Forgejo on GKE Autopilot

Forgejo is a lightweight, community-managed, self-hosted Git service — a fork of Gitea — providing repository hosting, issue tracking, pull requests, a built-in CI/CD (Actions) runner, code review, and a package registry from a single Go binary. This module deploys Forgejo on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services Forgejo uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

1. Overview

Forgejo runs as a single Go binary supervised by s6 inside the stock codeberg.org/forgejo/forgejo image, wrapped by a thin platform entrypoint that composes the database connection at runtime. The deployment wires together a focused set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	Forgejo pods on port 3000 (HTTP), 2 vCPU / 2Gi by default
Database	Cloud SQL for PostgreSQL 15	Locked in practice — db-init.sh uses psql; the database_type dropdown lists MYSQL/NONE as options but they are not supported
File persistence	Cloud Filestore (NFS)	Enabled by default; repositories, LFS objects and attachments live under the NFS mount (/mnt/nfs), shared across pods
Object storage	Cloud Storage	A generic, unused data-suffixed bucket is provisioned by the foundation default — Forgejo itself stores nothing in GCS
Secrets	Secret Manager	Auto-generated SECRET_KEY and INTERNAL_TOKEN, plus the database password; delivered to pods via CSI-mounted files because the GKE SecretSync CRD forbids __ in synced-secret keys
Ingress	Cloud Load Balancing (Gateway API)	External LoadBalancer with a reserved static IP; custom domain support is enabled by default, falling back to an auto-provisioned nip.io HTTPS hostname when no domain is set

Sensible defaults worth knowing up front:

• PostgreSQL 15 is the only engine that actually works. database_type defaults to POSTGRES_15; the db-init job's script is written entirely against psql, so selecting MySQL or NONE breaks database setup even though the variable metadata lists them as options.
• Cloud SQL is reached via the Auth Proxy sidecar on loopback. enable_cloudsql_volume = true by default, so a cloud-sql-proxy sidecar listens on 127.0.0.1:5432; the platform entrypoint selects SSL_MODE=disable for that hop.
• Deployment (not StatefulSet), NFS-backed, scale-to-zero capable. workload_type = "Deployment", min_instance_count = 0, max_instance_count = 3. Because enable_nfs = true by default, the foundation forces the Recreate rollout strategy (see App_GKE) so an update never runs two pods against the same NFS volume and database simultaneously.
• NFS is enabled by default, mounted at /mnt/nfs (GITEA__server__APP_DATA_PATH) — this is where repositories, Git LFS objects, and attachments persist.
• Session affinity is ClientIP.
• No separate migration job. GITEA__security__INSTALL_LOCK = "true" skips Forgejo's web installer; the forgejo/forgejo image creates and migrates its own schema on container start against the empty database the db-init job prepared.
• No admin account is bootstrapped by Terraform. There is no init job that creates a Forgejo admin user — see Section 3 for the manual step.
• SECRET_KEY and INTERNAL_TOKEN are auto-generated and stored in Secret Manager; on GKE they (and the DB password) are read from CSI-mounted secret files via Forgejo's native GITEA__section__KEY__FILE convention.
• public_domain / public_url default to localhost. Even though enable_custom_domain = true auto-provisions a reachable HTTPS endpoint, GITEA__server__DOMAIN / GITEA__server__ROOT_URL are not automatically synced to it — set public_domain (and optionally public_url) to the real external hostname so clone URLs and links resolve correctly.
• Self-registration is open by default (GITEA__service__DISABLE_REGISTRATION = "false").
• Redis is provisioned but not actually wired into Forgejo's config. enable_redis = true by default and the foundation injects REDIS_HOST / REDIS_PORT into the container, but Forgejo_Common sets no GITEA__cache__* / GITEA__session__* / GITEA__queue__* variables to consume them — Forgejo falls back to its built-in cache/session defaults unless you add that wiring yourself via environment_variables.

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the Forgejo workload

Forgejo pods run the codeberg.org/forgejo/forgejo image behind a thin custom build that installs a platform entrypoint (/platform-entrypoint.sh), then execs the stock Forgejo entrypoint under s6. Because the workload is NFS-backed by default, the Deployment uses the Recreate strategy.

• Console: Kubernetes Engine → Workloads → select the Forgejo workload for pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
• CLI:

  kubectl get pods,svc -n "$NAMESPACE" --selector app=forgejo 2>/dev/null || kubectl get pods,svc -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100
  kubectl describe pod -n "$NAMESPACE" -l app=<service-name>

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. Cloud SQL for PostgreSQL 15

Forgejo stores all application metadata (users, repositories, issues, pull requests, Actions runs) in a managed Cloud SQL for PostgreSQL 15 instance. Pods reach it through the Cloud SQL Auth Proxy sidecar on 127.0.0.1:5432; no public IP is exposed. On first deploy the db-init job creates the application role and database; Forgejo then creates and migrates its own schema on first container start.

• Console: SQL → select the instance for connections, backups, flags, metrics.
• CLI:

  gcloud sql instances list --project "$PROJECT"
  gcloud sql instances describe <instance-name> --project "$PROJECT"
  gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"

The instance name, database, user, and the Secret Manager secret holding the password are all in the Outputs. See App_GKE for the connection model, automated backups, and password rotation.

C. Cloud Filestore (NFS) — repository storage

Forgejo's repository data, Git LFS objects, and attachments live on NFS (Cloud Filestore), mounted inside the pod at /mnt/nfs by default (GITEA__server__APP_DATA_PATH). No GCS bucket is used for application data — Forgejo_Common always reports an empty storage_buckets output — though the generic storage_buckets variable default still creates one unused data-suffixed bucket unless overridden.

• Console: Filestore → Instances; Cloud Storage → Buckets.
• CLI:

  gcloud filestore instances list --project "$PROJECT"
  kubectl get pvc -n "$NAMESPACE"
  gcloud storage buckets list --project "$PROJECT" --filter="name~data"

See App_GKE for NFS discovery/creation and GCS Fuse mounts.

D. Secret Manager

Two Forgejo secrets are generated automatically and stored in Secret Manager: SECRET_KEY (encrypts sensitive data such as 2FA and OAuth tokens) and INTERNAL_TOKEN (authenticates Forgejo's own internal API calls). The database password is the foundation-managed secret. On GKE, all three are projected into pods as files via the Secret Store CSI driver and read by Forgejo through the GITEA__section__KEY__FILE convention (GITEA__database__PASSWD__FILE, GITEA__security__SECRET_KEY__FILE, GITEA__security__INTERNAL_TOKEN__FILE) — because the GKE SecretSync CRD rejects __ in a synced-secret's targetKey, these are materialised under the simple keys SECRET_KEY / INTERNAL_TOKEN rather than the GITEA__ names used on Cloud Run.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~forgejo"
  gcloud secrets versions access latest --secret=<secret-key-secret-name> --project "$PROJECT"

See App_GKE for the Secret Store CSI integration and rotation.

E. Networking & ingress

By default the workload is exposed through an external Cloud Load Balancing IP (service_type = LoadBalancer, reserve_static_ip = true so the address survives redeploys) fronted by a Gateway (enable_custom_domain = true), which provisions an automatic nip.io HTTPS hostname when no application_domains are supplied. Only the HTTP port (container_port = 3000) is wired into the Kubernetes Service — Forgejo's internal sshd (supervised by the same s6 process, per the Dockerfile) is not exposed by this module, so git+ssh:// clone URLs are not reachable externally without additional, manually-added networking.

• Console: Network services → Load balancing; VPC network → IP addresses.
• CLI:

  kubectl get svc,gateway -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

F. Cloud Logging & Monitoring

Pod stdout/stderr flow to Cloud Logging; GKE and Cloud SQL metrics flow to Cloud Monitoring. Optional uptime checks and alert policies are available.

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. Forgejo Application Behaviour

• First-deploy database setup. The db-init job runs db-init.sh using postgres:15-alpine. It waits for Cloud SQL to accept connections, idempotently creates (or re-passwords) the application role with CREATEDB, creates the database owned by that role, and grants full database + public schema privileges (PG15+). No Postgres extensions are installed by the script itself. The job is safe to re-run (execute_on_apply = true, max_retries = 3) and signals the Cloud SQL Auth Proxy sidecar to shut down (POST /quitquitquit on localhost:9091) so the Job container exits cleanly.
• No separate migration job — schema creation happens on container boot. With GITEA__security__INSTALL_LOCK = "true", Forgejo's web installer is skipped; the stock forgejo/forgejo entrypoint creates and migrates the schema in the empty database on first start, and applies further migrations on subsequent version upgrades.
• No admin account is created automatically. No initialization job runs a forgejo admin user create (or equivalent) step, and self-registration is enabled (GITEA__service__DISABLE_REGISTRATION = "false"), so anyone who can reach the service can create an account. The operator-side step to bootstrap the first administrator is to kubectl exec into a running pod and use Forgejo's own admin CLI. TODO: the exact CLI invocation and confirmation that the CLI binary is on PATH inside the deployed container were not verified from this repository's source — confirm against the running pod (kubectl exec -n "$NAMESPACE" deploy/<service-name> -- forgejo admin user create --help) before relying on it.
• DB connection env-var wiring. The foundation injects DB_HOST (the Cloud SQL Auth Proxy loopback address on GKE), DB_NAME, DB_USER, and the DB_PASSWORD secret. Because Kubernetes-style $(VAR) references are not used (Cloud Run doesn't interpolate them, so the same entrypoint works on both platforms), /platform-entrypoint.sh composes GITEA__database__{HOST,NAME,USER,SSL_MODE} at runtime from the injected DB_* values, selecting SSL_MODE=disable for the Unix-socket / loopback-proxy hops used on GKE. GITEA__database__PASSWD is not injected directly on GKE; instead Forgejo reads it from the CSI-mounted GITEA__database__PASSWD__FILE.
• NFS-backed rollouts use Recreate. Updates terminate the old pod before starting the new one, avoiding two pods writing to the same repository data on NFS. max_instance_count still defaults to 3 (not 1) — Forgejo is not a single-writer app in the same sense as a SQLite-backed one, but no multi-replica correctness testing for concurrent Git writes against the same NFS-backed data directory is documented in this module, so treat scaling beyond a single steady-state replica with the same caution as any other shared-filesystem workload.
• Health path. Both probes are HTTP GET /api/healthz, which Forgejo serves without authentication once database migrations complete: startup probe initial_delay_seconds=0, timeout_seconds=10, period_seconds=30, failure_threshold=10; liveness probe initial_delay_seconds=60, timeout_seconds=5, period_seconds=30, failure_threshold=3.
• Inspect the init job and running config:

  kubectl get jobs -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" job/<db-init-job-name>
  kubectl exec -n "$NAMESPACE" deploy/<service-name> -- env | grep GITEA__

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Forgejo are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 3 — Application Identity

Variable	Default	Description
application_name	forgejo	Base name for resources. Do not change after first deploy.
application_version	11	codeberg.org/forgejo/forgejo image tag, applied via the app-specific FORGEJO_VERSION build arg (latest maps to the pinned 11).
description	Forgejo - Self-hosted Git service and source-code hosting	Populates the workload description field.

Group 4 — Runtime & Scaling

Variable	Default	Description
container_image_source	custom	Builds a thin wrapper FROM codeberg.org/forgejo/forgejo:${FORGEJO_VERSION} that adds the platform DB-wiring entrypoint.
container_port	3000	Forgejo HTTP port; also sets GITEA__server__HTTP_PORT.
enable_cloudsql_volume	true	Cloud SQL Auth Proxy sidecar on loopback — required on GKE.
cpu_limit	2000m	2 vCPU per pod (Forgejo-specific override of the generic container_resources default).
memory_limit	2Gi	2Gi per pod (Forgejo-specific override).

Group 6 — GKE Backend & Cluster

Variable	Default	Description
workload_type	Deployment	Deployment (NFS-backed, Recreate strategy — see App_GKE).
service_type	LoadBalancer	External IP for the Forgejo UI/Git-over-HTTP.
session_affinity	ClientIP	Sticky routing so a client reaches the same pod.
public_domain	localhost	Sets GITEA__server__DOMAIN; used to build clone URLs and links. Override before/after first deploy.
public_url	"" → http://<public_domain>/	Sets GITEA__server__ROOT_URL.

Group 10 — Observability & Health

Variable	Default	Description
startup_probe	HTTP /api/healthz, failure_threshold=10, period_seconds=30	App-specific startup probe (see Section 3).
liveness_probe	HTTP /api/healthz, initial_delay_seconds=60, period_seconds=30, failure_threshold=3	App-specific liveness probe.

Group 13 — Filesystem (NFS)

Variable	Default	Description
enable_nfs	true	NFS is on by default so repositories, LFS objects, and attachments persist and are shared across pods.
nfs_mount_path	/mnt/nfs	Mounted path, also set as GITEA__server__APP_DATA_PATH. This is the effective default for this module — the Forgejo_Common module's own internal default (/data) is overridden by this variant.

Group 15 — Redis

Variable	Default	Description
enable_redis	true	Injects REDIS_HOST (defaulting to the NFS server IP) / REDIS_PORT into the container, but Forgejo_Common does not set any GITEA__cache__* / GITEA__session__* config to consume them — see the caution in Section 1.
redis_host	""	Override to point at Cloud Memorystore or another Redis instance.
redis_port	6379	Redis port.
redis_auth	"" (sensitive)	Redis AUTH password, if required.

Group 16 — Database Backend

Variable	Default	Description
database_type	POSTGRES_15	The only engine db-init.sh supports — do not change.
db_name	forgejo	Database name, injected as GITEA__database__NAME. Immutable after first deploy.
db_user	forgejo	Database user, injected as GITEA__database__USER; password auto-generated in Secret Manager and delivered via GITEA__database__PASSWD__FILE.
enable_postgres_extensions	true	postgres_extensions defaults to ["uuid-ossp"]. Forgejo's own schema does not require any Postgres extension; this is a foundation-level convenience default.

Group 19 — Custom Domain, Static IP & Networking

Variable	Default	Description
enable_custom_domain	true	Provisions a Gateway with a static IP; falls back to an auto-generated nip.io hostname when application_domains is empty.
application_domains	[]	Custom hostnames + managed certificate.
reserve_static_ip	true	Stable external IP across redeploys.

All other inputs follow standard App_GKE behaviour.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip	In-cluster ClusterIP.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific services.
service_external_ip	External LoadBalancer IP (when a static IP is reserved).
service_url	URL to reach Forgejo.
database_instance_name	Cloud SQL instance name.
database_name / database_user	Application database name / user.
database_password_secret	Secret Manager secret holding the DB password.
database_host / database_port	DB endpoint (127.0.0.1 via the Auth Proxy) / port.
storage_buckets	Created Cloud Storage buckets (the generic, unused data-suffixed bucket by default).
network_name / network_exists / regions	VPC network, presence, available regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
initialization_jobs / db_import_job	Names of the setup (db-init) and (optional) import jobs.
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / cicd_configuration	CI/CD status and details (repo, trigger, registry).
github_repository_url / github_repository_owner / github_repository_name	CI/CD GitHub details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time — a StatefulSet forced alongside a stateless setting, IAP with no authorized identities, quota_memory_* given as bare integers, an out-of-range container_port/backup_retention_days. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Setting	Sensible value	Risk	Consequence if wrong
database_type	POSTGRES_15	Critical	db-init.sh is psql-only; MySQL/NONE breaks database setup even though the variable metadata lists them.
db_name / db_user	Set once	Critical	Immutable after first deploy; renaming recreates the DB/user and orphans all repositories, issues, and PRs stored against the old role.
SECRET_KEY / INTERNAL_TOKEN (auto-generated)	Never change	Critical	Rotating these invalidates 2FA/OAuth-encrypted data and Forgejo's own internal API auth, breaking Git and API operations.
enable_nfs	true	Critical	Disabling it makes repositories, LFS objects, and attachments ephemeral — lost on pod recreation.
enable_cloudsql_volume	true	High	The Auth Proxy sidecar on 127.0.0.1:5432 is required for DB connectivity on GKE; the entrypoint's SSL-mode selection assumes it.
public_domain / public_url	Real external hostname	High	Defaults to localhost / http://localhost/, producing wrong Git clone URLs and broken links until overridden.
GITEA__service__DISABLE_REGISTRATION (via environment_variables)	true for non-public instances	High	Self-registration is open by default and no admin account is auto-created — anyone reaching the service can sign up.
Initial admin account	Create manually post-deploy	High	No init job bootstraps an admin; until one is created via the Forgejo CLI, the instance has no privileged user.
enable_redis	true, but confirm it is actually needed	Medium	REDIS_HOST/REDIS_PORT are injected with no effect unless you also add the matching GITEA__cache__*/GITEA__session__* config — provisioning Redis capacity for no benefit otherwise.
max_instance_count	3 (default)	Medium	Concurrent replicas share the same NFS-backed Git data directory and Postgres DB; multi-replica correctness for concurrent writes is not documented here — treat scaling like any shared-filesystem workload.
quota_memory_requests / _limits	binary units (4Gi, 8192Mi)	Critical	Bare integers are treated as bytes and block all pod scheduling in the namespace.
storage_buckets	Leave as-is or set create_cloud_storage = false	Low	The default data-suffixed bucket is provisioned but unused by Forgejo (all app data lives on NFS) — minor unnecessary cost if left enabled needlessly.
reserve_static_ip	true	Medium	Without it, the external IP can change across redeploys, breaking DNS and public_domain/public_url.
backup_retention_days	7 (raise for prod)	Medium	Too short for compliance retention.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Forgejo-specific application configuration shared with the Cloud Run variant is described in Forgejo_Common.
