Hoppscotch on Google Cloud Run

Hoppscotch is an open-source, Postman-style API development platform for designing, sending, and inspecting HTTP, GraphQL, and WebSocket requests from the browser. This module deploys the self-hosted Hoppscotch frontend as a stateless single-page app on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure.

This guide focuses on the cloud services Hoppscotch uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.

---

1. Overview

Hoppscotch runs as a static single-page web app (served by Caddy) in a container on Cloud Run v2. It is deliberately stateless — no database, no cache, no persistent storage — so the deployment wires together a small set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	Cloud Run v2	Static SPA container on port 3000; 1 vCPU / 512 MiB by default; scale-to-zero
Container image	Artifact Registry + Cloud Build	Thin custom build FROM hoppscotch/hoppscotch-frontend, tag mirrored into Artifact Registry
Ingress	Cloud Run URL / Cloud Load Balancing	Default run.app URL; optional external HTTPS load balancer + custom domain
Secrets	Secret Manager	None app-specific — Hoppscotch requires no secrets
Observability	Cloud Logging & Monitoring	Container logs, metrics, optional uptime check and alerts

Services that are deliberately not used: Cloud SQL (database_type = "NONE"), Cloud Storage (no buckets), and Redis (off by default; the static frontend has no server-side rate-limiting or queue to back).

Sensible defaults worth knowing up front:

• No database, ever. database_type = "NONE" and enable_cloudsql_volume = false. Hoppscotch keeps all collections, environments, and history in browser local storage, so there is no server-side state. Setting a database type only wastes money on an idle Cloud SQL instance — the GKE variant even blocks it at plan time.
• The frontend-only image is used on purpose. The all-in-one hoppscotch/hoppscotch image bundles a NestJS backend that exit(1)s without a DATABASE_URL. This module uses hoppscotch/hoppscotch-frontend, which serves the SPA on port 3000 with no backend requirement.
• HOPPSCOTCH_VERSION, not APP_VERSION, pins the image. A custom build sets an app-specific HOPPSCOTCH_VERSION ARG so the Foundation's injected APP_VERSION does not overwrite the tag; application_version = "latest" resolves to a pinned, known-good tag at build time.
• Scale-to-zero is enabled by default (min_instance_count = 0). The first request after idle incurs a cold start of a few seconds. Because the app is a static SPA with no warm-up work, cold starts are cheap; set min_instance_count = 1 only if you want to eliminate that first-request latency.
• Request-based billing by default (cpu_always_allocated = false). Hoppscotch does no in-process background work, so CPU is billed only while serving a request.
• Public ingress by default. ingress_settings = "all" exposes the run.app URL. Enable IAP to require Google sign-in for internal/organisation-only deployments.
• No secrets and no storage buckets are provisioned by this module.

---

2. Google Cloud Services & How to Explore Them

All commands assume PROJECT and REGION are set. Service and resource names are reported in the deployment Outputs.

A. Cloud Run — the Hoppscotch service

Hoppscotch runs as a Cloud Run v2 service that autoscales by request load between the minimum (0) and maximum instance counts. Each deployment creates an immutable revision; traffic can be split across revisions for safe rollouts. The container listens on port 3000 and answers GET / with the app UI (HTTP 200).

• Console: Cloud Run → select the service for revisions, traffic, logs, and metrics.
• CLI:

  gcloud run services list --project "$PROJECT" --region "$REGION" \
    --filter="metadata.name~hoppscotch"
  gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
  gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"
  # Confirm the injected port and env of the live revision:
  gcloud run services describe <service-name> --region "$REGION" \
    --format='value(spec.template.spec.containers[0].ports,spec.template.spec.containers[0].env)'

See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.

B. Container image — Artifact Registry & Cloud Build

Because container_image_source = "custom", the image is built by Cloud Build from the thin Dockerfile (FROM hoppscotch/hoppscotch-frontend:${HOPPSCOTCH_VERSION}) and pushed to Artifact Registry (image mirroring is on by default to avoid Docker Hub rate limits).

• Console: Artifact Registry → Repositories; Cloud Build → History.
• CLI:

  gcloud builds list --project "$PROJECT" --region "$REGION" --limit 5
  gcloud artifacts docker images list \
    "$REGION-docker.pkg.dev/$PROJECT/<repo>" --project "$PROJECT" \
    --include-tags --filter="package~hoppscotch"

The repository name and image URI are in the Outputs (artifact_registry_repository, container_image).

C. Secret Manager

Hoppscotch provisions no application secrets — secret_ids is empty. You can still map your own env-var-to-secret references through secret_environment_variables if you extend the deployment, but nothing is required.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~hoppscotch"

See App_CloudRun for secret injection and rotation details.

D. Networking & ingress

The service is reachable at its run.app URL by default (ingress_settings = "all"). An external HTTPS load balancer with a custom domain, Cloud CDN, and Cloud Armor can be layered on; ingress settings and VPC egress control connectivity.

• Console: Cloud Run (service URL); Network services → Load balancing.
• CLI:

  gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'
  gcloud compute addresses list --project "$PROJECT"

See App_CloudRun.

E. Cloud Logging & Monitoring

Container logs flow to Cloud Logging; Cloud Run metrics flow to Cloud Monitoring, with optional uptime checks and alert policies. An uptime check against / confirms the SPA is serving.

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50

---

3. Hoppscotch Application Behaviour

• No first-deploy database setup. There is no db-init job, no Cloud SQL instance, and no schema. The container serves a static bundle immediately.
• No server-side persistence. Collections, environments, request history, and settings live in browser local storage on each user's machine. Redeploying, scaling to zero, or rolling out a new revision loses no user data — there is none on the server to lose.
• No immutable keys. With no secrets and no database, there is no cryptographic material that could corrupt stored data if changed. Rotations are a non-issue.
• Health path. Startup and liveness probes target the root /, which returns the app UI (HTTP 200) as soon as Caddy binds port 3000 — typically within seconds. A failing probe almost always means the image tag is invalid, not that a backend is unreachable.
• No first-run admin account. The self-hosted frontend has no login or user management of its own; open the URL and start building requests. (Team workspaces, which do require the backend + database, are intentionally out of scope for this module.)
• Scaling is unconstrained. Because there is no shared queue or database, any number of instances can run independently — increase max_instance_count freely as a cost/throughput ceiling.
• Verify the running revision:

  gcloud run services describe <service-name> \
    --region "$REGION" --project "$PROJECT" --format='value(status.url)'
  curl -sS -o /dev/null -w '%{http_code}\n' "$(gcloud run services describe <service-name> \
    --region "$REGION" --format='value(status.url)')/"

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Hoppscotch are listed; every other input is inherited from App_CloudRun with its standard behaviour.

Group 1 — Project & Identity

Variable	Default	Description
project_id	(required)	Target Google Cloud project.
region	us-central1	Region for the service and regional resources.

Group 3 — Application Identity

Variable	Default	Description
application_name	hoppscotch	Base name for resources. Do not change after first deploy.
display_name	Hoppscotch	Human-readable name shown in the Console.
application_version	latest	Hoppscotch image tag; latest resolves to a pinned known-good hoppscotch-frontend tag at build time.

Group 4 — Runtime & Scaling

Variable	Default	Description
deploy_application	true	Set false to provision supporting infrastructure only.
container_image_source	custom	Thin custom build FROM hoppscotch/hoppscotch-frontend. Keep custom.
cpu_limit	1000m	CPU per instance.
memory_limit	512Mi	Memory per instance; ≥ 256Mi (gen2 floor is 512Mi).
cpu_always_allocated	false	Request-based billing — Hoppscotch does no background work.
container_port	3000	The port the frontend SPA listens on.
min_instance_count	0	Scale-to-zero; set 1 to avoid cold starts.
max_instance_count	3	Cost/throughput ceiling; safe to raise (no shared state).
execution_environment	gen2	Recommended for faster startup and networking.
timeout_seconds	60	Maximum request duration (0–3600).
enable_cloudsql_volume	false	Hoppscotch has no database — leave false.
enable_image_mirroring	true	Mirror the image into Artifact Registry (avoids Docker Hub limits).

All other inputs follow standard App_CloudRun behaviour.

Group 5 — Access & Ingress Control

Variable	Default	Description
ingress_settings	all	Public run.app URL. Use internal / IAP for private deployments.
vpc_egress_setting	PRIVATE_RANGES_ONLY	Route only RFC 1918 traffic via VPC.
enable_iap	false	Require Google sign-in in front of Hoppscotch.
iap_authorized_users / iap_authorized_groups	[]	Who may access through IAP.

All other inputs follow standard App_CloudRun behaviour.

Group 6 — Environment Variables & Secrets

Variable	Default	Description
environment_variables	{}	Optional extra plain-text env vars (e.g. { PORT = "3000" }). None are required.
secret_environment_variables	{}	Optional env var → Secret Manager references. None are required.

All other inputs follow standard App_CloudRun behaviour.

Group 21 — Redis Cache & Queue

Variable	Default	Description
enable_redis	false	Off by default. The static frontend has no server-side queue or rate limiter, so leave disabled.
redis_host / redis_port / redis_auth	"" / 6379 / ""	Only relevant if you wire Redis in for a custom purpose.

All other inputs follow standard App_CloudRun behaviour.

---

5. Outputs

Returned on a successful deployment — the quickest way to locate and explore the running resources.

Output	Description
service_name	Cloud Run service name.
service_url	Default run.app URL of the service.
service_location	Region the service runs in.
stage_services	Stage-specific service URLs (Cloud Deploy).
load_balancer_ip / load_balancer_url	External HTTPS load balancer IP / URL (when enabled).
storage_buckets	Created Cloud Storage buckets (empty — Hoppscotch is stateless).
network_name / network_exists / regions	VPC network, presence, regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels / uptime_check_names	Monitoring status, channels, uptime checks.
initialization_jobs	Names of setup jobs (empty — no DB bootstrap).
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / github_repository_url / github_repository_owner / github_repository_name / cicd_configuration	CI/CD status and details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_CloudRun foundation engine, which validates values and combinations at plan time — IAP with no authorized identities, a gen1 runtime with NFS/GCS mounts, out-of-range timeout_seconds/redis_port. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Setting	Sensible value	Risk	Consequence if wrong
container_image_source	custom	High	Switching to prebuilt points the service at an unbuilt Artifact Registry path (Image not found); Hoppscotch requires the custom hoppscotch-frontend build.
application_version	latest or a real hoppscotch-frontend tag	High	An invalid tag makes the Cloud Build fail (MANIFEST_UNKNOWN); the service then runs a stale or missing image.
enable_cloudsql_volume	false	Medium	Enabling it mounts an Auth Proxy sidecar for a database that does not exist — wasted cost and a needless dependency.
container_port	3000	High	The frontend serves only on 3000; a mismatched port fails the startup probe and the revision never becomes Ready.
memory_limit	512Mi	Medium	Below 512Mi is rejected under the gen2 execution-environment floor; the plan/apply fails.
enable_iap	false for public use	High	Enabling IAP without OAuth credentials silently exposes or blocks the app; enabling it deliberately requires Google sign-in for every request.
min_instance_count	0 (or 1 for no cold start)	Low	Scale-to-zero adds a small cold-start delay to the first request after idle; harmless for a static SPA.
enable_redis	false	Low	The static frontend has no server-side queue; enabling Redis adds cost with no benefit.

---

For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_CloudRun. Hoppscotch-specific application configuration shared with the GKE variant is described in Hoppscotch_Common.
