Strapi GKE Module — Configuration Guide

Strapi is an open-source headless CMS that gives developers the freedom to choose their favourite tools and frameworks while enabling content editors to manage their content independently. This module deploys Strapi on GKE Autopilot, backed by a managed Cloud SQL PostgreSQL instance, a Cloud Filestore NFS volume for media uploads, and a GCS bucket for object storage.

Strapi GKE is a wrapper module built on top of App GKE. It uses App GKE for all GCP infrastructure provisioning (cluster, networking, Cloud SQL, GCS, secrets, CI/CD) and adds Strapi-specific application configuration and secret management on top.

Note: Variables marked as platform-managed are set and maintained by the platform. You do not normally need to change them.

---

How This Guide Is Structured

This guide documents only the variables that are unique to Strapi_GKE or that have Strapi-specific defaults that differ from the App_GKE base module. For all other variables — project identity, runtime scaling, backend configuration, storage, CI/CD, observability, networking, IAP, and Cloud Armor — refer directly to the App_GKE Configuration Guide.

Variables fully covered by the App GKE guide:

Configuration Area	App GKE.md Section	Strapi-Specific Notes
Module Metadata & Configuration	App_GKE §1 Module Overview	Different defaults for module_description and module_documentation.
Project & Identity	App_GKE §2 IAM & Access Control	Refer to base App GKE module documentation.
Application Identity	App_GKE §1 Module Overview	See Strapi Application Identity below for Strapi-specific defaults.
Runtime & Scaling	App_GKE §3.A Compute (GKE Autopilot)	See Strapi Runtime Configuration below. container_image_source defaults to "custom"; container_port defaults to 1337.
Environment Variables & Secrets	App_GKE §3.A Compute (GKE Autopilot)	See Strapi Environment Variables below for email and GCS defaults.
GKE Backend Configuration	App_GKE §3.A Compute (GKE Autopilot)	Refer to base App GKE module documentation.
Jobs & Scheduled Tasks	App_GKE §3.E Initialization Jobs & CronJobs	A db-init job runs automatically — see Platform-Managed Behaviours. Refer to App_GKE for customising additional jobs.
CI/CD & GitHub Integration	App_GKE §6 CI/CD & Delivery	Refer to base App GKE module documentation.
Storage — NFS	App_GKE §3.C Storage (NFS / GCS / GCS Fuse)	NFS is enabled by default in this module. See NFS Storage below.
Storage — GCS	App_GKE §3.C Storage (NFS / GCS / GCS Fuse)	A default data bucket is provisioned. Refer to App GKE module documentation for bucket configuration.
Database Configuration	App_GKE §3.B Database (Cloud SQL)	See Strapi Database Configuration below.
Backup Schedule & Retention	App_GKE §8.B Backup Import & Recovery	Refer to base App GKE module documentation. See also Backup Import & Recovery below.
Custom SQL Scripts	App_GKE §3.E Initialization Jobs & CronJobs	Refer to base App GKE module documentation.
Observability & Health	App_GKE §5 Traffic & Ingress	See Strapi Health Probes below for Strapi-specific defaults.
Reliability Policies	App_GKE §7 Reliability & Scheduling	Refer to base App GKE module documentation.
Resource Quota	App_GKE §7.C Resource Quotas	Refer to base App GKE module documentation.
Custom Domain, Static IP & Network	App_GKE §5 Traffic & Ingress	Refer to base App GKE module documentation.
Identity-Aware Proxy	App_GKE §4.B Identity-Aware Proxy (IAP)	Refer to base App GKE module documentation.
Cloud Armor	App_GKE §4.A Cloud Armor WAF	Refer to base App GKE module documentation.

---

Platform-Managed Behaviours

The following behaviours are applied automatically by Strapi GKE regardless of the variable values in your tfvars file. They cannot be overridden by user configuration.

Behaviour	Detail
Strapi security secrets	Five secrets are auto-generated and stored in Secret Manager: JWT_SECRET, ADMIN_JWT_SECRET, API_TOKEN_SALT, TRANSFER_TOKEN_SALT, and APP_KEYS (a comma-separated list of four keys). These are required by Strapi for authentication and API security and are injected into the container automatically. You do not need to generate or manage these values.
GCS environment variables	GCS_BUCKET_NAME and GCS_BASE_URL are automatically injected into the container, pointing to the provisioned GCS uploads bucket. Strapi is pre-configured to use the GCS upload provider when these variables are present.
Database initialisation job	A db-init Kubernetes Job runs automatically on each deployment using postgres:15-alpine. It idempotently creates the Strapi database and user, waits for Cloud SQL to be ready, and handles password updates. You do not need to run manual database setup. To override the default job, set initialization_jobs with your custom job definition.
PostgreSQL required	database_type defaults to "POSTGRES" (latest managed Cloud SQL PostgreSQL). Strapi requires PostgreSQL — setting database_type = "NONE" or a MySQL variant will cause the application to fail at startup.
Container port 1337	Strapi listens on port 1337 by default. The container_port variable is set to 1337, and the PORT environment variable controls the listen port at runtime (configurable in environment_variables if needed).
Custom image build	container_image_source defaults to "custom". The module includes a Strapi Dockerfile (based on node:20-alpine) that installs dependencies, builds the application, and packages it for production. Set container_image_source = "prebuilt" with a container_image URI to skip the build and deploy an existing image.
NFS enabled	enable_nfs = true by default. Strapi stores media uploads on the NFS volume mounted at /mnt/nfs, which persists across pod restarts and is shared between replicas. Disabling NFS is possible but will result in media uploads being stored ephemerally in the container filesystem.
Email provider support	If SMTP_HOST is set in environment_variables, the Strapi plugins.js automatically configures the nodemailer email provider. No code changes are required to enable email delivery.

---

Strapi Application Identity

These variables control how the Strapi deployment is named and described. They correspond directly to the application_name, application_display_name, and application_description variables in App GKE and behave identically — the only difference is the Strapi-specific default values.

Variable	Default	Options / Format	Description & Implications
application_name	"strapi"	[a-z][a-z0-9-]{0,19}	Internal identifier used as the base name for GKE workloads, Cloud SQL, GCS buckets, Artifact Registry, and Secret Manager secrets. Do not change after initial deployment. See App_GKE §1 Module Overview for full details.
application_display_name	"Strapi CMS"	Any string	Human-readable name shown in the platform UI and monitoring dashboards. Can be updated freely without affecting resource names.
application_description	"Strapi Headless CMS on GKE"	Any string	Brief description of the deployment. Populated into Kubernetes resource annotations and platform documentation.
application_version	"5.0.0"	Strapi version string (e.g. "5.0.0", "4.25.0")	Version tag applied to the container image and used for deployment tracking. When container_image_source = "custom", incrementing this value triggers a new Cloud Build run. When container_image_source = "prebuilt", this value is informational only. Use the official Strapi release version matching the image you intend to deploy.

Validating Application Identity

# Confirm the Deployment exists with the expected name
kubectl get deployments -n NAMESPACE -o wide

# View workload labels and annotations
kubectl describe deployment strapi -n NAMESPACE | grep -A5 Labels

---

Strapi Runtime Configuration

Strapi is a Node.js application. The module defaults are sized for a development or small production instance. For high-traffic deployments, increase container_resources.

Strapi-specific runtime defaults that differ from App GKE:

Variable	App GKE Default	Strapi GKE Default	Reason
container_image_source	"custom"	"custom"	The included Strapi Dockerfile provides a production-ready build.
container_port	8080	1337	Strapi listens on port 1337 by default (configurable via the PORT environment variable).
container_resources.cpu_limit	"1000m"	"1000m"	Suitable for development and low-traffic production. Increase for higher throughput.
container_resources.memory_limit	"512Mi"	"512Mi"	Increase to "1Gi" or higher for production workloads with large media libraries or many concurrent users.
min_instance_count	1	1	Keeps at least one Strapi pod running at all times to avoid cold-start latency.
max_instance_count	3	10	Allows horizontal scaling up to 10 replicas under load.

Note on container_resources: The full container_resources object (as documented in App_GKE §3.A Compute (GKE Autopilot)) is available. Use it to set cpu_request, mem_request, and ephemeral storage limits in addition to the defaults above.

deploy_application

Variable	Default	Options / Format	Description & Implications
deploy_application	true	true / false	When false, the module provisions all supporting infrastructure (Cloud SQL, GCS buckets, Artifact Registry, Secret Manager secrets) without deploying the Strapi workload. This is useful for staged rollouts or when you need to validate infrastructure before the first application deployment.

Validating Runtime Configuration

# View container resource requests and limits on the running pod
kubectl describe pod -n NAMESPACE -l app=strapi | grep -A10 "Limits:"

# Confirm the image and port being used
kubectl get deployment strapi -n NAMESPACE \
  -o jsonpath='{.spec.template.spec.containers[0].image}'

kubectl get service strapi -n NAMESPACE \
  -o jsonpath='{.spec.ports[0].port}'

---

Strapi Database Configuration

Strapi requires PostgreSQL. The module uses application_database_name and application_database_user (consistent with the App GKE interface) to configure the database.

All other database variables (database_type, sql_instance_name, database_password_length, enable_auto_password_rotation, rotation_propagation_delay_sec, etc.) behave identically to the App_GKE equivalents — refer to App_GKE §3.B Database (Cloud SQL) for their documentation.

Variable	Default	Options / Format	Description & Implications
application_database_name	"strapi"	[a-z][a-z0-9_]{0,62}	The name of the PostgreSQL database created within the Cloud SQL instance. Injected as the DB_NAME environment variable. Do not change after initial deployment — Strapi stores all application data in this database and renaming it requires manual migration.
application_database_user	"strapi"	[a-z][a-z0-9_]{0,31}	The PostgreSQL user created for the Strapi application. Injected as the DB_USER environment variable. The password is auto-generated, stored in Secret Manager, and injected as DB_PASSWORD.
database_type	"POSTGRES"	POSTGRES, POSTGRES_15, POSTGRES_14, etc.	The Cloud SQL PostgreSQL version. Defaults to the latest managed version. Strapi requires PostgreSQL — do not set this to "NONE" or a MySQL variant.

Note: The db-init initialisation job connects as the postgres superuser to create the Strapi database and user before the application starts. You do not need to run these steps manually.

Validating Database Configuration

# Confirm the database and user were created
gcloud sql databases list --instance=INSTANCE_NAME --project=PROJECT_ID

gcloud sql users list --instance=INSTANCE_NAME --project=PROJECT_ID

# Confirm DB_NAME and DB_USER env vars are injected into the pod
kubectl exec -n NAMESPACE POD_NAME -- env | grep -E "^DB_"

---

Strapi Environment Variables

The environment_variables variable (documented in App_GKE §3.A Compute (GKE Autopilot)) is used by Strapi to configure email delivery and other runtime settings.

Email delivery (optional):

If SMTP_HOST is set, the built-in plugins.js automatically configures the nodemailer email provider for Strapi notifications (user invitations, password resets, and workflow notifications). For sensitive values such as SMTP_PASSWORD, use secret_environment_variables instead:

environment_variables = {
  SMTP_HOST     = "smtp.sendgrid.net"
  SMTP_PORT     = "587"
  SMTP_USERNAME = "apikey"
  EMAIL_FROM    = "noreply@example.com"
}

secret_environment_variables = {
  SMTP_PASSWORD = "strapi-smtp-password"   # Secret Manager secret name
}

GCS upload integration (auto-injected):

GCS_BUCKET_NAME and GCS_BASE_URL are injected automatically by the platform and do not need to be set manually. Strapi's plugins.js reads these values to configure the GCS upload provider.

All other environment_variables and secret_environment_variables behaviour is identical to App_GKE — refer to App_GKE §3.A Compute (GKE Autopilot).

---

Strapi Health Probes

Strapi performs database connection validation and may run pending migrations on startup. The health probes in Strapi GKE use the Strapi-native /_health endpoint rather than a generic path, and have extended timeouts to accommodate the Node.js startup sequence and database checks.

Probe routing in Strapi_GKE: startup_probe_config and health_check_config each serve a dual role — they are passed to Strapi_Common (as startup_probe and liveness_probe respectively) to configure the Kubernetes container probes, and also forwarded directly to App_GKE (using the same startup_probe_config / health_check_config names) to configure the load balancer backend health checks. Other App_GKE wrapper modules use separate startup_probe/liveness_probe variables for container probes; Strapi_GKE consolidates both paths into the single _config pair. See App_GKE §5 Traffic & Ingress for the App_GKE field reference.

Strapi-specific probe defaults that differ from App GKE:

Variable	App GKE Default path	Strapi GKE Default path	Reason
startup_probe_config	"/"	"/_health"	Strapi exposes a dedicated health endpoint at /_health that confirms the application and database connection are ready.
health_check_config	"/"	"/_health"	Using /_health for the liveness probe ensures Cloud Run only routes traffic to fully initialised Strapi instances.

Default probe configuration:

startup_probe_config = {
  enabled               = true
  type                  = "HTTP"
  path                  = "/_health"
  initial_delay_seconds = 10
  timeout_seconds       = 5
  period_seconds        = 10
  failure_threshold     = 3
}

health_check_config = {
  enabled               = true
  type                  = "HTTP"
  path                  = "/_health"
  initial_delay_seconds = 15
  timeout_seconds       = 5
  period_seconds        = 30
  failure_threshold     = 3
}

On first deployment, when Strapi initialises its database schema, startup may take longer than usual. If the startup probe fails on initial deploy, increase startup_probe_config.initial_delay_seconds or failure_threshold.

Validating Health Probes

# View startup and liveness probe config on the running pod
kubectl get deployment strapi -n NAMESPACE \
  -o jsonpath='{.spec.template.spec.containers[0].startupProbe}' | jq .

kubectl get deployment strapi -n NAMESPACE \
  -o jsonpath='{.spec.template.spec.containers[0].livenessProbe}' | jq .

# View pod restart counts (rising count indicates probe failures)
kubectl get pods -n NAMESPACE -o wide

# View Strapi startup logs
kubectl logs -n NAMESPACE -l app=strapi --since=10m | head -100

---

NFS Storage

Strapi stores media uploads and shared files on the NFS volume. Strapi GKE enables NFS by default, unlike the App GKE base module where NFS is opt-in.

Variable	Default	Options / Format	Description & Implications
enable_nfs	true	true / false	When true, a Cloud Filestore instance is provisioned and mounted into the Strapi container. Media uploads written to nfs_mount_path are preserved across pod restarts and shared between all Strapi replicas. Set to false only if you are using GCS as the sole upload backend (via the GCS upload provider).
nfs_mount_path	"/mnt/nfs"	Filesystem path	The path inside the container where the NFS volume is mounted. Strapi should be configured to write uploads to this path.

Note: All other NFS configuration variables (nfs_share_name, nfs_server_ip, filestore_tier, etc.) are identical to the App_GKE equivalents — refer to App_GKE §3.C Storage (NFS / GCS / GCS Fuse) for their documentation.

Validating NFS Configuration

# Confirm the NFS PersistentVolume is bound
kubectl get pv -n NAMESPACE

# Confirm the NFS volume is mounted in the pod
kubectl describe pod -n NAMESPACE -l app=strapi | grep -A5 "Mounts:"

# Test NFS write access from within the container
kubectl exec -n NAMESPACE POD_NAME -- ls -la /mnt/nfs

---

Redis Cache

Strapi supports Redis as a session store and application-level cache. When enable_redis = true, the REDIS_HOST, REDIS_PORT, REDIS_PASSWORD, and ENABLE_REDIS environment variables are injected into the Strapi container, and Strapi's built-in configuration automatically enables the Redis cache backend. The Redis integration is provided by App_GKE — see §8.A Redis / Memorystore for the full integration reference.

Variable	Default	Options / Format	Description & Implications
enable_redis	false	true / false	When true, Redis connection details are injected into the Strapi container. Strapi's built-in config/plugins.js detects ENABLE_REDIS = "true" and switches the cache backend automatically. For production multi-replica deployments, enabling a shared Redis cache is recommended to prevent session inconsistency across replicas.
redis_host	"" (defaults to NFS server IP)	IP address or hostname	The hostname or IP address of the Redis server. Leave empty to fall back to the NFS server IP (suitable for single-node shared environments). For production, set this explicitly to a Cloud Memorystore for Redis instance private IP or a dedicated Redis VM.
redis_port	"6379"	Port number as string	The TCP port of the Redis server. The default 6379 is the standard Redis port and is correct for Cloud Memorystore and most self-hosted Redis instances.
redis_auth	"" (no authentication)	Password string (sensitive)	Authentication password for the Redis server. Leave empty if the Redis instance does not require authentication. When set, the value is injected securely via REDIS_PASSWORD. For Cloud Memorystore with AUTH enabled, set this to the instance's auth string.

Validating Redis Configuration

# Confirm REDIS_HOST, REDIS_PORT, and ENABLE_REDIS are injected into the pod
kubectl exec -n NAMESPACE POD_NAME -- env | grep -E "^REDIS|ENABLE_REDIS"

---

Backup Import & Recovery

In addition to the scheduled backup (backup_schedule and backup_retention_days, documented in App_GKE §8.B Backup Import & Recovery), Strapi_GKE supports a one-time import of an existing database backup during deployment. This is designed for migrating an existing Strapi instance to GCP or seeding a new environment with production data.

Variable	Default	Options / Format	Description & Implications
enable_backup_import	false	true / false	When true, triggers a one-time Kubernetes Job to restore the backup file specified by backup_file from the source defined in backup_source. The import job runs after the database is provisioned. If the database already contains data, the import may produce errors — test in a non-production environment first.
backup_source	"gcs"	gcs / gdrive	The source from which the backup file is retrieved. gcs: imports from the module's provisioned GCS backup bucket. gdrive: imports from a Google Drive file ID.
backup_file	"backup.sql"	Filename string	The filename (for GCS) or file ID (for Google Drive) of the backup to import. For GCS, the file must exist in the module's backup bucket before deployment.
backup_format	"sql"	sql / tar / gz / tgz / tar.gz / zip / auto	The format of the backup file. Use "auto" to detect the format from the file extension (GCS only).

Validating Backup Import

# Confirm the import job completed successfully
kubectl get jobs -n NAMESPACE --selector=app=backup-import

kubectl logs -n NAMESPACE -l job-name=IMPORT_JOB_NAME

# Verify the Strapi database is present after import
gcloud sql databases list --instance=INSTANCE_NAME --project=PROJECT_ID

---

StatefulSet PVC Configuration

When workload_type = "StatefulSet" is set (see App_GKE §3.A Compute (GKE Autopilot)), the following variables configure the per-pod PersistentVolumeClaim automatically created for each StatefulSet replica.

Strapi use case: A StatefulSet with per-pod PVCs is relevant only if you are running Strapi with a local disk-backed file store. For the default configuration (NFS-backed uploads at /mnt/nfs), a StatefulSet is not needed and the default Deployment workload type is recommended.

Variable	Default	Options / Format	Description & Implications
stateful_pvc_enabled	false	true / false	When true and workload_type = "StatefulSet", a PVC is provisioned for each StatefulSet replica.
stateful_pvc_size	"10Gi"	Kubernetes storage quantity	The capacity of each per-pod PVC.
stateful_pvc_mount_path	"/data"	Filesystem path	The path inside the container where the PVC is mounted.
stateful_pvc_storage_class	"standard-rwo"	Kubernetes storage class name	"standard-rwo" is the GKE Autopilot default. Use "premium-rwo" for lower-latency workloads.
stateful_headless_service	true	true / false	When true, creates a headless Kubernetes Service giving each pod a stable DNS name.
stateful_pod_management_policy	"OrderedReady"	OrderedReady / Parallel	Controls StatefulSet pod creation ordering. OrderedReady starts pods one at a time; Parallel starts all simultaneously.
stateful_update_strategy	"RollingUpdate"	RollingUpdate / OnDelete	Controls how StatefulSet pods are updated when the pod spec changes.

Configuration Pitfalls & Sensible Defaults

Risk levels: Critical (data loss, full outage, security breach) — High (service unavailable or significant degradation) — Medium (degraded function or increased cost) — Low (minor impact).

Variable	Sensible Default	Risk	Consequence of Incorrect Value
APP_KEYS (auto-generated)	Auto-generated four-key set stored in Secret Manager	Critical	Signs all Strapi session cookies. Changing after first deploy immediately invalidates all active admin and user sessions. All users are logged out and client apps using session-based auth fail.
ADMIN_JWT_SECRET (auto-generated)	Auto-generated and stored in Secret Manager	Critical	Signs all admin panel JWT tokens. Changing it invalidates all admin tokens — every admin user is immediately logged out and all in-flight admin API calls fail with 401.
JWT_SECRET (auto-generated)	Auto-generated and stored in Secret Manager	Critical	Signs all API user JWT tokens. Changing it after first deploy immediately breaks every issued API token — all user sessions terminate and all client apps fail with 401.
API_TOKEN_SALT (auto-generated)	Auto-generated and stored in Secret Manager	Critical	Hashes all API tokens. Changing it permanently breaks every existing API token — they cannot be validated and must be regenerated by all API consumers.
TRANSFER_TOKEN_SALT (auto-generated)	Auto-generated and stored in Secret Manager	High	Hashes data transfer tokens. Changing it invalidates all existing transfer tokens, breaking scheduled or in-progress data migration operations.
application_name	"strapi"	Critical	Immutable after first deploy. Changing it renames all GCP and Kubernetes resources, triggering full recreation and complete data loss.
db_name	"strapi"	Critical	Immutable after first deploy. Changing it causes Strapi to connect to a new empty database, losing all content types, content data, users, and API configurations.
enable_redis	false	Medium	Only enable Redis if using plugins that explicitly require it. Enabling without a valid redis_host causes a startup failure — the Redis connection string will be empty. Validated by the Strapi GKE validation guard: "When enable_redis is true, either redis_host must be set or enable_nfs must be true."
redis_host	null (uses NFS server IP when enable_nfs = true)	High	When enable_redis = true, redis_host is null/empty, and enable_nfs = false, the GKE validation guard fires a blocking error at plan time.
memory_limit	"512Mi"	High	Strapi is a Node.js application. Values below 512Mi cause OOM kills during admin panel operations. Increase to 1Gi for deployments with custom plugins or complex content types. Under Kubernetes, OOM-killed pods trigger CrashLoopBackOff if limits are consistently too low.
min_instance_count	1	High	GKE does not support true scale-to-zero without KEDA. Setting to 0 may leave the HPA in an inconsistent state. The validation guard rejects min > max.
workload_type	null (defaults to Deployment)	High	Setting stateful_pvc_enabled = true without an explicit workload_type automatically resolves to StatefulSet. Setting workload_type = "Deployment" alongside stateful_pvc_enabled = true fails at plan time.
stateful_pvc_size	"10Gi"	Medium	PVC size is immutable after creation in most Kubernetes storage classes. Plan capacity in advance — resizing requires manual volume expansion or data migration.
quota_memory_requests / quota_memory_limits	"" (not enforced)	High	Must use binary suffixes ("512Mi", "1Gi"). Bare integers are treated as bytes by Kubernetes and block all pod scheduling in the namespace.
enable_cloudsql_volume	true	High	Required for PostgreSQL connectivity in GKE. Setting to false while database_type != "NONE" is blocked at plan time by the GKE validation guard.
enable_nfs	true	High	Strapi stores uploaded media files in its /uploads directory. Without NFS or GCS, all uploaded assets are stored on ephemeral pod storage and lost on pod restart or rescheduling.
enable_iap	false	High	Enabling IAP without both iap_oauth_client_id and iap_oauth_client_secret is blocked at plan time by the GKE validation guard.
session_affinity	"ClientIP"	Medium	Strapi's admin panel uses persistent WebSocket connections for real-time content updates. Disabling affinity ("None") can cause admin panel disconnections and "unsaved changes" warnings.
enable_pod_disruption_budget	true	Medium	Disabling PDB allows GKE to evict all Strapi pods during node maintenance, causing a complete outage. In-flight content saves may be lost.
termination_grace_period_seconds	30	Medium	Node.js needs time to finish handling in-flight HTTP requests before shutdown. Values below 15 may cause request aborts and incomplete content saves from the admin panel.
enable_topology_spread	false	Low	With max_instance_count > 1, enabling topology spread prevents all Strapi pods from landing on the same node. Recommended for multi-replica production deployments.
