LubeLogger on Google Cloud Run
LubeLogger is a free, open-source vehicle maintenance and fuel-mileage tracker built on ASP.NET Core (.NET), shipped as a single container image with an embedded LiteDB database. This module deploys LubeLogger on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure.
This guide focuses on the cloud services LubeLogger uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.
1. Overview
LubeLogger runs as an ASP.NET Core container on Cloud Run v2. The deployment wires together a minimal set of Google Cloud services — there is no managed database in the default configuration:
| Capability | Google Cloud service | Notes |
|---|---|---|
| Compute | Cloud Run v2 | ASP.NET Core service, 1 vCPU / 1 GiB by default, serverless autoscaling; fixed at a single instance |
| Database | None (default) | LubeLogger's default mode uses an internal embedded LiteDB database file — no Cloud SQL instance is created |
| Object storage | Cloud Storage | Two buckets: storage (LiteDB database file + uploaded photos/receipts/documents) and dpkeys (ASP.NET Core Data Protection keys) |
| Cache & queue | None | LubeLogger has no Redis usage and no background worker/queue |
| Secrets | None | No secrets are generated — the first account is created via self-service registration |
| Ingress | Cloud Run URL / Cloud Load Balancing | Default run.app URL (ingress_settings = "all"); optional external HTTPS load balancer + custom domain |
Sensible defaults worth knowing up front:
- No external database by default.
database_type = "NONE"— LubeLogger's own embedded LiteDB database file is the source of truth, persisted via a GCS FUSE volume. LubeLogger also supports an optional external Postgres backend via a singlePOSTGRES_CONNECTIONDSN environment variable, but this module does not wire Cloud SQL for it. - Single instance only.
min_instance_count = 1andmax_instance_count = 1— LubeLogger's default mode serves one shared database file from one volume; running multiple instances against the same file corrupts it. - Secure by default.
EnableAuth = "true"overrides LubeLogger's ownappsettings.jsondefault of fully open access. There is no seeded admin account — the first person to complete the Register form on/Logingains access. - Persistent Data Protection keys. A dedicated small
dpkeysbucket is always mounted at/root/.aspnet/DataProtection-Keysso login sessions survive container restarts; this is separate from the mainstoragebucket. - Prebuilt image, no build step. The module deploys the official
ghcr.io/hargata/lubeloggerimage directly (mirrored into Artifact Registry by default) — there is no Dockerfile or Cloud Build involved. - Health probes use
/Login, not/— the app root is[Authorize]-gated and would fail an unauthenticated platform probe even on a healthy container.
2. Google Cloud Services & How to Explore Them
All commands assume PROJECT and REGION are set. Service and resource names are
reported in the deployment Outputs.
A. Cloud Run — the LubeLogger service
LubeLogger runs as a single Cloud Run v2 service (fixed at one instance). Each deployment creates an immutable revision; traffic can be split across revisions for safe rollouts.
- Console: Cloud Run → select the service for revisions, traffic, logs, and metrics.
- CLI:
gcloud run services list --project "$PROJECT" --region "$REGION"
gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"
See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.
B. Cloud Storage
Two dedicated Cloud Storage buckets are provisioned automatically:
storage— mounted at/App/datavia GCS FUSE; holds the embedded LiteDB database file and uploaded photos/receipts/documents.dpkeys— mounted at/root/.aspnet/DataProtection-Keys; holds ASP.NET Core's cookie/session signing keys.
gcloud storage buckets list --project "$PROJECT" --filter="name~lubelogger"
gcloud storage ls gs://<storage-bucket>/ # bucket names are in the Outputs
See App_CloudRun for GCS Fuse and CMEK options.
C. Networking & ingress
The service is reachable at its run.app URL by default (ingress_settings = "all").
An external HTTPS load balancer with a custom domain, Cloud CDN, and Cloud Armor can
be layered on.
- Console: Cloud Run (service URL); Network services → Load balancing.
- CLI:
gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'
gcloud compute addresses list --project "$PROJECT"
See App_CloudRun.
D. Cloud Logging & Monitoring
Container logs flow to Cloud Logging; Cloud Run metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.
- Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
- CLI:
gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50
3. LubeLogger Application Behaviour
- No first-deploy database setup. There is no
db-initjob — LubeLogger initialises its own LiteDB database file and directory structure (config/,documents/,images/,temp/,themes/,translations/under/App/data) on first boot. - No fixed admin credential. Open the service, go to
/Login, and submit the Register form — that becomes the usable account. Complete this immediately after first deploy:EnableAuth = "true"restricts the rest of the app, but registration itself is open to anyone who can reach the URL until a first account exists. - Health path. Startup and liveness probes target
/Login— LubeLogger's public, unauthenticated page. The app root/is[Authorize]-gated and would 401/redirect an unauthenticated probe even on a healthy container. - Optional external Postgres. LubeLogger supports a single
POSTGRES_CONNECTIONDSN environment variable (Host=<host>;Port=5432;Username=<user>;Password=<pass>;Database=<db>;) to use an external Postgres database instead of the embedded LiteDB file. This module does not provision Cloud SQL for this path — an operator supplying their own Postgres instance can set the variable viasecret_environment_variables. - Single instance, always.
max_instance_countis fixed at1— LubeLogger's default mode has no distributed-locking or multi-writer support for its embedded database. - Inspect the running revision:
gcloud run services describe <service-name> \
--region "$REGION" --project "$PROJECT" \
--format='value(status.url)'
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for LubeLogger are listed; every other input is inherited from App_CloudRun with its standard behaviour.
Group 1 — Project & Identity
| Variable | Default | Description |
|---|---|---|
project_id | (required) | Target Google Cloud project. |
region | us-central1 | Region for the service and regional resources. |
Group 2 — Deployment Environment
| Variable | Default | Description |
|---|---|---|
tenant_deployment_id | demo | Short suffix that makes resource names unique per environment. |
support_users | [] | Emails granted project access and monitoring alerts. |
resource_labels | {} | Labels applied to all resources. |
Group 3 — Application Identity
| Variable | Default | Description |
|---|---|---|
application_name | lubelogger | Base name for resources. Do not change after first deploy. |
application_display_name | LubeLogger | Human-readable name shown in the Console. |
description | (set) | Service description. |
application_version | latest | Image tag on ghcr.io/hargata/lubelogger. Since the image is prebuilt (not custom-built), this directly selects the released version. |
Group 4 — Runtime & Scaling
| Variable | Default | Description |
|---|---|---|
deploy_application | true | Set false to provision infrastructure only. |
cpu_limit | 1000m | CPU per instance. |
memory_limit | 1Gi | Memory per instance. |
min_instance_count | 1 | Kept at 1 to avoid cold starts. |
max_instance_count | 1 | Must stay at 1 — LubeLogger's default mode serves one shared database file. |
container_port | 8080 | LubeLogger listens on port 8080. |
execution_environment | gen2 | Gen2 required for GCS Fuse mounts. |
timeout_seconds | 300 | Maximum request duration (0–3600 seconds). |
enable_cloudsql_volume | false | LubeLogger's default mode has no Cloud SQL. |
enable_image_mirroring | true | Mirror the LubeLogger image into Artifact Registry. |
traffic_split | [] | Split traffic across revisions for staged rollouts. |
max_revisions_to_retain | 7 | Declared for convention parity; not referenced by this module's deployment. |
Group 5 — Access & Ingress Control
| Variable | Default | Description |
|---|---|---|
ingress_settings | all | Public access — LubeLogger is a user-facing web app. |
vpc_egress_setting | PRIVATE_RANGES_ONLY | Route only RFC 1918 traffic via VPC. |
enable_iap | false | Require Google sign-in. |
iap_authorized_users / iap_authorized_groups | [] | Who may access through IAP. |
Group 6 — Environment Variables & Secrets
| Variable | Default | Description |
|---|---|---|
environment_variables | {} | Extra non-secret settings, merged with the module's default EnableAuth = "true". |
secret_environment_variables | {} | Map of env var → Secret Manager secret name. Use this for POSTGRES_CONNECTION if wiring the optional external Postgres backend. |
secret_propagation_delay | 30 | Seconds to wait after secret creation before proceeding. |
secret_rotation_period | 2592000s | Secret Manager rotation notification frequency. |
Group 7 — Backup & Restore
| Variable | Default | Description |
|---|---|---|
backup_schedule | 0 2 * * * | Automated backup cron (UTC). |
backup_retention_days | 7 | Retention; raise for production/compliance. |
enable_backup_import / backup_source / backup_uri / backup_format | restore options | Restore from a backup on deploy. |
Group 8 — CI/CD & Binary Authorization
Standard App_CloudRun Cloud Build / Cloud Deploy integration — see
App_CloudRun. Key inputs: enable_cicd_trigger,
github_repository_url, github_token, enable_cloud_deploy,
enable_binary_authorization.
Group 10 — Storage & Filesystem
| Variable | Default | Description |
|---|---|---|
create_cloud_storage | true | Create GCS buckets defined in storage_buckets. |
storage_buckets | [] | Additional GCS buckets beyond the auto-provisioned storage/dpkeys buckets. |
enable_nfs | false | Not used by LubeLogger by default. |
gcs_volumes | [] | Additional GCS Fuse volume mounts (requires gen2). |
manage_storage_kms_iam / enable_artifact_registry_cmek | false | CMEK options. |
Group 12 — Database Backend
| Variable | Default | Description |
|---|---|---|
database_type | NONE | Fixed — LubeLogger's default mode has no Cloud SQL database. |
database_password_length | 32 | Not referenced in the default configuration. |
Group 13 — Jobs & Scheduled Tasks
| Variable | Default | Description |
|---|---|---|
initialization_jobs | [] | LubeLogger's default mode needs no init job. |
cron_jobs | [] | No platform-scheduled recurring tasks by default. |
Group 14 — Observability & Health
| Variable | Default | Description |
|---|---|---|
startup_probe | HTTP /Login 15s delay | Startup probe. |
liveness_probe | HTTP /Login 30s delay | Liveness probe. |
startup_probe_config | HTTP /Login | Alternative structured probe. |
health_check_config | HTTP /Login | Alternative structured liveness probe. |
uptime_check_config | { enabled=false, path="/Login" } | Cloud Monitoring uptime check; disabled by default. |
alert_policies | [] | Metric alert policies. |
Group 23 — VPC Service Controls & Audit Logging
| Variable | Default | Description |
|---|---|---|
enable_vpc_sc | false | Enforce a VPC-SC perimeter (requires organization_id). |
vpc_cidr_ranges / vpc_sc_dry_run | (set) | Access level CIDRs / dry-run mode. |
enable_audit_logging | false | Detailed Cloud Audit Logs. |
5. Outputs
Returned on a successful deployment — the quickest way to locate and explore the running resources.
| Output | Description |
|---|---|
service_name | Cloud Run service name. |
lubelogger_url | Internal VPC URL for the LubeLogger web UI. |
service_location | Region the service runs in. |
stage_services | Stage-specific service URLs (Cloud Deploy). |
load_balancer_ip / load_balancer_url | External HTTPS load balancer IP / URL (when enabled). |
storage_buckets | Created Cloud Storage buckets (storage, dpkeys). |
network_name / network_exists / regions | VPC network, presence, regions. |
container_image / container_registry | Deployed image and Artifact Registry repo. |
monitoring_enabled / monitoring_notification_channels / uptime_check_names | Monitoring status, channels, uptime checks. |
deployment_id / tenant_id / resource_prefix | Naming identifiers. |
project_id / project_number | Project identifiers. |
cicd_enabled / github_repository_url / github_repository_owner / github_repository_name / cicd_configuration | CI/CD status and details. |
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id | Registry and build trigger. |
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode | VPC-SC status. |
audit_logging_enabled / artifact_registry_cmek_enabled | Audit logging and CMEK status. |
6. Configuration Pitfalls & Sensible Defaults
Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).
Inherited plan-time validation. This module passes its configuration through the App_CloudRun foundation engine, which validates values and combinations at plan time. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.
| Setting | Sensible value | Risk | Consequence if wrong |
|---|---|---|---|
max_instance_count | 1 | Critical | LubeLogger's default mode serves one shared embedded database file from one volume; more than one instance risks database corruption from concurrent writers. |
storage/dpkeys buckets | Never delete | Critical | Losing storage loses every vehicle record; losing dpkeys invalidates all existing login sessions (recoverable — forces re-login only). |
EnableAuth | true (default) | Critical | Setting it to false reverts to LubeLogger's fully open-access mode — anyone with the URL can view/edit all data with no login at all. |
| First-run registration | Complete immediately after deploy | High | Until a first account is registered, the Register form is reachable by anyone who can reach the URL. |
startup_probe/liveness_probe path | /Login | Critical | Pointing probes at / (or any [Authorize]-gated path) fails the probe on an otherwise-healthy container — the revision never becomes Ready. |
database_type | NONE (default) | High | LubeLogger's default mode ignores this setting entirely; changing it does not connect LubeLogger to a Cloud SQL instance — use POSTGRES_CONNECTION instead for the optional external Postgres path. |
min_instance_count | 1 | Medium | Setting to 0 allows cold starts; since max_instance_count is fixed at 1 there is no traffic-splitting risk, only added latency on the first request after idle. |
backup_retention_days | 7 (raise for prod) | Medium | Too short for compliance retention. |
enable_cloud_armor | enable for production | Medium | The public web UI and REST API are reachable without WAF protection otherwise. |
For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_CloudRun. LubeLogger-specific application configuration shared with the GKE variant is described in LubeLogger_Common.
