Gitea on GKE Autopilot

Gitea is a lightweight, self-hosted Git service and source-code hosting platform (a community fork of Gogs) providing repository hosting, issue tracking, pull requests, a built-in CI/CD runner (Actions), code review, and a package registry from a single Go binary. This module deploys Gitea on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services Gitea uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

What Gitea costs on RAD, and how that compares

Running Gitea in your own Google Cloud project costs about US$142.62/month in Google Cloud charges, on top of a one-time 110-credit RAD module fee (99 credits — 10% lower — in a RAD-managed project). Gitea is a lightweight, self-hosted Git service and source-code hosting platform (a community fork of Gogs) with 45,000+ GitHub stars. If you deploy into a RAD-managed project, you can pause the whole thing for free and pick it back up later — see "Pause it for free" below.

Gitea is also available on Cloud Run — see the Cloud Run guide for the lower-cost option; this guide covers the GKE variant.

What you pay on RAD

	Own project	RAD-managed project
Module fee	110 credits (one-time)	99 credits (one-time, 10% lower)
Build time	~3–6 credits (one-time, per build)	~3–6 credits (one-time, per build)
Google Cloud running cost	~US$142.62/month, billed to your own Google billing account at list price	~108 credits/day (~US$10.80/day), metered hourly at list price plus RAD's margin

Default running cost in your own project

Resource	US$/month (Google list price, us-central1)
GKE Autopilot pod, 2x vCPU / 2 GiB	US$72.16
Cloud SQL for PostgreSQL, 1 vCPU / 3.75 GB, zonal, 10 GB SSD	US$51.02
NFS/cache file server (small VM)	US$13.43
Cloud NAT and networking	US$5
Cloud Storage (add-ons, backups)	US$1
GKE cluster management fee	shared across every GKE app in the project; $0 if this is your only cluster, else ~73
Total	US$142.62

How it compares

• Gitea Cloud's Enterprise tier starts at US$9.50/user/month (1-year commitment required online; SAML SSO, audit logs, priority support) — verified at https://about.gitea.com/pricing. For a team of five that is roughly US$47.50/month and climbing with headcount; RAD's own-project running cost is a flat ~US$142.62/month (GKE) regardless of how many people use it, on an open-source instance you fully control.
• The honest trade here is cap vs. control, not price: a managed SaaS plan is cheaper at this scale, and RAD's running cost is what real Cloud SQL, compute and networking actually cost at Google's list price with nothing hidden in a bundled seat price.
• RAD is not claiming to be cheaper than a bare VPS in cash terms — it usually is not. The case for RAD is what's managed for you.

Pause it for free: delete a RAD-managed project, restore it when you need it

If Gitea is running in a RAD-managed project, you can stop paying for it entirely without destroying it. Deleting that project first unlinks its billing, then asks Google to delete the project outright — Google's own 30-day recoverable soft delete. Unlike deleting the Gitea module on its own, this does not tear down Cloud SQL, any VM or the compute resource one by one: the whole project simply stops, and nothing is charged while it waits, because billing is already unlinked.

Restoring, within 30 days and only by the project's owner, asks Google to undelete the project and reattaches its billing account, then asks you to run Update on each deployment to confirm everything came back. Because nothing was individually destroyed, that Update finds the same resources already there — it is a check, not a rebuild, and an Update never charges the module fee again. This costs only a handful of build-time credits in total — roughly 5–10 credits, under US$1, for a typical 2–3-deployment chain. The 99-credit module fee is not charged again.

What this needs: you must own the project (not one RAD only manages billing for), you must restore it yourself within 30 days — after that Google deletes it for good — and restoring is admitted like creating a new project, so your purchased credit balance must still clear the tier's floor (100 credits for the sandbox tier most study/demo use fits). Google says most services are fully working again within 36 hours of a restore.

One real gap: nightly backups are written to a bucket inside the project, and that bucket has Cloud Storage's soft-delete explicitly turned off, so it is very likely gone as soon as you delete the project — even though the project itself is recoverable for 30 days. If you have customised Gitea and want to keep that work, copy a backup out (to Google Drive, or a bucket outside the project) before deleting. For a default install with nothing irreplaceable in it, this does not matter.

Pay only while you use it, the other way: delete and redeploy

If Gitea is in your own project (or more than 30 days have passed on a RAD-managed one), the way to stop paying is to delete the deployment and redeploy later when you need it again.

A redeploy costs the module fee again, plus the builds: roughly 110 + ~3–6 credits (~US$11.45) in your own project, or 99 + ~3–6 credits on a RAD-managed one.

Deleting only saves money once Gitea would otherwise sit unused long enough to clear that redeploy cost against its own running cost: roughly about 3 days or more idle in your own project (against its ~US$142.62/month Google Cloud bill), or about 1 days or more idle in a RAD-managed project (against its ~108 credits/day).

Most of Gitea's running cost is the database and the shared file/cache VM. They stop only when nothing else in the project uses them, so deleting this app while something else shares the project saves only this app's own compute share of the total above.

Keep data first: nightly backups go to a bucket inside the deployment and are deleted with it, so copy the latest backup out before deleting if you want to keep it.

Lab sessions and Managed Environments

• Lab sessions, for training: a trainer runs a session for a class. Each participant gets the app in their own Google Cloud project for 15 minutes to 24 hours, within an allowance the trainer sets. Either the trainer funds every place, or each participant pays for their own. Everything is deleted when the session ends and unused credits go back to the trainer.
• Managed Environments, for consultancies: a partner runs the app for a client from a ring-fenced wallet it funds, and settles with the client directly. If the wallet runs low, billing pauses and the data is kept, so nobody receives an unexpected charge. At the end the partner hands the project over and the deployments become the client's own.
• Credits can be bought in more than 20 currencies, including XAF, XOF, NGN, GHS, KES and ZAR, by card, bank transfer or mobile money.

Sources (8 October 2026): Google Cloud Billing Catalog API list prices; radmodules.dev/pricing for RAD's own fees and daily-credit estimates; Google's project delete/restore docs for the pause/restore mechanics; Gitea Cloud pricing for the Gitea Cloud figures.

1. Overview

Gitea runs as a single Go binary web workload (repository server + built-in SSH/CI runner supervised by s6). The deployment wires together a focused set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	Gitea pods on port 3000, 1 vCPU / 512Mi by default
Database	Cloud SQL for PostgreSQL 15	database_type defaults to POSTGRES_15; the db-init job is PostgreSQL-only
File persistence	Cloud Filestore (NFS)	Repositories, LFS objects and attachments persist under /data, shared across pods
Object storage	Cloud Storage	None — Gitea_Common declares no GCS buckets (storage_buckets = [])
Secrets	Secret Manager	Auto-generated SECRET_KEY and INTERNAL_TOKEN; database password
Ingress	Cloud Load Balancing / Gateway	service_type = LoadBalancer by default, with enable_custom_domain = true provisioning a Gateway + managed certificate

Sensible defaults worth knowing up front:

• PostgreSQL 15 is the intended engine, and only Postgres actually works. database_type defaults to POSTGRES_15, but the variable's validation also accepts MYSQL/MYSQL_8_0. The bundled db-init script (scripts/gitea/db-init.sh) is hard-coded to psql — selecting a MySQL engine breaks database initialization. Leave database_type on a Postgres value.
• Cloud SQL is reached via the Auth Proxy sidecar on loopback by default. enable_cloudsql_volume = true runs a cloud-sql-proxy sidecar; the platform entrypoint (/platform-entrypoint.sh) composes GITEA__database__HOST from the injected DB_HOST/DB_IP and selects SSL_MODE=disable for the socket/loopback path or SSL_MODE=require for a direct private-IP TCP hop.
• This is a thin custom build, not the stock gitea/gitea image used verbatim. container_image_source defaults to "custom": Cloud Build produces FROM gitea/gitea:${APP_VERSION} plus a platform entrypoint that composes the GITEA__database__* values at runtime (Cloud Run does not interpolate $(VAR) references the way Kubernetes does, so the same entrypoint is shared across both variants for consistency). The stock s6-svscan CMD is preserved.
• NFS is enabled by default (enable_nfs = true, mounted at /data via nfs_mount_path) so repositories, Git LFS objects, and issue/PR attachments persist and are shared across pods (GITEA__server__APP_DATA_PATH).
• Scale-to-zero by default. min_instance_count = 0, max_instance_count = 3. Because repository data lives on shared NFS rather than per-pod storage, running more than one replica is generally safe for stateless HTTP requests, but Git's own locking and any in-flight background jobs are not explicitly coordinated across replicas by this module — keep max_instance_count conservative unless verified.
• No installer, no automated admin account. GITEA__security__INSTALL_LOCK = "true" skips the first-run web installer (config is supplied entirely via env vars) and GITEA__service__DISABLE_REGISTRATION = "false" leaves self-registration open. No Terraform-managed job creates an admin user — register the first account through the web UI, or promote/create one via kubectl exec ... -- gitea admin user create --admin (verify the binary path in the deployed image before relying on this).
• SECRET_KEY and INTERNAL_TOKEN are generated automatically and stored in Secret Manager; the database password is the foundation-managed DB_PASSWORD secret, delivered to Gitea as GITEA__database__PASSWD.
• public_domain/public_url default to localhost. Unlike some modules, Gitea's clone URLs (GITEA__server__DOMAIN / GITEA__server__ROOT_URL) are not auto-populated from the assigned LoadBalancer/Gateway address — set public_domain (or public_url) to your real hostname after deploy, or clone links and OAuth/webhook callbacks will reference localhost.
• enable_redis has no effect on Gitea's own behaviour. The variable defaults true and the foundation injects REDIS_HOST/REDIS_PORT, but Gitea_Common never sets any GITEA__cache__*/GITEA__session__*/GITEA__queue__* config to consume them — Gitea runs with its built-in in-memory/SQLite-free defaults regardless of this setting.
• git-over-SSH is not exposed. Only the HTTP port (container_port, default 3000) is wired into the Kubernetes Service. The image's own sshd (supervised by s6 alongside the web server) is not published — clone over HTTPS, or add a custom Service/port mapping if SSH access is required.

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the Gitea workload

Gitea pods are scheduled on Autopilot, which bills for the CPU/memory the pods actually request. The default workload_type is Deployment.

• Console: Kubernetes Engine → Workloads → select the Gitea workload for pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
• CLI:

  kubectl get pods,svc -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100
  kubectl describe pod -n "$NAMESPACE" -l app=<service-name>

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. Cloud SQL for PostgreSQL 15

Gitea stores all application data (repository metadata, issues, pull requests, users, organizations) in a managed Cloud SQL for PostgreSQL 15 instance. Pods reach it through the Cloud SQL Auth Proxy sidecar; no public IP is exposed. On first deploy the db-init job idempotently creates the application role and database and grants privileges — Gitea itself creates and migrates its schema on first start.

• Console: SQL → select the instance for connections, backups, flags, metrics.
• CLI:

  gcloud sql instances list --project "$PROJECT"
  gcloud sql instances describe <instance-name> --project "$PROJECT"
  gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"

The instance name, database, user, and the Secret Manager secret holding the password are all in the Outputs. See App_GKE for the connection model, automated backups, and password rotation.

C. NFS storage — repositories, LFS, and attachments

Gitea's document root (GITEA__server__APP_DATA_PATH) lives on NFS (Cloud Filestore) mounted at /data by default, shared across pods. No GCS buckets are provisioned for this module.

• Console: Filestore → Instances.
• CLI:

  gcloud filestore instances list --project "$PROJECT"
  kubectl get pvc -n "$NAMESPACE"
  kubectl exec -n "$NAMESPACE" deploy/<service-name> -- df -h /data

See App_GKE for CMEK options and GCS Fuse mounts.

D. Secret Manager

Two Gitea secrets are generated automatically and stored in Secret Manager: SECRET_KEY (encrypts sensitive data such as 2FA secrets and OAuth tokens) and INTERNAL_TOKEN (authenticates Gitea's own internal API calls). The database password is managed separately by the foundation. On GKE, both secrets are materialised under simple Secret Manager keys (SECRET_KEY / INTERNAL_TOKEN, not the GITEA__security__* names used on Cloud Run) because the Secret Store CSI driver's SecretSync CRD forbids consecutive underscores in a synced-secret targetKey; Gitea reads them from the CSI-mounted files via its native GITEA__section__KEY__FILE convention.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~gitea"
  gcloud secrets versions access latest --secret=<secret-key-name> --project "$PROJECT"

See App_GKE for the Secret Store CSI integration and rotation.

E. Networking & ingress

By default the workload is exposed through an external Cloud Load Balancing IP (service_type = LoadBalancer, reserve_static_ip = true), and enable_custom_domain = true provisions a Gateway with a managed certificate (a nip.io hostname is used automatically if application_domains is left empty).

• Console: Network services → Load balancing; VPC network → IP addresses.
• CLI:

  kubectl get svc,ingress -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

F. Cloud Logging & Monitoring

Pod stdout/stderr flow to Cloud Logging; GKE and Cloud SQL metrics flow to Cloud Monitoring. Optional uptime checks and alert policies are available.

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. Gitea Application Behaviour

• First-deploy database setup. The db-init job runs db-init.sh using postgres:15-alpine. It waits for Cloud SQL to accept connections, idempotently creates (or re-passwords) the application role with CREATEDB, creates the database owned by that role, grants full database and public-schema privileges (PostgreSQL 15+ requires explicit schema grants), then signals the Cloud SQL Auth Proxy sidecar to shut down (POST /quitquitquit). The job is safe to re-run (execute_on_apply = true, max_retries = 3).
• Schema creation is Gitea's own responsibility. No separate migration job exists — Gitea creates and migrates its schema itself on first start against the empty database. No Postgres extensions are installed (db-init.sh needs none).
• Database env-var composition at runtime. The foundation injects discrete DB_HOST/DB_PORT/DB_NAME/DB_USER (+ the DB_PASSWORD secret). The platform entrypoint composes GITEA__database__{HOST,NAME,USER,SSL_MODE} from these at container start — branching on whether DB_HOST is a Cloud SQL socket path (/cloudsql/..., SSL disabled), the local proxy loopback (127.0.0.1, SSL disabled), or a direct private IP (SSL required) — then hands off to Gitea's stock /usr/bin/entrypoint.
• No installer, self-registration open. GITEA__security__INSTALL_LOCK = "true" skips the interactive first-run installer; GITEA__service__DISABLE_REGISTRATION = "false" leaves account self-registration enabled. There is no automated admin bootstrap — create/promote an admin manually after first deploy.
• Repository data on NFS. GITEA__server__APP_DATA_PATH points at the nfs_mount_path (default /data), so repositories, Git LFS objects, and attachments persist across pod restarts and redeploys.
• Set public_domain/public_url after the IP or domain is known. They default to localhost / http://localhost/. Patch them via environment_variables (or the module's public_domain/public_url variables) once the external address is assigned, so clone URLs, webhook callbacks, and OAuth redirects resolve correctly.
• Health path. Both startup and liveness probes are HTTP GET /api/healthz, which Gitea serves unauthenticated with HTTP 200 once it has finished booting.
• Inspect the init job and running config:

  kubectl get jobs -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" job/<db-init-job-name>
  kubectl exec -n "$NAMESPACE" deploy/<service-name> -- env | grep GITEA__

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Gitea are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 3 — Application Identity

Variable	Default	Description
application_name	gitea	Base name for resources. Do not change after first deploy.
application_version	1	gitea/gitea image tag consumed by the Dockerfile's APP_VERSION build arg.
container_image_source	custom	Builds the thin platform-entrypoint wrapper over gitea/gitea. prebuilt deploys gitea/gitea directly with no runtime GITEA__database__* composition — only use this if you wire the database env vars yourself.

Group 4 — Runtime & Scaling

Variable	Default	Description
container_port	3000	Gitea's HTTP port (GITEA__server__HTTP_PORT).
min_instance_count	0	Scale-to-zero by default.
max_instance_count	3	Cost ceiling; raise cautiously — replica coordination for background Git/CI operations is not explicitly managed by this module.
enable_cloudsql_volume	true	Auth Proxy sidecar (loopback) for Cloud SQL connectivity.

Group 6 — GKE Backend & Cluster

Variable	Default	Description
service_type	LoadBalancer	External IP for the Gitea UI.
workload_type	Deployment	Stateless Deployment; persistent data lives on NFS, not per-pod storage.
session_affinity	ClientIP	Sticky routing so a client reaches the same pod.
public_domain	localhost	Sets GITEA__server__DOMAIN; used for clone URLs and links. Set to your real hostname.
public_url	"" → http://<public_domain>/	Sets GITEA__server__ROOT_URL.

Group 13 — Filesystem (NFS)

Variable	Default	Description
enable_nfs	true	NFS is on by default so repositories, LFS objects, and attachments persist and are shared.
nfs_mount_path	/data	Mount path for the NFS share (matches Gitea_Common's own default). The value passed is also what GITEA__server__APP_DATA_PATH is set to, so the effective data directory always matches the mount.

Group 16 — Database Backend

Variable	Default	Description
database_type	POSTGRES_15	The db-init job is PostgreSQL-only (psql); do not switch to a MySQL value despite it being accepted by validation.
db_name	gitea	Database name. Immutable after first deploy.
db_user	gitea	Application database user; password auto-generated in Secret Manager.

Group 20 — Access & Networking (IAP)

Variable	Default	Description
enable_iap	false	Identity-Aware Proxy in front of the Gateway. Requires enable_custom_domain or enable_cdn.

Group 19 — Custom Domain, Static IP & Networking

Variable	Default	Description
enable_custom_domain	true	Provisions a Gateway + managed certificate; falls back to a nip.io hostname if application_domains is empty.
reserve_static_ip	true	Stable external IP across redeploys.
application_domains	[]	Custom hostnames + managed certificate.

All other inputs follow standard App_GKE behaviour.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip	In-cluster ClusterIP.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific services.
service_external_ip	External LoadBalancer IP (when a static IP is reserved).
service_url	URL to reach Gitea.
database_instance_name	Cloud SQL instance name.
database_name / database_user	Application database name / user.
database_password_secret	Secret Manager secret holding the DB password.
database_host / database_port	DB endpoint (127.0.0.1 via the Auth Proxy) / port.
storage_buckets	Created Cloud Storage buckets (empty — Gitea persists to NFS).
network_name / network_exists / regions	VPC network, presence, available regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
initialization_jobs / db_import_job	Names of the setup (db-init) and (optional) import jobs.
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / cicd_configuration	CI/CD status and details (repo, trigger, registry).
github_repository_url / github_repository_owner / github_repository_name	CI/CD GitHub details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time — a StatefulSet forced alongside a stateless setting, IAP with no authorized identities, quota_memory_* given as bare integers, an out-of-range container_port/backup_retention_days. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Setting	Sensible value	Risk	Consequence if wrong
database_type	POSTGRES_15	Critical	Switching to a MySQL value passes variable validation but breaks the PostgreSQL-only db-init.sh script, leaving the database uninitialized.
db_name / db_user	Set once	Critical	Immutable after first deploy; renaming recreates the DB/user and orphans all data.
SECRET_KEY / INTERNAL_TOKEN (auto-generated)	Never change	Critical	Changing these after first boot invalidates 2FA secrets, OAuth tokens, and internal API authentication.
enable_nfs	true	Critical	Disabling it makes repositories, LFS objects, and attachments ephemeral — lost on pod recreation.
enable_cloudsql_volume	true	High	The Auth Proxy sidecar is required for the default socket/loopback DB connectivity path.
public_domain / public_url	Set to the real hostname	High	Left at localhost, clone URLs, webhook callbacks, and OAuth redirects are wrong for every user.
max_instance_count	Keep conservative (3 default)	High	Scaling further without verifying multi-replica coordination for background Git/Actions work is unverified behaviour.
memory_limit / cpu_limit	512Mi / 1000m (defaults)	High	Below Kubernetes' gen2-equivalent floors the pod OOMs or throttles under load; raise for larger repositories or CI workloads.
quota_memory_requests / _limits	binary units (4Gi, 8192Mi)	Critical	Bare integers are treated as bytes and block all pod scheduling in the namespace.
Admin account creation	Manual post-deploy step	Medium	No account is bootstrapped automatically; forgetting this step with open self-registration means the first registered user is not guaranteed to be an admin.
enable_redis	Inert for Gitea	Low	Toggling it has no effect — no GITEA__cache__*/GITEA__session__* wiring consumes REDIS_HOST.
reserve_static_ip	true	Medium	Without it, the external IP can change across redeploys, breaking DNS and public_url.
backup_retention_days	7 (raise for prod)	Medium	Too short for compliance retention.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Gitea-specific application configuration shared with the Cloud Run variant is described in Gitea_Common.

Related guides

• Hands-on lab: Gitea on GKE Autopilot — deploy it step by step, with the console screens and commands at each stage.
• Gitea on Google Cloud Run — the same application on Cloud Run, for when you need the other deployment target.
• Gitea Common — Shared Application Configuration — the configuration shared by both deployment targets.
