Filebrowser on Google Cloud Run

Filebrowser on Google Cloud Run

File Browser is a lightweight, open-source web file manager written in Go — it serves a directory tree over HTTP for browsing, uploading, editing, and sharing files. This module deploys Filebrowser on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure.

This guide focuses on the cloud services Filebrowser uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.

1. Overview​

Filebrowser runs as a single Go container on Cloud Run v2. It is deliberately minimal — no SQL database, no cache, no queue — so the deployment wires together a small set of Google Cloud services:

CapabilityGoogle Cloud serviceNotes
ComputeCloud Run v2Single Go service, 1 vCPU / 1 GiB by default; min = max = 1
Persistent stateCloud Storage (GCS FUSE)One bucket mounted at /database holding the embedded SQLite DB
DatabaseNone (embedded SQLite)database_type = NONE; no Cloud SQL is provisioned
Cache & queueNoneFilebrowser uses no Redis
SecretsSecret ManagerNo app secrets generated; users live in the SQLite DB
IngressCloud Run URL / Cloud Load BalancingDefault ingress is internal — public access must be enabled explicitly

Sensible defaults worth knowing up front:

  • State lives in an embedded SQLite file on GCS. Filebrowser has no Cloud SQL database. Its users, settings, and share links are stored in /database/filebrowser.db, which is a Cloud Storage bucket mounted via GCS FUSE. Losing or wiping that bucket loses all Filebrowser state.
  • Single instance by design. min_instance_count = max_instance_count = 1. SQLite on a GCS FUSE mount does not tolerate concurrent writers — running more than one instance risks database corruption. Keep max = 1.
  • Default login is admin / admin. Filebrowser seeds this credential on first boot. Change it in the web UI immediately after deploy.
  • Ingress defaults to internal. The service is reachable only from within the VPC out of the box. To expose it publicly, set ingress_settings = "all" or front it with the HTTPS load balancer (enable_cloud_armor = true + application_domains).
  • No Redis, no init job. enable_redis = false and no db-init job runs; the app is ready as soon as the container starts.
  • Container port 80. Filebrowser serves plain HTTP/1.1 on port 80 (container_protocol = http1).
  • Scale-to-zero is safe but not the default. The SQLite DB is on the persistent GCS volume, so a cold start reloads all state; min = 1 is the default only to avoid the cold-start delay while the file index loads.

2. Google Cloud Services & How to Explore Them​

All commands assume PROJECT and REGION are set. Service and resource names are reported in the deployment Outputs.

A. Cloud Run — the Filebrowser service​

Filebrowser runs as a Cloud Run v2 service pinned to a single instance. Each deployment creates an immutable revision; traffic can be split across revisions for safe rollouts.

  • Console: Cloud Run → select the service for revisions, traffic, logs, and metrics.
  • CLI:
    gcloud run services list --project "$PROJECT" --region "$REGION" \
      --filter="metadata.name~filebrowser"
    gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
    gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"

See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.

B. Cloud Storage — persistent state (GCS FUSE)​

Filebrowser has no Cloud SQL database. Its embedded SQLite database (/database/filebrowser.db) lives in a dedicated Cloud Storage bucket mounted into the container at /database via GCS FUSE (requires the gen2 execution environment). This bucket is the single source of truth for users, settings, and share links.

  • Console: Cloud Storage → Buckets.
  • CLI:
    gcloud storage buckets list --project "$PROJECT" --filter="name~storage"
    gcloud storage ls gs://<data-bucket>/                 # bucket name is in the Outputs
    gcloud storage ls gs://<data-bucket>/filebrowser.db   # the SQLite DB object

See App_CloudRun for GCS FUSE and CMEK options.

C. Secret Manager​

Filebrowser generates no application secrets — there is no encryption key or JWT secret to manage, because all identity state lives in the SQLite database. Secret Manager is still used by the foundation for platform-managed secrets (e.g. CI/CD tokens if configured).

  • Console: Security → Secret Manager.
  • CLI:
    gcloud secrets list --project "$PROJECT" --filter="name~filebrowser"

See App_CloudRun for injection and rotation details.

D. Networking & ingress​

The service's ingress defaults to internal — reachable only from within the VPC. To serve users on the public internet, set ingress_settings = "all", or layer an external HTTPS load balancer with a custom domain, Cloud CDN, and Cloud Armor.

  • Console: Cloud Run (service URL); Network services → Load balancing.
  • CLI:
    gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'
    gcloud compute addresses list --project "$PROJECT"

See App_CloudRun.

E. Cloud Logging & Monitoring​

Container logs flow to Cloud Logging; Cloud Run metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.

  • Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
  • CLI:
    gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50

3. Filebrowser Application Behaviour​

  • No first-deploy database setup. There is no db-init job and no Cloud SQL instance. On first start the Filebrowser binary creates its SQLite database at /database/filebrowser.db (on the GCS FUSE mount) if it does not already exist and seeds the default admin/admin user.
  • State persistence. Users, settings, and share links live entirely in /database/filebrowser.db. Because that file is on the persistent GCS bucket, it survives restarts, redeploys, and scale-to-zero. FB_ROOT = /srv is the file tree the app serves and manages.
  • Default credentials must be changed. The seeded admin/admin login is well-known. Log in and change the password (and ideally the username) in the web UI immediately after the first deploy.
  • Single-writer constraint. The embedded SQLite database does not support concurrent writers across instances on a GCS FUSE mount. Keep max_instance_count = 1; scaling out risks corrupting the database.
  • Health path. Startup and liveness probes target /health — Filebrowser's unauthenticated health endpoint, which returns 200 as soon as the server is listening. Startup is fast (no migrations), so the default 15-second startup delay is ample:
    curl -s "$SERVICE_URL/health"    # 200 once the server is up
  • No Redis. enable_redis = false; Filebrowser is a self-contained file manager with no queue or cache.
  • Inspect the running revision's env and mounts:
    gcloud run services describe <service-name> \
      --region "$REGION" --project "$PROJECT" \
      --format='value(spec.template.spec.containers[0].env)'

4. Configuration Variables​

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Filebrowser are listed; every other input is inherited from App_CloudRun with its standard behaviour.

Group 1 — Project & Identity​

VariableDefaultDescription
project_id(required)Target Google Cloud project.
regionus-central1Region for the service and regional resources.

Group 3 — Application Identity​

VariableDefaultDescription
application_namefilebrowserBase name for resources. Do not change after first deploy.
application_display_nameFile BrowserHuman-readable name shown in the Console.
application_versionlatestFilebrowser image tag. latest resolves to the pinned v2.32.0 at build time; pin explicitly in production.

Group 4 — Runtime & Scaling​

VariableDefaultDescription
deploy_applicationtrueSet false to provision supporting infrastructure only.
cpu_limit1000mCPU per instance; Filebrowser is lightweight.
memory_limit1GiMemory per instance; 256Mi is ample for the Go server.
min_instance_count11 avoids cold-start delay while the file index loads; 0 (scale-to-zero) is safe because state is on GCS.
max_instance_count1Keep at 1 — SQLite on GCS FUSE cannot take concurrent writers.
container_port80Filebrowser's HTTP/1.1 listener.
container_protocolhttp1Filebrowser serves plain HTTP/1.1.
execution_environmentgen2Required for the /database GCS FUSE mount.
enable_cloudsql_volumefalseFilebrowser has no Cloud SQL; leave false.
enable_image_mirroringtrueMirror the Filebrowser image into Artifact Registry (avoids Docker Hub rate limits).

Group 5 — Access & Ingress Control​

VariableDefaultDescription
ingress_settingsinternalDefault is VPC-only. Set all for public access or internal-and-cloud-load-balancing behind a Load Balancer.
vpc_egress_settingPRIVATE_RANGES_ONLYRoute only RFC 1918 traffic via VPC.
enable_iapfalseRequire Google sign-in in front of Filebrowser.
iap_authorized_users / iap_authorized_groups[]Who may access through IAP.

Group 6 — Environment Variables & Secrets​

VariableDefaultDescription
environment_variables{}Extra non-secret settings. FB_DATABASE, FB_ROOT are set automatically.
secret_environment_variables{}Map of env var → Secret Manager secret name. Filebrowser uses none by default.
secret_propagation_delay30Seconds to wait after secret creation before proceeding.

Group 9 — Custom SQL Scripts​

enable_custom_sql_scripts, custom_sql_scripts_bucket, custom_sql_scripts_path, custom_sql_scripts_use_root — not applicable to Filebrowser (no SQL database). Leave at defaults.

Group 11 — Storage & Filesystem​

VariableDefaultDescription
create_cloud_storagetrueCreate the Filebrowser /database bucket (and any extra storage_buckets).
storage_buckets[]Additional GCS buckets beyond the auto-provisioned /database bucket.
enable_nfsfalseNFS is off by default; not needed for Filebrowser.
gcs_volumes[]Extra GCS FUSE mounts. The /database bucket is added automatically.
manage_storage_kms_iam / enable_artifact_registry_cmekfalseCMEK options.

Group 12 — Database Backend​

Not applicable — Filebrowser has no SQL database. database_type is fixed to NONE by Filebrowser_Common, and database_password_length, the db_*_env_var_name inputs, and password rotation are forwarded only for foundation compatibility.

Group 13 — Jobs & Scheduled Tasks​

VariableDefaultDescription
initialization_jobs[]No default init job. Provide jobs only for custom data loading/migration.
cron_jobs[]Optional recurring Cloud Run jobs (e.g. snapshot/maintenance tasks).

Group 14 — Observability & Health​

VariableDefaultDescription
startup_probeHTTP /health 15s delayStartup probe; Filebrowser exposes /health once ready.
liveness_probeHTTP /health 30s delayLiveness probe on the unauthenticated /health endpoint.
uptime_check_configdisabled, path /healthCloud Monitoring uptime check; disabled by default.
alert_policies[]Metric alert policies.

Group 23 — VPC Service Controls & Audit Logging​

VariableDefaultDescription
enable_vpc_scfalseEnforce a VPC-SC perimeter (requires organization_id).
vpc_cidr_ranges / vpc_sc_dry_run(set)Access level CIDRs / dry-run mode.
enable_audit_loggingfalseDetailed Cloud Audit Logs.

All other inputs follow standard App_CloudRun behaviour.

5. Outputs​

Returned on a successful deployment — the quickest way to locate and explore the running resources.

OutputDescription
service_nameCloud Run service name.
filebrowser_urlURL of the Filebrowser web UI (port 80). VPC-internal when ingress_settings = internal.
service_locationRegion the service runs in.
stage_servicesStage-specific service details (Cloud Deploy).
load_balancer_ip / load_balancer_urlExternal HTTPS load balancer IP / URL (when enabled).
storage_bucketsCreated Cloud Storage buckets (includes the /database bucket).
network_name / network_exists / regionsVPC network, presence, regions.
container_image / container_registryDeployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels / uptime_check_namesMonitoring status, channels, uptime checks.
initialization_jobsNames of any init jobs (empty by default).
deployment_id / tenant_id / resource_prefixNaming identifiers.
project_id / project_numberProject identifiers.
cicd_enabled / github_repository_url / github_repository_owner / github_repository_name / cicd_configurationCI/CD status and details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_idRegistry and build trigger.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_modeVPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabledAudit logging and CMEK status.

6. Configuration Pitfalls & Sensible Defaults​

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_CloudRun foundation engine, which validates values and combinations at plan time — IAP with no authorized identities, a gen1 runtime with GCS FUSE mounts, min_instance_count > max_instance_count, out-of-range timeouts. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

SettingSensible valueRiskConsequence if wrong
/database GCS bucketNever deleteCriticalThe embedded SQLite DB lives here; deleting the bucket destroys all users, settings, and share links.
admin / admin (seeded login)Change on first loginCriticalLeaving the default credential lets anyone who can reach the service take full control.
max_instance_count1High>1 puts concurrent writers on SQLite over GCS FUSE, corrupting the database.
ingress_settingsinternal (or all for public)HighDefault internal makes the service unreachable from the public internet; setting all exposes it — pair with IAP or Cloud Armor.
container_port80HighFilebrowser listens on 80; a different port makes the startup probe fail and the revision never becomes Ready.
startup_probe / liveness_probe path/healthHighPointing probes at an authenticated path returns 401/403 and the revision never goes Ready.
enable_cloudsql_volumefalseMediumFilebrowser has no Cloud SQL; enabling adds a useless Auth Proxy sidecar.
execution_environmentgen2Highgen1 cannot mount the /database GCS FUSE volume, so state is not persisted.
min_instance_count1 (or 0)Medium0 adds a cold-start delay while the file index loads; state is safe either way.
application_versionpin in productionMediumlatest resolves to a pinned v2.32.0 at build time; pin explicitly to control upgrades.

For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_CloudRun. Filebrowser-specific application configuration shared with the GKE variant is described in Filebrowser_Common.
