code-server on GKE Autopilot

code-server is Coder's open-source (MIT) build of Visual Studio Code that runs on a remote server and is accessed entirely through the browser — a full IDE with the VS Code extension marketplace, integrated terminal, and language servers, backed by a persistent workspace. This module deploys code-server on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services code-server uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

1. Overview

code-server runs as a single self-contained web workload listening on port 8080. Unlike database-backed apps, it wires together a deliberately minimal set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	Single pod on port 8080; 1 vCPU / 1 GiB by default
Persistent workspace	Cloud Storage (GCS FUSE) or Persistent Disk (block PVC)	Mounted at /home/coder; block PVC when stateful_pvc_enabled = true
Database	None	database_type = NONE — code-server has no SQL database
Cache & queue	None	Redis is explicitly disabled (enable_redis = false)
Secrets	Secret Manager	Auto-generated editor PASSWORD (when enable_password = true), delivered via SecretSync
Ingress	Cloud Load Balancing	Default service_type = ClusterIP — in-cluster only; opt into external exposure

Sensible defaults worth knowing up front:

• No database and no Redis. code-server is a single container; all state lives in the workspace volume. database_type is fixed to NONE and Redis is disabled.
• Service type is ClusterIP by default. The workload is reachable only inside the cluster out of the box. Set service_type = LoadBalancer (or enable a custom domain) for external browser access.
• Two workspace storage modes. By default the workspace is a GCS FUSE volume at /home/coder. Setting stateful_pvc_enabled = true switches to a StatefulSet block PVC at /home/coder (lower-latency I/O for large workspaces); the wrapper then automatically disables the GCS volume to avoid a double-mount.
• A random editor PASSWORD is generated automatically and stored in Secret Manager, delivered into the pod via SecretSync as the PASSWORD env var. PASSWORD is a valid SecretSync targetKey (no __/consecutive separators).
• Single replica by design. min_instance_count = max_instance_count = 1. code-server holds per-session editor state in memory and owns one workspace volume.
• fsGroup = 3000 is set on the StatefulSet security context so the block PVC is group-writable by the code-server process (which runs as UID 1000 / GID 2000).
• The image is a thin wrapper over codercom/code-server, built and mirrored into Artifact Registry via Cloud Build; latest pins to 4.99.1 at build time.

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the code-server workload

code-server runs as a single pod on Autopilot (a Deployment by default, or a StatefulSet when stateful_pvc_enabled = true / workload_type = StatefulSet). Autopilot bills for the CPU/memory the pod actually requests.

• Console: Kubernetes Engine → Workloads → select the code-server workload to see the pod, revisions, and events. Kubernetes Engine → Services & Ingress shows the ClusterIP / external IP.
• CLI:

  kubectl get pods,svc -n "$NAMESPACE"
  kubectl get statefulset,pvc -n "$NAMESPACE"          # when stateful_pvc_enabled = true
  kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. Workspace storage — GCS FUSE or Persistent Disk

The single stateful resource, mounted at /home/coder:

• GCS FUSE (default). A dedicated Cloud Storage bucket is provisioned and mounted via the CSI driver at /home/coder.
• Block PVC (stateful_pvc_enabled = true). A per-pod Persistent Disk PVC (standard-rwo by default, 20Gi) is mounted at /home/coder instead, and the GCS volume is disabled to avoid a double-mount.

# GCS FUSE workspace bucket:
gcloud storage buckets list --project "$PROJECT" --filter="name~codeserver"
# Block PVC (when enabled):
kubectl get pvc -n "$NAMESPACE"
kubectl describe pvc -n "$NAMESPACE" <pvc-name>

See App_GKE for CMEK options, GCS FUSE, and StatefulSet PVC details.

C. Secret Manager — the editor password

When enable_password = true (default), a 24-character random PASSWORD is generated and stored in Secret Manager, then synced into the pod as the PASSWORD env var via SecretSync to gate the login page. There is no database password (no database).

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~codeserver AND name~password"
  gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"
  # Confirm the env var reached the pod:
  kubectl exec -n "$NAMESPACE" deploy/<service-name> -- env | grep -c PASSWORD

The secret ID is surfaced as the codeserver_password_secret_id output. See App_GKE for the Secret Store CSI integration and rotation.

D. Networking & ingress

The Service defaults to ClusterIP — in-cluster only. For external browser access set service_type = LoadBalancer, or enable a custom domain (enable_custom_domain, true by default) with a Google-managed certificate via the Gateway API. A static IP is reserved by default (reserve_static_ip = true) so the address survives redeploys.

• Console: Network services → Load balancing; VPC network → IP addresses.
• CLI:

  kubectl get ingress,svc -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

E. Cloud Logging & Monitoring

Pod stdout/stderr flow to Cloud Logging; GKE metrics flow to Cloud Monitoring. Optional uptime checks and alert policies are available (an uptime check needs a reachable external endpoint).

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. code-server Application Behaviour

• No first-deploy database setup. code-server has no SQL database and no initialization job. The pod comes up as soon as the container binds to 0.0.0.0:8080 (set via BIND_ADDR).
• No migrations. Upgrading application_version rolls a new pod on the newer image; there is no schema to migrate.
• The workspace is the only durable state. Everything under /home/coder — open folders, settings.json, keybindings, and installed extensions — persists on the GCS FUSE bucket or the block PVC. Deleting it wipes the workspace.
• Login is gated by the PASSWORD secret. With enable_password = true, the editor prompts for the SecretSync-delivered password (§2C). With it disabled, anyone reaching the Service gets an unauthenticated IDE — only run that way behind ClusterIP.
• Health path. The GKE variant's startup/liveness probes default to /health; when a password is enabled, override the path to the unauthenticated /healthz (which returns 200 without auth), since /health returns 401 and would fail the probe. Inspect the running pod:

  kubectl exec -n "$NAMESPACE" deploy/<service-name> -- env | grep BIND_ADDR

• Single-replica scaling. Keep min = max = 1. Editor sessions are in memory and the workspace volume has a single writer. With a block PVC, stateful_pod_management_policy defaults to OrderedReady for safe restarts.

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for code-server are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 1 — Project & Identity

Variable	Default	Description
project_id	(required)	Target Google Cloud project.
region	us-central1	Region for the workload and regional resources.

Group 2 — Deployment Environment

Variable	Default	Description
tenant_deployment_id	demo	Short suffix that makes resource names unique per environment.
support_users	[]	Emails granted project access and monitoring alerts.
resource_labels	{}	Labels applied to all resources.

Group 3 — Application Identity

Variable	Default	Description
application_name	codeserver	Base name for resources. Do not change after first deploy.
application_version	latest	code-server image tag; latest pins to 4.99.1 at build time. Pin a release in production.
enable_password	true	Generate a random editor PASSWORD and require it at login. Leave enabled for any externally exposed deployment.

Group 4 — Runtime & Scaling

Variable	Default	Description
deploy_application	true	Set false to provision infrastructure only.
cpu_limit	1000m	CPU per pod; raise for heavy language servers.
memory_limit	1Gi	Memory per pod; size to the workspaces and extensions you run.
min_instance_count	1	Keep at 1 — single-instance editor. GKE does not scale to zero.
max_instance_count	1	Keep at 1 — one workspace volume, in-memory session.
enable_cloudsql_volume	false	code-server has no Cloud SQL — keep false.
enable_image_mirroring	true	Mirror the code-server image into Artifact Registry.

Group 6 — GKE Backend & Cluster

Variable	Default	Description
service_type	ClusterIP	In-cluster by default. Set LoadBalancer for external browser access.
workload_type	null	Auto-resolves to StatefulSet when stateful_pvc_enabled = true; otherwise Deployment.
session_affinity	None	Sticky routing is unnecessary for a single-replica editor.
namespace_name	""	Auto-generated from application_name + tenant_deployment_id when empty.
termination_grace_period_seconds	60	Allow code-server to flush in-flight writes before SIGKILL.

Group 7 — StatefulSet

Variable	Default	Description
stateful_pvc_enabled	null	Set true to mount a block PVC at /home/coder (recommended for large workspaces); auto-selects StatefulSet and disables the GCS volume.
stateful_pvc_size	20Gi	Per-pod PVC size; hold all workspace files plus overhead.
stateful_pvc_mount_path	/home/coder	Workspace mount path.
stateful_pvc_storage_class	standard-rwo	Balanced PD default; use premium-rwo for higher IOPS.
stateful_pod_management_policy	null	OrderedReady recommended for safe restarts.
stateful_fs_group	3000	Pod-level fsGroup so the PVC is group-writable (code-server runs as UID 1000 / GID 2000).

Group 10 — Observability & Health

Variable	Default	Description
startup_probe	HTTP /health 15s delay	Startup probe. Override path to /healthz when a password is enabled.
liveness_probe	HTTP /health 30s delay	Liveness probe. Override path to /healthz when a password is enabled.
uptime_check_config	{ enabled = false, path = "/health" }	Cloud Monitoring uptime check; disabled by default (needs an external endpoint).
alert_policies	[]	Metric alert policies.

Group 13 — Filesystem (NFS)

Variable	Default	Description
enable_nfs	false	NFS is off by default; the workspace uses GCS FUSE or a block PVC, not NFS.
nfs_mount_path	/mnt/nfs	Mount path if NFS is enabled.

Group 15 — Redis Cache & Queue

Variable	Default	Description
enable_redis	(forced false)	Not applicable to code-server; the wrapper overrides the App_GKE default of true.
redis_auth	""	Not applicable; forwarded to the foundation for compatibility.

Group 16 — Database Backend

Variable	Default	Description
db_name	codeserverdb	Not referenced — code-server has no SQL database; forwarded for compatibility.
db_user	codeserveruser	Not referenced — forwarded for compatibility.

Group 19 — Custom Domain, Static IP & Networking

Variable	Default	Description
enable_custom_domain	true	Provision Gateway API Ingress + managed certificate for custom hostnames.
application_domains	[]	Hostnames to serve (e.g. codeserver.example.com).
reserve_static_ip	true	Stable external IP across redeploys.

All other inputs follow standard App_GKE behaviour.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip	In-cluster ClusterIP.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific services.
service_external_ip	External LoadBalancer IP (when a static IP is reserved).
service_url	URL to reach code-server.
codeserver_password_secret_id	Secret Manager secret ID holding the editor password (empty when enable_password = false).
storage_buckets	Created Cloud Storage buckets (the workspace bucket).
statefulset_name	Name of the StatefulSet (when a block PVC is enabled).
network_name / network_exists / regions	VPC network, presence, regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
initialization_jobs	Names of any user-supplied init jobs (none by default).
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / cicd_configuration	CI/CD status and details (repo, trigger, registry).
github_repository_url / github_repository_owner / github_repository_name	CI/CD GitHub details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time — workload_type = "Deployment" alongside stateful_pvc_enabled = true, IAP with no authorized identities, a bare-integer quota_memory_* value, an out-of-range timeout_seconds. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Setting	Sensible value	Risk	Consequence if wrong
enable_password	true (keep on for external exposure)	Critical	Disabling with service_type = LoadBalancer (or a custom domain) exposes a fully unauthenticated IDE — including a terminal — to the internet.
Workspace volume (bucket / PVC)	Never delete	Critical	The /home/coder GCS bucket or PVC is the only persistent state; deleting it wipes all settings, extensions, and files.
startup_probe / liveness_probe path	/healthz when a password is set	High	The GKE default /health returns 401 under a password; the pod never becomes Ready and restart-loops.
stateful_pvc_enabled + workload_type	Do not set Deployment with PVC enabled	High	The combination is rejected at plan time; PVC requires a StatefulSet.
max_instance_count	1	High	Scaling beyond 1 splits editor sessions across pods and risks concurrent writes to a single workspace volume.
stateful_fs_group	3000 (non-zero)	High	Setting 0 leaves fsGroup unset; the block PVC may be root-owned and code-server (UID 1000) cannot write to /home/coder.
service_type	ClusterIP (or LoadBalancer + password)	High	LoadBalancer without a password publishes an open IDE; ClusterIP blocks all external browser access.
enable_cloudsql_volume	false	Low	code-server has no database; enabling adds an unused Auth Proxy sidecar.
memory_limit	1Gi+	Medium	Heavy language servers/extensions can OOM below 1 GiB.
quota_memory_requests / _limits	binary units (4Gi, 8192Mi)	Critical	Bare integers are bytes and block all pod scheduling in the namespace.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. code-server-specific application configuration shared with the Cloud Run variant is described in CodeServer_Common.
