Ollama GKE Module — Configuration Guide

Ollama is an open-source LLM inference server that serves large language models such as Llama, Mistral, Gemma, and Phi via a REST API on port 11434. This module deploys Ollama on GKE Autopilot as a Kubernetes Deployment with model weights persisted to a GCS Fuse volume so that pod restarts load models from storage rather than re-downloading them.

Ollama GKE is a wrapper module built on top of App GKE. It delegates all GCP infrastructure provisioning to App GKE (GKE cluster, networking, GCS, Secret Manager, CI/CD) and uses an Ollama Common sub-module to supply Ollama-specific application configuration, the GCS models bucket, and the optional model-pull initialization job. The Ollama Common outputs feed into App GKE's application_config, module_storage_buckets, and scripts_dir inputs.

Ollama GKE is designed as a shared in-cluster AI inference endpoint. Any pod in the same cluster namespace calls the API via the internal ClusterIP service URL http://ollama.<namespace>.svc.cluster.local:11434. For CPU-only, serverless inference use Ollama CloudRun.

---

§1 · Module Overview

What Ollama GKE provides

• An Ollama Kubernetes Deployment (prebuilt image ollama/ollama, mirrored to Artifact Registry when enable_image_mirroring = true) with a ClusterIP service on port 11434.
• A GCS bucket (<resource_prefix>-models) mounted via GCS Fuse CSI driver at /mnt/gcs. OLLAMA_MODELS is set to /mnt/gcs/ollama/models so weights persist across pod restarts.
• An optional model-pull Kubernetes Job that starts a local Ollama server in the background, pulls the specified model, and stores it in the GCS bucket. Runs when default_model is non-empty and initialization_jobs = [].
• Horizontal Pod Autoscaler (HPA) between min_instance_count and max_instance_count.
• No database, no Redis — Ollama is stateless beyond its GCS-backed model cache.

Key differences from App GKE defaults

Feature	App GKE default	Ollama GKE default
container_port	8080	11434 (set by Ollama Common)
container_resources.cpu_limit	"1000m"	"8"
container_resources.memory_limit	"512Mi"	"16Gi"
container_resources.cpu_request	"500m"	"4"
container_resources.mem_request	"256Mi"	"8Gi"
min_instance_count	1	1
max_instance_count	3	3
service_type	"ClusterIP"	"ClusterIP"
enable_redis	varies	always false (hard-coded)
Database	varies	NONE (via database_type)
GCS models bucket	none	auto-provisioned via Ollama Common
Model-pull job	none	auto-generated when default_model is set
Auto-injected env vars	none	OLLAMA_MODELS, OLLAMA_HOST, OLLAMA_KEEP_ALIVE

---

§2 · IAM & Project Identity

Variable	Type	Default	Description
project_id	string	required	GCP project into which all resources are deployed.
tenant_deployment_id	string	"demo"	Short suffix appended to resource names. 1–20 lowercase letters, numbers, hyphens.
resource_creator_identity	string	"rad-module-creator@tec-rad-ui-2b65.iam.gserviceaccount.com"	Service account used by Terraform.
support_users	list(string)	[]	Email addresses granted IAM access and monitoring alert recipients.
resource_labels	map(string)	{}	Labels applied to all module-managed resources.
deployment_region	string	"us-central1"	GCP region fallback when network discovery cannot determine region from VPC subnets. Also used as the GCS bucket region.
module_description	string	(Ollama GKE description)	Platform UI description.
module_documentation	string	"https://docs.radmodules.dev/docs/modules/Ollama_GKE"	External documentation URL.
module_dependency	list(string)	["Services GCP"]	Modules that must be deployed before this one.
module_services	list(string)	(GCP service list)	GCP services consumed by this module.
credit_cost	number	150	Platform credits consumed on deployment.
require_credit_purchases	bool	false	Enforce credit balance check before deployment.
enable_purge	bool	true	Permit full deletion of all module resources on destroy.
public_access	bool	true	Controls platform UI visibility.
deployment_id	string	""	Optional fixed deployment ID. Auto-generated when blank.

---

§3 · Core Service Configuration

§3.A · Application Identity (Group 2)

Variable	Type	Default	Description
application_name	string	"ollama"	Base name for Kubernetes resources and GCS bucket. Do not change after initial deployment.
application_display_name	string	"Ollama LLM Server"	Human-readable name shown in the platform UI.
application_description	string	"Ollama — standalone open-source LLM inference server on GKE..."	Brief description surfaced in Kubernetes annotations.
application_version	string	"latest"	Ollama Docker image tag. Use a pinned tag in production.

§3.B · Ollama Model Configuration (Group 18)

Variable	Type	Default	Description
default_model	string	""	Model to pull on first deployment. Examples: "llama3.2:3b", "mistral", "phi3:mini". Leave empty to skip the auto-pull job.
model_pull_timeout_seconds	number	3600	Timeout for the model-pull init job. Large models take 20–30 minutes on first pull. Valid range: 300–7200.

When default_model is set and initialization_jobs is empty, a Kubernetes Job named model-pull is created automatically using the scripts/model-pull.sh script from Ollama Common. The job mounts the ollama-models GCS volume so pulled weights persist.

§3.C · Runtime & Scaling (Group 3)

Variable	Type	Default	Description
deploy_application	bool	true	Set false to provision storage and IAM without deploying the Kubernetes workload.
workload_type	string	"Deployment"	Kubernetes workload type. "Deployment" is recommended for GCS-backed Ollama. Use "StatefulSet" only when local PVC storage is preferred over GCS.
container_resources	object	{ cpu_limit="8", memory_limit="16Gi", cpu_request="4", mem_request="8Gi" }	Container CPU and memory configuration. For 3B models: cpu_limit="4", memory_limit="8Gi". For 7B models: cpu_limit="8", memory_limit="16Gi".
min_instance_count	number	1	Minimum pod replicas. 1 keeps a warm instance for low-latency inference.
max_instance_count	number	3	Maximum pod replicas for HPA.
timeout_seconds	number	300	Kubernetes pod termination grace period seconds. Increase for long inference requests. Valid range: 0–3600.
termination_grace_period_seconds	number	60	Seconds Kubernetes waits before force-killing the pod after a SIGTERM.
service_type	string	"ClusterIP"	Kubernetes Service type. "ClusterIP" keeps the API internal (recommended). "LoadBalancer" for external access only. Options: ClusterIP, LoadBalancer, NodePort.
session_affinity	string	"None"	Session affinity for the Kubernetes Service. "ClientIP" routes all requests from the same client IP to the same pod.
enable_image_mirroring	bool	true	Mirror ollama/ollama to Artifact Registry to avoid Docker Hub rate limits.
enable_vertical_pod_autoscaling	bool	false	Enable VPA to automatically adjust CPU/memory requests. Recommended for GKE Autopilot.
container_image_source	string	"prebuilt"	Image source: "prebuilt" uses ollama/ollama directly; "custom" triggers a Cloud Build.
container_image	string	"ollama/ollama"	Full container image URI when container_image_source = "prebuilt".
container_build_config	object	{ enabled=false }	Cloud Build configuration when container_image_source = "custom".
container_protocol	string	"http1"	HTTP protocol version.
service_annotations	map(string)	{}	Custom annotations applied to the Kubernetes service.
service_labels	map(string)	{}	Custom labels applied to the Kubernetes service.
enable_cloudsql_volume	bool	false	Not needed for Ollama. Required by the App GKE interface.
cloudsql_volume_mount_path	string	"/cloudsql"	Cloud SQL Auth Proxy socket path. Present for interface compatibility.

§3.D · Automatically Injected Environment Variables

The following environment variables are set automatically by Ollama Common:

Variable	Value	Purpose
OLLAMA_MODELS	"/mnt/gcs/ollama/models"	Points Ollama at the GCS Fuse subdirectory for model persistence.
OLLAMA_HOST	"0.0.0.0:11434"	Binds to all interfaces so the Kubernetes service can forward traffic.
OLLAMA_KEEP_ALIVE	"24h"	Keeps loaded model resident in memory between requests.

§3.E · Environment Variables & Secrets (Group 5)

Variable	Type	Default	Description
environment_variables	map(string)	{}	Additional plain-text env vars. The three Ollama vars above are injected automatically.
secret_environment_variables	map(string)	{}	Map of env var name → Secret Manager secret name.
secret_propagation_delay	number	30	Seconds to wait after secret creation. Valid range: 0–300.
secret_rotation_period	string	"2592000s"	Rotation notification period (30 days). Set null to disable.
enable_auto_password_rotation	bool	false	Not applicable for Ollama (no database).
rotation_propagation_delay_sec	number	90	Seconds to wait after rotation before restarting pods.

§3.F · Access & Networking (Group 4)

Variable	Type	Default	Description
enable_iap	bool	false	Enable Identity-Aware Proxy.
iap_authorized_users	list(string)	[]	Users granted access through IAP.
iap_authorized_groups	list(string)	[]	Google Groups granted access through IAP.
iap_oauth_client_id	string	""	OAuth 2.0 client ID for IAP (required for GKE IAP).
iap_oauth_client_secret	string	""	OAuth 2.0 client secret for IAP. Sensitive.
iap_support_email	string	""	Support email shown on the IAP consent screen.
enable_cloud_armor	bool	false	Enable Cloud Armor WAF.
cloud_armor_policy_name	string	""	Name of an existing Cloud Armor security policy.
application_domains	list(string)	[]	Custom domain names for the load balancer.
enable_custom_domain	bool	false	Configure a custom domain for the application.
enable_cdn	bool	false	Enable Cloud CDN on the load balancer.
reserve_static_ip	bool	false	Reserve a static external IP for the load balancer.
static_ip_name	string	""	Name of the reserved static IP. Auto-generated when empty.
enable_vpc_sc	bool	false	Enable VPC Service Controls perimeter enforcement.
vpc_cidr_ranges	list(string)	[]	VPC subnet CIDR ranges for VPC-SC.
vpc_sc_dry_run	bool	true	Log VPC-SC violations without blocking.
organization_id	string	""	GCP Organization ID for VPC-SC policy.
enable_audit_logging	bool	false	Enable detailed Cloud Audit Logs.
admin_ip_ranges	list(string)	[]	CIDR ranges for administrative access.

---

§4 · GKE-Specific Configuration (Group 15)

Variable	Type	Default	Description
gke_cluster_name	string	""	Name of an existing GKE Autopilot cluster. Uses the Services GCP-managed cluster when empty.
namespace_name	string	""	Kubernetes namespace for the Ollama deployment. Auto-generated from the application name when empty.
enable_pod_disruption_budget	bool	true	Create a PodDisruptionBudget to maintain availability during node upgrades.
pdb_min_available	number	1	Minimum pods available during voluntary disruptions.
enable_network_segmentation	bool	false	Apply Kubernetes NetworkPolicies to restrict pod-to-pod traffic.
configure_service_mesh	bool	false	Configure Anthos Service Mesh (Istio) for traffic management and mTLS.
network_tags	list(string)	[]	GCP network tags applied to GKE nodes for firewall rule matching.
deployment_timeout	number	600	Seconds to wait for the Kubernetes Deployment to become ready.
enable_resource_quota	bool	false	Apply Kubernetes ResourceQuota to the namespace.

---

§5 · StatefulSet Settings (Group 16)

These settings apply only when workload_type = "StatefulSet". The default "Deployment" workload type with GCS Fuse is recommended and these are not needed.

Variable	Type	Default	Description
stateful_pvc_enabled	bool	false	Provision a PVC for local model storage. Not required when using GCS Fuse.
stateful_pvc_size	string	"50Gi"	PVC size (e.g. "100Gi" for multiple large models).
stateful_pvc_mount_path	string	"/mnt/data"	Container path for the PVC.
stateful_pvc_storage_class	string	"standard-rwo"	Kubernetes StorageClass for the PVC.
stateful_headless_service	bool	false	Create a headless service for the StatefulSet.
stateful_pod_management_policy	string	"OrderedReady"	Pod management: "OrderedReady" or "Parallel".
stateful_update_strategy	string	"RollingUpdate"	StatefulSet update strategy.

---

§6 · Storage & Filesystem (Group 10)

Variable	Type	Default	Description
create_cloud_storage	bool	true	Provision GCS buckets in storage_buckets. The models bucket is always created.
storage_buckets	list(object)	[]	Additional GCS buckets beyond the Ollama models bucket.
enable_nfs	bool	false	Provision and mount Cloud Filestore NFS. Not required for Ollama.
nfs_mount_path	string	"/mnt/nfs"	Filesystem path for the NFS volume.
nfs_instance_name	string	""	Name of an existing NFS GCE VM. Auto-discovered when empty.
nfs_instance_base_name	string	"app-nfs"	Base name for an inline NFS GCE VM.
gcs_volumes	list(object)	[]	Additional GCS buckets to mount as GCS Fuse volumes. The ollama-models bucket is always appended.
manage_storage_kms_iam	bool	false	Create a CMEK KMS key for GCS encryption.
enable_artifact_registry_cmek	bool	false	Enable CMEK encryption for Artifact Registry.

GCS volume layout:

<resource_prefix>-models/          ← GCS bucket root
└── ollama/
    └── models/                    ← /mnt/gcs/ollama/models (OLLAMA_MODELS)

---

§7 · Backup & Maintenance (Group 6)

Ollama has no database — backup settings are present for App GKE interface compatibility only.

Variable	Type	Default	Description
backup_schedule	string	""	Not applicable for Ollama.
backup_retention_days	number	7	Days to retain backup files.
enable_backup_import	bool	false	Not applicable for Ollama.
backup_source	string	"gcs"	"gcs" or "gdrive".
backup_uri	string	""	Location of the backup file.
backup_format	string	"sql"	Format: sql, tar, gz, tgz, tar.gz, zip, auto.

---

§8 · CI/CD Integration (Group 7)

Variable	Type	Default	Description
enable_cicd_trigger	bool	false	Create a Cloud Build trigger on GitHub pushes.
github_repository_url	string	""	Full HTTPS URL of the GitHub repository.
github_token	string	""	GitHub Personal Access Token. Sensitive.
github_app_installation_id	string	""	Cloud Build GitHub App installation ID.
cicd_trigger_config	object	{ branch_pattern = "^main$" }	Branch filter, trigger name, and build substitutions.
enable_cloud_deploy	bool	false	Switch to a Cloud Deploy pipeline.
cloud_deploy_stages	list(object)	[dev, staging, prod(approval)]	Ordered promotion stages.
enable_binary_authorization	bool	false	Enforce Binary Authorization for signed container images.

---

§9 · Custom Initialization & Jobs (Group 8)

Variable	Type	Default	Description
enable_custom_sql_scripts	bool	false	Not applicable for Ollama.
custom_sql_scripts_bucket	string	""	GCS bucket containing SQL scripts.
custom_sql_scripts_path	string	""	Path prefix within the bucket.
custom_sql_scripts_use_root	bool	false	Execute scripts as root database user.
initialization_jobs	list(object)	[]	Kubernetes Jobs executed once during deployment. When non-empty, overrides the auto-generated model-pull job.
cron_jobs	list(object)	[]	Recurring Kubernetes CronJobs.
additional_services	list(any)	[]	Additional containers deployed as separate Kubernetes Deployments with ClusterIP services (e.g. a Qdrant vector database alongside Ollama).

---

§10 · Database Backend (Group 11)

Ollama has no database dependency. Redis is also disabled for this module.

Variable	Type	Default	Description
database_password_length	number	32	Not used. Present for interface compatibility. Valid range: 16–64.
enable_postgres_extensions	bool	false	Not applicable for Ollama.
postgres_extensions	list(string)	[]	Not applicable for Ollama.
enable_mysql_plugins	bool	false	Not applicable for Ollama.
mysql_plugins	list(string)	[]	Not applicable for Ollama.
database_type	string	"NONE"	Always "NONE" for Ollama — no Cloud SQL instance is provisioned.

Hard-coded values (not user-configurable):

• enable_redis = false

---

§11 · Observability & Health (Group 13)

Ollama's root endpoint (/) returns "Ollama is running" once the server is ready.

Variable	Type	Default	Description
startup_probe	object	{ enabled=true, type="HTTP", path="/", initial_delay_seconds=30, timeout_seconds=5, period_seconds=15, failure_threshold=20 }	Startup probe forwarded through Ollama Common to the container spec. The 20-attempt threshold allows up to ~5 minutes for model loading from GCS.
liveness_probe	object	{ enabled=true, type="HTTP", path="/", initial_delay_seconds=60, timeout_seconds=5, period_seconds=30, failure_threshold=3 }	Liveness probe. 60 s initial delay avoids false restarts during model loading.
startup_probe_config	object	{ enabled=true }	Structured startup probe passed directly to App GKE (300 s timeout by default).
health_check_config	object	{ enabled=true, initial_delay_seconds=60 }	Structured liveness probe passed directly to App GKE.
uptime_check_config	object	{ enabled=true, path="/", check_interval="60s", timeout="10s" }	Cloud Monitoring uptime check.
alert_policies	list(object)	[]	Cloud Monitoring alert policies.

---

§12 · Outputs

Output	Description
service_name	Kubernetes service name.
service_url	Service URL (LoadBalancer or ClusterIP).
namespace	Kubernetes namespace containing the Ollama deployment.
ollama_cluster_url	Internal Kubernetes URL for the Ollama API: http://<service_name>.<namespace>.svc.cluster.local:11434. Other pods in the same cluster call this URL.
service_cluster_ip	ClusterIP of the Kubernetes service.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific Kubernetes services (Cloud Deploy).
service_external_ip	External LoadBalancer IP when reserve_static_ip = true.
models_bucket	GCS bucket name where Ollama model weights are persisted.
storage_buckets	All provisioned GCS buckets.
network_name	VPC network name.
network_exists	Whether the VPC network exists.
regions	Available regions in the VPC.
container_image	Container image URI.
container_registry	Artifact Registry repository name.
deployment_id	Unique deployment identifier.
tenant_id	Tenant identifier.
resource_prefix	Resource naming prefix.
project_id	GCP project ID.
project_number	GCP project number.
monitoring_enabled	Whether Cloud Monitoring is configured.
monitoring_notification_channels	Monitoring notification channel names.
uptime_check_names	Uptime check names (returns [] for GKE).
initialization_jobs	Created initialization job names.
cron_jobs	Created cron job names.
statefulset_name	StatefulSet name when workload_type = "StatefulSet".
nfs_server_ip	NFS server internal IP (sensitive).
nfs_mount_path	NFS mount path in containers.
nfs_share_path	NFS share path on server.
nfs_setup_job	NFS setup job name.
db_import_job	Database import job name.
deployment_summary	Summary of the deployment.
cicd_enabled	Whether CI/CD pipeline is enabled.
github_repository_url	Connected GitHub repository URL.
github_repository_owner	GitHub repository owner.
github_repository_name	GitHub repository name.
artifact_registry_repository	Artifact Registry repository.
cloudbuild_trigger_name	Cloud Build trigger name.
cloudbuild_trigger_id	Cloud Build trigger ID.
cicd_configuration	CI/CD pipeline configuration details.
kubernetes_ready	true when the GKE cluster endpoint is available and all workload resources have been deployed. false on first apply of a new cluster.

---

§13 · Platform-Managed Behaviours

Behaviour	Detail
OLLAMA_MODELS injected	Set to /mnt/gcs/ollama/models. Do not set this in environment_variables.
OLLAMA_HOST injected	Set to "0.0.0.0:11434" for Kubernetes service forwarding.
OLLAMA_KEEP_ALIVE injected	Set to "24h". Override by setting OLLAMA_KEEP_ALIVE in environment_variables.
Models bucket always provisioned	The <resource_prefix>-models GCS bucket is always created, regardless of create_cloud_storage or storage_buckets settings.
GCS volume always mounted	The ollama-models volume is always appended to gcs_volumes inside Ollama Common.
No database, no Redis	enable_redis = false and database_type = "NONE" are hard-coded.
Model-pull job auto-generated	When default_model is set and initialization_jobs = [], a Kubernetes Job (model-pull) is created using scripts/model-pull.sh. Providing any entry in initialization_jobs disables it.
Network discovery	The module uses the App_Common/modules/app_networking module to discover the VPC region from existing subnets. The first discovered region is used as deployment_region. Falls back to var.deployment_region when no subnets are found.
Namespace auto-generated	When namespace_name = "", the namespace defaults to <resource_prefix> (the full app<name><tenant><id> string).
scripts_dir	Set to Ollama Common's bundled scripts/ directory.

---

§14 · Variable Reference

Complete variable reference with UIMeta group assignments.

Variable	Default	Group
module_description	(Ollama GKE description)	0
module_documentation	"https://docs.radmodules.dev/docs/modules/Ollama_GKE"	0
module_dependency	["Services GCP"]	0
module_services	(list of GCP services)	0
credit_cost	150	0
require_credit_purchases	false	0
enable_purge	true	0
public_access	true	0
deployment_id	""	0
resource_creator_identity	"rad-module-creator@..."	0
project_id	(required)	1
tenant_deployment_id	"demo"	1
support_users	[]	1
resource_labels	{}	1
deployment_region	"us-central1"	1
application_name	"ollama"	2
application_display_name	"Ollama LLM Server"	2
application_description	"Ollama — standalone open-source LLM inference server on GKE..."	2
application_version	"latest"	2
deploy_application	true	3
workload_type	"Deployment"	3
container_resources	{ cpu_limit="8", memory_limit="16Gi", cpu_request="4", mem_request="8Gi" }	3
min_instance_count	1	3
max_instance_count	3	3
timeout_seconds	300	3
termination_grace_period_seconds	60	3
service_type	"ClusterIP"	3
session_affinity	"None"	3
enable_image_mirroring	true	3
enable_vertical_pod_autoscaling	false	3
container_image_source	"prebuilt"	3
container_image	"ollama/ollama"	3
container_build_config	{ enabled=false }	3
container_protocol	"http1"	3
service_annotations	{}	3
service_labels	{}	3
enable_cloudsql_volume	false	3
cloudsql_volume_mount_path	"/cloudsql"	3
enable_iap	false	4
iap_authorized_users	[]	4
iap_authorized_groups	[]	4
iap_oauth_client_id	""	4
iap_oauth_client_secret	""	4
iap_support_email	""	4
enable_cloud_armor	false	4
cloud_armor_policy_name	""	4
application_domains	[]	4
enable_custom_domain	false	4
enable_cdn	false	4
reserve_static_ip	false	4
static_ip_name	""	4
enable_vpc_sc	false	4
vpc_cidr_ranges	[]	4
vpc_sc_dry_run	true	4
organization_id	""	4
enable_audit_logging	false	4
admin_ip_ranges	[]	4
environment_variables	{}	5
secret_environment_variables	{}	5
secret_propagation_delay	30	5
secret_rotation_period	"2592000s"	5
enable_auto_password_rotation	false	5
rotation_propagation_delay_sec	90	5
backup_schedule	""	6
backup_retention_days	7	6
enable_backup_import	false	6
backup_source	"gcs"	6
backup_uri	""	6
backup_format	"sql"	6
enable_cicd_trigger	false	7
github_repository_url	""	7
github_token	""	7
github_app_installation_id	""	7
cicd_trigger_config	{ branch_pattern = "^main$" }	7
enable_cloud_deploy	false	7
cloud_deploy_stages	[dev, staging, prod(approval)]	7
enable_binary_authorization	false	7
enable_custom_sql_scripts	false	8
custom_sql_scripts_bucket	""	8
custom_sql_scripts_path	""	8
custom_sql_scripts_use_root	false	8
initialization_jobs	[]	8
cron_jobs	[]	8
additional_services	[]	8
create_cloud_storage	true	10
storage_buckets	[]	10
enable_nfs	false	10
nfs_mount_path	"/mnt/nfs"	10
nfs_instance_name	""	10
nfs_instance_base_name	"app-nfs"	10
gcs_volumes	[]	10
manage_storage_kms_iam	false	10
enable_artifact_registry_cmek	false	10
database_password_length	32	11
enable_postgres_extensions	false	11
postgres_extensions	[]	11
enable_mysql_plugins	false	11
mysql_plugins	[]	11
database_type	"NONE"	11
startup_probe_config	{ enabled=true }	13
health_check_config	{ enabled=true, initial_delay_seconds=60 }	13
uptime_check_config	{ enabled=true, path="/" }	13
alert_policies	[]	13
startup_probe	{ path="/", initial_delay_seconds=30, failure_threshold=20 }	13
liveness_probe	{ path="/", initial_delay_seconds=60, failure_threshold=3 }	13
gke_cluster_name	""	15
namespace_name	""	15
enable_pod_disruption_budget	true	15
pdb_min_available	1	15
enable_network_segmentation	false	15
configure_service_mesh	false	15
network_tags	[]	15
deployment_timeout	600	15
enable_resource_quota	false	15
stateful_pvc_enabled	false	16
stateful_pvc_size	"50Gi"	16
stateful_pvc_mount_path	"/mnt/data"	16
stateful_pvc_storage_class	"standard-rwo"	16
stateful_headless_service	false	16
stateful_pod_management_policy	"OrderedReady"	16
stateful_update_strategy	"RollingUpdate"	16
default_model	""	18
model_pull_timeout_seconds	3600	18

---

§15 · Configuration Examples

Basic Deployment

CPU-only inference for 3B models. Suitable for evaluation and shared internal cluster use.

# config/basic.tfvars
resource_creator_identity = ""
project_id               = "my-gcp-project-id"
tenant_deployment_id     = "demo"
application_name         = "ollama"

container_resources = {
  cpu_limit    = "8"
  memory_limit = "16Gi"
  cpu_request  = "4"
  mem_request  = "8Gi"
}

min_instance_count = 1
max_instance_count = 3

service_type = "ClusterIP"

default_model = "llama3.2:3b"

Advanced Deployment

Production inference endpoint for 7B models with pod disruption budget, monitoring, and environment tuning.

# config/advanced.tfvars
resource_creator_identity    = ""
project_id                   = "my-gcp-project-id"
tenant_deployment_id         = "prod"
application_name             = "ollama"
application_display_name     = "Ollama LLM Server"
application_version          = "latest"

container_resources = {
  cpu_limit    = "8"
  memory_limit = "16Gi"
  cpu_request  = "6"
  mem_request  = "12Gi"
}

min_instance_count = 1
max_instance_count = 5

workload_type = "Deployment"
service_type  = "ClusterIP"

default_model              = "mistral"
model_pull_timeout_seconds = 3600

environment_variables = {
  OLLAMA_NUM_PARALLEL = "2"
  OLLAMA_KEEP_ALIVE   = "24h"
}

enable_pod_disruption_budget = true
pdb_min_available            = 1

support_users = ["ops@example.com"]
resource_labels = {
  env     = "production"
  team    = "ai-platform"
  service = "ollama"
}

enable_image_mirroring = true

Configuration Pitfalls & Sensible Defaults

Risk levels: Critical (data loss, full outage, security breach) — High (service unavailable or significant degradation) — Medium (degraded function or increased cost) — Low (minor impact).

Variable	Sensible Default	Risk	Consequence of Incorrect Value
container_resources.memory_limit	16Gi (7B) / 8Gi (3B)	Critical	Insufficient memory causes OOM-kill mid-inference and crash-loops the pod. GKE Autopilot will not schedule the pod if the requested memory exceeds node capacity. Allocate at least 2× the quantised model weight size.
container_resources.cpu_limit	8 (7B) / 4 (3B)	High	Too few CPUs causes multi-second token latency on large models. For production throughput on 7B models, 6–8 cores are recommended.
container_resources (GPU)	CPU-only defaults	High	The module documentation notes NVIDIA L4 GPU support. To enable GPU inference, you must provision an NVIDIA L4 node pool in the GKE Autopilot cluster (outside this module) and add nvidia.com/gpu: 1 as a resource request via container_resources. Without this, GPU acceleration is silently not used and inference runs on CPU.
min_instance_count	1	High	Setting to 0 allows scale-to-zero but causes 60–120 s cold starts (GCS Fuse mount + model load). Inappropriate for low-latency inference workloads.
model_pull_timeout_seconds	3600	High	A short timeout (e.g., 300) causes the model-pull Kubernetes Job to fail before the download completes for models larger than ~2 GB. The service starts but no default model is loaded.
default_model	"" (skip pull)	Medium	If no model is pulled at deploy time, the Ollama API returns an error on all inference requests until a model is manually pulled.
workload_type	null (auto-select)	Medium	Using "StatefulSet" without enabling stateful_pvc_enabled results in pods with no persistent local storage. Conversely, setting stateful_pvc_enabled = true while specifying workload_type = "Deployment" fails at plan time.
service_type	"ClusterIP"	Critical	Setting service_type = "LoadBalancer" exposes the Ollama API (port 11434) publicly without authentication. Ollama has no built-in auth. Always keep ClusterIP for internal cluster-only access.
environment_variables.OLLAMA_ORIGINS	"*" (Ollama default)	High	If not explicitly restricted, CORS accepts any origin. Set to the specific UI origins (e.g., "http://openwebui.namespace.svc.cluster.local:8080") to prevent cross-cluster or external browser access to the API.
environment_variables.OLLAMA_KEEP_ALIVE	"5m" (Ollama default)	Medium	Ollama evicts models from GPU/CPU memory after 5 minutes idle. Subsequent requests trigger a full reload (30–60 s). Set to "24h" or "-1" for always-warm deployments.
environment_variables.OLLAMA_NUM_PARALLEL	1	Medium	Serialises all inference requests. For shared cluster deployments with multiple callers (OpenWebUI, Flowise, N8N), increase to 2–4 based on available CPU/memory.
stateful_pvc_enabled	false	Medium	Using GCS Fuse (default) means model weight loading at startup incurs network latency. A local PVC (StatefulSet) eliminates this but prevents pod migration during node pool upgrades.
quota_memory_requests / quota_memory_limits	"16Gi" / "32Gi"	Critical	Must use binary unit suffixes (Gi, Mi). A bare integer (e.g., "4") is treated as bytes by Kubernetes and will block all pod scheduling in the namespace.
enable_pod_disruption_budget	true	Medium	With pdb_min_available = 1 and only one replica, rolling node upgrades stall because Kubernetes cannot evict the single pod. Ensure max_instance_count ≥ 2 when using a PDB with pdb_min_available = 1.
deployment_timeout	600	High	The default 600 s wait for the Deployment to become ready may be insufficient when pulling a large model (13B+) from GCS for the first time. Increase to 1200 for models over 8 GB.
session_affinity	"None"	Low	Setting to "ClientIP" routes all requests from the same caller to the same pod, which improves context continuity for multi-turn conversations but unevenly distributes load across replicas.
enable_resource_quota	false	Medium	Without a ResourceQuota, a misconfigured or runaway Ollama pod can consume all cluster resources. Enable and tune quotas in shared clusters.
enable_image_mirroring	true	Medium	Disabling pulls directly from Docker Hub (rate-limited). Keep true in production.
gcs_volumes mount options	implicit-dirs	Medium	Without implicit-dirs in GCS Fuse mount options, directory listings fail and Ollama cannot discover models stored in GCS subdirectories.
max_instance_count	3	High	Each pod independently loads the full model into memory. For a 7B model (16 GiB each), three replicas require 48 GiB of cluster memory. Size the node pool accordingly or cap at 1 for large models.
