OpenClaw on Google Cloud Run

OpenClaw is a multi-tenant AI agent gateway purpose-built for isolated, persistent agent deployments. It lets teams run per-tenant AI assistants backed by Anthropic models, with dedicated GCS workspaces and optional Telegram or Slack channel integration — all without shared state between agents. This module deploys OpenClaw on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure.

This guide focuses on the cloud services OpenClaw uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.

---

1. Overview

OpenClaw runs as a Node.js container on Cloud Run v2 (Gen2). The deployment wires together a focused set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	Cloud Run v2 (Gen2)	Node.js service, 1 vCPU / 1 GiB by default, CPU always allocated
Workspace storage	Cloud Storage (GCS Fuse)	Per-tenant workspace bucket mounted at /data via GCS Fuse
AI credentials	Secret Manager	Anthropic API key and gateway token always stored; Telegram and Slack secrets optional
Ingress	Cloud Run URL / Cloud Load Balancing	Internal by default (behind a router); optional external HTTPS LB + custom domain
Secrets	Secret Manager	All credentials injected at runtime; plaintext never in config

Sensible defaults worth knowing up front:

• No database, no Redis. OpenClaw is a stateful Node.js gateway backed entirely by GCS Fuse at /data. Cloud SQL and Redis are never provisioned.
• CPU is always allocated. cpu_always_allocated = true is required. WebSocket connections and async agent operations break under CPU throttling. Do not set to false.
• Gen2 execution environment is required. GCS Fuse volume mounts are not available in Gen1 and will silently fail.
• Custom container image is always built. The module layers an entrypoint.sh onto the upstream ghcr.io/openclaw/openclaw image.
• GCS workspace at /data is always mounted. A dedicated <prefix>-storage bucket is always provisioned and mounted. Persistent agent state lives here across container restarts.
• OPENCLAW_STATE_DIR is on local disk. npm staging and the XDG config home are redirected to /tmp/openclaw to avoid GCS Fuse hard-link limitations during startup.
• min_instance_count = 0 by default (scale-to-zero). Set to 1 for latency-sensitive agent deployments to avoid 15–20 s cold starts.
• max_instance_count = 1 per tenant. OpenClaw is stateful; multiple instances for the same tenant split state across replicas unless sticky routing is in place.
• Ingress defaults to internal. The gateway is designed to be fronted by an OpenClaw router. Set to all for direct public access.

---

2. Google Cloud Services & How to Explore Them

All commands assume PROJECT and REGION are set. Service and resource names are reported in the deployment Outputs.

A. Cloud Run — the OpenClaw service

OpenClaw runs as a Cloud Run v2 service on the Gen2 execution environment. CPU is always allocated to support WebSocket connections and async agent operations. Each deployment creates an immutable revision; traffic can be split across revisions for safe rollouts.

• Console: Cloud Run → select the service for revisions, traffic, logs, and metrics.
• CLI:

  gcloud run services list --project "$PROJECT" --region "$REGION"
  gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
  gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"

See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.

B. Cloud Storage — GCS Fuse workspace

All durable agent state is stored in a dedicated Cloud Storage bucket and mounted into the service at /data by GCS Fuse. The workspace layout is:

<prefix>-storage/
├── workspace/              ← agent workspace (/data/workspace)
│   └── skill-library/      ← shared skills repo (when skills_repo_url is set)
├── agents/main/agent/      ← agent state directory
└── ...

• Console: Cloud Storage → Buckets → select the <prefix>-storage bucket.
• CLI:

  gcloud storage buckets list --project "$PROJECT"
  gcloud storage ls gs://<prefix>-storage/

See App_CloudRun for the GCS Fuse mount, CMEK options, and bucket lifecycle.

C. Secret Manager — credentials

The Anthropic API key and the gateway token are always stored in Secret Manager. When Telegram or Slack integration is enabled, the bot tokens and webhook/signing secrets are stored there as well. All credentials are injected into the service at runtime.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT"
  # Retrieve the Anthropic key (initial deploy only; manage via Secret Manager thereafter):
  gcloud secrets versions access latest --secret=<prefix>-anthropic-api-key --project "$PROJECT"
  # Retrieve the gateway token (needed to register clients):
  gcloud secrets versions access latest --secret=<prefix>-gateway-token --project "$PROJECT"

See App_CloudRun for injection and rotation details.

D. Networking & ingress

The service is reachable at its run.app URL by default, restricted to internal VPC traffic (ingress_settings = "internal"). An external HTTPS load balancer with a custom domain, Cloud CDN, and Cloud Armor can be layered on.

• Console: Cloud Run (service URL); Network services → Load balancing.
• CLI:

  gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'
  gcloud compute addresses list --project "$PROJECT"

See App_CloudRun.

E. Cloud Logging & Monitoring

Container logs flow to Cloud Logging; Cloud Run metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50

---

3. OpenClaw Application Behaviour

• No database setup job. OpenClaw requires no Cloud SQL and no init job. The agent state lives entirely on GCS; the first container startup creates the workspace directories automatically via entrypoint.sh.
• Config regenerated on every startup. entrypoint.sh always rewrites openclaw.json in $OPENCLAW_STATE_DIR, ensuring the Terraform-managed environment variables (API keys, gateway token, channel settings) win over any stale values previously persisted on GCS.
• Skills repository sync (optional). When skills_repo_url is set, entrypoint.sh performs a shallow clone or update of the repository into /data/workspace/skill-library on every container startup. The sync is non-fatal — the gateway starts even if the clone fails. Check Cloud Logging for skill-library entries to verify sync status.
• Health path. Startup and liveness probes both target GET /health on port 8080. The startup probe allows ~2 minutes for GCS Fuse mount and Node.js startup.
• Telegram and Slack webhooks. When enable_telegram or enable_slack is set, the corresponding bot token is injected as TELEGRAM_BOT_TOKEN or SLACK_BOT_TOKEN. The webhook/signing secrets are stored in Secret Manager for a companion router service and are not injected into the agent container.
• Scale-to-zero and cold starts. With min_instance_count = 0, Telegram/Slack webhook events arriving during a cold start (15–20 s) may be dropped. Set min_instance_count = 1 for production agent deployments.

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for OpenClaw are listed; every other input is inherited from App_CloudRun with its standard behaviour.

Group 1 — Project & Identity

Variable	Default	Description
project_id	(required)	Target Google Cloud project.
region	us-central1	Region for the service and regional resources.
anthropic_api_key	(required on first deploy)	Anthropic API key. Stored in Secret Manager and injected as ANTHROPIC_API_KEY. Omit on updates to retain the stored value. Sensitive.
gateway_token	(auto-generated)	Gateway authentication token. A secure 64-character hex token is generated when left blank. Stored in Secret Manager as OPENCLAW_GATEWAY_TOKEN. Sensitive.

Group 2 — Deployment Environment

Variable	Default	Description
tenant_deployment_id	demo	Short suffix that makes resource names unique per environment.
support_users	[]	Emails granted project access and monitoring alerts.
resource_labels	{}	Labels applied to all resources.

Group 3 — Application Identity

Variable	Default	Description
application_name	openclaw	Base name for resources. Do not change after first deploy.
application_display_name	OpenClaw Gateway	Friendly name shown in the Console.
description	OpenClaw AI Gateway - Serverless multi-tenant AI agent gateway on Cloud Run	Service description.
application_version	latest	OpenClaw image tag used as the BASE_IMAGE build arg. Pin to a specific release for reproducible builds.

Group 4 — Runtime & Scaling

Variable	Default	Description
deploy_application	true	Set false to provision infrastructure only.
cpu_limit	1000m	CPU per instance.
memory_limit	1Gi	Memory per instance. Sized for light/typical usage (observed ~400Mi peak); raise to 2Gi for heavier concurrent agent sessions.
min_instance_count	0	0 enables scale-to-zero (15–20 s cold start). Set ≥ 1 to eliminate cold starts.
max_instance_count	1	Keep at 1 per tenant to avoid split-state. Increase only with sticky routing.
container_port	8080	Port the OpenClaw gateway listens on. Must match the PORT env var.
execution_environment	gen2	Gen2 required for GCS Fuse. Do not change to gen1.
cpu_always_allocated	true	Required for WebSocket connections and async operations. Do not set to false.
timeout_seconds	3600	Maximum request duration. Agent sessions are long-running; 3600 s is the maximum.
enable_cloudsql_volume	false	OpenClaw does not use Cloud SQL. Leave false.
traffic_split	[]	Canary/blue-green traffic allocation. All entries must sum to 100.
max_revisions_to_retain	7	Old revisions to keep after each deployment.

Group 5 — Access & Ingress Control

Variable	Default	Description
ingress_settings	all	internal for VPC-only (recommended behind a router); all for direct public access.
vpc_egress_setting	PRIVATE_RANGES_ONLY	VPC egress routing.
enable_iap	false	Require Google sign-in via Identity-Aware Proxy.
iap_authorized_users / iap_authorized_groups	[]	Who may access through IAP.

Group 6 — Environment Variables & Secrets

Variable	Default	Description
environment_variables	{}	Extra non-secret settings. Module-managed vars (OPENCLAW_STATE_DIR, NODE_ENV, etc.) always take precedence.
secret_environment_variables	{}	Map of env var → existing Secret Manager secret name. Core credentials are handled automatically.
secret_propagation_delay	30	Seconds to wait after secret creation before proceeding.
secret_rotation_period	2592000s	Rotation notification frequency (30 days).

Group 7 — Backup & Restore

Variable	Default	Description
backup_schedule	0 2 * * *	Cron for automated workspace backup (UTC).
backup_retention_days	7	Retention days; raise for production/compliance.
enable_backup_import / backup_source / backup_format	restore options	Import a workspace backup on deploy. backup_format defaults to tar.

Group 8 — CI/CD & Binary Authorization

Standard App_CloudRun Cloud Build / Cloud Deploy integration — see App_CloudRun. Key inputs: enable_cicd_trigger, github_repository_url, github_token, enable_cloud_deploy, enable_binary_authorization.

Group 10 — Load Balancer, CDN & Image Retention

Variable	Default	Description
enable_cloud_armor	false	Provision a Global HTTPS LB + Cloud Armor WAF.
admin_ip_ranges	[]	CIDRs exempted from WAF rules.
application_domains	[]	Custom domain names for the HTTPS LB.
enable_cdn	false	Enable Cloud CDN on the LB backend.
max_images_to_retain / delete_untagged_images / image_retention_days	(set)	Artifact Registry cleanup policy.

Group 11 — Storage & Filesystem

Variable	Default	Description
create_cloud_storage	true	Provision additional buckets defined in storage_buckets. The workspace bucket is always created.
storage_buckets	[]	Additional GCS buckets beyond the auto-provisioned workspace bucket.
enable_nfs	false	OpenClaw uses GCS Fuse for state. NFS is not required and disabled by default.
gcs_volumes	[]	Additional GCS Fuse mounts. The openclaw-data volume at /data is always appended.
manage_storage_kms_iam / enable_artifact_registry_cmek	false	CMEK options.

Group 13 — Jobs & Scheduled Tasks

Variable	Default	Description
initialization_jobs	[]	OpenClaw has no default init job. Use for custom workspace seeding.
cron_jobs	[]	Recurring Cloud Run jobs triggered by Cloud Scheduler.

Group 14 — Observability & Health

Variable	Default	Description
startup_probe / startup_probe_config	HTTP /health, 24-attempt threshold	Allows ~2 minutes for GCS Fuse mount and Node.js startup.
liveness_probe / health_check_config	HTTP /health	Restarts the container if the gateway becomes unresponsive.
uptime_check_config	{ enabled = false, path = "/health" }	Cloud Monitoring uptime check. Disabled by default; enable for production monitoring.
alert_policies	[]	Metric alert policies.

Group 15 — OpenClaw Configuration

Variable	Default	Description
skills_repo_url	""	GitHub URL of a shared skills repository. Cloned into /data/workspace/skill-library on every container startup. Leave empty to skip.
skills_repo_ref	main	Git ref (branch, tag, or SHA) to check out.
enable_telegram	false	Provision a Telegram bot token secret and inject TELEGRAM_BOT_TOKEN. Requires telegram_bot_token.
telegram_bot_token	""	Telegram bot token from @BotFather. Sensitive.
telegram_webhook_secret	""	Webhook validation secret for the router (not injected into the agent). Generate with openssl rand -hex 32. Sensitive.
enable_slack	false	Provision Slack secrets and inject SLACK_BOT_TOKEN. Requires slack_bot_token.
slack_bot_token	""	Slack bot token (xoxb-...). Sensitive.
slack_signing_secret	""	Slack signing secret for the router (not injected into the agent). Sensitive.

---

5. Outputs

Returned on a successful deployment — the quickest way to locate and explore the running resources.

Output	Description
service_name	Cloud Run service name.
service_url	Default run.app URL of the service.
service_location	Region the service runs in.
stage_services	Stage-specific service URLs (Cloud Deploy).
storage_buckets	Created Cloud Storage buckets (including the workspace bucket).
network_name / network_exists / regions	VPC network, presence, regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels / uptime_check_names	Monitoring status, channels, uptime checks.
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
initialization_jobs	Names of any custom init jobs.
cicd_enabled / cicd_configuration	CI/CD status and details.
github_repository_url / github_repository_owner / github_repository_name	Connected GitHub repo.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Setting	Sensible value	Risk	Consequence if wrong
anthropic_api_key	Set on first deploy	Critical	Without a valid key the agent starts but all AI requests fail with 401 errors.
gateway_token consistency	Auto-generated or set once	Critical	Rotating the token in Secret Manager without redeploying the service causes all client requests to be rejected until the service is redeployed.
enable_backup_import	false unless restoring	Critical	Enabling without a valid backup_uri fails the import job.
execution_environment	gen2	High	Gen1 does not support GCS Fuse; the workspace mount silently fails.
cpu_always_allocated	true	High	CPU throttling breaks WebSocket connections and async agent operations.
telegram_bot_token / slack_bot_token	set when integration enabled	High	Empty token causes all API calls to fail; messages are dropped.
telegram_webhook_secret / slack_signing_secret	set when integration enabled	High	Empty value disables signature verification, allowing fake webhook injection.
min_instance_count	1 for production agents	High	0 means webhook events from Telegram/Slack are dropped during cold start (15–20 s).
skills_repo_url	reachable URL or empty	High	An unreachable URL causes the git clone to fail at startup, restarting the container.
skills_repo_ref	existing ref	High	A non-existent branch or tag causes the clone to fail at every startup.
max_instance_count	1 per tenant	High	Multiple instances for the same tenant split agent state across replicas.
enable_iap	enable for admin-facing	Medium	The gateway is otherwise reachable at its run.app URL. Telegram/Slack webhook endpoints cannot authenticate with Google identity — ensure they are not behind IAP.
backup_retention_days	7 (raise for prod)	Medium	Too short for compliance; an accidental bucket purge permanently loses agent state.
enable_vpc_sc without organization_id	set explicitly	Medium	VPC-SC is silently skipped, leaving credentials without perimeter protection.

---

For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_CloudRun. OpenClaw- specific application configuration shared with the GKE variant is described in OpenClaw_Common.
