1–2 seconds under light use. GCS FUSE's object-storage translation layer is built around eventual-consistency, whole-object semantics; it does not sustain that kind of high-frequency small-write pattern. Grocy_CloudRun originally mounted /config on a GCS-FUSE-backed bucket — this catalogue's usual pattern for persistent app config — and it crash-looped in production. Confirmed live over 12 full boot cycles across 20+ minutes, with real HTTP checks never once returning a working page:

  • Repeated BufferedWriteHandler.OutOfOrderError
  • HTTP 429 rate-limiting responses from GCS
  • Stale-file-handle errors
  • A permanent crash-restart loop

The fix: switch /config from GCS FUSE to the Foundation's native NFS volume support — enable_nfs = true, nfs_mount_path = "/config" — with Grocy_Common's own enable_gcs_storage_volume set to false to avoid a double-mount at the same path. NFS implements real POSIX file semantics (rename/fsync/advisory locks) that GCS FUSE's translation layer does not, and it sustains Grocy's write pattern without issue.

Why this is a genuinely different bug from the catalogue's other SQLite-on-shared- storage incident (UptimeKuma): UptimeKuma's problem was WAL-mode lock incompatibility with NFS. Grocy never enables WAL mode at all — there is no journal_mode PRAGMA anywhere in its source (confirmed against upstream DatabaseService.php); it uses SQLite's default DELETE/rollback-journal mode. So Grocy's failure on GCS FUSE had nothing to do with locking — it was purely a write-frequency problem that GCS FUSE's object-storage semantics cannot absorb. Read together, the general lesson broadens: gcsfuse can break an embedded SQLite database for more than one reason — not only WAL-mode locking, but also high-frequency write patterns in general, independent of journal mode.

A secondary, unrelated bug was fixed in passing during this module's build: a stray container_image_source = "prebuilt" override in deploy.tfvars silently bypassed the custom Dockerfile build entirely — the same footgun class already documented in this catalogue for UptimeKuma.

The GKE variant takes a different approach to the same underlying problem. Grocy_GKE is scaffolded but has not yet been deployed or verified. Its planned fix is a StatefulSet block PVC at /config — real block storage, not a network filesystem at all — matching this catalogue's general pattern for GKE variants of SQLite-heavy apps (e.g. CalibreWeb_GKE). This guide will be updated once that variant is deployed and verified.

5. Configuration Variables​

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Grocy are listed; every other input is inherited from App_CloudRun with its standard behaviour.

Group 3 — Application Identity​

VariableDefaultDescription
application_namegrocyBase name for resources. Do not change after first deploy.
application_display_nameGrocyHuman-readable name shown in the Console.
application_versionlatestLinuxServer image tag. "latest" resolves to the pinned v4.6.0-ls333 (the GROCY_VERSION build ARG, not the generic APP_VERSION).

Group 4 — Runtime & Scaling​

VariableDefaultDescription
cpu_limit / memory_limit1000m / 1GiGrocy is lightweight; the memory default gives headroom for image/attachment uploads.
min_instance_count1Keeps the instance warm — avoids cold starts.
max_instance_count1Must stay at 1. Grocy's SQLite database is single-writer with no clustering support.
container_port80Grocy's default HTTP port.
container_protocolhttp1Grocy serves plain HTTP/1.1; h2c is not required.
execution_environmentgen2Required for the NFS mount.
enable_cloudsql_volumefalseGrocy has no Cloud SQL — keep false.

Group 6 — Environment Variables & Secrets​

VariableDefaultDescription
environment_variables{}Merged with Grocy_Common's defaults: PUID=1000, PGID=1000, TZ=Etc/UTC.
secret_environment_variables{}No default secrets exist for Grocy — this map is purely operator-supplied.

Group 11 — Cloud Storage & Filesystem​

VariableDefaultDescription
enable_nfstrueDefaults to true for this module — required so /config can sustain Grocy's SQLite write pattern (see §4). Do not disable unless replacing it with an equally durable, POSIX-correct mount.
nfs_mount_path/configGrocy keeps all state (database, config, uploads, backups) here. Do not change unless the upstream image's data path changes.
create_cloud_storagetrueThe storage bucket is still created (unused for /config by default; available for custom gcs_volumes).

Group 12 — Database Backend​

VariableDefaultDescription
database_typeNONEFixed — Grocy has no SQL database of any kind.

Group 13 — Jobs & Scheduled Tasks​

VariableDefaultDescription
initialization_jobs[]No default init job — Grocy bootstraps its own SQLite schema on first boot.

Group 14 — Observability & Health​

VariableDefaultDescription
startup_probeHTTP / , 15s delay, 10 retriesGrocy's login page — no dedicated health endpoint exists.
liveness_probeHTTP / , 30s delay, 3 retriesSame endpoint as the startup probe.

All other inputs are inherited from App_CloudRun with standard behaviour.

6. Outputs​

OutputDescription
service_nameCloud Run service name.
grocy_urlURL for the Grocy UI (port 80). Only reachable within the VPC when ingress_settings = "internal".
service_locationRegion the service runs in.
stage_servicesStage-specific service details (Cloud Deploy).
load_balancer_ip / load_balancer_urlExternal HTTPS load balancer IP / URL (when enabled).
storage_bucketsCreated Cloud Storage buckets (the storage bucket, unused for /config by default).
network_name / network_exists / regionsVPC network, presence, regions.
container_image / container_registryDeployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels / uptime_check_namesMonitoring status, channels, uptime checks.
deployment_id / tenant_id / resource_prefixNaming identifiers.
project_id / project_numberProject identifiers.
initialization_jobsCreated initialization job names (empty by default).
cicd_enabled / github_repository_url / github_repository_owner / github_repository_name / cicd_configurationCI/CD status and details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_idRegistry and build trigger.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_modeVPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabledAudit logging and CMEK status.

7. Configuration Pitfalls & Sensible Defaults​

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_CloudRun foundation engine, which validates values and combinations at plan time. Most out-of-range or contradictory inputs are caught before any resource is created.

SettingSensible valueRiskConsequence if wrong
enable_nfstrueCriticalDisabling it without an equally durable POSIX mount reverts /config to GCS FUSE (or an ephemeral in-container path), reproducing the confirmed crash-restart loop (BufferedWriteHandler.OutOfOrderError, 429s, stale-file-handle errors) — or silently losing all state on every restart.
nfs_mount_path/configCriticalGrocy hardcodes its data path to /config. Changing the mount path without a matching image change loses access to the database, config, and uploads.
max_instance_count1CriticalGrocy's SQLite database is single-writer with no clustering support. Any value above 1 risks concurrent writers corrupting the database.
container_image_sourcecustom (the module default)HighA stray "prebuilt" override silently bypasses the custom Dockerfile build (already hit once during this module's build, and documented for UptimeKuma) — Cloud Run then points at an unbuilt Artifact Registry path.
database_typeNONEMediumGrocy ignores this entirely (no code path reads it), but setting anything else provisions an unused, billed Cloud SQL instance.
Admin passwordChange on first loginHighThe upstream image's default admin / admin credentials are publicly documented; leaving them unchanged on a public ingress_settings = "all" deployment is a real exposure.
min_instance_count1LowSetting 0 saves cost but reintroduces cold starts on Grocy's nginx + php-fpm stack.

For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_CloudRun. Grocy-specific application configuration is described in Grocy_Common.
