Wikijs CloudRun Module — Configuration Guide
Wikijs_CloudRun is a pre-configured wrapper around the App_CloudRun module that deploys Wiki.js — a powerful open-source wiki platform — on Google Cloud Run Gen2.
Every variable in this module is passed through to App CloudRun. The wrapper's role is to supply Wiki.js-appropriate defaults and to call the Wikijs Common sub-module, which generates the application's container image configuration, database initialisation logic, GCS Fuse storage mounts, and database password wiring. You configure this module exactly as you would App CloudRun; the sections below highlight only the variables whose defaults or behaviour differ meaningfully from App CloudRun, or that are unique to this wrapper.
Where to look: If a variable you are configuring is not described here, consult the App_CloudRun Configuration Guide. All
App_CloudRunfeatures — access and networking, IAP, Cloud Armor, CDN, CI/CD, Cloud Deploy, Binary Authorization, traffic splitting, and VPC Service Controls — are available inWikijs_CloudRunwith identical behaviour and configuration.
§1 Module Overview
| Property | Value |
|---|---|
| Sub-module | Wikijs Common |
| Default application name | wikijs |
| Default display name | Wiki.js |
| Default version | 2.5.311 |
| Container port | 3000 (set by Wikijs Common) |
| Execution environment | gen2 |
| Database engine | PostgreSQL 15 (with pg_trgm extension) |
| Default DB name | wikijs |
| Default DB user | wikijs |
| NFS enabled | true (mount: /mnt/nfs) |
| Redis enabled | false |
| Image source | Managed by Wikijs Common |
| Platform-managed job | db-init (from Wikijs Common when initialization_jobs = []) |
Wikijs Common manages the container image source, build configuration, and GCS Fuse storage (wikijs-storage bucket provisioned for persistent asset storage). The database password is wired from module.app_cloudrun.database_password_secret into module_secret_env_vars as the key database_password_secret, which the platform maps to the DB_PASS environment variable consumed by Wiki.js. The pg_trgm PostgreSQL extension is installed by Wikijs Common to enable native full-text search.
§2 IAM & Project Identity
Behaviour is identical to App CloudRun. The following variables are passed through unchanged.
| Variable | Default | Notes |
|---|---|---|
project_id | (required) | Target GCP project |
tenant_deployment_id | "demo" | Appended to resource names |
resource_creator_identity | "rad-module-creator@..." | Terraform executor SA |
resource_labels | {} | Applied to all resources |
support_users | [] | Alert recipients & IAM members |
§3 Core Service Configuration
§3.A Application Identity
| Variable | Default | Notes |
|---|---|---|
application_name | "wikijs" | Base name for Cloud Run service, secrets, Artifact Registry |
display_name | "Wiki.js" | Human-readable name in UI and dashboards |
application_version | "2.5.311" | Image tag; increment to update the Wiki.js release |
Note: there is no application_display_name or description variable in this module — the Cloud Run wrapper uses display_name (passed to Wikijs Common) rather than the application_display_name used by App GKE. A deploy_application variable (default true) controls whether the Cloud Run service is deployed; set to false to provision only supporting infrastructure (secrets, storage, IAM).
§3.B Resource Sizing
| Variable | Default | Notes |
|---|---|---|
cpu_limit | "1000m" | 1 vCPU; increase for wikis with heavy concurrent editing |
memory_limit | "2Gi" | 2 GiB; required for Wiki.js with PostgreSQL full-text search |
min_instance_count | 0 | Scale-to-zero by default; set to 1 to eliminate cold starts |
max_instance_count | 1 | Single-instance default |
execution_environment | "gen2" | Cloud Run execution environment; gen2 required for NFS mounts |
timeout_seconds | 300 | Increase for large page exports or asset processing |
§3.C Environment Variables & Secrets
environment_variables has a non-empty default that configures Wiki.js database connectivity:
environment_variables = {
DB_TYPE = "postgres"
DB_PORT = "5432"
DB_USER = "wikijs"
DB_NAME = "wikijs"
DB_SSL = "false"
HA_STORAGE_PATH = "/wiki-storage"
}
Override individual keys to change database settings or storage path. Do not remove DB_TYPE or DB_PORT as Wiki.js requires them to connect.
Module-injected secrets (wired via module_secret_env_vars in main.tf):
module_secret_env_vars key | Source | Env var visible to Wiki.js |
|---|---|---|
database_password_secret | module.app_cloudrun.database_password_secret | DB_PASS (mapped by entrypoint.sh) |
main.tf passes module_secret_env_vars = { database_password_secret = module.app_cloudrun.database_password_secret } to App CloudRun. Wikijs Common's config.secret_environment_variables carries DB_PASS = "database_password_secret", which the platform resolves to the actual Secret Manager ID and injects into the container as DB_PASSWORD. entrypoint.sh then maps DB_PASSWORD → DB_PASS at container start. This is wired automatically and does not require user configuration.
User-supplied secrets:
secret_environment_variables = {
GITHUB_CLIENT_SECRET = "my-github-oauth-secret"
}
§3.D Networking
Key defaults:
| Variable | Default |
|---|---|
ingress_settings | "all" |
vpc_egress_setting | "PRIVATE_RANGES_ONLY" |
enable_cloudsql_volume | true |
cloudsql_volume_mount_path | "/cloudsql" |
container_protocol | "http1" |
Set container_protocol = "h2c" to enable HTTP/2 communication between the load balancer and the Cloud Run service.
§3.E Container Image & Build
Container image source and build configuration are fully managed by Wikijs_Common. The container_image_source, container_image, and container_build_config variables are not exposed in this module's variables.tf. Wikijs_Common always produces image_source = "custom" and container_image = "requarks/wiki:2" with a Cloud Build context pointing to its own scripts/ directory.
| Variable | Default | Notes |
|---|---|---|
enable_image_mirroring | true | Mirrors requarks/wiki:2 from Docker Hub to Artifact Registry before the build |
Additional Artifact Registry lifecycle variables exposed in this module:
| Variable | Default | Notes |
|---|---|---|
max_images_to_retain | 7 | Keep this many recent images; 0 = disabled |
delete_untagged_images | true | Auto-delete untagged/dangling images |
image_retention_days | 30 | Delete images older than this; 0 = disabled |
max_revisions_to_retain | 7 | Maximum Cloud Run revisions to keep; 0 = disabled |
§4 Advanced Security
§4.A Identity-Aware Proxy
enable_iap = true
iap_authorized_groups = ["group:wiki-editors@example.com"]
§4.B VPC Service Controls
enable_vpc_sc = true # group=21; requires existing VPC-SC perimeter
§4.C Cloud Armor & CDN
enable_cloud_armor = true
application_domains = ["wiki.example.com"]
enable_cdn = true
§4.D Binary Authorization
enable_binary_authorization = true
§4.E Secret Rotation
secret_rotation_period = "2592000s" # 30-day notification
enable_auto_password_rotation = false
rotation_propagation_delay_sec = 90
§5 Traffic & Ingress
§5.A Traffic Splitting
traffic_split = [
{ type = "TRAFFIC_TARGET_ALLOCATION_TYPE_LATEST", percent = 90 },
{ type = "TRAFFIC_TARGET_ALLOCATION_TYPE_REVISION", revision = "wikijs-00002", percent = 10 },
]
§5.B Ingress Control
ingress_settings = "internal-and-cloud-load-balancing"
vpc_egress_setting = "ALL_TRAFFIC"
§6 CI/CD Integration
§6.A Cloud Build Trigger
enable_cicd_trigger = true
github_repository_url = "https://github.com/my-org/wikijs-config"
github_token = "ghp_xxxx" # or use github_app_installation_id
cicd_trigger_config = {
branch_pattern = "^main$"
}
§6.B Cloud Deploy Pipeline
enable_cloud_deploy = true
cloud_deploy_stages = [
{ name = "dev", require_approval = false },
{ name = "staging", require_approval = false },
{ name = "prod", require_approval = true },
]
§7 Reliability & Data
§7.A Health Probes
Wikijs CloudRun uses only startup_probe and liveness_probe (passed to Wikijs Common). There is no separate startup_probe_config / health_check_config interface in this module.
| Variable | Default | Notes |
|---|---|---|
startup_probe.type | "HTTP" | |
startup_probe.path | "/healthz" | Wiki.js health endpoint |
startup_probe.initial_delay_seconds | 60 | Allows time for PostgreSQL schema init |
startup_probe.timeout_seconds | 5 | |
startup_probe.period_seconds | 10 | |
startup_probe.failure_threshold | 3 | |
liveness_probe.type | "HTTP" | |
liveness_probe.path | "/healthz" | |
liveness_probe.initial_delay_seconds | 60 | |
liveness_probe.timeout_seconds | 5 | |
liveness_probe.period_seconds | 30 | |
liveness_probe.failure_threshold | 3 |
The /healthz endpoint reflects both application readiness and live database connection status.
§7.B Backup & Recovery
| Variable | Default | Notes |
|---|---|---|
backup_schedule | "0 2 * * *" | Daily at 02:00 UTC |
backup_retention_days | 7 | GCS lifecycle rule |
enable_backup_import | false | One-time restore on deploy |
backup_source | "gcs" | "gcs" or "gdrive" |
backup_uri | "" | Full GCS URI or Google Drive file ID |
backup_format | "sql" | sql, tar, gz, tgz, tar.gz, zip |
Note: this module uses backup_uri (aliased to backup_file in main.tf). The backup_format variable has no validation constraint in this module; accepted values are sql, tar, gz, tgz, tar.gz, and zip.
§7.C Scheduled Jobs
cron_jobs = [{
name = "wiki-export"
schedule = "0 3 * * 0" # weekly Sunday at 03:00
image = "postgres:15-alpine"
command = ["pg_dump", "wikijs"]
}]
§7.D Observability
uptime_check_config = {
enabled = true
path = "/"
check_interval = "60s"
timeout = "10s"
}
alert_policies = [{
name = "high-latency"
metric_type = "run.googleapis.com/request_latencies"
comparison = "COMPARISON_GT"
threshold_value = 2000
duration_seconds = 300
aggregation_period = "60s"
}]
§8 Integrations
§8.A Redis Cache
Wiki.js can use Redis for session caching. When enable_redis = false (the default), no Redis environment variables are injected.
enable_redis = true
redis_host = "10.0.0.5" # required when Redis enabled
redis_port = "6379" # string type
redis_auth = ""
§8.B NFS Storage
enable_nfs = true
nfs_mount_path = "/mnt/nfs"
§8.C GCS Fuse Volumes (wikijs-storage)
Wikijs Common provisions a wikijs-storage GCS bucket and expects it to be mounted at /wiki-storage for persistent asset storage. To wire this up, use gcs_volumes:
gcs_volumes = [{
name = "wikijs-storage"
bucket_name = "" # leave empty for the auto-provisioned bucket
mount_path = "/wiki-storage"
readonly = false
}]
The HA_STORAGE_PATH = "/wiki-storage" default in environment_variables points Wiki.js to this mount. If you change the mount path, update HA_STORAGE_PATH accordingly.
§8.D Additional Services & Scheduled Jobs
Wikijs CloudRun does not expose the additional_services variable. However, cron_jobs is exposed and allows scheduling recurring Cloud Run jobs (e.g. database backups) using Cloud Scheduler. See §7.C for an example.
§9 Platform-Managed Behaviours
The following are set or injected automatically and do not require configuration.
Database password wiring
Unlike most other wrapper modules, Wikijs CloudRun wires the database password directly from App CloudRun's output (module.app_cloudrun.database_password_secret) into module_secret_env_vars as database_password_secret. This cross-module reference is handled in main.tf and does not require user input.
PostgreSQL pg_trgm extension
Wikijs Common installs the pg_trgm PostgreSQL extension during database initialisation to enable Wiki.js's native full-text search. This is performed automatically and requires no additional configuration.
GCS storage bucket
Wikijs Common provisions a storage bucket with the suffix wikijs-storage. The bucket name is made available via module.wikijs_app.storage_buckets and passed to App CloudRun as module_storage_buckets. Set gcs_volumes to mount this bucket at /wiki-storage.
Default environment variables
The non-empty environment_variables default (DB_TYPE, DB_PORT, DB_USER, DB_NAME, DB_SSL, HA_STORAGE_PATH) is required for Wiki.js to connect to the database and locate its storage path. These values are merged with any user-supplied environment_variables; user values take precedence.
Probe endpoint
Wiki.js exposes /healthz for both startup and liveness checks. This endpoint returns 200 when the application is running and connected to PostgreSQL. The initial_delay_seconds = 60 on both probes allows time for PostgreSQL schema initialisation on first boot.
§10 Variable Reference
The table below covers all variables unique to or with notable defaults in Wikijs_CloudRun. For the full set of inherited variables, see the App_CloudRun Variable Reference.
| Variable | Type | Default | Group | Notes |
|---|---|---|---|---|
application_name | string | "wikijs" | 2 | Base resource name |
display_name | string | "Wiki.js" | 2 | Passed to Wikijs Common |
application_version | string | "2.5.311" | 2 | Image tag |
deployment_id | string | "" | 0 | Auto-generated when empty; pin to stabilise resource names across runs |
db_name | string | "wikijs" | 11 | PostgreSQL DB name |
db_user | string | "wikijs" | 11 | PostgreSQL user |
cpu_limit | string | "1000m" | 3 | 1 vCPU |
memory_limit | string | "2Gi" | 3 | 2 GiB |
min_instance_count | number | 0 | 3 | Scale-to-zero |
max_instance_count | number | 1 | 3 | |
enable_image_mirroring | bool | true | 3 | Mirror to Artifact Registry |
container_protocol | string | "http1" | 3 | "http1" or "h2c" |
enable_cloudsql_volume | bool | true | 3 | Injects Cloud SQL Auth Proxy sidecar |
cloudsql_volume_mount_path | string | "/cloudsql" | 3 | Auth Proxy Unix socket mount path |
ingress_settings | string | "all" | 4 | "all", "internal", or "internal-and-cloud-load-balancing" |
vpc_egress_setting | string | "PRIVATE_RANGES_ONLY" | 4 | "ALL_TRAFFIC" or "PRIVATE_RANGES_ONLY" |
environment_variables | map(string) | { DB_TYPE="postgres", DB_PORT="5432", ... } | 5 | Non-empty default; required for DB connectivity |
database_password_length | number | 32 | 11 | 16–64 characters |
create_cloud_storage | bool | true | 10 | Set to false to skip provisioning storage_buckets |
enable_nfs | bool | true | 10 | Cloud Filestore mount |
nfs_mount_path | string | "/mnt/nfs" | 10 | Container mount path |
nfs_instance_name | string | "" | 8 | Target an existing NFS GCE VM by name; empty = auto-discover |
nfs_instance_base_name | string | "app-nfs" | 8 | Base name for an inline NFS VM when none is found |
storage_buckets | list | [{ name_suffix = "data", location = "" }] | 10 | GCS buckets provisioned for the app (separate from the wikijs-storage bucket) |
gcs_volumes | list | [] | 10 | Mount wikijs-storage at /wiki-storage |
backup_uri | string | "" | 6 | Full GCS URI or Drive ID (aliased to backup_file in main.tf) |
backup_format | string | "sql" | 6 | sql, tar, gz, tgz, tar.gz, zip; no validation constraint in this module |
enable_redis | bool | false | 20 | Redis cache |
redis_host | string | "" | 20 | Required when Redis enabled |
redis_port | string | "6379" | 20 | String type |
redis_auth | string | "" | 20 | Sensitive |
startup_probe | object | { type="HTTP", path="/healthz", initial_delay_seconds=60 } | 13 | |
liveness_probe | object | { type="HTTP", path="/healthz", initial_delay_seconds=60 } | 13 | |
initialization_jobs | list | [] | 12 | Empty = use platform-managed db-init job; supply entries to override |
cron_jobs | list | [] | 12 | Recurring Cloud Run jobs triggered by Cloud Scheduler |
enable_custom_sql_scripts | bool | false | 8 | Run custom SQL scripts from GCS against the DB |
custom_sql_scripts_bucket | string | "" | 8 | GCS bucket name for custom SQL scripts |
custom_sql_scripts_path | string | "" | 8 | Path prefix within the bucket |
custom_sql_scripts_use_root | bool | false | 8 | Run scripts as root DB user |
manage_storage_kms_iam | bool | false | 10 | Enable CMEK for GCS buckets |
enable_artifact_registry_cmek | bool | false | 10 | Enable CMEK for Artifact Registry |
service_annotations | map(string) | {} | 3 | Custom Cloud Run service annotations |
service_labels | map(string) | {} | 3 | Custom Cloud Run service labels |
admin_ip_ranges | list(string) | [] | 9 | IP CIDR ranges for admin access allowlist |
enable_cloud_armor | bool | false | 9 | Cloud Armor WAF |
secret_propagation_delay | number | 30 | 5 | Seconds to wait after secret creation/update |
secret_rotation_period | string | "2592000s" | 5 | Secret Manager rotation notification period |
traffic_split | list | [] | 3 | Traffic allocation across revisions |
max_revisions_to_retain | number | 7 | 3 | Cloud Run revisions to retain |
vpc_cidr_ranges | list(string) | [] | 21 | VPC CIDR ranges for VPC-SC access level |
vpc_sc_dry_run | bool | true | 21 | Log-only VPC-SC enforcement (no blocking) |
organization_id | string | "" | 21 | GCP Org ID for VPC-SC policy |
enable_audit_logging | bool | false | 21 | Enable Cloud Audit Logs |
enable_vpc_sc | bool | false | 21 | VPC Service Controls |
Configuration Pitfalls & Sensible Defaults
Risk levels: Critical (data loss, full outage, security breach) — High (service unavailable or significant degradation) — Medium (degraded function or increased cost) — Low (minor impact).
| Variable | Sensible Default | Risk | Consequence of Incorrect Value |
|---|---|---|---|
DB_TYPE | "postgres" (hardcoded in Common) | Critical | The Common module hardcodes DB_TYPE = "postgres" and enables the pg_trgm extension for full-text search. Overriding to "mysql" or "sqlite" via environment_variables will cause Wiki.js to misconnect and the pg_trgm extension install to fail during the db-init job. |
DB_PASS | Auto-injected from database_password_secret | Critical | Overriding DB_PASS via environment_variables (plain text) bypasses Secret Manager and exposes the database password in Terraform state and Cloud Run environment variable logs. Always use secret_environment_variables. |
db_name | "wikijs" | High | Must exactly match DB_NAME in environment_variables. The Common module pre-populates both to "wikijs". If you change one, change the other. Mismatches cause the db-init job to create a different database than the one Wiki.js connects to. Immutable after first apply. |
db_user | "wikijs" | High | Must exactly match DB_USER in environment_variables. Same immutability constraint as db_name. |
HA_STORAGE_PATH | "/wiki-storage" (hardcoded in Common) | High | Wiki.js uses this path for file uploads and assets. The GCS volume is mounted at this path by the module. Overriding without also changing the GCS volume mount path causes Wiki.js to write uploads to the ephemeral container disk, which is lost on each new revision. |
memory_limit | "2Gi" | High | Under 512Mi the Node.js/Wiki.js process is OOM-killed on startup. Wiki.js renders pages in-process with markdown/HTML pipelines that are memory-intensive. Minimum "1Gi"; "2Gi" recommended. |
enable_cloudsql_volume | true | Critical | Required for the Cloud SQL Auth Proxy sidecar. Disabling with a PostgreSQL backend causes all DB connections to fail immediately. |
application_version | "2.5.311" | High | Wiki.js 2.x and 3.x have different database schemas that are not forward-compatible. Do not mix versions between the container image and any existing database. Always test upgrades in staging. |
startup_probe.initial_delay_seconds | 60 | High | Wiki.js performs database schema migrations and module loading on first start. Reducing below 30 causes the container to be killed before the app is ready to serve requests. |
startup_probe.failure_threshold | 3 | Medium | With period_seconds = 10 the default allows only 30 s for the app to become healthy after the initial delay. Increase failure_threshold to 12 or more for environments with slow Cloud SQL cold-start times. |
min_instance_count | 1 | High | Scale-to-zero causes cold starts of 15–30 s. Wiki.js must reconnect to PostgreSQL and reload its module system, during which all page requests return errors. |
max_instance_count | 3 | Medium | Wiki.js uses PostgreSQL for persistent state and the GCS volume for file uploads. Multiple instances are safe for reads. However, the GCS FUSE mount is shared — ensure gcs_volumes is configured correctly before scaling out. |
gcs_volumes | [] (default; Common creates the bucket) | High | The storage bucket is created by the Common module but the GCS FUSE volume mount is not auto-configured. Ensure gcs_volumes is set in the CloudRun module to mount the bucket at HA_STORAGE_PATH, otherwise file uploads go to ephemeral disk. |
enable_iap | false | High | Leaves the Wiki.js login page publicly accessible. For internal wikis, always enable IAP or set ingress_settings = "internal-and-cloud-load-balancing". |
ingress_settings | "all" | High | Default exposes Wiki.js to the public internet. For internal-only deployments restrict ingress. |
enable_redis | false | Low | Wiki.js does not natively integrate Redis for core functionality. Enabling Redis and providing redis_host is optional but not required for standard deployments. |
postgres_extensions | ["pg_trgm"] (hardcoded in Common) | High | The pg_trgm extension is required by Wiki.js for full-text search. Do not disable enable_postgres_extensions (set to true by the Common module) or remove pg_trgm from the extensions list. Doing so causes all search operations to fail with a PostgreSQL function-not-found error. |
backup_schedule | "0 2 * * *" | Medium | Disabling automated backups leaves all wiki content, user accounts, and page history unprotected against accidental deletion. |
enable_auto_password_rotation | false | Medium | Enabling without sufficient rotation_propagation_delay_sec causes brief intervals of DB connectivity failures during the rotation window, making all wiki pages temporarily inaccessible. |
secret_environment_variables | { DB_PASS = "database_password_secret" } | Critical | Removing DB_PASS from secret_environment_variables breaks the database connection — Wiki.js will fail to authenticate to PostgreSQL on startup. |
timeout_seconds | 300 | Low | Exporting large wiki spaces can take several minutes. Reducing below 120 s may abort in-progress export operations. |
Destroying Resources
Known Deletion Issue: Serverless IPv4 Address Release
When destroying a Cloud Run deployment, you may encounter an error similar to:
Error: Error waiting for Subnetwork to be deleted: The following serverless IPv4 address(es) on subnet ... are still in use.
Cause: GCP holds serverless IPv4 addresses on the VPC subnet asynchronously after a Cloud Run service is deleted. These addresses are released by GCP approximately 20–30 minutes after the Cloud Run service is removed. Terraform/OpenTofu cannot complete the subnet or VPC deletion until they are fully released.
Resolution: Wait 20–30 minutes after the initial destroy attempt, then re-run the destroy command:
tofu destroy
The second run will succeed once GCP has released the reserved addresses.
