CloudBeaver on GKE Autopilot
CloudBeaver is a web-based, browser-accessible database manager from the DBeaver project — a single administrative console for connecting to and querying PostgreSQL, MySQL, SQL Server, Oracle, SQLite and many other engines. This module deploys CloudBeaver on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.
This guide focuses on the cloud services CloudBeaver uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.
1. Overview
CloudBeaver runs as a single JVM web workload. Because CloudBeaver keeps all of its own state in a persistent workspace and provisions no application database, the deployment wires together a deliberately small set of Google Cloud services:
| Capability | Google Cloud service | Notes |
|---|---|---|
| Compute | GKE Autopilot | Single JVM pod, 1 vCPU / 1 GiB by default, port 8978 |
| Persistent workspace | Persistent Disk (block PVC) via StatefulSet | Recommended: a per-pod block PVC mounted at /opt/cloudbeaver/workspace backs the embedded H2 store |
| Database | None provisioned | database_type = "NONE" — CloudBeaver stores its own state; it connects out to databases you configure in the UI |
| Cache & queue | None | CloudBeaver uses no Redis; enable_redis is forced off |
| Secrets | Secret Manager | No app-level secret is generated — the admin account is created via the first-run setup wizard |
| Ingress | Cloud Load Balancing | ClusterIP by default (in-cluster); use LoadBalancer / a custom domain for external access |
Sensible defaults worth knowing up front:
- No application database is provisioned.
database_type = "NONE". CloudBeaver keeps its metadata in an embedded H2 store inside the workspace volume. The databases it manages are added by an operator in the UI after deploy. - Use a block PVC for the workspace, not GCS FUSE.
stateful_pvc_enabled = trueis strongly recommended: a block Persistent Disk — not GCS FUSE — is the correct backing store for CloudBeaver's embedded H2 database. When the PVC is enabled the module automatically skips the GCS FUSE volume at the same path to avoid a double-mount. - StatefulSet is auto-selected. Setting
stateful_pvc_enabled = truewithout an explicitworkload_typeresolves the workload to aStatefulSetfor stable pod identity and orderly restarts. - Single instance by design.
min_instance_count = 1(avoid slow JVM cold starts, and GKE has no scale-to-zero) andmax_instance_count = 1(the workspace is a single-writer store). Do not raisemax_instance_count. - Service is
ClusterIPby default. In-cluster only — appropriate for a database admin console. For browser access from outside the cluster, useservice_type = "LoadBalancer"or an Ingress with a custom domain (and IAP). - The admin account is claimed by the first visitor. CloudBeaver has no seeded admin — complete the setup wizard immediately once the service is reachable.
2. Google Cloud Services & How to Explore Them
All commands assume you have run
gcloud container clusters get-credentials <cluster> --region <region> --project <project>
and that PROJECT, REGION, and NAMESPACE are set. The namespace and other
identifiers are reported in the deployment Outputs.
A. GKE Autopilot — the CloudBeaver workload
CloudBeaver pods are scheduled on Autopilot, which bills for the CPU/memory the pods actually request. With a block PVC enabled the workload runs as a StatefulSet (port 8978) for stable pod identity. Because the workspace is single-writer, keep the workload at a single replica.
- Console: Kubernetes Engine → Workloads → select the CloudBeaver workload to see pods and events. Kubernetes Engine → Services & Ingress shows how it is exposed.
- CLI:
kubectl get pods,svc,statefulset -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" statefulset/<service-name> --tail=100
kubectl describe statefulset -n "$NAMESPACE"
See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.
B. Persistent Disk — the workspace volume (block PVC)
CloudBeaver's entire state — its embedded H2 metadata database, saved connections,
users, and configuration — persists under /opt/cloudbeaver/workspace. The
recommended backing store is a block Persistent Disk provisioned per-pod by the
StatefulSet's PVC template and mounted at that path. This is the durable heart of the
deployment and the correct store for the embedded H2 database.
- Console: Kubernetes Engine → Storage → Persistent Volume Claims.
- CLI:
kubectl get pvc -n "$NAMESPACE"
kubectl describe pvc -n "$NAMESPACE"
# Inspect the workspace contents inside the pod:
kubectl exec -n "$NAMESPACE" statefulset/<service-name> -- ls -la /opt/cloudbeaver/workspace
When stateful_pvc_enabled = true, the module sets enable_gcs_storage_volume = false
so the GCS FUSE volume is not also mounted at the same path. A storage Cloud Storage
bucket is still declared by CloudBeaver_Common for parity with the Cloud Run variant.
C. Cloud Storage
A storage Cloud Storage bucket is declared for the deployment. With the
recommended block-PVC setup the workspace lives on the Persistent Disk rather than the
bucket, but the bucket is still provisioned and available for auxiliary storage.
- Console: Cloud Storage → Buckets.
- CLI:
gcloud storage buckets list --project "$PROJECT"
See App_GKE for CMEK options and GCS Fuse mounts.
D. Database connectivity (no managed instance)
This module provisions no Cloud SQL instance — gcloud sql instances list will
not show one created by CloudBeaver. Instead, CloudBeaver connects out to whatever
databases you register in its UI. To reach the deployment's own shared Cloud SQL (or
any private database), the target must be reachable on the VPC from the pod.
- CLI (test reachability from within the pod):
kubectl exec -n "$NAMESPACE" statefulset/<service-name> -- sh -c 'nc -zv <db-private-ip> 5432'
E. Secret Manager
CloudBeaver generates no application-level secret — there is no encryption key, no JWT secret, and no database password to manage (there is no database). The admin account is created through the first-run setup wizard, and all state lives in the workspace.
- Console: Security → Secret Manager.
- CLI:
gcloud secrets list --project "$PROJECT"
See App_GKE for the Secret Store CSI integration and rotation.
F. Networking & ingress
By default the workload is exposed as a ClusterIP Service — reachable only from
inside the cluster, which suits a database administration console. For browser access
from outside the cluster, use service_type = "LoadBalancer" or enable an Ingress
with a custom domain and Google-managed certificate (optionally with IAP, Cloud Armor,
and a reserved static IP).
- Console: Network services → Load balancing; VPC network → IP addresses.
- CLI:
kubectl get svc,ingress -n "$NAMESPACE"
gcloud compute addresses list --project "$PROJECT"
See App_GKE for custom domains, Cloud CDN, and static IP details.
G. Cloud Logging & Monitoring
Pod stdout/stderr flow to Cloud Logging; GKE metrics flow to Cloud Monitoring. Optional uptime checks and alert policies are available (uptime checks require a publicly reachable endpoint, e.g. a LoadBalancer Service).
- Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
- CLI:
gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
--project "$PROJECT" --limit 50
3. CloudBeaver Application Behaviour
- No first-deploy database setup. There is no db-init job and no application database. CloudBeaver initialises its own embedded metadata store inside the workspace on first start.
- State is entirely in the workspace volume. The embedded H2 database, saved
connections, managed users, and configuration all live under
/opt/cloudbeaver/workspace, backed by the block PVC. The PVC survives pod restarts and rescheduling, which is why a StatefulSet + block PVC is strongly recommended over GCS FUSE for the embedded H2 store. - First-run setup wizard. On first access CloudBeaver presents a setup wizard to create the server configuration and the administrator account. There is no seeded admin — whoever completes the wizard first becomes the admin. Do this immediately, and keep the Service internal until you have.
- Adding databases to manage. After logging in as admin, add connections in the UI (New Connection → choose the driver → supply host/port/credentials). To reach private databases, ensure they are reachable on the VPC from the pod.
- Health path. Startup and liveness probes target
/(the CloudBeaver web UI), which returns HTTP 200 once the JVM has finished starting. - Single-writer scaling. Keep
max_instance_count = 1. The workspace store cannot be shared safely by concurrent pods. - Inspect the running configuration:
kubectl exec -n "$NAMESPACE" statefulset/<service-name> -- env | sort
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for CloudBeaver are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.
Group 1 — Project & Identity
| Variable | Default | Description |
|---|---|---|
project_id | (required) | Target Google Cloud project. |
region | us-central1 | Region for the workload and regional resources. |
Group 2 — Deployment Environment
| Variable | Default | Description |
|---|---|---|
tenant_deployment_id | demo | Short suffix that makes resource names unique per environment. |
support_users | [] | Emails granted project access and monitoring alerts. |
resource_labels | {} | Labels applied to all resources. |
Group 3 — Application Identity
| Variable | Default | Description |
|---|---|---|
application_name | cloudbeaver | Base name for resources. Do not change after first deploy. |
application_display_name | CloudBeaver | Human-readable name shown in the Console. |
application_version | latest | CloudBeaver image tag (built from dbeaver/cloudbeaver:<version>); pin for reproducibility. |
Group 4 — Runtime & Scaling
| Variable | Default | Description |
|---|---|---|
min_instance_count | 1 | Keep 1 warm replica (GKE has no scale-to-zero; avoids slow JVM cold starts). |
max_instance_count | 1 | Keep at 1. The workspace is a single-writer store; concurrent pods corrupt it. |
cpu_limit | 1000m | CPU per pod. |
memory_limit | 1Gi | Memory per pod. CloudBeaver runs on the JVM — size accordingly. |
container_port | 8978 | Fixed by CloudBeaver_Common; not forwarded to App_GKE and has no effect here. |
Group 6 — GKE Backend & Cluster
| Variable | Default | Description |
|---|---|---|
service_type | ClusterIP | In-cluster by default (recommended for a DB console). Use LoadBalancer for external access. |
workload_type | null | Leave unset — with stateful_pvc_enabled = true it auto-resolves to StatefulSet. |
session_affinity | (set) | Sticky routing for UI sessions. |
Group 7 — StatefulSet
| Variable | Default | Description |
|---|---|---|
stateful_pvc_enabled | null | Set true — a block PVC (not GCS FUSE) is the correct store for CloudBeaver's embedded H2 DB. |
stateful_pvc_size | 20Gi | Per-pod PVC size; hold the workspace plus overhead. |
stateful_pvc_mount_path | /opt/cloudbeaver/workspace | Must be CloudBeaver's workspace directory. |
stateful_pvc_storage_class | (set) | Kubernetes StorageClass for the PVC. |
stateful_headless_service | (set) | Headless Service for stable pod DNS names. |
Group 10 — Observability & Health
| Variable | Default | Description |
|---|---|---|
startup_probe | HTTP / 15s delay | Startup probe against the CloudBeaver UI. |
liveness_probe | HTTP / 30s delay | Liveness probe against the CloudBeaver UI. |
uptime_check_config | (set) | Cloud Monitoring uptime check — requires a publicly reachable endpoint (e.g. a LoadBalancer Service). |
Group 13 — Filesystem (NFS)
| Variable | Default | Description |
|---|---|---|
enable_nfs | false | NFS is off — CloudBeaver's workspace is on the block PVC, not NFS. |
Group 14 — Cloud Storage & Artifact Registry
| Variable | Default | Description |
|---|---|---|
create_cloud_storage | true | Provision the declared GCS buckets. |
storage_buckets | [] | Additional buckets to provision. |
enable_image_mirroring | true | Mirror the CloudBeaver image into Artifact Registry before deployment. |
All other inputs follow standard App_GKE behaviour. Note that
enable_redis is forced to false and no application database is provisioned
(database_type = NONE) by this module.
5. Outputs
These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.
| Output | Description |
|---|---|
service_name | Kubernetes Service name. |
namespace | Namespace the workload runs in. |
service_cluster_ip | In-cluster ClusterIP. |
stage_service_cluster_ips | Map of ClusterIPs for stage-specific services. |
service_external_ip | External LoadBalancer IP (when a static IP is reserved / LoadBalancer is used). |
service_url | URL to reach CloudBeaver. |
storage_buckets | Created Cloud Storage buckets. |
network_name / network_exists / regions | VPC network, presence, available regions. |
container_image / container_registry | Deployed image and Artifact Registry repo. |
monitoring_enabled / monitoring_notification_channels | Monitoring status and channels. |
initialization_jobs | Names of any initialization jobs (empty by default). |
statefulset_name | Name of the StatefulSet. |
deployment_id / tenant_id / resource_prefix | Naming identifiers. |
project_id / project_number | Project identifiers. |
cicd_enabled / cicd_configuration | CI/CD status and details (repo, trigger, registry). |
github_repository_url / github_repository_owner / github_repository_name | CI/CD GitHub details. |
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id | Registry and build trigger. |
kubernetes_ready | Whether the cluster/workload is ready. |
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode | VPC-SC status. |
audit_logging_enabled / artifact_registry_cmek_enabled | Audit logging and CMEK status. |
6. Configuration Pitfalls & Sensible Defaults
Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).
Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time —
workload_type = "Deployment"alongsidestateful_pvc_enabled = true,quota_memory_requests/_limitswithout binary unit suffixes, IAP with no authorized identities. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.
| Setting | Sensible value | Risk | Consequence if wrong |
|---|---|---|---|
stateful_pvc_enabled | true (block PVC) | Critical | Without a persistent block PVC the workspace (embedded H2 DB, connections, users, config) is lost on pod restart. GCS FUSE is not a safe store for the embedded H2 database. |
| Workspace PVC | Preserve across redeploys | Critical | The PVC holds all CloudBeaver state; deleting it wipes every saved connection and setting. |
max_instance_count | 1 | Critical | The workspace is single-writer; two pods writing the embedded H2 store concurrently corrupt it. |
stateful_pvc_mount_path | /opt/cloudbeaver/workspace | High | CloudBeaver's workspace path is baked into the image; mounting elsewhere leaves state on ephemeral storage. |
| First-run setup wizard | Complete immediately | High | There is no seeded admin — anyone who reaches the UI first can claim the administrator account. |
service_type | ClusterIP (or LB+IAP) | High | LoadBalancer without IAP/Cloud Armor exposes a database admin console to the public internet. |
memory_limit | 1Gi | High | CloudBeaver is JVM-based; too little memory causes OOM kills. |
min_instance_count | 1 | Medium | GKE requires min ≥ 1; a warm replica avoids slow JVM cold starts. |
application_version | Pin a tag in production | Medium | latest can shift the CloudBeaver version between rebuilds; pin for reproducibility. |
quota_memory_requests / _limits | binary units (4Gi, 8192Mi) | Critical | Bare integers are bytes and block all pod scheduling in the namespace. |
enable_redis / database_type | Leave as set (off / NONE) | Low | CloudBeaver uses neither; overriding has no benefit and is unsupported here. |
For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. CloudBeaver-specific application configuration shared with the Cloud Run variant is described in CloudBeaver_Common.
