Crawl4AI on Google Cloud Run

Crawl4AI is an open-source LLM-friendly web crawler and scraper. This module deploys Crawl4AI on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure.

This guide focuses on the cloud services Crawl4AI uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.

---

What Crawl4AI costs on RAD, and how that compares

Crawl4AI on RAD's Cloud Run module costs about US$22.33 a month in a Google Cloud project you own, plus a one-time 40-credit module fee (US$4). Crawl4AI is an open-source, LLM-friendly web crawler and scraper for RAG ingestion pipelines. GKE Autopilot suits Crawl4AI that must stay up, scale across pods, or run beside other Kubernetes workloads; for the lowest cost, this Cloud Run module is usually the right pick — see the GKE guide if you need the other.

If Crawl4AI is only needed occasionally — a demo, a trial, a seasonal or study workload — a RAD-managed project can be deleted and restored within 30 days for a handful of credits, so that US$22.33 becomes a few dollars a month instead. See Pause it for free, below.

What you pay on RAD

	In a Google Cloud project you own	In a project RAD manages for you
Module fee, once per deployment	40 credits (US$4 at the top-up price)	36 credits (10% lower)
Build time	A few credits per build (roughly 3–6)	The same
Google Cloud running cost	Billed by Google to your own billing account, about US$22.33 a month for the default configuration (table below)	Metered hourly in credits; RAD publishes 3 credits a day, about 90 a month (about US$9 at the top-up price)
Who owns what	You own the project and its billing; RAD deploys and updates it	RAD owns the project, with guardrails, quotas and budget alerts; you get console access, and a minimum purchased balance is held in reserve

10 credits cost US$1 on a one-off top-up, less on a plan. In a project RAD manages, the database, file server and network are shared by every application in the project, so a second application does not add a second database.

Default running cost in your own project (us-central1, Google list prices):

Resource (module default)	Per month
Cloud Run, 1x vCPU / 4 GiB (scaleToZero)	US$16.33
Cloud NAT and networking	US$5
Cloud Storage (add-ons, backups)	US$1
Total	about US$22.33

How it compares

• Run it yourself and a VPS running Crawl4AI's own container costs less in cash: sized to roughly 1 vCPU/4 GiB, a comparable VPS (Hetzner or DigitalOcean) runs about $24–48 a month, or a GCP e2-standard-2-class VM about $49 — plus your own time for backups, security patches and upgrades, which RAD's managed Cloud SQL, Secret Manager and monitoring cover for you.
• RAD never claims to be cheaper than bare infrastructure in cash terms — it usually is not. The difference is what RAD manages for you: patching, backups, secrets and monitoring, plus the ability to pause Crawl4AI for free rather than paying for idle capacity (see below).

Pause it for free: delete a RAD-managed project, restore it when you need it

If Crawl4AI runs in a project RAD manages for you, you have a second option that goes well beyond scaling to zero: delete the whole project, and restore it within 30 days for close to nothing. This suits Crawl4AI that you only need occasionally far better than running it continuously.

• How it works. Deleting a RAD-managed project unlinks its billing first, then asks Google to delete the project. Google does not remove the project immediately: it keeps it, recoverable, for 30 days. Because billing is already unlinked, nothing is charged while it waits. Unlike deleting one module, this does not tear down Cloud Run resources one by one — the whole project, and everything in it, simply stops.
• Restoring costs a handful of credits, not a rebuild. Within 30 days, the project's owner can restore it. RAD asks Google to undelete the project and reattaches its billing account, then asks you to run Update on each deployment to confirm everything came back. Because nothing was individually destroyed, that Update finds the same resources already there — it is a check, not a rebuild, and an Update never charges the module fee again. That is a handful of credits (under US$1) in total for a typical Crawl4AI chain, against the 45 credits a full redeploy costs.
• So a month of occasional use can cost a few dollars, not US$22.33. Deploy Crawl4AI, use it, delete the project. Restore it next time you want it, confirm with Update, and delete it again when you're done. You pay only for the module fee once, the builds, and whatever hours it was actually live.
• What this needs. You must own the project (not a bring-your-own one RAD only manages billing for), and you restore it yourself within the 30 days — after that, Google deletes it for good. Restoring is admitted like creating a new project: your purchased credit balance must still clear the tier's floor (100 credits for the sandbox tier most study and demo use fits). Google says most services are fully working again within 36 hours of a restore.
• One real gap: the backup bucket does not survive. Nightly backups are written to a bucket inside the project, and that bucket is not protected by Cloud Storage's soft-delete, so it is very likely gone as soon as you delete the project — even though the project itself is recoverable for 30 days. If you have customised Crawl4AI and want to keep that work, copy a backup out (to Google Drive, or a bucket outside the project) before you delete. For a default installation with nothing irreplaceable in it, this does not matter.

Pay only while you use it, the other way: delete and redeploy

Cloud Run already scales to zero between requests. The option above only applies to a RAD-managed project; in your own project, or once the 30-day window has passed, the way to stop paying is to delete the deployment and deploy it again when you need it.

• What a redeploy costs. The module fee again plus the builds: about 45 credits (US$4.50) in your own project. Deleting saves money only once Crawl4AI would otherwise sit unused for about 7 days or more in your own project (US$0.74 a day), or about 14 days or more in a RAD-managed one (3 credits a day).
• Keep your data first. Nightly backups are written to a bucket inside the deployment and are deleted with it, so copy the latest backup out before deleting if you want to keep it.
• Note your settings. RAD does not recreate a deleted deployment for you; you enter the settings again when you deploy.

Lab sessions and Managed Environments

• Lab sessions, for training. A trainer runs a session for a class. Each participant gets the app in their own Google Cloud project for 15 minutes to 24 hours, within an allowance the trainer sets. Either the trainer funds every place, or each participant pays for their own. Everything is deleted when the session ends and unused credits go back to the trainer.
• Managed Environments, for consultancies. A partner runs the app for a client from a ring-fenced wallet it funds, and settles with the client directly. If the wallet runs low, billing pauses and the data is kept, so nobody receives an unexpected charge. At the end the partner hands the project over and the deployments become the client's own.

Credits can be bought in more than 20 currencies, including XAF, XOF, NGN, GHS, KES and ZAR, by card, bank transfer or mobile money.

Sources (8 October 2026): Google Cloud list prices from the Cloud Billing Catalog API; RAD's own fees and daily-credit estimates from radmodules.dev/pricing; Delete and restore projects for the 30-day recovery window and what it says about Cloud Storage objects without soft delete. Prices change; check each source before relying on a figure.

1. Overview

Crawl4AI runs as a Python/ASGI container on Cloud Run v2 Gen2. The deployment wires together a focused set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	Cloud Run v2 (Gen2)	Python service, 1 vCPU / 4 GiB by default, request-based autoscaling
Task queue	Embedded Redis (in-container)	Supervisord starts Redis inside the container; ephemeral per instance
ASGI server	Embedded Gunicorn (in-container)	Port 11235, managed by supervisord alongside Redis
Object storage	Cloud Storage	Optional buckets for crawl result caching (none by default)
Secrets	Secret Manager	API keys and JWT secret injected at runtime
Ingress	Cloud Run URL / Cloud Load Balancing	Default run.app URL, optional external HTTPS load balancer + custom domain

Sensible defaults worth knowing up front:

• No external database. database_type is fixed to NONE — Cloud SQL is not provisioned. All task state lives in the in-container Redis instance and is lost when the container restarts.
• Gen2 is required. Supervisord needs a full Linux process tree, and Chromium uses /tmp for shared memory via --disable-dev-shm-usage. Gen1 cannot support this.
• ALL_TRAFFIC egress is required. The crawler must reach arbitrary public URLs on the internet; PRIVATE_RANGES_ONLY blocks all external crawl targets.
• Redis runs inside the container. Do not set REDIS_HOST or REDIS_PORT as environment variables — they must stay at localhost:6379 to reach the bundled instance.
• Security is off by default. JWT authentication requires providing a SECRET_KEY via secret_environment_variables and a custom config.yml with security.jwt_enabled=true.

---

2. Google Cloud Services & How to Explore Them

All commands assume PROJECT and REGION are set. Service and resource names are reported in the deployment Outputs.

A. Cloud Run — the Crawl4AI service

Crawl4AI runs as a Cloud Run v2 Gen2 service that autoscales by request load between the minimum and maximum instance counts. Each deployment creates an immutable revision; traffic can be split across revisions for safe rollouts. Each instance runs its own supervisord tree: Redis (priority 10) starts first, then Gunicorn (priority 20).

• Console: Cloud Run → select the service for revisions, traffic, logs, and metrics.
• CLI:

  gcloud run services list --project "$PROJECT" --region "$REGION"
  gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
  gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"

See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.

B. Embedded Redis and task queue

Redis runs inside each container instance as a supervisord-managed process on localhost:6379. It stores task results with a configurable TTL (redis_task_ttl_seconds, default 3600 s). Task results are lost when the container restarts — this is expected for an ephemeral crawl API. There is no Memorystore instance; the embedded Redis does not appear in the Console.

There is no direct shell access on Cloud Run, but you can observe Redis behaviour from logs:

gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" \
  --filter="supervisord" --limit 50

C. Cloud Storage (optional)

Crawl4AI has no default GCS bucket — it is stateless. Optional buckets can be provisioned via storage_buckets to store crawl results or custom config.yml files.

• Console: Cloud Storage → Buckets.
• CLI:

  gcloud storage buckets list --project "$PROJECT"
  gcloud storage ls gs://<results-bucket>/

See App_CloudRun for GCS Fuse mounts and CMEK.

D. Secret Manager

LLM API keys and the JWT signing secret are stored as Secret Manager secrets and injected into the service at runtime; plaintext never appears in configuration. Crawl4AI has no auto-generated secrets — all secrets must be provided via secret_environment_variables.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT"
  gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"

Recognised secret names (pass the Secret Manager secret name, not the value): SECRET_KEY, OPENAI_API_KEY, ANTHROPIC_API_KEY, DEEPSEEK_API_KEY, GROQ_API_KEY, GEMINI_API_KEY, LLM_API_KEY.

See App_CloudRun for injection and rotation details.

E. Networking & ingress

The service is reachable at its run.app URL by default with ingress_settings = "all". An external HTTPS load balancer with a custom domain, Cloud CDN, and Cloud Armor can be layered on. VPC egress is set to ALL_TRAFFIC so the crawler can reach arbitrary public URLs.

• Console: Cloud Run (service URL); Network services → Load balancing.
• CLI:

  gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'
  gcloud compute addresses list --project "$PROJECT"

See App_CloudRun.

F. Cloud Logging & Monitoring

Container logs (Python output streamed via PYTHONUNBUFFERED=1) flow to Cloud Logging. Cloud Run metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50

---

3. Crawl4AI Application Behaviour

• Supervisord startup sequence. On every container start, supervisord (PID 1) starts Redis first (priority 10), then Gunicorn (priority 20). The /health endpoint only responds after both processes are ready — allow at least 40 seconds of initial delay before health checks start.

• REST API endpoints. Crawl4AI exposes:

  Endpoint	Method	Purpose
  /crawl	POST	Submit an asynchronous crawl job; returns a task_id
  /task/{id}	GET	Poll status and retrieve results for a task
  /crawl/sync	POST	Synchronous crawl (blocks until complete)
  /health	GET	Health check — returns {"status":"ok"} when ready
  /playground	GET	Interactive browser-based crawl UI

• Task result lifecycle. Async crawl results are stored in the embedded Redis with a TTL of redis_task_ttl_seconds (default 1 hour). After the TTL expires the result is gone. There is no durable result store.

• No database migrations or initialization jobs. Crawl4AI is fully stateless — Crawl4AI_Common supplies no initialization job. No database setup is required.

• LLM-based extraction. Provide LLM API keys via secret_environment_variables and set LLM_PROVIDER (or provider-specific keys such as OPENAI_API_KEY) via environment_variables to enable AI-driven content extraction.

• JWT authentication (optional). Security is disabled by default. To enable, supply SECRET_KEY via secret_environment_variables and provide a custom config.yml with security.jwt_enabled=true. The /token endpoint issues short-lived JWTs when authentication is enabled.

• CRAWL4AI_HOOKS_ENABLED warning. Setting this variable to "true" enables arbitrary Python code execution via webhook hooks. Only enable in a fully trusted environment.

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Crawl4AI are listed; every other input is inherited from App_CloudRun with its standard behaviour.

Group 1 — Project & Identity

Variable	Default	Description
project_id	(required)	Target Google Cloud project.
region	us-central1	Region for the service and regional resources.

Group 2 — Deployment Environment

Variable	Default	Description
tenant_id	demo	Short suffix that makes resource names unique per environment.
support_users	[]	Emails granted project access and monitoring alerts.
resource_labels	{}	Labels applied to all resources.

Group 3 — Application Identity

Variable	Default	Description
application_name	crawl4ai	Base name for resources. Do not change after first deploy.
application_display_name	Crawl4AI Web Crawler	Friendly name shown in the Console.
description	(set)	Service description.
application_version	0.7.8	Crawl4AI image version tag; pin to a specific tag for production.

Group 4 — Runtime & Scaling

Variable	Default	Description
deploy_application	true	Set false to provision infrastructure only without deploying the container.
cpu_limit	1000m	CPU per instance; ~0.5–1 vCPU per active browser context.
memory_limit	4Gi	Memory per instance. Minimum 4 GiB for stable Chromium operation; 8 GiB recommended for concurrent crawls.
min_instance_count	0	Minimum instances. Set to 1 for a warm Chromium pool; default 0 causes 30–60 s cold starts.
max_instance_count	3	Maximum instances (cost ceiling).
cpu_always_allocated	false	Request-based billing — a crawl runs synchronously within its HTTP request with no post-response background work, so CPU throttling between requests is safe.
execution_environment	gen2	Required — Gen2 for supervisord's process tree and Chromium's /tmp shared memory.
timeout_seconds	3600	Maximum request duration; set to the Cloud Run maximum to allow long batch crawl jobs.
container_protocol	http1	HTTP protocol version.
enable_image_mirroring	true	Mirror the Crawl4AI image to Artifact Registry to avoid Docker Hub rate limits.
traffic_split	[]	Percentage-based canary/blue-green traffic allocation across revisions.

Group 5 — Access & Networking

Variable	Default	Description
ingress_settings	all	Traffic sources permitted to reach the service. Use "internal-and-cloud-load-balancing" when fronted by Cloud Armor.
vpc_egress_setting	ALL_TRAFFIC	Required — routes all outbound traffic through the VPC so the crawler can reach arbitrary public URLs.
enable_iap	false	Require Google sign-in via Identity-Aware Proxy.
iap_authorized_users / iap_authorized_groups	[]	Who may access through IAP.
enable_cloud_armor	false	Provision a Global HTTPS Load Balancer with Cloud Armor WAF.
application_domains	[]	Custom hostnames for the external load balancer.
enable_cdn	false	Enable Cloud CDN on the LB backend.

Group 6 — Environment Variables & Secrets

Variable	Default	Description
environment_variables	{}	Extra non-secret settings. PYTHONUNBUFFERED and REDIS_TASK_TTL are set automatically. Do not set REDIS_HOST or REDIS_PORT. Recognised overrides: LLM_PROVIDER, LLM_BASE_URL, LLM_TEMPERATURE, CRAWL4AI_HOOKS_ENABLED.
secret_environment_variables	{}	Map of env var → Secret Manager secret name. Use for SECRET_KEY, OPENAI_API_KEY, ANTHROPIC_API_KEY, etc.
secret_propagation_delay	30	Seconds to wait after secret creation before proceeding.
secret_rotation_period	2592000s	Secret Manager rotation notification frequency.

Group 7 — Backup & Restore

Not applicable for Crawl4AI — the service is stateless and carries no database. backup_schedule, backup_retention_days, and enable_backup_import are present for interface compatibility but have no effect.

Group 8 — CI/CD & Binary Authorization

Standard App_CloudRun Cloud Build / Cloud Deploy integration — see App_CloudRun. Key inputs: enable_cicd_trigger, github_repository_url, github_token, enable_cloud_deploy, enable_binary_authorization.

Group 9 — Jobs & Custom SQL

Variable	Default	Description
initialization_jobs	[]	Crawl4AI_Common supplies no default init job — leave empty unless a custom setup step is needed.
cron_jobs	[]	Optional recurring Cloud Run Jobs triggered by Cloud Scheduler.
enable_custom_sql_scripts	false	Not applicable for Crawl4AI (no database).

Group 11 — Storage & Filesystem

Variable	Default	Description
create_cloud_storage	true	Provision any buckets listed in storage_buckets.
storage_buckets	[]	No buckets by default — Crawl4AI is stateless. Add entries to provision crawl-result buckets.
enable_nfs	false	Provision a Filestore NFS volume. Not required for standard Crawl4AI deployments.
gcs_volumes	[]	GCS Fuse mounts.
manage_storage_kms_iam / enable_artifact_registry_cmek	false	CMEK options.

Group 12 — Database Backend

Variable	Default	Description
database_type	NONE	Fixed — no Cloud SQL instance is provisioned for Crawl4AI.

All other database variables (enable_cloudsql_volume, database_password_length, etc.) are present for interface compatibility and have no effect.

Group 14 — Observability & Health

Variable	Default	Description
startup_probe_config / startup_probe	HTTP /health, 40 s delay	Allow supervisord time to start Redis then Gunicorn before the first probe fires.
health_check_config / liveness_probe	HTTP /health, 60 s delay	Liveness probe after startup.
uptime_check_config	disabled by default, path /health	Cloud Monitoring uptime check.
alert_policies	[]	Optional metric alert policies.
max_images_to_retain / delete_untagged_images / image_retention_days	(set)	Artifact Registry cleanup policy.

Group 19 — Crawl4AI Application Settings

Variable	Default	Description
redis_task_ttl_seconds	3600	TTL in seconds for task results in embedded Redis. Valid range: 300–86400. Too short causes results to expire before clients poll; too long causes unbounded memory growth.

---

5. Outputs

Returned on a successful deployment — the quickest way to locate and explore the running resources.

Output	Description
service_name	Cloud Run service name.
service_url	Default run.app URL of the service.
service_location	Region the service runs in.
stage_services	Stage-specific service URLs (Cloud Deploy).
load_balancer_ip / load_balancer_url	External HTTPS load balancer IP / URL (when enabled).
storage_buckets	Created Cloud Storage buckets.
network_name / network_exists / regions	VPC network, presence, regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels / uptime_check_names	Monitoring status, channels, uptime checks.
initialization_jobs	Names of any setup jobs.
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / github_repository_url / github_repository_owner / github_repository_name / cicd_configuration	CI/CD status and details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Setting	Sensible value	Risk	Consequence if wrong
vpc_egress_setting	ALL_TRAFFIC	Critical	Using PRIVATE_RANGES_ONLY blocks all external crawl targets; every crawl to a public URL fails with a connection error.
memory_limit	8Gi	Critical	Below 4 GiB, Chromium processes are OOM-killed mid-crawl returning partial results; below 2 GiB the container fails to start.
REDIS_HOST / REDIS_PORT (env vars)	do not set	Critical	Overriding these breaks the embedded Redis connection; all async crawl jobs fail immediately.
database_type	NONE	Critical	Crawl4AI has no database; changing this causes unnecessary Cloud SQL provisioning and a startup failure.
execution_environment	gen2	High	Gen1 cannot run supervisord's process tree; the service fails to deploy with VPC network configuration.
min_instance_count	1	High	Scale-to-zero (0) causes 30–60 s cold starts (supervisord must boot Redis then Gunicorn); the first request typically times out.
cpu_limit	4000m	High	Below 2000m, Chromium rendering triggers internal timeouts on complex pages; crawl throughput drops significantly.
enable_iap / enable_cloud_armor	enable for production	High	With ingress_settings = "all", the API is publicly accessible and anyone can submit crawl jobs consuming cloud resources.
LLM_API_KEY / provider API keys	via secret_environment_variables	High	Missing or expired keys cause LLM-based extraction to fail silently (empty extracted_content). Inject as secrets, not plain-text env vars.
redis_task_ttl_seconds	3600	Medium	Too short (< 300 s) causes results to expire before async clients poll; too long causes unbounded memory growth. Valid range: 300–86400.
timeout_seconds	3600	Medium	Deep crawls or LLM extraction of large pages can take several minutes; reduce only for short-lived APIs where zombie requests should be terminated faster.
application_version	pinned tag	Medium	Using "latest" is non-reproducible; a rebuild may pull a breaking Crawl4AI API change.
enable_image_mirroring	true	Low	Crawl4AI images are large; without mirroring, every deployment pulls from Docker Hub and risks rate-limit failures and slow cold starts.

---

For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, and image mirroring — see App_CloudRun. Crawl4AI-specific shared application configuration is described in Crawl4AI_Common.

Related guides

• Hands-on lab: Crawl4AI on Cloud Run — deploy it step by step, with the console screens and commands at each stage.
• Crawl4AI on GKE Autopilot — the same application on Kubernetes, for when you need the other deployment target.
• Crawl4AI Common — Shared Application Configuration — the configuration shared by both deployment targets.
• Deployed alongside Elasticsearch on GKE Autopilot, RAGFlow on GKE Autopilot, Qdrant on Google Cloud Run, Paperless-ngx on Google Cloud Run in the Enterprise RAG & Document Intelligence solution.
