Memos on GKE Autopilot
Memos is an open-source, MIT-licensed, self-hosted note-taking service built for quick markdown capture — a single ~20MB Go binary with a React frontend. This module deploys Memos on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.
This guide focuses on the cloud services Memos uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.
1. Overview
Memos runs as a single Go web workload. The deployment wires together a deliberately small set of Google Cloud services — Memos has no queue, no cache, and no background workers:
| Capability | Google Cloud service | Notes |
|---|---|---|
| Compute | GKE Autopilot | Go pod, 1 vCPU / 512 MiB by default, horizontally autoscaled |
| Database | Cloud SQL for PostgreSQL 15 | Required — this module standardizes on Postgres via a single MEMOS_DSN connection URL |
| Object storage | none | Not provisioned by this module — see the attachments note below |
| Cache & queue | none | Memos has no queue or cache dependency |
| Secrets | Secret Manager | Only the database password (managed by the Foundation); Memos itself has no app-level secret |
| Ingress | Cloud Load Balancing | External LoadBalancer, optional custom domain + managed certificate |
Sensible defaults worth knowing up front:
- PostgreSQL is the standardized engine.
Memos_Commonfixesdatabase_type = "POSTGRES_15". - No admin-bootstrap secret exists. The first account created through the web
UI becomes the host/admin — there is no
DEFAULTUSER-style env var and nothing to retrieve from Secret Manager for first login. workload_type = "Deployment", notStatefulSet. Memos keeps no local state that must survive a pod restart beyond what's already in Cloud SQL — no PVC, no NFS mount required.- Session affinity is not required. Memos has no in-process WebSocket state
tied to a specific pod (unlike Activepieces or Gotify's live-push patterns), so
the default
session_affinity = "None"is correct. min_instance_count = 0/max_instance_count = 1. GKE Autopilot bills per running pod; the HPA can scale to zero replicas when idle.- The database DSN is computed at container start, not baked into the image.
memos-entrypoint.shreads the platform-injectedDB_*variables — on GKE,DB_HOSTarrives as127.0.0.1(the cloud-sql-proxy sidecar) — and builds the singleMEMOS_DSNconnection URL Memos expects. - No object storage is provisioned. This module does not declare a GCS bucket, volume, or PVC for uploaded file attachments. Text notes persist fully in PostgreSQL, but binary attachments would live on the pod's ephemeral filesystem and would not survive a pod restart.
2. Google Cloud Services & How to Explore Them
All commands assume you have run
gcloud container clusters get-credentials <cluster> --region <region> --project <project>
and that PROJECT, REGION, and NAMESPACE are set. The namespace and other
identifiers are reported in the deployment Outputs.
A. GKE Autopilot — the Memos workload
Memos pods are scheduled on Autopilot, which bills for the CPU/memory the pods actually request. Horizontal Pod Autoscaling sizes the deployment between the minimum and maximum replica counts.
- Console: Kubernetes Engine → Workloads → select the Memos workload to see pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
- CLI:
kubectl get pods,svc,hpa -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100
kubectl describe hpa -n "$NAMESPACE" # current vs target utilisation
See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.
B. Cloud SQL for PostgreSQL 15
Memos stores all application data (notes, tags, users, resources metadata) in a
managed Cloud SQL for PostgreSQL 15 instance. Pods reach it privately through the
Cloud SQL Auth Proxy sidecar over 127.0.0.1; no public IP is exposed. On
first deploy an initialization Job creates the application database and user.
- Console: SQL → select the instance for connections, backups, flags, and metrics.
- CLI:
gcloud sql instances list --project "$PROJECT"
gcloud sql instances describe <instance-name> --project "$PROJECT"
gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"
The instance name, database, user, and password secret are in the Outputs. See App_GKE for the connection model, backups, and password rotation.
C. Secret Manager
Only the database password secret exists for this module — managed entirely by the
Foundation, not by Memos_Common. Memos generates its own internal session-signing
key and stores it in its own database on first boot.
- Console: Security → Secret Manager.
- CLI:
gcloud secrets list --project "$PROJECT" --filter="name~memos"
gcloud secrets versions access latest --secret=<db-password-secret-name> --project "$PROJECT"
D. Networking & ingress
The service is exposed via a Kubernetes Service (LoadBalancer by default) with an
external IP. A Gateway/Ingress with a custom domain and managed TLS certificate can
be layered on.
- Console: Kubernetes Engine → Services & Ingress; Network services → Load balancing.
- CLI:
kubectl get svc -n "$NAMESPACE" -o wide
gcloud compute addresses list --project "$PROJECT"
See App_GKE.
E. Cloud Logging & Monitoring
Container logs flow to Cloud Logging; GKE and Cloud SQL metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.
- Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
- CLI:
kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100 -f
3. Memos Application Behaviour
- First-deploy database setup. An initialization Job runs
create-db-and-user.shusingpostgres:15-alpine. It connects through the cloud-sql-proxy sidecar and idempotently creates the application role and database. The job is safe to re-run. - Schema migrations on start. Memos applies its own internal GORM auto-migrate schema setup on every pod start — no separate migration job is needed.
- No admin-bootstrap credential to retrieve. The first account created through the web UI's sign-up form becomes the host/admin.
- Database DSN is computed, not static.
memos-entrypoint.shbuildsMEMOS_DSNfromDB_HOST/DB_PORT/DB_USER/DB_NAME/DB_PASSWORDat container start — the loopback branch (DB_HOST=127.0.0.1,sslmode=disable) is taken on GKE, since the cloud-sql-proxy sidecar already terminates TLS. See Memos_Common for the full branching logic. - Health path. Startup and liveness probes target
/— Memos's public login/landing page, reachable without authentication. - Inspect job execution:
kubectl get jobs -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" job/<job-name>
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Memos are listed; every other input is inherited from App_GKE with its standard behaviour.
Group 1 — Project & Identity
| Variable | Default | Description |
|---|---|---|
project_id | (required) | Target Google Cloud project. |
region | us-central1 | Region for the cluster and regional resources. |
Group 2 — Deployment Environment
| Variable | Default | Description |
|---|---|---|
tenant_deployment_id | demo | Short suffix that makes resource names unique per environment. |
support_users | [] | Emails granted project access and monitoring alerts. |
resource_labels | {} | Labels applied to all resources. |
Group 3 — Application Identity
| Variable | Default | Description |
|---|---|---|
application_name | memos | Base name for resources. Do not change after first deploy. |
application_display_name | Memos | Human-readable name shown in the Console. |
application_description | Memos note-taking service on GKE | Workload description. |
application_version | latest | Deployment-tracking tag. Memos_Common maps "latest" to the pinned MEMOS_VERSION = "0.28.0" Dockerfile build arg. |
Group 4 — Runtime & Scaling
| Variable | Default | Description |
|---|---|---|
deploy_application | true | Set false to provision infrastructure only. |
container_image_source | custom | Builds the wrapper image with the computed-DSN entrypoint. |
cpu_limit | 1000m | CPU per pod. |
memory_limit | 512Mi | Memory per pod — sufficient for Memos's small footprint. |
min_instance_count | 0 | HPA minReplicas. |
max_instance_count | 1 | HPA maxReplicas; raise for higher concurrent load. |
container_port | 5230 | Memos's native default port — no remapping performed. |
enable_cloudsql_volume | true | cloud-sql-proxy sidecar for socket connections. |
enable_image_mirroring | true | Mirror the Memos image into Artifact Registry. |
session_affinity | None | No pod-level session required. |
Group 5 — Access & Ingress Control
Standard App_GKE service exposure and IAP settings — see App_GKE.
Key inputs: service_type (LoadBalancer by default), enable_iap,
iap_authorized_users.
Group 6 — Environment Variables & Secrets
| Variable | Default | Description |
|---|---|---|
environment_variables | {} | Extra non-secret settings. Any MEMOS_* value Memos documents can be set here. The database connection (MEMOS_DSN, MEMOS_DRIVER) is computed automatically — do not set them here. |
secret_environment_variables | {} | Map of env var → Secret Manager secret name. |
Group 7 — Backup & Restore
| Variable | Default | Description |
|---|---|---|
backup_schedule | 0 2 * * * | Automated backup cron (UTC). |
backup_retention_days | 7 | Retention; raise for production. |
enable_backup_import | false | Restore from a backup on deploy. |
Group 8 — CI/CD & Binary Authorization
Standard App_GKE Cloud Build integration — see App_GKE.
Group 11 — Storage & Filesystem
| Variable | Default | Description |
|---|---|---|
storage_buckets | [] | No bucket provisioned by default. |
enable_nfs | false | Not used — Memos keeps no state outside PostgreSQL in this module's wiring. |
stateful_pvc_enabled | false | Memos is stateless at the pod level; no block PVC needed. |
gcs_volumes | [] | Add an entry here (mounted at Memos's data directory) if attachment persistence is required. |
Group 12 — Database Backend
| Variable | Default | Description |
|---|---|---|
database_type | POSTGRES_15 | Fixed by Memos_Common. |
application_database_name | memos | PostgreSQL database name. Immutable after first deploy. |
application_database_user | memos | Application database user. Password auto-generated in Secret Manager. |
Group 13 — Jobs & Scheduled Tasks
| Variable | Default | Description |
|---|---|---|
initialization_jobs | [] | Leave empty to use the built-in db-init job. |
Group 14 — Observability & Health
| Variable | Default | Description |
|---|---|---|
startup_probe | HTTP / 30s delay | Startup probe — targets the public login page. |
liveness_probe | HTTP / 30s delay | Liveness probe. |
uptime_check_config | { enabled=false } | Cloud Monitoring uptime check; requires a publicly reachable endpoint. |
Group 22 — VPC Service Controls & Audit Logging
| Variable | Default | Description |
|---|---|---|
enable_vpc_sc | false | Enforce a VPC-SC perimeter (requires organization_id). |
enable_audit_logging | false | Detailed Cloud Audit Logs. |
5. Outputs
Returned on a successful deployment — the quickest way to locate and explore the running resources.
| Output | Description |
|---|---|
service_name | Kubernetes Service name. |
namespace | Kubernetes namespace. |
service_cluster_ip | ClusterIP of the Service. |
service_external_ip | External LoadBalancer IP (when service_type = "LoadBalancer"). |
service_url | URL of the deployed service. |
database_instance_name | Cloud SQL instance name. |
database_name / database_user | Application database name / user. |
database_password_secret | Secret Manager secret holding the DB password. |
database_host / database_port | DB endpoint / port. |
storage_buckets | Created Cloud Storage buckets — empty by default. |
network_name / network_exists / regions | VPC network, presence, regions. |
container_image / container_registry | Deployed image and Artifact Registry repo. |
monitoring_enabled / monitoring_notification_channels | Monitoring status and channels. |
initialization_jobs | Names of the setup jobs (includes db-init). |
deployment_id / tenant_id / resource_prefix | Naming identifiers. |
project_id / project_number | Project identifiers. |
kubernetes_ready | Whether the Kubernetes workload reached Ready state. |
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode | VPC-SC status. |
audit_logging_enabled / artifact_registry_cmek_enabled | Audit logging and CMEK status. |
6. Configuration Pitfalls & Sensible Defaults
Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).
| Setting | Sensible value | Risk | Consequence if wrong |
|---|---|---|---|
application_database_name / application_database_user | Set once | Critical | Immutable after first deploy; renaming recreates the DB/user and destroys all data. |
| First account created via sign-up | Create it immediately after deploy | Critical | The first account to register becomes host/admin — if left open, any visitor who reaches the external IP first claims that role. |
| Public self-registration | Disable after first admin | High | Memos ships with open sign-up by default. |
container_image_source | custom (default) | High | "prebuilt" deploys the official image directly, which has no logic to compute MEMOS_DSN — it must be wired manually or the pod CrashLoopBackOffs on a failed DB connection. |
stateful_pvc_enabled | false (default) | Low | Memos needs no block storage; enabling it adds unnecessary SSD quota consumption. |
gcs_volumes for attachments | Add explicitly if needed | Medium | Without it, uploaded binary attachments live on the pod's ephemeral filesystem and do not survive a pod restart. |
min_instance_count | 0 (default) | Low | Scale-to-zero briefly delays the first request after idle while a new pod schedules — Autopilot cold start, not an app bug. |
For the foundation behaviour referenced throughout — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Memos-specific application configuration shared with the Cloud Run variant is described in Memos_Common.
