Open WebUI on Google Cloud Run
This document provides a comprehensive reference for the modules/OpenWebUI_CloudRun Terraform module. It covers architecture, IAM, configuration variables, Open WebUI-specific behaviours, and operational patterns for deploying Open WebUI on Google Cloud Run (v2).
1. Module Overview
Open WebUI is a self-hosted AI interface with 90,000+ GitHub stars, providing a polished ChatGPT-style frontend for Ollama, OpenAI-compatible APIs, and dozens of LLM providers. OpenWebUI CloudRun is a wrapper module built on top of App CloudRun. It uses App CloudRun for all GCP infrastructure provisioning and injects Open WebUI-specific application configuration, secrets, and storage via OpenWebUI Common.
Key Capabilities:
- Compute: Cloud Run v2 (Gen2), 2 vCPU / 4 Gi by default. Scale-to-zero (
min_instance_count = 0) withmax_instance_count = 3— both are user-configurable. - Data Persistence: Cloud SQL PostgreSQL 15.
OpenWebUI Commonprovisions adb-initjob that creates the database and user on first apply. The Cloud SQL Auth Proxy sidecar is enabled by default (enable_cloudsql_volume = true). - Security: Inherits Cloud Armor WAF, IAP, Binary Authorization, and VPC Service Controls from
App CloudRun.WEBUI_SECRET_KEYis auto-generated and stored in Secret Manager byOpenWebUI Common. - No Redis: Open WebUI persists sessions and application state in PostgreSQL — no Redis session store is required. The
enable_redisvariable exists for compatibility but defaults tofalseand noREDIS_*env vars are injected. - AI Backend Integration:
ollama_base_urlandopenai_api_base_urlvariables configure backend AI connections. API keys should be supplied viasecret_environment_variables. - Health: Health probes target
/healthwith 30-second initial delay.
Project & Application Identity
| Variable | Group | Type | Default | Description |
|---|---|---|---|---|
project_id | 1 | string | — | GCP project ID. Required. |
tenant_deployment_id | 2 | string | 'demo' | Short suffix appended to all resource names. |
support_users | 2 | list(string) | [] | Email recipients for monitoring alerts. |
resource_labels | 2 | map(string) | {} | Labels applied to all provisioned resources. |
application_name | 3 | string | 'openwebui' | Base resource name. Do not change after initial deployment. |
display_name | 3 | string | 'Open WebUI' | Human-readable name shown in the GCP Console. |
description | 3 | string | 'Open WebUI — self-hosted AI interface...' | Cloud Run service description. |
application_version | 3 | string | 'latest' | Open WebUI image version tag. |
Wrapper architecture: OpenWebUI CloudRun calls OpenWebUI Common to produce an application_config object containing Open WebUI-specific environment variables, probe configuration, and the db-init job. module_storage_buckets carries the GCS data bucket provisioned by OpenWebUI Common. scripts_dir = abspath("${path.module}/scripts") at apply time (note: scripts live in the OpenWebUI CloudRun module itself, not in OpenWebUI Common).
2. IAM & Access Control
OpenWebUI CloudRun delegates all IAM provisioning to App CloudRun. The Cloud Run SA, Cloud Build SA, IAP service agent, and password rotation role sets are identical to those in App CloudRun.
Auto-generated secret: OpenWebUI Common auto-generates WEBUI_SECRET_KEY and stores it in Secret Manager. This key is used by Open WebUI to sign sessions. It is injected into the Cloud Run service via module_secret_env_vars.
Database initialisation: The db-init Cloud Run Job (provisioned by OpenWebUI Common) creates the PostgreSQL database and user on first apply. It runs under the Cloud Run SA.
3. Core Service Configuration
A. Compute (Cloud Run)
| Variable | Group | Default | Description |
|---|---|---|---|
deploy_application | 4 | true | Set false for infrastructure-only deployment. |
cpu_limit | 4 | '2000m' | CPU per instance. 2 vCPU for RAG and embeddings workloads. |
memory_limit | 4 | '4Gi' | Memory per instance. 4 Gi recommended for RAG pipelines. |
min_instance_count | 4 | 0 | Minimum instances. Scale-to-zero by default. |
max_instance_count | 4 | 3 | Maximum instances. |
container_port | 4 | 8080 | Open WebUI's HTTP port. Do not set the PORT env var — it is reserved by Cloud Run. |
execution_environment | 4 | 'gen2' | Gen2 recommended for NFS and GCS Fuse compatibility. |
timeout_seconds | 4 | 300 | Max request duration. Increase for long-running model inference requests. |
enable_cloudsql_volume | 4 | true | Cloud SQL Auth Proxy sidecar for Unix socket connection to PostgreSQL. |
service_annotations | 4 | {} | Advanced Cloud Run annotations. |
service_labels | 4 | {} | Labels applied to the Cloud Run service. |
B. Open WebUI Settings (Group 5)
These variables are unique to Open WebUI and are not present in App CloudRun.
| Variable | Group | Default | Description |
|---|---|---|---|
ollama_base_url | 5 | "" | Base URL for the Ollama backend (e.g., 'http://ollama:11434'). Leave empty to disable Ollama integration. |
openai_api_base_url | 5 | "" | Base URL for an OpenAI-compatible API (e.g., 'https://api.openai.com/v1'). Leave empty if not using OpenAI. |
default_user_role | 5 | 'pending' | Default role for new user registrations. Options: pending (requires admin approval), user, admin. |
enable_signup | 5 | true | Allow new users to self-register via the signup page. |
webui_auth | 5 | true | Enable the login/authentication system (WEBUI_AUTH). Only disable for single-user or air-gapped deployments. |
API key note: Supply OPENAI_API_KEY and other sensitive credentials via secret_environment_variables, not environment_variables.
C. Database (Cloud SQL — PostgreSQL 15)
Open WebUI requires PostgreSQL. The database type is fixed to PostgreSQL 15 and cannot be changed.
| Variable | Group | Default | Description |
|---|---|---|---|
db_name | 3 | 'openwebui_db' | PostgreSQL database name. Do not change after initial deployment. |
db_user | 3 | 'openwebui_user' | PostgreSQL application user. |
database_password_length | — | 32 | Auto-generated password length. |
D. Storage (GCS)
OpenWebUI Common provisions a GCS data bucket for Open WebUI's backend data directory (DATA_DIR=/app/backend/data).
| Variable | Group | Default | Description |
|---|---|---|---|
create_cloud_storage | 11 | true | Set false to skip GCS bucket creation. |
storage_buckets | 11 | [{ name_suffix = "data" }] | Additional GCS buckets to provision. |
enable_nfs | 11 | false | NFS disabled by default — PostgreSQL holds application state. |
nfs_mount_path | 11 | '/mnt/nfs' | Container path for NFS mount when enabled. |
gcs_volumes | 11 | [] | GCS buckets to mount via GCS Fuse (requires gen2). |
E. Networking
| Variable | Group | Default | Description |
|---|---|---|---|
ingress_settings | 5 | 'all' | 'all', 'internal', or 'internal-and-cloud-load-balancing'. |
vpc_egress_setting | 5 | 'PRIVATE_RANGES_ONLY' | VPC egress routing. |
F. Environment Variables & Secrets
The platform injects DB_HOST, DB_USER, DB_PASSWORD, DB_NAME automatically. OpenWebUI Common assembles DATABASE_URL from these. WEBUI_SECRET_KEY is auto-generated and injected from Secret Manager.
| Variable | Group | Default | Description |
|---|---|---|---|
environment_variables | 6 | {} | Plain-text env vars. Do not include DATABASE_URL — it is assembled automatically. |
secret_environment_variables | 6 | {} | Secret Manager references. Use for OPENAI_API_KEY and similar sensitive values. |
secret_propagation_delay | 6 | 30 | Seconds to wait after secret creation before dependent resources proceed. |
4. Advanced Security
A. Cloud Armor WAF
| Variable | Group | Default | Description |
|---|---|---|---|
enable_cloud_armor | 10 | false | Provisions Global HTTPS LB + Cloud Armor WAF. |
admin_ip_ranges | 10 | [] | CIDR ranges exempted from WAF rules. |
application_domains | 10 | [] | Custom domains with Google-managed SSL certificates. |
enable_cdn | 10 | false | Enables Cloud CDN on the HTTPS LB backend. |
B. Identity-Aware Proxy (IAP)
| Variable | Group | Default | Description |
|---|---|---|---|
enable_iap | 5 | false | Enables IAP on the Cloud Run service. Note: enabling IAP requires additional OAuth configuration. |
iap_authorized_users | 5 | [] | Users/SAs granted IAP access. |
iap_authorized_groups | 5 | [] | Google Groups granted IAP access. |
C. Binary Authorization & VPC-SC
| Variable | Group | Default | Description |
|---|---|---|---|
enable_binary_authorization | 8 | false | Enforces image attestation on deployment. |
enable_vpc_sc | 22 | false | Registers module API calls within the project's VPC-SC perimeter. |
enable_audit_logging | 22 | false | Enables detailed Cloud Audit Logs. |
5. CI/CD & Delivery
| Variable | Group | Default | Description |
|---|---|---|---|
enable_cicd_trigger | 8 | false | Provisions a Cloud Build GitHub trigger. |
github_repository_url | 8 | "" | Full HTTPS URL of the GitHub repository. |
github_token | 8 | "" | GitHub PAT. Sensitive. |
github_app_installation_id | 8 | "" | GitHub App installation ID. |
cicd_trigger_config | 8 | { branch_pattern = "^main$" } | Advanced Cloud Build trigger config. |
enable_cloud_deploy | 8 | false | Provisions a Cloud Deploy progressive delivery pipeline. |
cloud_deploy_stages | 8 | [dev, staging, prod(approval)] | Ordered Cloud Deploy promotion stages. |
6. Reliability
A. Health Probes
Open WebUI exposes /health. Both startup and liveness probes target this path.
| Variable | Group | Default | Description |
|---|---|---|---|
startup_probe | 14 | { path="/health", initial_delay_seconds=30, failure_threshold=30, ... } | Startup probe. 30s delay accommodates first-boot DB migrations. |
liveness_probe | 14 | { path="/health", initial_delay_seconds=60, failure_threshold=3, ... } | Liveness probe. |
uptime_check_config | 14 | { enabled=true, path="/health" } | Cloud Monitoring uptime check. |
alert_policies | 14 | [] | Cloud Monitoring metric alert policies. |
B. Backup & Recovery
| Variable | Group | Default | Description |
|---|---|---|---|
backup_schedule | 7 | '0 2 * * *' | Cron expression (UTC) for automated daily backups. |
backup_retention_days | 7 | 7 | Days to retain backup files in GCS. |
enable_backup_import | 7 | false | Triggers a one-time restore on apply. |
backup_source | 7 | 'gcs' | 'gcs' or 'gdrive'. |
backup_uri | 7 | "" | Full GCS URI or Google Drive file ID. |
backup_format | 7 | 'sql' | Backup file format. |
7. Platform-Managed Behaviours
| Behaviour | Implementation | Detail |
|---|---|---|
| PostgreSQL required | Fixed in OpenWebUI Common | Open WebUI requires PostgreSQL for session and state persistence. |
| WEBUI_SECRET_KEY auto-generated | OpenWebUI Common creates and stores in Secret Manager | Injected via module_secret_env_vars. Do not set manually. |
| DATABASE_URL assembled automatically | OpenWebUI Common entrypoint | Constructed from injected DB_* env vars. Do not override. |
| No Redis | module_env_vars = {} | Unlike Odoo or Moodle, no REDIS_* env vars are injected. enable_redis defaults to false. |
| Scripts directory | scripts_dir = abspath("${path.module}/scripts") | Init scripts reside in OpenWebUI_CloudRun/scripts/, not in OpenWebUI Common. |
8. Outputs
| Output | Description |
|---|---|
service_name | Name of the Cloud Run service. |
service_url | Public URL of the Cloud Run service. |
service_location | GCP region where the Cloud Run service is deployed. |
project_id | GCP project ID. |
deployment_id | Deployment ID suffix used in resource names. |
database_instance_name | Name of the Cloud SQL PostgreSQL instance. |
database_name | Name of the application database. |
database_user | Name of the application database user. |
database_password_secret | Secret Manager secret name for the database password. |
storage_buckets | Created GCS storage buckets. |
container_image | Container image used for the deployment. |
Configuration Pitfalls & Sensible Defaults
Risk levels: Critical (data loss, full outage, security breach) — High (service unavailable or significant degradation) — Medium (degraded function or increased cost) — Low (minor impact).
| Variable | Sensible Default | Risk | Consequence of Incorrect Value |
|---|---|---|---|
ollama_base_url | "" (disabled) | Critical | If neither ollama_base_url nor openai_api_base_url is set, Open WebUI starts but has no AI backend. All model requests fail with "No connection to Ollama" or equivalent. At least one backend URL must be provided for AI functionality. |
openai_api_base_url | "" (disabled) | High | Required for OpenAI-compatible backends (LiteLLM, OpenRouter, etc.). Must include the full path including /v1 (e.g., "https://api.openai.com/v1"). Omitting /v1 causes API call failures that are hard to diagnose. |
WEBUI_SECRET_KEY (auto-generated) | Random 32-char secret in Secret Manager | Critical | WEBUI_SECRET_KEY is used to sign all user sessions. Rotating or changing it after first use immediately invalidates all active sessions, logging out every user. Treat as immutable after the first login. Never set this to a predictable value. |
webui_auth | true | Critical | Setting to false disables the login form entirely — anyone who can reach the URL has full access without credentials. Only safe for single-user or fully air-gapped deployments behind IAP or VPN. |
default_user_role | "pending" | High | Setting to "user" auto-approves all self-registered accounts without admin review. In a publicly accessible deployment this allows unrestricted signups. Use "pending" and enable enable_iap for production. |
enable_signup | true | High | With webui_auth = true and default_user_role = "user", any visitor can self-register and immediately access all models. Set default_user_role = "pending" or enable_signup = false to restrict access. |
min_instance_count | 0 | Medium | Scale-to-zero causes 20–40 s cold starts (Cloud SQL connection + Python startup). For teams using Open WebUI interactively, set to 1 to keep a warm instance. |
memory_limit | 4Gi | High | Open WebUI's RAG pipeline (document ingestion with embedding models) can consume 3–6 Gi under load. If memory is insufficient, the container is OOM-killed mid-ingestion and the document import silently fails. |
db_host | Auto-discovered (Cloud SQL proxy socket) | Critical | Leaving empty with enable_cloudsql_volume = true works automatically. If set to a manual IP without the Cloud SQL proxy, SSL/IAM auth is bypassed and the connection may be rejected. |
enable_cloudsql_volume | true | Critical | Disabling while relying on Cloud SQL causes all database connections to fail. Only disable when connecting to an external PostgreSQL instance via TCP. |
ollama_base_url (format) | "http://<host>:11434" | High | Must not include a trailing slash and must be reachable from the Cloud Run VPC. If Ollama is on GKE, use the ClusterIP service DNS name (only reachable within the cluster — not from Cloud Run). Use the internal VPC IP or a shared VPC service instead. |
service_url | Auto-set from Cloud Run URL | Medium | Open WebUI uses WEBUI_URL for constructing share links and OAuth redirect URIs. If set incorrectly (e.g., to http:// in a TLS deployment), OAuth social logins and sharing links break. |
ingress_settings | "all" | High | "all" exposes the UI to the public internet. Combine with webui_auth = true and default_user_role = "pending" or enable IAP for access control. |
enable_iap | false | High | Without IAP, the only access control is Open WebUI's built-in auth. If webui_auth = false is set accidentally, the deployment is completely unprotected. |
timeout_seconds | 300 | Medium | Document ingestion and large model responses can exceed 5 minutes. Requests are cut off with a 504. Increase to 3600 for deployments handling large file uploads or slow LLM backends. |
execution_environment | "gen2" | High | NFS mounts and Direct VPC Egress are not supported in gen1. Always use gen2. |
database_type | "POSTGRES" | Critical | Open WebUI requires PostgreSQL. Changing to "MYSQL" or "NONE" leaves the application unable to store users, chats, or settings. |
gcs_volumes (data persistence) | Auto-provisioned GCS bucket | High | Open WebUI stores uploaded documents, user avatars, and model files in GCS Fuse. Unmounting or changing the bucket path without migrating existing data causes all uploaded content to disappear. |
enable_nfs | false | Medium | NFS is needed for shared file access when running multiple instances (max_instance_count > 1). Without shared storage, each instance has isolated file state and uploaded documents may not be visible across replicas. |
application_version | "latest" | Medium | Pinning to "latest" risks unintended upgrades that change the database schema. Open WebUI performs automatic schema migrations on startup; a failed migration crashes the container. Pin to a specific release tag in production. |
backup_schedule | "" (disabled) | High | Without automated backups, the PostgreSQL database (users, conversations, RAG index) is unprotected. Enable with a cron expression (e.g., "0 2 * * *") for daily backups. |
enable_auto_password_rotation | false | Medium | Enabling password rotation without configuring rotation_propagation_delay can cause a race condition where Cloud Run restarts before the new secret is available, resulting in connection errors. |
Destroying Resources
Known Deletion Issue: Serverless IPv4 Address Release
When destroying a Cloud Run deployment, you may encounter an error similar to:
Error: Error waiting for Subnetwork to be deleted: The following serverless IPv4 address(es) on subnet ... are still in use.
Resolution: Wait 20–30 minutes after the initial destroy attempt, then re-run tofu destroy. GCP releases serverless IPv4 addresses approximately 20–30 minutes after the Cloud Run service is deleted.
