Crawl4AI on GKE Autopilot

Crawl4AI on GKE Autopilot

Crawl4AI is an open-source LLM-friendly web crawler and scraper. This module deploys Crawl4AI on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services Crawl4AI uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.


What Crawl4AI costs on RAD, and how that compares​

Crawl4AI on RAD's GKE Autopilot module costs about US$164.69 a month in a Google Cloud project you own, plus a one-time 175-credit module fee (US$17.50). Crawl4AI is an open-source, LLM-friendly web crawler and scraper for RAG ingestion pipelines. For the lowest cost, the Cloud Run guide runs the same Crawl4AI for about US$22.33 a month; pick GKE here only if Crawl4AI must stay up continuously, scale across pods, or run beside other Kubernetes workloads.

If Crawl4AI is only needed occasionally — a demo, a trial, a seasonal or study workload — a RAD-managed project can be deleted and restored within 30 days for a handful of credits, so that US$164.69 becomes a few dollars a month instead. See Pause it for free, below.

What you pay on RAD​

In a Google Cloud project you ownIn a project RAD manages for you
Module fee, once per deployment175 credits (US$17.50 at the top-up price)157.5 credits (10% lower)
Build timeA few credits per build (roughly 3–6)The same
Google Cloud running costBilled by Google to your own billing account, about US$164.69 a month for the default configuration (table below)Metered hourly in credits; RAD publishes 117 credits a day, about 3510 a month (about US$351 at the top-up price)
Who owns whatYou own the project and its billing; RAD deploys and updates itRAD owns the project, with guardrails, quotas and budget alerts; you get console access, and a minimum purchased balance is held in reserve

10 credits cost US$1 on a one-off top-up, less on a plan. In a project RAD manages, the database, file server and network are shared by every application in the project, so a second application does not add a second database.

Default running cost in your own project (us-central1, Google list prices):

Resource (module default)Per month
GKE Autopilot pod, 4x vCPU / 8 GiBUS$158.69
Cloud NAT and networkingUS$5
Cloud Storage (add-ons, backups)US$1
GKE cluster management feeshared across every GKE app in the project; $0 if this is your only cluster, else ~73
Totalabout US$164.69

How it compares​

  • Run it yourself and a VPS running Crawl4AI's own container costs less in cash: sized to roughly 4 vCPU/8 GiB, a comparable VPS (Hetzner or DigitalOcean) runs about $24–48 a month, or a GCP e2-standard-2-class VM about $49 — plus your own time for backups, security patches and upgrades, which RAD's managed Cloud SQL, Secret Manager and monitoring cover for you.
  • RAD never claims to be cheaper than bare infrastructure in cash terms — it usually is not. The difference is what RAD manages for you: patching, backups, secrets and monitoring, plus the ability to pause Crawl4AI for free rather than paying for idle capacity (see below).

Pause it for free: delete a RAD-managed project, restore it when you need it​

If Crawl4AI runs in a project RAD manages for you, you have a second option that goes well beyond scaling to zero: delete the whole project, and restore it within 30 days for close to nothing. This suits Crawl4AI that you only need occasionally far better than running it continuously.

  • How it works. Deleting a RAD-managed project unlinks its billing first, then asks Google to delete the project. Google does not remove the project immediately: it keeps it, recoverable, for 30 days. Because billing is already unlinked, nothing is charged while it waits. Unlike deleting one module, this does not tear down GKE Autopilot resources one by one — the whole project, and everything in it, simply stops.
  • Restoring costs a handful of credits, not a rebuild. Within 30 days, the project's owner can restore it. RAD asks Google to undelete the project and reattaches its billing account, then asks you to run Update on each deployment to confirm everything came back. Because nothing was individually destroyed, that Update finds the same resources already there — it is a check, not a rebuild, and an Update never charges the module fee again. That is a handful of credits (under US$1) in total for a typical Crawl4AI chain, against the 180 credits a full redeploy costs.
  • So a month of occasional use can cost a few dollars, not US$164.69. Deploy Crawl4AI, use it, delete the project. Restore it next time you want it, confirm with Update, and delete it again when you're done. You pay only for the module fee once, the builds, and whatever hours it was actually live.
  • What this needs. You must own the project (not a bring-your-own one RAD only manages billing for), and you restore it yourself within the 30 days — after that, Google deletes it for good. Restoring is admitted like creating a new project: your purchased credit balance must still clear the tier's floor (100 credits for the sandbox tier most study and demo use fits). Google says most services are fully working again within 36 hours of a restore.
  • One real gap: the backup bucket does not survive. Nightly backups are written to a bucket inside the project, and that bucket is not protected by Cloud Storage's soft-delete, so it is very likely gone as soon as you delete the project — even though the project itself is recoverable for 30 days. If you have customised Crawl4AI and want to keep that work, copy a backup out (to Google Drive, or a bucket outside the project) before you delete. For a default installation with nothing irreplaceable in it, this does not matter.

Pay only while you use it, the other way: delete and redeploy​

GKE Autopilot keeps at least one pod running, so it never scales to zero on its own. The option above only applies to a RAD-managed project; in your own project, or once the 30-day window has passed, the way to stop paying is to delete the deployment and deploy it again when you need it.

  • What a redeploy costs. The module fee again plus the builds: about 180 credits (US$18) in your own project. Deleting saves money only once Crawl4AI would otherwise sit unused for about 4 days or more in your own project (US$5.49 a day), or about 2 days or more in a RAD-managed one (117 credits a day).
  • Keep your data first. Nightly backups are written to a bucket inside the deployment and are deleted with it, so copy the latest backup out before deleting if you want to keep it.
  • Note your settings. RAD does not recreate a deleted deployment for you; you enter the settings again when you deploy.

Lab sessions and Managed Environments​

  • Lab sessions, for training. A trainer runs a session for a class. Each participant gets the app in their own Google Cloud project for 15 minutes to 24 hours, within an allowance the trainer sets. Either the trainer funds every place, or each participant pays for their own. Everything is deleted when the session ends and unused credits go back to the trainer.
  • Managed Environments, for consultancies. A partner runs the app for a client from a ring-fenced wallet it funds, and settles with the client directly. If the wallet runs low, billing pauses and the data is kept, so nobody receives an unexpected charge. At the end the partner hands the project over and the deployments become the client's own.

Credits can be bought in more than 20 currencies, including XAF, XOF, NGN, GHS, KES and ZAR, by card, bank transfer or mobile money.

Sources (8 October 2026): Google Cloud list prices from the Cloud Billing Catalog API; RAD's own fees and daily-credit estimates from radmodules.dev/pricing; Delete and restore projects for the 30-day recovery window and what it says about Cloud Storage objects without soft delete. Prices change; check each source before relying on a figure.

1. Overview​

Crawl4AI runs as a Python/ASGI service managed by supervisord. The deployment wires together a focused set of Google Cloud services:

CapabilityGoogle Cloud serviceNotes
ComputeGKE AutopilotPython pods, 4 vCPU / 8 GiB by default, horizontally autoscaled
Task queueEmbedded Redis (in-pod)Supervisord starts Redis inside the container; ephemeral per pod
ASGI serverEmbedded Gunicorn (in-pod)Port 11235, managed by supervisord alongside Redis
Object storageCloud StorageOptional buckets for crawl result caching (none by default)
SecretsSecret ManagerAPI keys and JWT secret injected at runtime
IngressCloud Load BalancingExternal LoadBalancer, optional custom domain + managed certificate

Sensible defaults worth knowing up front:

  • No external database. database_type is fixed to NONE — Cloud SQL is not provisioned. All task state lives in the in-pod Redis instance and is lost when the pod restarts.
  • Gen2 is not a concern on GKE. Unlike Cloud Run, GKE provides a proper Linux process tree so supervisord runs without constraint. Chromium gets a real /dev/shm emptyDir volume — the --disable-dev-shm-usage Cloud Run workaround is not needed.
  • Redis runs inside the pod. Do not set REDIS_HOST or REDIS_PORT as environment variables — they must stay at localhost:6379 to reach the bundled instance.
  • Session affinity is None. Task IDs issued by one pod are not visible to other pods; clients polling task status should route requests back to the originating pod or use synchronous crawl calls (POST /crawl/sync).
  • Security is off by default. JWT authentication requires providing a SECRET_KEY via secret_environment_variables and a custom config.yml with security.jwt_enabled=true.

2. Google Cloud Services & How to Explore Them​

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the Crawl4AI workload​

Crawl4AI pods run on Autopilot, which bills for the CPU/memory the pods actually request. Horizontal Pod Autoscaling sizes the deployment between the minimum and maximum replica counts. Each pod runs its own supervisord tree: Redis (priority 10) starts first, then Gunicorn (priority 20).

  • Console: Kubernetes Engine → Workloads → select the Crawl4AI workload to see pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
  • CLI:
    kubectl get pods,svc,hpa -n "$NAMESPACE"
    kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100
    kubectl describe hpa -n "$NAMESPACE" # current vs target utilisation
    # Confirm supervisord is managing both processes:
    kubectl exec -n "$NAMESPACE" deploy/<service-name> -- supervisorctl status

See App_GKE for how Autopilot, scaling, and workload type (Deployment vs StatefulSet) are managed.

B. Embedded Redis and task queue​

Redis runs inside each pod as a supervisord-managed process on localhost:6379. It stores task results with a configurable TTL (redis_task_ttl_seconds, default 3600 s). Task results are lost when the pod restarts — this is expected for an ephemeral crawl API. There is no Memorystore instance; the embedded Redis does not appear in the Console.

  • CLI (from inside a pod):
    kubectl exec -n "$NAMESPACE" deploy/<service-name> -- redis-cli ping
    kubectl exec -n "$NAMESPACE" deploy/<service-name> -- redis-cli info keyspace
    kubectl exec -n "$NAMESPACE" deploy/<service-name> -- redis-cli dbsize

C. Cloud Storage (optional)​

Crawl4AI has no default GCS bucket — it is stateless. Optional buckets can be provisioned via storage_buckets to store crawl results or custom config.yml files.

  • Console: Cloud Storage → Buckets.
  • CLI:
    gcloud storage buckets list --project "$PROJECT"
    gcloud storage ls gs://<results-bucket>/

See App_GKE for GCS Fuse mounts and CMEK options.

D. Secret Manager​

LLM API keys and the JWT signing secret are stored as Secret Manager secrets and injected into pods at runtime; plaintext never appears in configuration. Crawl4AI has no auto-generated secrets — all secrets must be provided via secret_environment_variables.

  • Console: Security → Secret Manager.
  • CLI:
    gcloud secrets list --project "$PROJECT"
    gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"

Recognised secret names (pass the Secret Manager secret name, not the value): SECRET_KEY, OPENAI_API_KEY, ANTHROPIC_API_KEY, DEEPSEEK_API_KEY, GROQ_API_KEY, GEMINI_API_KEY, LLM_API_KEY.

See App_GKE for the Secret Store CSI integration and rotation.

E. Networking & ingress​

By default the workload is exposed through an external Cloud Load Balancing IP. A custom domain with a Google-managed certificate can be enabled, and a static IP can be reserved so the address survives redeploys.

  • Console: Network services → Load balancing; VPC network → IP addresses.
  • CLI:
    kubectl get ingress,svc -n "$NAMESPACE"
    gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

F. Cloud Logging & Monitoring​

Pod stdout/stderr (Python logs via PYTHONUNBUFFERED=1) flow to Cloud Logging. GKE metrics flow to Cloud Monitoring. Optional uptime checks and alert policies are available.

  • Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
  • CLI:
    gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

3. Crawl4AI Application Behaviour​

  • Supervisord startup sequence. On every pod start, supervisord (PID 1) starts Redis first (priority 10), then Gunicorn (priority 20). The /health endpoint only responds after both processes are ready — allow at least 40 seconds of initial delay before health checks start.

  • REST API endpoints. Crawl4AI exposes:

    EndpointMethodPurpose
    /crawlPOSTSubmit an asynchronous crawl job; returns a task_id
    /task/{id}GETPoll status and retrieve results for a task
    /crawl/syncPOSTSynchronous crawl (blocks until complete)
    /healthGETHealth check — returns {"status":"ok"} when ready
    /playgroundGETInteractive browser-based crawl UI
  • Task result lifecycle. Async crawl results are stored in the embedded Redis with a TTL of redis_task_ttl_seconds (default 1 hour). After the TTL expires the result is gone. There is no durable result store.

  • No database migrations or initialization jobs. Crawl4AI is fully stateless — Crawl4AI_Common supplies no initialization job. No database setup is required.

  • LLM-based extraction. Provide LLM API keys via secret_environment_variables and set LLM_PROVIDER (or provider-specific keys such as OPENAI_API_KEY) via environment_variables to enable AI-driven content extraction.

  • JWT authentication (optional). Security is disabled by default. To enable, supply SECRET_KEY via secret_environment_variables and provide a custom config.yml with security.jwt_enabled=true. The /token endpoint issues short-lived JWTs when authentication is enabled.

  • CRAWL4AI_HOOKS_ENABLED warning. Setting this variable to "true" enables arbitrary Python code execution via webhook hooks. Only enable in a fully trusted environment.


4. Configuration Variables​

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Crawl4AI are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 1 — Project & Identity​

VariableDefaultDescription
project_id(required)Target Google Cloud project.
regionus-central1Region for the workload and regional resources.

Group 2 — Deployment Environment​

VariableDefaultDescription
tenant_iddemoShort suffix that makes resource names unique per environment.
support_users[]Emails granted project access and monitoring alerts.
resource_labels{}Labels applied to all resources for cost/ownership tracking.

Group 3 — Application Identity​

VariableDefaultDescription
application_namecrawl4aiBase name for resources. Do not change after first deploy.
application_display_nameCrawl4AI Web CrawlerFriendly name shown in the Console.
application_description(set)Workload description annotation.
application_version0.7.8Crawl4AI image version tag; pin to a specific tag for production.

Group 4 — Runtime & Scaling​

VariableDefaultDescription
deploy_applicationtrueSet false to provision IAM without deploying the workload.
workload_typenull"Deployment" (default, stateless) or "StatefulSet" for PVC-backed caching.
container_resources{ cpu_limit="4", memory_limit="8Gi", cpu_request="2", mem_request="4Gi" }Container CPU and memory. Minimum 4 GiB memory for stable Chromium operation.
min_instance_count1Minimum replicas. Keep ≥ 1 so a warm Chromium pool is always available.
max_instance_count5Maximum replicas (autoscaler ceiling).
timeout_seconds1800Pod termination grace period; set ≥ 1800 to allow long batch crawls to drain.
termination_grace_period_seconds60Seconds Kubernetes waits after SIGTERM before force-killing.
service_typeLoadBalancerHow the Service is exposed. Use ClusterIP for cluster-internal access only.
session_affinityNoneNo sticky routing — task IDs are pod-local; use /crawl/sync for cross-pod reliability.
container_image_sourceprebuilt"prebuilt" uses unclecode/crawl4ai directly; "custom" builds via Cloud Build.
container_imageunclecode/crawl4aiImage URI when container_image_source = "prebuilt".
enable_image_mirroringtrueMirror the image into Artifact Registry to avoid Docker Hub rate limits.
enable_vertical_pod_autoscalingfalseLet Autopilot tune resource requests automatically.

Group 5 — Environment Variables & Secrets​

VariableDefaultDescription
environment_variables{}Extra non-secret settings. PYTHONUNBUFFERED and REDIS_TASK_TTL are set automatically. Do not set REDIS_HOST or REDIS_PORT. Recognised overrides: LLM_PROVIDER, LLM_BASE_URL, LLM_TEMPERATURE, CRAWL4AI_HOOKS_ENABLED.
secret_environment_variables{}Map of env var → Secret Manager secret name. Use for SECRET_KEY, OPENAI_API_KEY, ANTHROPIC_API_KEY, etc.

Group 6 — GKE Backend & Cluster​

VariableDefaultDescription
gke_cluster_name""Target cluster name. Leave empty to auto-discover.
gke_cluster_selection_modeprimaryCluster selection strategy.
namespace_name""Kubernetes namespace. Generated from resource prefix when empty.
enable_multi_cluster_servicefalseEnable Multi-Cluster Services ServiceExport.
reserve_static_iptrueReserve a static external IP for the load balancer so the address survives redeploys (fleet-wide default per the GKE campaign — an ephemeral IP can otherwise leave GKE_SERVICE_URL/self-referencing config pointed at unreachable internal DNS).
static_ip_name""Name of an existing static IP to use. Leave empty to auto-create.

Group 7 — Backup & Maintenance​

Not applicable for Crawl4AI — the service is stateless and carries no database. backup_schedule, backup_retention_days, and enable_backup_import are present for interface compatibility but have no effect.

Group 8 — Resource Quota​

VariableDefaultDescription
enable_resource_quotafalseCap namespace CPU/memory/object counts.
quota_cpu_requests8Total CPU requests allowed across all pods.
quota_cpu_limits16Total CPU limits allowed.
quota_memory_requests32GiMust use binary units (32Gi, 8192Mi) — bare integers are read as bytes and block scheduling.
quota_memory_limits64GiMust use binary units — same constraint as quota_memory_requests.
quota_max_pods20Maximum pods in the namespace.

Group 9 — CI/CD & GitHub Integration​

Standard App_GKE Cloud Build / Cloud Deploy integration — see App_GKE. Key inputs: enable_cicd_trigger, github_repository_url, github_token, enable_cloud_deploy.

Group 10 — Jobs & Scheduled Tasks​

VariableDefaultDescription
initialization_jobs[]Crawl4AI_Common supplies no default init job — leave empty unless a custom setup step is needed.
cron_jobs[]Optional Kubernetes CronJobs (e.g., periodic cache-warming crawls).

Group 11 — Cloud Storage & Artifact Registry​

VariableDefaultDescription
create_cloud_storagetrueProvision any buckets listed in storage_buckets.
storage_buckets[]No buckets by default — Crawl4AI is stateless. Add entries to provision crawl-result buckets.
gcs_volumes[]GCS Fuse mounts.
manage_storage_kms_iam / enable_artifact_registry_cmekfalseCMEK options.
max_images_to_retain / delete_untagged_images / image_retention_days(set)Artifact Registry cleanup policy.

Group 12 — Database Backend​

VariableDefaultDescription
database_typeNONEFixed — no Cloud SQL instance is provisioned for Crawl4AI.

All other database variables (enable_cloudsql_volume, sql_instance_name, etc.) are present for interface compatibility and have no effect.

Group 14 — Observability & Health​

VariableDefaultDescription
startup_probe_config / startup_probeHTTP /health, 40 s initial delayAllow supervisord time to start Redis then Gunicorn before the first probe fires.
health_check_config / liveness_probeHTTP /health, 60 s initial delayLiveness probe after startup.
uptime_check_configdisabledOptional Cloud Monitoring uptime check.
alert_policies[]Optional metric alert policies.

Group 16 — Advanced GKE Features​

VariableDefaultDescription
enable_pod_disruption_budgettrueProtect availability during node upgrades. Skipped automatically when max_instance_count ≤ 1.
pdb_min_available1Raise min_instance_count above 1 if you need eviction headroom.
enable_topology_spreadfalseSpread pods across zones.
enable_network_segmentationfalseApply Kubernetes NetworkPolicies to isolate the namespace.

Group 17 — StatefulSet​

VariableDefaultDescription
stateful_pvc_enablednullEnable PVC templates if local cache persistence is required.
stateful_pvc_size20GiPVC size per pod.
stateful_pvc_mount_path/mnt/dataContainer path for the PVC.
stateful_pvc_storage_classstandard-rwoKubernetes StorageClass.

Group 19 — Crawl4AI Application Settings​

VariableDefaultDescription
redis_task_ttl_seconds3600TTL in seconds for task results in embedded Redis. Valid range: 300–86400. Too short causes results to expire before clients poll; too long causes unbounded memory growth.

5. Outputs​

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

OutputDescription
service_nameKubernetes Service name.
namespaceNamespace the workload runs in.
service_cluster_ipIn-cluster ClusterIP.
stage_service_cluster_ipsMap of ClusterIPs for stage-specific services (Cloud Deploy).
service_external_ipExternal LoadBalancer IP (when a static IP is reserved).
service_urlURL to reach Crawl4AI.
storage_bucketsCreated Cloud Storage buckets.
network_name / network_exists / regionsVPC network, presence, available regions.
container_image / container_registryDeployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channelsMonitoring status and channels.
initialization_jobsNames of any setup jobs.
deployment_id / tenant_id / resource_prefixNaming identifiers.
project_id / project_numberProject identifiers.
cicd_enabled / github_repository_url / github_repository_owner / github_repository_name / cicd_configurationCI/CD status and details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_idRegistry and build trigger.
kubernetes_readyWhether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_modeVPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabledAudit logging and CMEK status.

6. Configuration Pitfalls & Sensible Defaults​

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

SettingSensible valueRiskConsequence if wrong
memory_limit (in container_resources)8GiCriticalBelow 4 GiB, Chromium processes are OOM-killed mid-crawl returning partial results; below 2 GiB the container fails to start.
quota_memory_requests / quota_memory_limitsbinary units (32Gi)CriticalBare integers are read as bytes by Kubernetes and block all pod scheduling.
REDIS_HOST / REDIS_PORT (env vars)do not setCriticalOverriding these breaks the embedded Redis connection; all async crawl jobs fail immediately.
database_typeNONECriticalCrawl4AI has no database; changing this causes unnecessary Cloud SQL provisioning and a startup failure.
min_instance_count1HighScale-to-zero (0) causes 30–60 s cold starts (supervisord must boot Redis then Gunicorn); the first request typically times out.
cpu_limit (in container_resources)4HighBelow 2 vCPU, Chromium JavaScript rendering triggers internal timeouts on complex pages, slowing crawl throughput significantly.
enable_iap / enable_cloud_armorenable for productionHighWithout IAP or a crawl API token, the LoadBalancer IP is publicly accessible and anyone can submit crawl jobs.
LLM_API_KEY / provider API keysvia secret_environment_variablesHighMissing or expired keys cause LLM-based extraction to fail silently (empty extracted_content). Inject as secrets, not plain-text env vars.
redis_task_ttl_seconds3600MediumToo short (< 300 s) causes results to expire before async clients poll; too long causes unbounded Redis memory growth.
session_affinityNoneMediumSetting to ClientIP pins clients to one pod and breaks load distribution without helping task routing (task IDs are already pod-local).
application_versionpinned tagMediumUsing "latest" is non-reproducible; a rebuild may pull a breaking Crawl4AI API change.
enable_image_mirroringtrueLowCrawl4AI images are large; without mirroring, every pod start pulls from Docker Hub and risks rate-limit failures.

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, and image mirroring — see App_GKE. Crawl4AI-specific shared application configuration is described in Crawl4AI_Common.

Need RAD to do something it does not do yet? Request it on the roadmap, or vote on what is already there.
