LobeChat on GKE Autopilot

LobeChat is an open-source, modern LLM chat UI (built with Next.js) that lets users converse with many model providers — OpenAI, Anthropic, Google, and others — through a single polished interface, with users supplying their own API keys client-side. This module deploys LobeChat on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services LobeChat uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

1. Overview

LobeChat runs as a single stateless Next.js web workload on Autopilot. Because its default client-stored mode keeps all state in the browser, the deployment wires together a deliberately minimal set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	Next.js pods, 500m vCPU / 1 GiB by default, horizontally autoscaled
Database	(none)	database_type = "NONE" — no Cloud SQL is provisioned; state lives in the browser
Object storage	(none)	Stateless — no GCS bucket, NFS mount, or PVC declared by default
Cache	Redis (optional, off)	Only for rate limiting / bot detection on public deployments
Secrets	Secret Manager (none by default)	LobeChat generates no secrets; inject provider keys yourself if desired
Ingress	Cloud Load Balancing	External LoadBalancer, optional custom domain + managed certificate

Sensible defaults worth knowing up front:

• No database, no secrets, no storage. LobeChat is stateless in client-stored mode — users add their own model API keys in the browser. There is nothing to back up and nothing to migrate. (An optional Postgres server mode exists upstream but is not wired by this module.)
• Port 3210 is fixed. The custom image pins PORT=3210 and container_port = 3210; do not change it without rebuilding the image.
• Default is 500m CPU / 1Gi memory (container_resources). LobeChat's Next.js SSR process (plus its pdfjs-dist/@napi-rs/canvas rendering deps) OOMs and CrashLoopBackOffs at 512Mi (JavaScript heap out of memory) — 1Gi is the floor for a stable boot; raise container_resources.memory_limit further under heavier load.
• Minimum 1 replica (min_instance_count = 1, forced by the wiring). GKE does not support scale-to-zero, so at least one pod is always running to keep the UI reachable; max_instance_count = 3.
• Stateless — Deployment, not StatefulSet. There is no persistent volume; pods can be replaced freely and scaled horizontally without a queue or cache prerequisite.
• service_type = LoadBalancer, session_affinity = None. With no server-side session state, requests need no sticky routing.
• Redis is optional and off. Enable it only to add rate limiting / bot detection in front of a public deployment.
• latest maps to a real image tag. The build ARG LOBECHAT_VERSION passes the version through unchanged, so application_version = "latest" resolves to the real lobehub/lobe-chat:latest.

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the LobeChat workload

LobeChat pods are scheduled on Autopilot, which bills for the CPU/memory the pods actually request. Horizontal Pod Autoscaling sizes the deployment between the minimum (1) and maximum replica counts.

• Console: Kubernetes Engine → Workloads → select the LobeChat workload to see pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
• CLI:

  kubectl get pods,svc,hpa -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100
  kubectl describe hpa -n "$NAMESPACE"          # current vs target utilisation

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. No database

LobeChat provisions no Cloud SQL instance — database_type = "NONE". In client-stored mode every conversation, setting, and provider key lives in the user's browser, so there is no server-side database to connect to, back up, or migrate, and no Cloud SQL Auth Proxy sidecar is injected. Enabling LobeChat's upstream Postgres server mode (for cross-device sync) is out of scope for this module.

C. No object storage or persistent volume

No GCS bucket, NFS mount, or block PVC is declared by default (storage_buckets is empty, enable_nfs = false, stateful_pvc_enabled unset/null). The workload is stateless; pods carry no persistent data.

• CLI (to confirm none are app-owned):

  gcloud storage buckets list --project "$PROJECT"
  kubectl get pvc -n "$NAMESPACE"          # none expected

D. Redis (optional — rate limiting / bot detection)

Redis is disabled by default (enable_redis = false). Enable it only to add rate limiting and bot detection in front of a public LobeChat instance. When enable_redis = true and redis_host is empty, the app falls back to 127.0.0.1 unless the NFS-co-located Redis is used — set redis_host (or enable_nfs = true) explicitly.

• Console: Memorystore → Redis (if using a managed instance).
• CLI:

  redis-cli -h <redis-host> ping
  # Confirm the Redis env injected into the running pod:
  kubectl exec -n "$NAMESPACE" deploy/<service-name> -- env | grep -i redis

E. Secret Manager

LobeChat generates no secrets — there are no cryptographic keys to protect. Secret Manager (via the Secret Store CSI driver) is used only if you choose to inject a server-side provider key (e.g. OPENAI_API_KEY) via secret_environment_variables, which references a secret you create.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~lobechat"
  gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"

See App_GKE for the Secret Store CSI integration and rotation.

F. Networking & ingress

By default the workload is exposed through an external Cloud Load Balancing IP (service_type = LoadBalancer). A custom domain with a Google-managed certificate can be enabled, and a static IP reserved so the address survives redeploys.

• Console: Network services → Load balancing; VPC network → IP addresses.
• CLI:

  kubectl get ingress,svc -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

G. Cloud Logging & Monitoring

Pod stdout/stderr flow to Cloud Logging; GKE metrics flow to Cloud Monitoring. Optional uptime checks and alert policies are available.

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. LobeChat Application Behaviour

• No first-deploy database setup. There is no db-init job and no schema — the initialization_jobs output is empty. First boot simply starts the Next.js server.
• No migrations. With no server-side database in the default mode, upgrading application_version just rolls out a new image; there is no schema to migrate.
• No admin account / no default credentials. LobeChat client-stored mode has no server-side user store. The only access gate is the optional ACCESS_CODE shared passphrase (see below); without it the UI is open to anyone who reaches the LoadBalancer IP.
• Users supply their own model keys. Each user pastes provider API keys into the UI, held in browser localStorage. To preconfigure a server-side provider instead, inject e.g. OPENAI_API_KEY (as a secret) and/or OPENAI_PROXY_URL via secret_environment_variables / environment_variables.
• Gate access with ACCESS_CODE. For any externally exposed deployment, set a shared passphrase so the chat UI (and any keys users paste) are not exposed:

  # via the module: environment_variables = { ACCESS_CODE = "<passphrase>" }
  # verify it reached the running pod:
  kubectl exec -n "$NAMESPACE" deploy/<service-name> -- env | grep ACCESS_CODE

• Health path. Startup, liveness, and readiness probes target / — the LobeChat Next.js server returns HTTP 200 there once booted, with no auth. Allow the default startup window for the next-server cold start.
• Fixed port 3210. The custom image pins PORT=3210; container_port must stay 3210.
• imagePullPolicy = Always for the mirrored image. App_GKE forces Always for custom-built/mirrored images so a rebuilt tag is re-pulled on redeploy rather than serving a stale cached layer.

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for LobeChat are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 3 — Application Identity

Variable	Default	Description
application_name	lobechat	Base name for resources. Do not change after first deploy.
application_version	latest	LobeChat image tag; latest maps to the real lobehub/lobe-chat:latest. Pin a specific tag in production.

Group 4 — Runtime & Scaling

Variable	Default	Description
deploy_application	true	Set false to provision infrastructure only.
container_resources	500m CPU / 1Gi memory	Per-pod requests/limits. Next.js next-server (plus pdfjs-dist/canvas rendering deps) OOM-crashes at boot under 1Gi — raise memory further if you see the same failure under load.
min_instance_count	1	Minimum replicas (GKE has no scale-to-zero); keeps the UI reachable.
max_instance_count	3	Safe to raise — no shared server-side state or queue prerequisite.
container_port	3210	LobeChat's Next.js server port. Do not change without rebuilding the image.
enable_image_mirroring	true	Mirror lobehub/lobe-chat into Artifact Registry.

Group 5 — Environment Variables & Secrets

Variable	Default	Description
environment_variables	{}	Optional overrides — notably ACCESS_CODE (gate the UI) and provider/theme defaults.
secret_environment_variables	{}	Map of env var → Secret Manager secret name. Use this for any server-side provider key (e.g. OPENAI_API_KEY).

Group 6 — GKE Backend & Cluster

Variable	Default	Description
service_type	LoadBalancer	How the Kubernetes Service is exposed.
workload_type	null	Resolves to a stateless Deployment — LobeChat needs no per-pod PVCs.
session_affinity	None	No server-side session state, so no sticky routing is required.

Group 7 — StatefulSet

Variable	Default	Description
stateful_pvc_enabled	null	Leave unset — LobeChat is stateless in client-stored mode; there is no data to persist per pod.

Group 15 — Redis Cache

Variable	Default	Description
enable_redis	false	Enable only for rate limiting / bot detection on public deployments.
redis_host	""	Redis endpoint. Set explicitly when enable_redis = true (empty falls back to 127.0.0.1).
redis_port	6379	Redis port.

The Database Backend, Backup & Maintenance, Filesystem (NFS), and Cloud Storage groups exist for convention mirroring but are inert — database_type = "NONE" and no buckets/volumes are declared, so those inputs create no resources. All other inputs follow standard App_GKE behaviour.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip	In-cluster ClusterIP.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific services.
service_external_ip	External LoadBalancer IP (when a static IP is reserved).
service_url	URL to reach LobeChat.
storage_buckets	Created Cloud Storage buckets (empty by default).
network_name / network_exists / regions	VPC network, presence, available regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
initialization_jobs	Names of setup jobs (empty — LobeChat has none).
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / cicd_configuration	CI/CD status and details (repo, trigger, registry).
github_repository_url / github_repository_owner / github_repository_name	CI/CD GitHub details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time — a workload_type = "Deployment" alongside stateful_pvc_enabled = true, IAP with no authorized identities, binary memory-quota units, an out-of-range redis_port. Invalid configuration fails the plan with a clear, named error before any resource is created.

Setting	Sensible value	Risk	Consequence if wrong
ACCESS_CODE	Set on any exposed deployment	High	Without it the chat UI — and any provider keys users paste — is open to anyone who reaches the LoadBalancer IP.
container_resources memory	1Gi (floor)	High	Below 1 GiB, Next.js next-server OOM-crashes at boot (JavaScript heap out of memory) and the pod never becomes Ready.
container_port	3210	High	The image pins PORT=3210; a mismatch means the probe never connects and the pod fails to start.
Server-side provider keys	Inject via secret_environment_variables	High	Putting an API key in plain environment_variables exposes it in the pod spec and logs.
min_instance_count	1	High	GKE requires min ≥ 1; the validation guard rejects 0. Keeping 1 ensures the UI stays reachable.
stateful_pvc_enabled	leave unset (null)	Medium	Enabling a PVC adds pointless per-pod storage — LobeChat persists nothing server-side in the default mode.
enable_redis	false unless public	Medium	Enabling without a reachable redis_host (empty → 127.0.0.1) leaves rate limiting non-functional.
quota_memory_requests / _limits	binary units (4Gi, 8192Mi)	Critical	Bare integers are bytes and block all pod scheduling in the namespace.
application_version	Pin a tag in prod	Medium	latest moves with upstream; a surprise release can change behaviour on the next rollout.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, and image mirroring — see App_GKE. LobeChat-specific application configuration shared with the Cloud Run variant is described in LobeChat_Common.
