Strapi CloudRun Module — Configuration Guide

Strapi_CloudRun is a pre-configured wrapper around the App_CloudRun module that deploys Strapi — an open-source headless CMS — on Google Cloud Run Gen2.

Every variable in this module is passed through to App CloudRun. The wrapper's role is to supply Strapi-appropriate defaults and to call the Strapi Common sub-module, which generates the application's container build context, database initialisation jobs, Strapi-specific secrets, and GCS bucket configuration. You configure this module exactly as you would App CloudRun; the sections below highlight only the variables whose defaults or behaviour differ meaningfully from App CloudRun, or that are unique to this wrapper.

Where to look: If a variable you are configuring is not described here, consult the App_CloudRun Configuration Guide. All App_CloudRun features — access and networking, IAP, Cloud Armor, CDN, CI/CD, Cloud Deploy, Binary Authorization, traffic splitting, and VPC Service Controls — are available in Strapi_CloudRun with identical behaviour and configuration.

---

§1 Module Overview

Property	Value
Sub-module	Strapi Common
Default application name	strapi
Default display name	Strapi CMS
Default version	5.0.0
Container port	8080
Execution environment	gen2
Database engine	PostgreSQL 15
Default DB name	strapidb
Default DB user	strapiuser
NFS enabled	true (mount: /mnt/nfs)
Redis enabled	false
Image source	custom (Cloud Build)
Platform-managed job	db-init

Strapi Common generates the Dockerfile, build scripts, and a db-init Cloud Run job. It also generates five Strapi application secrets (APP_KEYS, API_TOKEN_SALT, ADMIN_JWT_SECRET, TRANSFER_TOKEN_SALT, JWT_SECRET) and two GCS environment variables (GCS_BUCKET_NAME, GCS_BASE_URL).

---

§2 IAM & Project Identity

Behaviour is identical to App CloudRun. The following variables are passed through unchanged.

Variable	Default	Notes
project_id	(required)	Target GCP project
tenant_deployment_id	"demo"	Appended to resource names
resource_creator_identity	"rad-module-creator@..."	Terraform executor SA
resource_labels	{}	Applied to all resources
support_users	[]	Alert recipients & IAM members

---

§3 Core Service Configuration

§3.A Application Identity

Variable	Default	Notes
application_name	"strapi"	Base name for Cloud Run service, secrets, Artifact Registry
application_display_name	"Strapi CMS"	Human-readable name in UI and dashboards
application_description	"Strapi CMS on Cloud Run"	Cloud Run service description
application_version	"5.0.0"	Image tag; increment to trigger rebuild

Note: unlike some other wrapper modules, these variables are named application_display_name and application_description (not display_name/description).

§3.B Resource Sizing

Variable	Default	Notes
cpu_limit	"2000m"	2 vCPU; Strapi's SSR and media processing benefit from the headroom
memory_limit	"2Gi"	2 GiB; required for Node.js + Strapi admin panel compilation
min_instance_count	0	Scale-to-zero by default; set to 1 to eliminate cold starts
max_instance_count	1	Single-instance default; increase after confirming NFS shared state
timeout_seconds	300	Increase for long-running media processing or migration jobs

§3.C Environment Variables & Secrets

Plain-text variables are injected via environment_variables; sensitive values via secret_environment_variables.

Module-injected environment variables (set automatically by strapi.tf):

Variable	Source
GCS_BUCKET_NAME	Auto-provisioned GCS bucket name (suffix: strapi-uploads)
GCS_BASE_URL	https://storage.googleapis.com/<bucket-name>

Module-injected secrets (provisioned by Strapi Common, injected via module_secret_env_vars):

Secret env var	Purpose
APP_KEYS	Strapi session signing keys
API_TOKEN_SALT	API token derivation
ADMIN_JWT_SECRET	Admin panel JWT signing
TRANSFER_TOKEN_SALT	Data transfer token salt
JWT_SECRET	User-facing JWT signing

These secrets are auto-generated and cannot be overridden via secret_environment_variables. Use secret_rotation_period to configure notification-based rotation reminders.

User-supplied variables (non-sensitive):

environment_variables = {
  STRAPI_TELEMETRY_DISABLED = "true"
  NODE_ENV                  = "production"
}

User-supplied secrets:

secret_environment_variables = {
  SENDGRID_API_KEY = "my-sendgrid-secret"
}

§3.D Networking

Behaviour is identical to App CloudRun. Key defaults:

Variable	Default
ingress_settings	"all"
vpc_egress_setting	"PRIVATE_RANGES_ONLY"
enable_cloudsql_volume	true
cloudsql_volume_mount_path	"/cloudsql"
container_protocol	"http1"

Set container_protocol = "h2c" to enable HTTP/2 (gRPC) communication between the load balancer and the Cloud Run service.

§3.E Container Image & Build

Variable	Default	Notes
container_image_source	"custom"	"custom" triggers Cloud Build; "prebuilt" deploys an existing image
container_image	""	Leave empty for Cloud Build output; set for prebuilt image URI
container_build_config	{ enabled = true }	Strapi Common controls Dockerfile path and context; module overrides dockerfile_path = "Dockerfile" and context_path = "." in strapi.tf
enable_image_mirroring	true	Mirrors image to Artifact Registry before deployment

Strapi Common owns the build context (Dockerfile, scripts). The container_build_config override in strapi.tf corrects paths after symlink removal; only change build_args or artifact_repo_name if needed.

---

§4 Advanced Security

§4.A Identity-Aware Proxy

enable_iap            = true
iap_authorized_groups = ["group:strapi-admins@example.com"]

§4.B VPC Service Controls

enable_vpc_sc = true  # group=21; requires existing VPC-SC perimeter

§4.C Cloud Armor & CDN

enable_cloud_armor  = true
application_domains = ["cms.example.com"]
enable_cdn          = true

§4.D Binary Authorization

enable_binary_authorization = true

§4.E Secret Rotation

secret_rotation_period         = "2592000s"  # 30-day notification
enable_auto_password_rotation  = false
rotation_propagation_delay_sec = 90

---

§5 Traffic & Ingress

§5.A Traffic Splitting

traffic_split = [
  { type = "TRAFFIC_TARGET_ALLOCATION_TYPE_LATEST",   percent = 90 },
  { type = "TRAFFIC_TARGET_ALLOCATION_TYPE_REVISION", revision = "strapi-00002", percent = 10 },
]

§5.B Ingress Control

ingress_settings   = "internal-and-cloud-load-balancing"
vpc_egress_setting = "ALL_TRAFFIC"

---

§6 CI/CD Integration

§6.A Cloud Build Trigger

enable_cicd_trigger   = true
github_repository_url = "https://github.com/my-org/strapi-app"
github_token          = "ghp_xxxx"  # or use github_app_installation_id
cicd_trigger_config = {
  branch_pattern = "^main$"
  included_files = ["src/**", "Dockerfile"]
}

§6.B Cloud Deploy Pipeline

enable_cloud_deploy = true
cloud_deploy_stages = [
  { name = "dev",     require_approval = false },
  { name = "staging", require_approval = false },
  { name = "prod",    require_approval = true  },
]

---

§7 Reliability & Data

§7.A Health Probes

Strapi CloudRun exposes two independent probe interfaces:

Interface 1 — startup_probe / liveness_probe (passed to Strapi Common):

Variable	Default
startup_probe.type	"HTTP"
startup_probe.path	"/_health"
startup_probe.initial_delay_seconds	60
startup_probe.timeout_seconds	5
startup_probe.period_seconds	10
startup_probe.failure_threshold	3
liveness_probe.type	"HTTP"
liveness_probe.path	"/_health"
liveness_probe.initial_delay_seconds	30
liveness_probe.timeout_seconds	5
liveness_probe.period_seconds	30
liveness_probe.failure_threshold	3

Interface 2 — startup_probe_config / health_check_config (passed directly to App CloudRun):

Variable	Default
startup_probe_config.path	"/_health"
startup_probe_config.initial_delay_seconds	30
startup_probe_config.timeout_seconds	5
startup_probe_config.period_seconds	10
startup_probe_config.failure_threshold	30
health_check_config.path	"/_health"
health_check_config.initial_delay_seconds	15
health_check_config.timeout_seconds	5
health_check_config.period_seconds	30
health_check_config.failure_threshold	3

Both interfaces should be kept consistent. On cold starts with database initialisation, consider increasing startup_probe_config.failure_threshold to allow sufficient boot time.

§7.B Backup & Recovery

Variable	Default	Notes
backup_schedule	"0 2 * * *"	Daily at 02:00 UTC
backup_retention_days	7	GCS lifecycle rule
enable_backup_import	false	One-time restore on deploy
backup_source	"gcs"	"gcs" or "gdrive"
backup_file	"backup.sql"	Filename in GCS backups bucket, or Google Drive file ID
backup_format	"sql"	sql, tar, gz, tgz, tar.gz, zip, auto

Note: this module uses backup_file (not backup_uri) — the variable is named directly, not aliased.

§7.C Scheduled Jobs

cron_jobs = [{
  name     = "strapi-cleanup"
  schedule = "0 3 * * *"
  image    = "strapi:5.0.0"
  command  = ["node", "scripts/cleanup.js"]
}]

§7.D Observability

uptime_check_config = {
  enabled        = true
  path           = "/_health"
  check_interval = "60s"
  timeout        = "10s"
}

alert_policies = [{
  name               = "high-error-rate"
  metric_type        = "run.googleapis.com/request_count"
  comparison         = "COMPARISON_GT"
  threshold_value    = 100
  duration_seconds   = 60
  aggregation_period = "60s"
}]

---

§8 Integrations

§8.A Redis Cache

Strapi supports Redis for session caching. When enable_redis = false (the default), no Redis environment variables are injected.

enable_redis = true
redis_host   = "10.0.0.5"  # required; no automatic fallback
redis_port   = "6379"       # string type
redis_auth   = ""

redis_host defaults to null. When enable_redis = true, you must explicitly set redis_host to point to a Memorystore instance or other Redis server.

§8.B NFS Storage

enable_nfs     = true
nfs_mount_path = "/mnt/nfs"

§8.C GCS Fuse Volumes

gcs_volumes = [{
  name        = "strapi-assets"
  bucket_name = "my-assets-bucket"
  mount_path  = "/mnt/assets"
  readonly    = false
}]

§8.D Additional Services

Strapi CloudRun exposes the additional_services variable, enabling co-deployed Cloud Run services (e.g. a background worker or internal Redis):

additional_services = [{
  name                = "worker"
  image               = "strapi:5.0.0"
  port                = 3001
  min_instance_count  = 0
  max_instance_count  = 1
  ingress             = "INGRESS_TRAFFIC_INTERNAL_ONLY"
  output_env_var_name = "WORKER_URL"
}]

---

§9 Platform-Managed Behaviours

The following are set or injected automatically and do not require configuration.

Database credentials

App CloudRun generates a random PostgreSQL password and stores it in Secret Manager. Strapi Common derives the database connection string from this secret and the Cloud SQL instance connection name.

Strapi application secrets

Strapi Common auto-generates all five Strapi cryptographic secrets (APP_KEYS, API_TOKEN_SALT, ADMIN_JWT_SECRET, TRANSFER_TOKEN_SALT, JWT_SECRET) on first deploy. These are stored in Secret Manager and injected at runtime.

GCS bucket environment variables

strapi.tf injects GCS_BUCKET_NAME and GCS_BASE_URL after the storage bucket is created. These point to the auto-provisioned strapi-uploads suffix bucket and do not need to be set in environment_variables.

Platform-managed initialisation job: db-init

The db-init job (defined in the initialization_jobs default) runs scripts/create-db-and-user.sh using a postgres:15-alpine image on every Terraform apply (execute_on_apply = true). It creates the Strapi database user and initialises the schema. This job is idempotent.

Probe endpoints

Strapi exposes /_health for both startup and liveness checks. This endpoint returns 200 when the application is ready to serve traffic, including when the database connection is established. The default failure_threshold = 30 on startup_probe_config provides approximately 5 minutes of grace time during first-boot database initialisation.

---

§10 Variable Reference

The table below covers all variables unique to or with notable defaults in Strapi_CloudRun. For the full set of inherited variables, see the App_CloudRun Variable Reference.

Variable	Type	Default	Group	Notes
application_name	string	"strapi"	2	Base resource name
application_display_name	string	"Strapi CMS"	2	UI display name
application_description	string	"Strapi CMS on Cloud Run"	2	Service description
application_version	string	"5.0.0"	2	Image tag
cpu_limit	string	"2000m"	3	2 vCPU
memory_limit	string	"2Gi"	3	2 GiB
min_instance_count	number	0	3	Scale-to-zero
max_instance_count	number	1	3
container_port	number	8080	3	Cloud Run module default; overrides Strapi Common's 1337
container_protocol	string	"http1"	3	"http1" or "h2c"
container_image_source	string	"custom"	3	"prebuilt" or "custom"
container_image	string	""	3	Override for prebuilt
container_build_config	object	{ enabled = true }	3	Cloud Build config
enable_image_mirroring	bool	true	3	Mirror to Artifact Registry
enable_cloudsql_volume	bool	true	3	Unix socket proxy
cloudsql_volume_mount_path	string	"/cloudsql"	3	Socket path
application_database_name	string	"strapidb"	11	PostgreSQL DB name
application_database_user	string	"strapiuser"	11	PostgreSQL user
database_password_length	number	32	11	16–64 characters
enable_nfs	bool	true	10	Cloud Filestore mount
nfs_mount_path	string	"/mnt/nfs"	10	Container mount path
storage_buckets	list	[{ name_suffix = "data" }]	10	GCS buckets
backup_file	string	"backup.sql"	6	GCS filename or Drive ID
backup_format	string	"sql"	6	Includes "auto" option
enable_redis	bool	false	20	Redis cache
redis_host	string	null	20	Must be set when Redis enabled
redis_port	string	"6379"	20	String type
redis_auth	string	""	20	Sensitive
startup_probe	object	{ type="HTTP", path="/_health", initial_delay_seconds=60 }	13	Passed to Strapi Common
liveness_probe	object	{ type="HTTP", path="/_health", initial_delay_seconds=30 }	13	Passed to Strapi Common
startup_probe_config	object	{ path="/_health", initial_delay_seconds=30, failure_threshold=30 }	13	Passed to App CloudRun
health_check_config	object	{ path="/_health" }	13	Passed to App CloudRun
initialization_jobs	list	[{ name="db-init", execute_on_apply=true }]	12	Platform-managed; modify with care
additional_services	list	[]	12	Co-deployed Cloud Run services
enable_vpc_sc	bool	false	21	VPC Service Controls

Configuration Pitfalls & Sensible Defaults

Risk levels: Critical (data loss, full outage, security breach) — High (service unavailable or significant degradation) — Medium (degraded function or increased cost) — Low (minor impact).

Variable	Sensible Default	Risk	Consequence of Incorrect Value
APP_KEYS (auto-generated — 4 comma-joined 32-char secrets)	Auto-generated and stored in Secret Manager	Critical	Used to sign Strapi session cookies. Changing these keys after first deploy immediately invalidates all active admin and API user sessions. All logged-in users are logged out and cannot re-authenticate until a new login is performed.
ADMIN_JWT_SECRET (auto-generated)	Auto-generated and stored in Secret Manager	Critical	Signs all admin panel JWT tokens. Changing it after first deploy invalidates all admin tokens — all admin users are immediately logged out and all in-flight admin API calls return 401 until re-authentication.
JWT_SECRET (auto-generated)	Auto-generated and stored in Secret Manager	Critical	Signs all API user JWT tokens. Changing it after first deploy invalidates every issued API token for end-users — all user sessions are terminated and all client apps using user tokens fail immediately with 401 errors.
API_TOKEN_SALT (auto-generated)	Auto-generated and stored in Secret Manager	Critical	Used to hash API tokens. Changing it after first deploy permanently breaks all existing API tokens — they cannot be validated and must be regenerated by every API consumer.
TRANSFER_TOKEN_SALT (auto-generated)	Auto-generated and stored in Secret Manager	High	Used to hash data transfer tokens. Changing it invalidates all existing transfer tokens, breaking any in-progress or scheduled data transfers.
application_name	"strapi"	Critical	Immutable after first deploy. Changing it renames all GCP resources, triggering full recreation and database loss.
db_name	"strapi"	Critical	Immutable after first deploy. Changing it causes Strapi to connect to a new empty database, losing all content types, content data, user accounts, and API configurations.
DATABASE_CLIENT type (resolved to PostgreSQL — db_name and db_user are the contract)	"postgres" (hard-coded in config/database.js)	High	Strapi is wired to PostgreSQL via the Foundation Module's Cloud SQL provisioning. The database client cannot be changed to SQLite or MySQL without replacing the entire Common and Foundation module stack. No SQLite support in cloud deployments.
memory_limit	"512Mi"	High	Strapi is a Node.js application with a multi-layered content management framework. Values below 512Mi cause frequent OOM kills during admin panel operations and content API calls. Increase to 1Gi for production with custom plugins or complex content types.
cpu_limit	"1000m"	Medium	Strapi's admin panel and content API are CPU-bound on cold starts and plugin initialization. Values below 500m cause severe startup throttling.
min_instance_count	1	Medium	Strapi defaults to min_instance_count = 1 to keep at least one warm instance. Scale-to-zero (0) causes cold starts of 15–30 seconds due to Strapi's Node.js startup time, which may fail health checks on first request.
max_instance_count	10 (Strapi default)	High	Strapi stores its admin user sessions and JWT tokens in the database (not local memory). However, rapid horizontal scaling combined with cold starts can cause temporary JWT validation inconsistencies. Use Redis (enable_redis = true) for session caching if scaling above 3.
enable_redis	false	Medium	Strapi does not use Redis by default. Enable with a Redis host and port only if using Strapi plugins that explicitly require it (e.g., rate-limiting plugins, custom caching layers). Enabling without a valid Redis host causes connection errors at startup.
redis_host	null (uses NFS server IP when enable_redis = true and NFS enabled)	High	When enable_redis = true and redis_host is null/empty and NFS is not enabled, the Redis connection string is blank and Strapi fails to connect to Redis at startup.
ENABLE_REDIS (injected from enable_redis)	"false"	High	Strapi's entrypoint script reads this env var to configure the Redis connection. Manually overriding it via environment_variables without also providing REDIS_HOST and REDIS_PORT causes a Redis connection failure at startup.
enable_nfs	Depends on deployment	Medium	Strapi uploads (media files, assets) are served from the /uploads directory. Without NFS or a GCS bucket configured as the upload provider, uploaded files are stored on ephemeral container filesystem and lost on restart.
enable_iap	false	High	Enabling IAP without valid iap_authorized_users or groups causes all requests to return 403, blocking the Strapi admin panel entirely.
ingress_settings	"all"	Medium	Setting to "internal" blocks all public API traffic, including frontend apps that call Strapi's content API. Use "internal-and-cloud-load-balancing" for a load-balanced setup.
backup_schedule	"0 2 * * *" (daily at 02:00)	Medium	All Strapi content, content types, user accounts, and API configurations live in PostgreSQL. Ensure the backup schedule aligns with your content publication RPO.
execution_environment	"gen2"	High	NFS mounts require gen2. Changing to gen1 causes NFS mount failures.
enable_vpc_sc	false	Medium	Requires organization_id. If empty, VPC-SC is silently skipped.
secret_propagation_delay	30 seconds	Low	Too short a delay may cause Strapi to start before the five auto-generated secrets have propagated from Secret Manager, causing startup failures on first deploy with "secret version not found" errors.

Destroying Resources

Known Deletion Issue: Serverless IPv4 Address Release

When destroying a Cloud Run deployment, you may encounter an error similar to:

Error: Error waiting for Subnetwork to be deleted: The following serverless IPv4 address(es) on subnet ... are still in use.

Cause: GCP holds serverless IPv4 addresses on the VPC subnet asynchronously after a Cloud Run service is deleted. These addresses are released by GCP approximately 20–30 minutes after the Cloud Run service is removed. Terraform/OpenTofu cannot complete the subnet or VPC deletion until they are fully released.

Resolution: Wait 20–30 minutes after the initial destroy attempt, then re-run the destroy command:

tofu destroy

The second run will succeed once GCP has released the reserved addresses.
