LubeLogger on GKE Autopilot
LubeLogger is a free, open-source vehicle maintenance and fuel-mileage tracker built
on ASP.NET Core (.NET), shipped as a single container image with an embedded LiteDB
database. This module deploys LubeLogger on GKE Autopilot on top of the
App_GKE foundation, which provisions and manages the shared Google
Cloud and Kubernetes infrastructure.
This guide focuses on the cloud services LubeLogger uses and how to explore and
operate them from the Google Cloud Console and the command line. For the mechanics
that are common to every GKE application — Workload Identity, ingress, autoscaling,
CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and
the deployment lifecycle — refer to the App_GKE foundation guide
rather than repeating them here.
1. Overview
LubeLogger runs as a single ASP.NET Core pod, recommended as a StatefulSet with a
real block-storage PVC. The deployment wires together a minimal set of Google Cloud
services — there is no managed database in the default configuration:
| Capability | Google Cloud service | Notes |
|---|
| Compute | GKE Autopilot | ASP.NET Core pod, 1 vCPU / 1 GiB by default, fixed at a single replica |
| Database | None (default) | LubeLogger's default mode uses an internal embedded LiteDB database file — no Cloud SQL instance is created |
| Object storage / block storage | Cloud Storage + Persistent Disk | A block PVC (recommended, stateful_pvc_enabled = true) at /App/data, plus a small dpkeys GCS bucket for ASP.NET Core Data Protection keys (always GCS-backed) |
| Cache & queue | None | LubeLogger has no Redis usage and no background worker/queue |
| Secrets | None | No secrets are generated — the first account is created via self-service registration |
| Ingress | Cloud Load Balancing | External LoadBalancer by default; optional custom domain + managed certificate |
Sensible defaults worth knowing up front:
- No external database by default.
database_type = "NONE" — LubeLogger's own
embedded LiteDB database file is the source of truth. LubeLogger also supports an
optional external Postgres backend via a single POSTGRES_CONNECTION DSN
environment variable, but this module does not wire Cloud SQL for it.
- Block-storage PVC is the recommended layout.
stateful_pvc_enabled = true
(default) runs LubeLogger as a StatefulSet with a per-pod PVC mounted at
/App/data — a real block device gives reliable file locking for the embedded
LiteDB database, unlike GCS FUSE.
- Single instance only.
min_instance_count = 1 and max_instance_count = 1 —
LubeLogger's default mode serves one shared database file from one volume; running
multiple replicas against the same file corrupts it.
- Runs as root; no fsGroup needed. Confirmed directly against the running
image — LubeLogger's official image has no
USER directive, so
stateful_fs_group defaults to 0 (unset).
- Secure by default.
EnableAuth = "true" overrides LubeLogger's own
appsettings.json default of fully open access. There is no seeded admin account —
the first person to complete the Register form on /Login gains access.
- Prebuilt image, no build step. The module deploys the official
ghcr.io/hargata/lubelogger image directly (mirrored into Artifact Registry by
default) — there is no Dockerfile or Cloud Build involved.
- Externally reachable by default.
service_type = "LoadBalancer" — LubeLogger is
a public-facing web application, not an internal-only workload.
2. Google Cloud Services & How to Explore Them
All commands assume you have run
gcloud container clusters get-credentials <cluster> --region <region> --project <project>
and that PROJECT, REGION, and NAMESPACE are set. The namespace and other
identifiers are reported in the deployment Outputs.
A. GKE Autopilot — the LubeLogger workload
LubeLogger runs as a single pod (StatefulSet by default), which Autopilot bills for
based on requested CPU/memory.
- Console: Kubernetes Engine → Workloads → select the LubeLogger workload to see
the pod, revisions, and events. Kubernetes Engine → Services & Ingress shows the
external IP.
- CLI:
kubectl get pods,svc -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" statefulset/<service-name> --tail=100
See App_GKE for how Autopilot, scaling, and the workload
type (Deployment vs StatefulSet) are managed.
B. Persistent storage — block PVC and Cloud Storage
The default layout (stateful_pvc_enabled = true) provisions a per-pod
Persistent Disk-backed PVC mounted at /App/data — this holds the embedded
LiteDB database file and uploaded photos/receipts/documents. A separate, small
Cloud Storage bucket (dpkeys) is always mounted via GCS FUSE at the fixed path
/root/.aspnet/DataProtection-Keys, independent of the PVC.
- Console: Kubernetes Engine → Storage (PVCs); Cloud Storage → Buckets.
- CLI:
kubectl get pvc -n "$NAMESPACE"
gcloud storage buckets list --project "$PROJECT" --filter="name~lubelogger"
See App_GKE for StorageClass, CMEK, and GCS Fuse mount options.
C. Networking & ingress
By default the workload is exposed through an external Cloud Load Balancing IP.
A custom domain with a Google-managed certificate can be enabled, and a static IP
can be reserved so the address survives redeploys.
- Console: Network services → Load balancing; VPC network → IP addresses.
- CLI:
kubectl get ingress,svc -n "$NAMESPACE"
gcloud compute addresses list --project "$PROJECT"
See App_GKE for custom domains, Cloud CDN, and static IP details.
D. Cloud Logging & Monitoring
Pod stdout/stderr flow to Cloud Logging; GKE metrics flow to Cloud Monitoring.
Optional uptime checks and alert policies are available.
- Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
- CLI:
gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
--project "$PROJECT" --limit 50
3. LubeLogger Application Behaviour
- No first-deploy database setup. There is no
db-init job — LubeLogger
initialises its own LiteDB database file and directory structure (config/,
documents/, images/, temp/, themes/, translations/ under /App/data) on
first boot.
- No fixed admin credential. Open the service, go to
/Login, and submit the
Register form — that becomes the usable account. Complete this immediately
after first deploy: EnableAuth = "true" restricts the rest of the app, but
registration itself is open to anyone who can reach the URL until a first account
exists.
- Health path. Startup and liveness probes target
/Login — LubeLogger's public,
unauthenticated page. The app root / is [Authorize]-gated and would fail an
unauthenticated probe even on a healthy container.
- Optional external Postgres. LubeLogger supports a single
POSTGRES_CONNECTION
DSN environment variable (Host=<host>;Port=5432;Username=<user>;Password=<pass>;Database=<db>;)
to use an external Postgres database instead of the embedded LiteDB file. This
module does not provision Cloud SQL for this path.
- Single instance, always.
max_instance_count is fixed at 1 — LubeLogger's
default mode has no distributed-locking or multi-writer support for its embedded
database.
- Runs as root. Confirmed via
docker inspect/docker exec against the actual
image — no USER directive, process runs as uid 0. Relevant if you ever add
a restricted securityContext — the default configuration needs none.
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only
settings specific to or notable for LubeLogger are listed; every other input is
inherited from App_GKE with its standard behaviour and defaults.
Group 1 — Project & Identity
| Variable | Default | Description |
|---|
project_id | (required) | Target Google Cloud project. |
region | us-central1 | Region for the workload and regional resources. |
Group 2 — Deployment Environment
| Variable | Default | Description |
|---|
tenant_deployment_id | demo | Short suffix that makes resource names unique per environment. |
support_users | [] | Emails granted project access and monitoring alerts. |
resource_labels | {} | Labels applied to all resources for cost/ownership tracking. |
Group 3 — Application Identity
| Variable | Default | Description |
|---|
application_name | lubelogger | Base name for resources. Do not change after first deploy. |
application_version | latest | Image tag on ghcr.io/hargata/lubelogger. Since the image is prebuilt (not custom-built), this directly selects the released version. |
Group 4 — Runtime & Scaling
| Variable | Default | Description |
|---|
deploy_application | true | Set false to provision infrastructure only. |
min_instance_count | 1 | Kept at 1 to avoid cold starts. |
max_instance_count | 1 | Must stay at 1 — LubeLogger's default mode serves one shared database file. |
cpu_limit | 1000m | CPU per pod. |
memory_limit | 1Gi | Memory per pod. |
timeout_seconds | 300 | Maximum request duration (0–3600 seconds). |
enable_cloudsql_volume | false | LubeLogger's default mode has no Cloud SQL. |
enable_image_mirroring | true | Mirror the LubeLogger image into Artifact Registry before deployment. |
Group 5 — Environment Variables & Secrets
| Variable | Default | Description |
|---|
environment_variables | {} | Extra non-secret settings, merged with the module's default EnableAuth = "true". |
secret_environment_variables | {} | Map of env var → Secret Manager secret name. Use this for POSTGRES_CONNECTION if wiring the optional external Postgres backend. |
secret_propagation_delay | 30 | Seconds to wait after secret creation before proceeding. |
secret_rotation_period | 2592000s | Secret Manager rotation notification frequency. |
Group 6 — GKE Backend & Cluster
| Variable | Default | Description |
|---|
service_type | LoadBalancer | LubeLogger is a public-facing web application, so it defaults to external access. |
workload_type | null (auto → StatefulSet) | Auto-resolves to StatefulSet when stateful_pvc_enabled = true. |
session_affinity | None | No sticky routing needed — single replica. |
network_tags | ["nfsserver"] | Node/pod network tags; only relevant if enable_nfs = true. |
termination_grace_period_seconds | 60 | Seconds to wait after SIGTERM before SIGKILL (lets LubeLogger flush writes). |
enable_network_segmentation | false | Create Kubernetes NetworkPolicy resources. |
Group 7 — StatefulSet
| Variable | Default | Description |
|---|
stateful_pvc_enabled | true | Recommended for LubeLogger — a real block PVC gives reliable file locking for the embedded LiteDB database. |
stateful_pvc_size | 20Gi | Per-pod PVC storage size — sized for the LiteDB database, uploaded documents/receipts, and overhead. |
stateful_pvc_mount_path | /App/data | Container mount path for the PVC — must match LubeLogger's data directory. |
stateful_pvc_storage_class | standard-rwo | Kubernetes StorageClass for PVCs; use premium-rwo for higher IOPS. |
stateful_headless_service | null | Create a headless Service for stable pod DNS names. |
stateful_pod_management_policy | null | Pod creation order: OrderedReady or Parallel. |
stateful_update_strategy | null | Update strategy: RollingUpdate or OnDelete. |
stateful_fs_group | 0 | Left unset — LubeLogger's official image runs as root and needs no fsGroup to write to the PVC. |
Group 8 — Resource Quota
| Variable | Default | Description |
|---|
enable_resource_quota | false | Create a Kubernetes ResourceQuota in the application namespace. |
quota_memory_requests / quota_memory_limits | "" | Requires a binary suffix (e.g. 4Gi, 8192Mi) per convention when set. |
Group 9 — Reliability Policies
| Variable | Default | Description |
|---|
enable_pod_disruption_budget | true | Protect availability during node upgrades. |
pdb_min_available | 1 | Minimum pods available during voluntary disruptions. |
Group 10 — Observability & Health
| Variable | Default | Description |
|---|
startup_probe | HTTP /Login 15s delay | Startup probe. |
liveness_probe | HTTP /Login 30s delay | Liveness probe. |
startup_probe_config | HTTP /Login | App_GKE-level infrastructure probe. |
health_check_config | HTTP /Login | App_GKE-level liveness probe. |
uptime_check_config | disabled | Optional Cloud Monitoring uptime check. |
alert_policies | [] | Optional metric alert policies. |
Group 11 — Jobs & Scheduled Tasks
| Variable | Default | Description |
|---|
initialization_jobs | [] | LubeLogger's default mode needs no init job. |
cron_jobs | [] | No platform-scheduled recurring tasks by default. |
additional_services | [] | Sidecar or helper services deployed alongside LubeLogger. |
Group 12 — CI/CD & GitHub Integration
Standard App_GKE Cloud Build / Cloud Deploy integration — see
App_GKE. Key inputs: enable_cicd_trigger,
github_repository_url, github_token, enable_cloud_deploy.
Group 14 — Cloud Storage & Artifact Registry
| Variable | Default | Description |
|---|
create_cloud_storage | true | Create the storage and dpkeys GCS buckets. |
storage_buckets | [] | Additional buckets to provision. |
gcs_volumes | [] | Additional GCS Fuse volume mounts via the CSI driver. |
max_images_to_retain | 7 | Maximum recent Artifact Registry images to keep. |
delete_untagged_images | true | Automatically delete untagged images. |
image_retention_days | 30 | Days after which images are eligible for deletion. |
Group 15 — Redis
| Variable | Default | Description |
|---|
enable_redis | true (foundation default) | Forwarded for compatibility; LubeLogger_GKE forces it false — LubeLogger needs no Redis. |
Group 16 — Database Backend
| Variable | Default | Description |
|---|
database_type | NONE | Fixed — LubeLogger's default mode has no Cloud SQL database. |
Group 19 — Custom Domain, Static IP & Networking
| Variable | Default | Description |
|---|
enable_custom_domain | true | Provision Ingress for custom hostnames + managed certificate. |
application_domains | [] | Hostnames to serve. |
reserve_static_ip | true | Stable external IP across redeploys. |
Group 22 — VPC Service Controls & Audit Logging
| Variable | Default | Description |
|---|
enable_vpc_sc | false | Enforce a VPC-SC perimeter (requires organization_id). |
enable_audit_logging | false | Detailed Cloud Audit Logs. |
5. Outputs
These values are returned on a successful deployment and are the quickest way to
locate and explore the running resources.
| Output | Description |
|---|
service_name | Kubernetes Service name. |
namespace | Namespace the workload runs in. |
service_cluster_ip | In-cluster ClusterIP. |
service_external_ip | External LoadBalancer IP (when a static IP is reserved). |
service_url | URL to reach LubeLogger. |
storage_buckets | Created Cloud Storage buckets (storage, dpkeys). |
network_name / network_exists / regions | VPC network, presence, available regions. |
container_image / container_registry | Deployed image and Artifact Registry repo. |
monitoring_enabled / monitoring_notification_channels | Monitoring status and channels. |
initialization_jobs | Names of setup jobs (none by default). |
statefulset_name | Name of the StatefulSet. |
deployment_id / tenant_id / resource_prefix | Naming identifiers. |
project_id / project_number | Project identifiers. |
cicd_enabled / cicd_configuration | CI/CD status and details. |
kubernetes_ready | Whether the cluster/workload is ready. |
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode | VPC-SC status. |
audit_logging_enabled / artifact_registry_cmek_enabled | Audit logging and CMEK status. |
6. Configuration Pitfalls & Sensible Defaults
Risk: Critical (data loss / outage / security) — High (service degraded) —
Medium (cost or partial degradation) — Low (minor).
Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.
| Setting | Sensible value | Risk | Consequence if wrong |
|---|
max_instance_count | 1 | Critical | LubeLogger's default mode serves one shared embedded database file from one volume; more than one replica risks database corruption from concurrent writers. Enforced by a plan-time validation guard. |
stateful_pvc_enabled | true | High | A real block PVC gives reliable file locking; falling back to GCS FUSE for /App/data (by setting this false) risks lock contention under concurrent writes. |
stateful_pvc_mount_path | /App/data | Critical | Must match LubeLogger's actual data directory — a wrong path means the database and uploads are written to ephemeral pod storage and lost on every restart. |
storage/dpkeys buckets, or the PVC | Never delete | Critical | Losing /App/data (PVC or storage bucket) loses every vehicle record; losing dpkeys invalidates all existing login sessions (recoverable — forces re-login only). |
EnableAuth | true (default) | Critical | Setting it to false reverts to LubeLogger's fully open-access mode — anyone with the URL can view/edit all data with no login at all. |
| First-run registration | Complete immediately after deploy | High | Until a first account is registered, the Register form is reachable by anyone who can reach the URL. |
startup_probe/liveness_probe path | /Login | Critical | Pointing probes at / (or any [Authorize]-gated path) fails the probe on an otherwise-healthy pod — it never becomes Ready. |
workload_type | leave null (auto) | High | Setting workload_type = "Deployment" alongside stateful_pvc_enabled = true fails at plan time — a PVC template requires a StatefulSet. |
database_type | NONE (default) | High | LubeLogger's default mode ignores this setting entirely; changing it does not connect LubeLogger to a Cloud SQL instance — use POSTGRES_CONNECTION instead for the optional external Postgres path. |
quota_memory_requests / _limits | binary units (4Gi, 8192Mi) | Critical | Bare integers are bytes and block all pod scheduling in the namespace. |
enable_pod_disruption_budget | true | Medium | Disabling allows GKE to evict the pod during maintenance with no protection. |
service_type | LoadBalancer (default) | Medium | Setting to ClusterIP makes the public web UI unreachable from outside the cluster. |
For the foundation behaviour referenced throughout — IAM and Workload Identity,
autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary
Authorization, VPC-SC, backups, and image mirroring — see
App_GKE. LubeLogger-specific application configuration shared
with the Cloud Run variant is described in
LubeLogger_Common.
