Certification track: AI Tooling
SearXNG on Google Cloud Run
SearXNG is a privacy-respecting, self-hosted metasearch engine that aggregates results from 70+ search services without tracking users or serving ads. This module deploys SearXNG on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure.
This guide focuses on the cloud services SearXNG uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.
1. Overview
SearXNG runs as a lightweight Python/Flask container on Cloud Run v2. The deployment wires together a minimal set of Google Cloud services:
| Capability | Google Cloud service | Notes |
|---|---|---|
| Compute | Cloud Run v2 | Python/Flask service, 1 vCPU / 512 MiB by default, request-based autoscaling |
| Cache / rate limiting | Redis | Optional — disabled by default; enables rate limiting and bot detection |
| Secrets | Secret Manager | Auto-generated SEARXNG_SECRET (session key) injected at runtime |
| Ingress | Cloud Run URL / Cloud Load Balancing | Default run.app URL, optional external HTTPS load balancer + custom domain |
Sensible defaults worth knowing up front:
- No database is provisioned. SearXNG is fully stateless — it aggregates search results at request time and stores nothing.
- No NFS or Cloud Storage is provisioned. SearXNG has no uploads or shared files.
min_instance_countis fixed at 0 (scale-to-zero). SearXNG cold starts are fast (under 5 seconds) because no database connections or migrations are performed on startup.- Redis is disabled by default. For public-facing deployments, enable Redis to activate rate limiting and bot detection against upstream engine abuse.
SEARXNG_SECRETis generated automatically and stored in Secret Manager. The same key is shared across all running instances — do not override it with a per-instance random value.- Health probes target
/healthz. SearXNG's built-in health endpoint returns 200 when the application is ready. vpc_egress_settingdefaults toPRIVATE_RANGES_ONLY. SearXNG must reach external search engines; ensure a Cloud NAT gateway is configured or switch toALL_TRAFFIC.
2. Google Cloud Services & How to Explore Them
All commands assume PROJECT and REGION are set. Service and resource names are
reported in the deployment Outputs.
A. Cloud Run — the SearXNG service
SearXNG runs as a Cloud Run v2 service that autoscales by request load, scaling to zero when idle. Each deployment creates an immutable revision; traffic can be split across revisions for safe rollouts.
- Console: Cloud Run → select the service for revisions, traffic, logs, and metrics.
- CLI:
gcloud run services list --project "$PROJECT" --region "$REGION"
gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"
See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.
B. Redis cache (optional)
When enable_redis = true, SearXNG uses Redis for per-IP rate limiting and bot
detection. This is strongly recommended for public-facing deployments to prevent
upstream search engine API quota exhaustion. When redis_host is left empty and
Redis is enabled, the module defaults to 127.0.0.1.
- Console: Memorystore → Redis (if using a managed instance).
- CLI:
redis-cli -h <redis-host> ping
redis-cli -h <redis-host> info keyspace
C. Secret Manager — SEARXNG_SECRET
SearXNG_Common auto-generates the SEARXNG_SECRET session key and stores it in
Secret Manager. This key signs SearXNG's session cookies and HMAC query
parameters; all instances must share the same value. It is injected into the
service at runtime.
- Console: Security → Secret Manager.
- CLI:
gcloud secrets list --project "$PROJECT"
gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"
See App_CloudRun for injection and rotation details.
D. Networking & ingress
The service is reachable at its run.app URL by default. An external HTTPS load
balancer with a custom domain, Cloud CDN, and Cloud Armor can be layered on;
ingress settings and VPC egress control connectivity to external search engines.
- Console: Cloud Run (service URL); Network services → Load balancing.
- CLI:
gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'
gcloud compute addresses list --project "$PROJECT"
See App_CloudRun.
E. Cloud Logging & Monitoring
Container logs flow to Cloud Logging; Cloud Run metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.
- Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
- CLI:
gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50
3. SearXNG Application Behaviour
- Fully stateless. SearXNG fetches results from external search engines at request time and stores nothing locally. No database migrations or initialisation jobs run.
- No first-deploy setup job. Because there is no database, the deployment completes without a db-init step — the service is ready as soon as the container starts.
SEARXNG_SECRETis stable. The session key is generated once and persists in Secret Manager across service revisions. Rotating it invalidates all active user sessions; avoid rotation in production unless required for security.SEARXNG_BIND_ADDRESSis injected automatically as0.0.0.0:8080so SearXNG listens on all interfaces at its native port.ENABLE_REDISandREDIS_URLare injected automatically whenenable_redis = true. The URL is derived fromredis_hostandredis_port.- Health path. Both the startup and liveness probes target
/healthz(HTTP GET), which SearXNG answers once the application is fully initialised. - Fast cold starts. SearXNG starts in under 5 seconds — no database connections or schema migrations. The startup probe uses a 10-second initial delay.
- VPC egress for external engines. SearXNG fetches results from upstream search services over the internet. Ensure the VPC connector's egress is not restricted to private ranges only, or configure Cloud NAT for internet access.
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for SearXNG are listed; every other input is inherited from App_CloudRun with its standard behaviour.
Group 1 — Project & Identity
| Variable | Default | Description |
|---|---|---|
project_id | (required) | Target Google Cloud project. |
region | us-central1 | Region for the service and regional resources. |
Group 2 — Deployment Environment
| Variable | Default | Description |
|---|---|---|
tenant_deployment_id | demo | Short suffix that makes resource names unique per environment. |
support_users | [] | Emails granted project access and monitoring alerts. |
resource_labels | {} | Labels applied to all resources. |
Group 3 — Application Identity
| Variable | Default | Description |
|---|---|---|
application_name | searxng | Base name for resources. Do not change after first deploy. |
display_name | SearXNG Search | Friendly name shown in the Console. |
description | SearXNG — privacy-respecting metasearch engine on Cloud Run | Service description. |
application_version | latest | SearXNG image tag; pin to a specific version for production. |
Group 4 — Runtime & Scaling
| Variable | Default | Description |
|---|---|---|
deploy_application | true | Set false to provision infrastructure only. |
cpu_limit | 1000m | CPU per instance. 1 vCPU handles moderate SearXNG traffic. |
memory_limit | 512Mi | Memory per instance. Scale to 1Gi for high-traffic public instances. |
max_instance_count | 3 | Maximum instances (cost ceiling). |
container_port | 8080 | SearXNG's native HTTP port. |
execution_environment | gen2 | Gen2 recommended for faster startup and improved networking. |
timeout_seconds | 60 | Max request duration. Slow upstream engines may require raising to 120–300. |
container_image_source | prebuilt | Use the official SearXNG image (prebuilt) or build from source (custom). |
cpu_always_allocated | false | Request-based billing — SearXNG is a stateless search proxy with no in-process background work, so CPU is only needed while serving a request. |
enable_image_mirroring | true | Mirror the image into Artifact Registry before deployment. |
enable_cloudsql_volume | false | Leave false — SearXNG does not use a database. |
traffic_split | [] | Split traffic across revisions for staged rollouts. |
max_revisions_to_retain | 7 | How many old revisions to keep. |
Group 5 — Access & Ingress Control
| Variable | Default | Description |
|---|---|---|
ingress_settings | all | Which networks may reach the service. Use internal for private deployments. |
vpc_egress_setting | PRIVATE_RANGES_ONLY | How outbound traffic is routed through the VPC connector. Set ALL_TRAFFIC if Cloud NAT is not configured. |
enable_iap | false | Require Google sign-in via Identity-Aware Proxy (internal deployments). |
iap_authorized_users / iap_authorized_groups | [] | Who may access through IAP. |
Group 6 — Environment Variables & Secrets
| Variable | Default | Description |
|---|---|---|
environment_variables | { INSTANCE_NAME="SearXNG", AUTOCOMPLETE="", SEARXNG_BIND_ADDRESS="0.0.0.0:8080" } | Extra settings. ENABLE_REDIS and REDIS_URL are also injected automatically. |
secret_environment_variables | {} | Map of env var → Secret Manager secret name for additional secrets (e.g., upstream engine API keys). |
secret_propagation_delay | 30 | Seconds to wait after secret creation before proceeding. |
secret_rotation_period | 2592000s | Secret Manager rotation notification frequency. |
Group 7 — Backup & Restore
SearXNG is stateless — there is no application data to back up. The backup variables are inherited from the foundation interface but have no practical use. See App_CloudRun.
Group 8 — CI/CD & Binary Authorization
Standard App_CloudRun Cloud Build / Cloud Deploy integration — see
App_CloudRun. Key inputs: enable_cicd_trigger,
github_repository_url, github_token, enable_cloud_deploy,
enable_binary_authorization.
Group 9 — Custom SQL
Not applicable to SearXNG (no database). See App_CloudRun.
Group 10 — Load Balancer, CDN & Image Retention
| Variable | Default | Description |
|---|---|---|
enable_cloud_armor | false | Provision Global HTTPS LB + Cloud Armor WAF. Recommended for public deployments. |
admin_ip_ranges | [] | CIDRs exempted from WAF rules. |
application_domains | [] | Custom domain names for the HTTPS LB (Google-managed SSL). |
enable_cdn | false | Enable Cloud CDN on the HTTPS LB backend. |
max_images_to_retain / delete_untagged_images / image_retention_days | (set) | Artifact Registry cleanup policy. |
Group 11 — Storage & Filesystem
| Variable | Default | Description |
|---|---|---|
create_cloud_storage | false | SearXNG is stateless — no GCS bucket is required. Leave false. |
enable_nfs | false | SearXNG is stateless — NFS is not required. Leave false. |
gcs_volumes | [] | GCS Fuse mounts (not used by SearXNG). |
manage_storage_kms_iam / enable_artifact_registry_cmek | false | CMEK options. |
Group 12 — Database Backend
| Variable | Default | Description |
|---|---|---|
database_type | NONE | Fixed — SearXNG does not use a database. Do not change. |
Group 13 — Jobs & Scheduled Tasks
| Variable | Default | Description |
|---|---|---|
initialization_jobs | [] | SearXNG requires no initialisation jobs — leave empty. |
cron_jobs | [] | Optional scheduled tasks (e.g., cache warming). |
Group 14 — Observability & Health
| Variable | Default | Description |
|---|---|---|
startup_probe / liveness_probe | HTTP /healthz | SearXNG's built-in health endpoint; startup allows 10s initial delay. |
uptime_check_config | disabled | Optional Cloud Monitoring uptime check. |
alert_policies | [] | Optional metric alert policies. |
Group 21 — Redis
| Variable | Default | Description |
|---|---|---|
enable_redis | false | Enable Redis for rate limiting and bot detection. Recommended for public-facing deployments. |
redis_host | "" | Redis endpoint. Leave empty to default to 127.0.0.1 when Redis is enabled; set to the Memorystore IP for a managed instance. |
redis_port | 6379 | Redis port. |
redis_auth | "" | Optional Redis auth password (sensitive). |
Group 22 — VPC Service Controls & Audit Logging
| Variable | Default | Description |
|---|---|---|
enable_vpc_sc | false | Enforce a VPC-SC perimeter (requires organization_id). |
vpc_cidr_ranges / vpc_sc_dry_run | (set) | Access level CIDRs / dry-run mode. |
enable_audit_logging | false | Detailed Cloud Audit Logs. |
5. Outputs
Returned on a successful deployment — the quickest way to locate and explore the running resources.
| Output | Description |
|---|---|
service_name | Cloud Run service name. |
service_url | Default run.app URL of the service. |
service_location | Region the service runs in. |
stage_services | Stage-specific service URLs (Cloud Deploy). |
load_balancer_ip / load_balancer_url | External HTTPS load balancer IP / URL (when enabled). |
storage_buckets | Created Cloud Storage buckets (empty for SearXNG). |
network_name / network_exists / regions | VPC network, presence, regions. |
container_image / container_registry | Deployed image and Artifact Registry repo. |
monitoring_enabled / monitoring_notification_channels / uptime_check_names | Monitoring status, channels, uptime checks. |
initialization_jobs | Names of any setup jobs (none by default). |
deployment_id / tenant_id / resource_prefix | Naming identifiers. |
project_id / project_number | Project identifiers. |
cicd_enabled / cicd_configuration | CI/CD status and details. |
github_repository_url / github_repository_owner / github_repository_name | GitHub connection details. |
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id | Registry and build trigger. |
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode | VPC-SC status. |
audit_logging_enabled / artifact_registry_cmek_enabled | Audit logging and CMEK status. |
6. Configuration Pitfalls & Sensible Defaults
Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).
| Setting | Sensible value | Risk | Consequence if wrong |
|---|---|---|---|
SEARXNG_SECRET (auto-generated) | auto-generated | Critical | If overridden with a per-instance random value, each cold start produces a different key, invalidating all existing session cookies. Always use the auto-generated Secret Manager value. |
database_type | NONE | Critical | Changing to a real DB type provisions an unused Cloud SQL instance and breaks startup. |
vpc_egress_setting | ALL_TRAFFIC or Cloud NAT configured | High | PRIVATE_RANGES_ONLY blocks SearXNG's outbound requests to external search engines (Google, Bing, DuckDuckGo, etc.), returning empty results. |
enable_redis | true for public deployments | High | Without Redis, SearXNG has no rate limiting; public instances are vulnerable to scraping that exhausts upstream engine quotas. |
redis_host | Memorystore IP or explicit value | High | When enable_redis = true and redis_host = "", the module defaults to 127.0.0.1 — there is no sidecar Redis in Cloud Run, so rate limiting is silently disabled. |
timeout_seconds | 60–300 | Medium | SearXNG waits for all enabled search engines; slow upstream engines may need up to 30 seconds per request. Too low causes 504 errors before results are aggregated. |
application_version | pinned (not latest) | Medium | Using latest makes deployments non-reproducible; a new SearXNG release may change config schema. |
enable_cloud_armor | true for public deployments | Medium | Without Cloud Armor, there is no WAF/DDoS protection on the public endpoint. |
enable_iap | true for internal-only | Medium | For internal search deployments, IAP restricts access to authenticated Google accounts. |
ingress_settings | all for public; internal for private | Medium | all is intentional for a public meta-search engine; combine with Redis rate limiting and Cloud Armor for production. |
For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_CloudRun. SearXNG-specific application configuration shared with the GKE variant is described in SearXNG_Common.
