Qdrant on Google Kubernetes Engine
This document provides a comprehensive reference for the modules/Qdrant_GKE Terraform module. It covers architecture, IAM, configuration variables, Qdrant-specific behaviours, and operational patterns for deploying Qdrant on GKE Autopilot.
1. Module Overview
Qdrant GKE is a wrapper module built on top of App GKE. It deploys Qdrant — the high-performance vector database and similarity search engine — on GKE Autopilot with production-grade StatefulSet persistence, GCS FUSE storage, optional API key authentication, Workload Identity, and horizontal auto-scaling.
Key Capabilities:
- Compute: GKE Autopilot, 1 vCPU / 1 Gi by default. StatefulSet or Deployment workload type.
- Data Persistence: StatefulSet PVC (recommended for production) or GCS FUSE-mounted Cloud Storage bucket at
/qdrant/storage. No Cloud SQL, no Redis.
- Security: Optional API key via Secret Manager injected as
QDRANT__SERVICE__API_KEY. Inherits Cloud Armor, IAP, and VPC-SC from App GKE.
- CI/CD: Cloud Build image pipeline by default; Cloud Deploy progressive delivery optional.
- Reliability: Startup probe targets
/readyz; liveness probe targets /livez. PodDisruptionBudget enabled by default.
- gRPC: Disabled by default. Enable via
environment_variables = { QDRANT__SERVICE__GRPC_PORT = "6334" } and configure a second Service port manually.
Project & Application Identity
| Variable | Group | Type | Default | Description |
|---|
project_id | 1 | string | — | GCP project ID. Required. |
region | 1 | string | 'us-central1' | GCP region fallback |
tenant_deployment_id | 2 | string | 'demo' | Short suffix appended to resource names |
support_users | 2 | list(string) | [] | Email recipients for monitoring alerts |
resource_labels | 2 | map(string) | {} | Labels applied to all resources |
application_name | 3 | string | 'qdrant' | Base resource name. Do not change after initial deployment. |
application_display_name | 3 | string | 'Qdrant Vector Database' | Human-readable name |
description | 3 | string | Qdrant description | Workload description |
application_version | 3 | string | 'latest' | Qdrant image tag |
2. IAM & Access Control
Qdrant GKE delegates all IAM provisioning to App GKE. Workload Identity is used — the Kubernetes service account is bound to a GCP service account with the minimum required roles (GCS read/write for the storage bucket, Secret Manager accessor for the API key).
API key: When enable_api_key = true, Qdrant Common generates a 32-character API key and stores it in Secret Manager as <prefix>-api-key. It is injected as QDRANT__SERVICE__API_KEY. All REST and gRPC calls must include api-key: <key> in the request header/metadata.
3. Core Service Configuration
A. Compute (GKE)
| Variable | Group | Default | Description |
|---|
deploy_application | 4 | true | Set false for infrastructure-only deployment |
cpu_limit | 4 | '1000m' | CPU limit per pod |
memory_limit | 4 | '1Gi' | Memory limit per pod. Qdrant loads HNSW indexes into memory — size accordingly. |
container_resources | 4 | { cpu_limit="1000m", memory_limit="1Gi" } | Structured resource spec. Provides cpu_request, mem_request, ephemeral_storage_* fields. |
min_instance_count | 4 | 1 | Minimum pod replicas |
max_instance_count | 4 | 1 | Maximum pod replicas. Keep at 1 for single-writer safety. |
timeout_seconds | 4 | 300 | Request timeout (0–3600 s) |
enable_image_mirroring | 4 | true | Mirror Qdrant image to Artifact Registry |
enable_vertical_pod_autoscaling | 4 | false | Enable VPA |
B. Kubernetes Workload
| Variable | Group | Default | Description |
|---|
gke_cluster_name | 6 | "" | Target GKE cluster. Auto-discovered when empty. |
gke_cluster_selection_mode | 6 | 'primary' | 'explicit', 'round-robin', or 'primary' |
namespace_name | 6 | "" | Kubernetes namespace. Auto-generated when empty. |
workload_type | 6 | null | 'Deployment' or 'StatefulSet'. Auto-resolves to StatefulSet when stateful_pvc_enabled = true. |
service_type | 6 | 'ClusterIP' | 'ClusterIP' (recommended), 'LoadBalancer', or 'NodePort' |
session_affinity | 6 | 'None' | 'None' or 'ClientIP' |
termination_grace_period_seconds | 6 | 60 | Grace period for Qdrant to flush WAL writes (0–3600 s) |
enable_network_segmentation | 6 | false | Enable Kubernetes NetworkPolicies |
configure_service_mesh | 6 | false | Enable Istio service mesh injection |
deployment_timeout | 6 | 1800 | Seconds Terraform waits for rollout completion |
C. StatefulSet Persistence
For production deployments, stateful_pvc_enabled = true is strongly recommended over GCS FUSE. Qdrant's WAL and HNSW index files are I/O-intensive — PVC-backed storage provides significantly lower latency than GCS FUSE for these access patterns.
| Variable | Group | Default | Description |
|---|
stateful_pvc_enabled | 7 | null | Enable PVC. Recommended for production. Auto-selects StatefulSet. |
stateful_pvc_size | 7 | '20Gi' | Per-pod PVC size. Size to hold all collection data, HNSW indexes, and WAL. |
stateful_pvc_mount_path | 7 | '/qdrant/storage' | Container path for the PVC. Matches QDRANT__STORAGE__STORAGE_PATH. |
stateful_pvc_storage_class | 7 | 'standard-rwo' | 'standard-rwo' (Balanced PD) or 'premium-rwo' (higher IOPS, lower latency) |
stateful_headless_service | 7 | null | Create a headless service for stable network identities |
stateful_pod_management_policy | 7 | null | 'OrderedReady' ensures safe sequential restarts |
stateful_update_strategy | 7 | null | 'RollingUpdate' for zero-downtime updates |
stateful_fs_group | 7 | 1000 | GID for PVC write access. Set to 0 to leave unset. |
PVC prevents GCS double-mount: When stateful_pvc_enabled = true, the wrapper passes enable_gcs_storage_volume = false to Qdrant Common, preventing the <prefix>-storage bucket from being mounted at /qdrant/storage alongside the PVC.
D. Storage (GCS FUSE)
When stateful_pvc_enabled is not set, Qdrant data is persisted via GCS FUSE at /qdrant/storage:
| Variable | Group | Default | Description |
|---|
create_cloud_storage | 14 | true | Provision GCS buckets |
storage_buckets | 14 | [] | Additional GCS buckets |
gcs_volumes | 14 | [] | Additional GCS FUSE volumes |
manage_storage_kms_iam | 14 | false | CMEK for storage |
enable_artifact_registry_cmek | 14 | false | CMEK for Artifact Registry |
4. Authentication & Access Control
A. Qdrant API Key
| Variable | Group | Default | Description |
|---|
enable_api_key | 3 | false | Generate API key in Secret Manager. Injected as QDRANT__SERVICE__API_KEY. Recommended for all deployments with external access. |
B. Identity-Aware Proxy (IAP)
IAP via the Kubernetes Gateway API. Requires enable_custom_domain or enable_cdn.
| Variable | Group | Default | Description |
|---|
enable_iap | 20 | false | Enable IAP via Kubernetes Gateway |
iap_authorized_users | 20 | [] | IAP-authorized users |
iap_authorized_groups | 20 | [] | IAP-authorized groups |
iap_oauth_client_id | 20 | "" | OAuth client ID. Sensitive. |
iap_oauth_client_secret | 20 | "" | OAuth client secret. Sensitive. |
C. Cloud Armor
| Variable | Group | Default | Description |
|---|
enable_cloud_armor | 21 | false | Attach Cloud Armor to GKE Ingress |
admin_ip_ranges | 21 | [] | CIDR ranges exempted from WAF rules |
cloud_armor_policy_name | 21 | 'default-waf-policy' | Cloud Armor policy name |
enable_cdn | 21 | false | Enable Cloud CDN via GCPBackendPolicy |
5. Observability & Health
A. Health Probes
| Variable | Group | Default | Description |
|---|
startup_probe_config | 10 | { path="/readyz", ... } | Startup probe via App GKE config interface |
health_check_config | 10 | { path="/livez", ... } | Liveness probe via App GKE config interface |
startup_probe | 10 | { path="/readyz", initial_delay=15, period=10, threshold=10 } | Startup probe (legacy format) |
liveness_probe | 10 | { path="/livez", initial_delay=30, period=30, threshold=3 } | Liveness probe (legacy format) |
uptime_check_config | 10 | { enabled=true, path="/readyz" } | Cloud Monitoring uptime check |
alert_policies | 10 | [] | Metric alert policies |
Critical probe guidance: Always use /readyz for the startup probe and /livez for the liveness probe. Qdrant temporarily marks itself as not-ready while loading collections from disk. Using /readyz as the liveness target causes Kubernetes to kill and restart the pod during every collection load — creating a crash loop on instances with large collections.
B. Pod Disruption Budget & Resource Quotas
| Variable | Group | Default | Description |
|---|
enable_pod_disruption_budget | 9 | true | Create a PodDisruptionBudget |
pdb_min_available | 9 | '1' | Minimum pods available during disruptions |
enable_resource_quota | 8 | false | Create a Kubernetes ResourceQuota |
quota_memory_requests | 8 | "" | Memory requests quota (binary suffix required, e.g., '4Gi') |
quota_memory_limits | 8 | "" | Memory limits quota (binary suffix required) |
| Behaviour | Implementation | Detail |
|---|
| No SQL database | database_type = "NONE" fixed by Qdrant Common | No Cloud SQL resources created |
| No Redis | Not used | Qdrant has no caching dependency |
| Storage path env var | QDRANT__STORAGE__STORAGE_PATH=/qdrant/storage always injected | Aligned with GCS FUSE / PVC mount point |
| HTTP port env var | QDRANT__SERVICE__HTTP_PORT=6333 always injected | Explicit port |
| gRPC disabled by default | QDRANT__SERVICE__GRPC_PORT not set | Port 6334 not exposed in default Service. Enable manually via environment_variables. |
| Separate liveness/readiness | Startup: /readyz, Liveness: /livez | Prevents restart loops during large collection loads |
| StatefulSet auto-select | stateful_pvc_enabled = true | Automatically resolves workload_type to "StatefulSet" |
| PVC prevents GCS double-mount | enable_gcs_storage_volume = false passed to Qdrant Common | Prevents simultaneous PVC and GCS FUSE at /qdrant/storage |
7. Variable Reference
| Variable | Group | Default | Description |
|---|
project_id | 1 | — | GCP project ID. Required. |
region | 1 | 'us-central1' | Region fallback |
tenant_deployment_id | 2 | 'demo' | Resource name suffix |
support_users | 2 | [] | Monitoring alert recipients |
resource_labels | 2 | {} | Resource labels |
application_name | 3 | 'qdrant' | Base resource name |
application_display_name | 3 | 'Qdrant Vector Database' | Display name |
description | 3 | Qdrant description | Workload description |
application_version | 3 | 'latest' | Image tag |
enable_api_key | 3 | false | Generate API key |
deploy_application | 4 | true | Deploy workload |
cpu_limit | 4 | '1000m' | CPU limit |
memory_limit | 4 | '1Gi' | Memory limit |
min_instance_count | 4 | 1 | Min replicas |
max_instance_count | 4 | 1 | Max replicas |
timeout_seconds | 4 | 300 | Request timeout |
enable_image_mirroring | 4 | true | Mirror to Artifact Registry |
environment_variables | 5 | {} | Plain-text env vars |
secret_environment_variables | 5 | {} | Secret Manager references |
secret_propagation_delay | 5 | 30 | Post-creation wait |
secret_rotation_period | 5 | '2592000s' | Rotation period |
gke_cluster_name | 6 | "" | GKE cluster name |
namespace_name | 6 | "" | Kubernetes namespace |
workload_type | 6 | null | 'Deployment' or 'StatefulSet' |
service_type | 6 | 'ClusterIP' | Kubernetes Service type |
termination_grace_period_seconds | 6 | 60 | Grace period |
stateful_pvc_enabled | 7 | null | Enable StatefulSet PVC |
stateful_pvc_size | 7 | '20Gi' | PVC size |
stateful_pvc_mount_path | 7 | '/qdrant/storage' | PVC mount path |
stateful_pvc_storage_class | 7 | 'standard-rwo' | StorageClass |
stateful_pod_management_policy | 7 | null | Pod management |
stateful_update_strategy | 7 | null | Update strategy |
stateful_fs_group | 7 | 1000 | fsGroup GID |
enable_resource_quota | 8 | false | ResourceQuota |
enable_pod_disruption_budget | 9 | true | PodDisruptionBudget |
pdb_min_available | 9 | '1' | Min available pods |
startup_probe | 10 | { path="/readyz" } | Startup probe |
liveness_probe | 10 | { path="/livez" } | Liveness probe |
uptime_check_config | 10 | { enabled=true } | Uptime check |
initialization_jobs | 11 | [] | Init jobs |
cron_jobs | 11 | [] | Scheduled jobs |
enable_cicd_trigger | 12 | false | Cloud Build trigger |
enable_cloud_deploy | 12 | false | Cloud Deploy pipeline |
enable_binary_authorization | 12 | false | Binary Authorization |
enable_nfs | 13 | false | NFS mount |
create_cloud_storage | 14 | true | GCS buckets |
storage_buckets | 14 | [] | Additional buckets |
gcs_volumes | 14 | [] | GCS FUSE volumes |
backup_schedule | 17 | '0 2 * * *' | Backup cron |
backup_retention_days | 17 | 7 | Backup retention |
enable_backup_import | 17 | false | One-time restore |
enable_custom_domain | 19 | false | Custom domain |
application_domains | 19 | [] | Domain names |
reserve_static_ip | 19 | false | Reserve static IP |
enable_iap | 20 | false | IAP via Gateway |
enable_cloud_armor | 21 | false | Cloud Armor |
enable_vpc_sc | 22 | false | VPC Service Controls |
organization_id | 22 | "" | GCP Org ID for VPC-SC |
enable_audit_logging | 22 | false | Cloud Audit Logs |
Configuration Pitfalls & Sensible Defaults
Risk levels: Critical (data loss, full outage, security breach) — High (service unavailable or significant degradation) — Medium (degraded function or increased cost) — Low (minor impact).
| Variable | Sensible Default | Risk | Consequence of Incorrect Value |
|---|
enable_api_key (Common) | false | Critical | Without an API key, any caller who can reach the Qdrant service can read, modify, or delete all collections. Set to true for any deployment reachable outside the pod namespace. The key is stored in Secret Manager. |
stateful_pvc_enabled | null | High | Without a PVC, Qdrant stores collection data in the ephemeral pod filesystem. Any pod restart, rolling update, or node eviction erases all collections permanently. Set stateful_pvc_enabled = true for any production deployment. |
stateful_pvc_size | "20Gi" | High | An undersized PVC fills up as collections grow (HNSW index + payload storage). A full disk causes Qdrant to crash and makes collections unrecoverable without manual PVC expansion. Provision generously — PVC capacity cannot be decreased after creation. For 1M vectors at 1536 dims, allow at least 10 Gi per collection. |
workload_type | null | High | null resolves to Deployment. With stateful_pvc_enabled = true, the module auto-selects StatefulSet. Explicitly combining workload_type = "Deployment" with stateful_pvc_enabled = true fails at plan time. |
stateful_pvc_storage_class | "standard-rwo" | Medium | Balanced PD is adequate for most query loads. High-throughput real-time index builds benefit from premium-rwo. Storage class cannot be changed after PVC creation without data migration. |
stateful_pvc_mount_path | "/qdrant/storage" | Critical | Must match Qdrant's storage.storage_path configuration. If the PVC is mounted to a different path than Qdrant reads, all data is stored in the ephemeral container layer and lost on restart. Do not change without a matching QDRANT__STORAGE__STORAGE_PATH environment variable override. |
collection vector dimensions | (immutable — set at collection creation via client) | Critical | Qdrant collection vector dimensions are immutable after creation. A mismatch with the embedding model dimension causes all upsert operations to fail. There is no migration path — the collection must be deleted and recreated, losing all vectors. |
memory_limit | "1Gi" | High | Qdrant loads HNSW graphs into memory. The default 1Gi supports only small test collections. Production workloads need 4Gi–16Gi or more. OOM kills drop all in-flight queries and trigger a full index reload from disk. |
cpu_limit | "1000m" | Medium | HNSW index builds and high-concurrency searches are CPU-bound. Throttling below 1000m degrades p99 latency and slows index construction. Scale to 2000m–4000m for production. |
min_instance_count | 1 | Medium | Scale-to-zero on GKE (0) deletes the pod. After restart, Qdrant reloads indexes from PVC, which takes tens of seconds for large collections. For latency-sensitive applications, keep at 1. |
max_instance_count | 1 | High | Multiple Qdrant replicas sharing a single PVC (RWO) are not supported. RWO PVCs can only be mounted by one pod at a time; scaling beyond 1 prevents additional pods from scheduling. For horizontal scaling, deploy separate Qdrant instances with collection sharding at the application level. |
liveness_probe (Common) | /livez | High | Qdrant's /readyz returns 503 while loading large collections. Using /readyz as the liveness target causes spurious restarts during collection load, which in turn triggers more reloads — a restart loop. Always use /livez for liveness checks. |
quota_memory_requests | "" | Critical | If enable_resource_quota = true with a bare integer (e.g. "4" instead of "4Gi"), Kubernetes treats it as bytes, blocking all pod scheduling. Always use binary suffixes. Note: Qdrant GKE accepts but does not forward this variable — check App GKE. |
application_version | "latest" | Medium | Qdrant's storage format changes between major versions. An unexpected image change via latest during rebuild can make existing collections unreadable. Pin to a specific semver tag for production. |
backup_schedule | "0 2 * * *" | Medium | Qdrant collections should be snapshotted regularly via the Qdrant API or GCS Fuse volume backup. Ensure the backup job is active and tested before relying on it for production recovery. |
enable_iap | false | High | Without IAP, the GKE Ingress endpoint is accessible to any caller. Enable IAP and enable_api_key = true together for defense-in-depth on production deployments. |
