Netdata on GKE Autopilot

Netdata is an open-source, real-time performance and health monitoring agent that collects thousands of per-second metrics (CPU, memory, disk, network, containers, services) with zero configuration and visualises them on a built-in interactive web dashboard. It is written in C for minimal overhead and exposes a REST API for querying collected data. This module deploys Netdata on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services Netdata uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

1. Overview

Netdata runs as a single Kubernetes workload. The deployment wires together a focused set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	A single Netdata pod on port 19999, 1 vCPU / 1 GiB by default
Database	None	database_type = "NONE" — Netdata keeps its own internal metrics database (dbengine) on disk; no Cloud SQL instance is created
File persistence	Per-pod block PVC (default)	stateful_pvc_enabled = true provisions a 20Gi standard-rwo (SSD) PVC at /var/lib/netdata; Cloud Filestore (NFS) is available but off by default
Object storage	Cloud Storage	A storage bucket is always provisioned, but only mounted at /var/lib/netdata via GCS FUSE when the block PVC is disabled
Secrets	Secret Manager	Optional NETDATA_ADMIN_PASSWORD (off by default) — Netdata's local dashboard has no built-in login
Ingress	Kubernetes Service (ClusterIP by default)	Optional custom domain via Kubernetes Gateway; LoadBalancer/NodePort available

Sensible defaults worth knowing up front:

• No database. Netdata is not backed by Cloud SQL — all state (the dbengine metrics store, alarm/health log, and configuration) lives on the mounted persistent volume. The GKE variant hard-forwards enable_cloudsql_volume = false and there is no db-init job.
• Block-storage PVC is the default persistence mechanism. stateful_pvc_enabled = true (and, since no workload_type is set, this auto-resolves the workload to a StatefulSet — see "StatefulSet auto-select" in the repository conventions). The PVC uses the standard-rwo (SSD-backed) StorageClass by default, sized 20Gi, mounted at /var/lib/netdata. Real block-device semantics are required because Netdata's dbengine files are corrupted by GCS FUSE.
• The GCS storage bucket is created either way but only mounted as a fallback. Netdata_GKE's main.tf sets enable_gcs_storage_volume = !stateful_pvc_enabled, so with the PVC default (true) the GCS FUSE mount is skipped to avoid a double-mount at the same path. Disable stateful_pvc_enabled to fall back to the GCS bucket instead of a block PVC.
• Redis is force-disabled. Netdata_GKE's main.tf hardcodes enable_redis = false in the call to App_GKE, overriding the variable's own default of true — Netdata does not use Redis.
• Single replica by default. min_instance_count = 1, max_instance_count = 1. Netdata writes its metrics database to one PVC; running multiple replicas against the same volume is not supported.
• No built-in authentication. Netdata's local dashboard is unauthenticated by default — anyone who can reach the Service can view all collected metrics. The optional enable_admin_password secret does not configure Netdata's own login; it generates a stable credential for an operator-managed reverse proxy or Netdata Cloud claim flow layered in front of it.
• service_type defaults to ClusterIP (internal-only), so the dashboard is not reachable from outside the cluster until you change service_type or configure a custom domain via enable_custom_domain (which itself defaults true but has no effect until application_domains is populated).
• Image is a thin custom build. Netdata_Common ships a minimal Dockerfile (FROM netdata/netdata:${NETDATA_VERSION}) purely so the foundation can mirror the upstream image into Artifact Registry; application_version = "latest" pins the build to a known-good tag (v2.2.6) via the app-specific NETDATA_VERSION build ARG.

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the Netdata workload

Netdata runs as a single pod scheduled on Autopilot, which bills for the CPU/memory the pod actually requests. With the default stateful_pvc_enabled = true, the workload is a StatefulSet with a stable pod identity and a dedicated per-pod PVC.

• Console: Kubernetes Engine → Workloads → select the Netdata workload for pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the ClusterIP or external IP.
• CLI:

  kubectl get pods,svc -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" statefulset/<service-name> --tail=100
  kubectl describe pod -n "$NAMESPACE" -l app=<service-name>

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. Persistent storage — block PVC (default) or NFS

Netdata's dbengine metrics store, alarm/health log, and configuration live under /var/lib/netdata. By default this is a per-pod block-storage PVC (stateful_pvc_enabled = true, standard-rwo StorageClass, 20Gi) — required because the dbengine's file format needs real block-device semantics (GCS FUSE corrupts it). Cloud Filestore (NFS) is available as an alternative shared mount (enable_nfs, default false) but is not the recommended path for Netdata's own data files.

• Console: Kubernetes Engine → Storage → Persistent Volume Claims; Filestore → Instances (only if NFS is enabled).
• CLI:

  kubectl get pvc -n "$NAMESPACE"
  gcloud filestore instances list --project "$PROJECT"

See App_GKE for StatefulSet PVC provisioning, the stateful_pvc_storage_class HDD/SSD tradeoff, and NFS discovery.

C. Cloud Storage (fallback path)

A Cloud Storage bucket (suffix storage) is provisioned automatically regardless of the PVC setting, and the workload service account is granted access to it. It is only mounted into the pod (via GCS FUSE) when stateful_pvc_enabled = false, as the fallback persistence mechanism for /var/lib/netdata.

• Console: Cloud Storage → Buckets.
• CLI:

  gcloud storage buckets list --project "$PROJECT" --filter="name~netdata"

See App_GKE for CMEK options and GCS Fuse mounts.

D. Secret Manager

Netdata has no mandatory generated secrets. The only optional secret is NETDATA_ADMIN_PASSWORD (gated behind enable_admin_password, default false) — a random 32-character value stored in Secret Manager and injected as a native Kubernetes Secret (via explicit_secret_values, not the Secret Store CSI/SecretSync path). It does not configure Netdata's own authentication; it exists as a stable credential for an operator-side reverse proxy or Netdata Cloud claim step.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~netdata-admin-password"
  gcloud secrets versions access latest --secret=<admin-password-secret-name> --project "$PROJECT"

See App_GKE for the Secret Store CSI integration and rotation.

E. Networking & ingress

By default the workload is exposed only inside the cluster (service_type = ClusterIP). Set service_type = LoadBalancer for an external IP, or configure application_domains (with enable_custom_domain, default true) for Gateway-routed access with a managed certificate.

• Console: Network services → Load balancing; VPC network → IP addresses.
• CLI:

  kubectl get svc,ingress -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

F. Cloud Logging & Monitoring

Pod stdout/stderr flow to Cloud Logging; GKE metrics flow to Cloud Monitoring. Optional uptime checks and alert policies are available (uptime_check_config, off by default; alert_policies).

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. Netdata Application Behaviour

• No initialization jobs by default. initialization_jobs defaults to [] — Netdata bootstraps its own on-disk metrics database at first boot; there is no db-init or migration job to wait on. Custom jobs can be supplied for data loading/migration tasks if needed.
• No first-run wizard / no login gate. The dashboard is reachable and fully functional (subject to service_type/ingress) as soon as the pod is Ready — Netdata does not require an admin account to be created before use.
• Health probes target /api/v1/info. The startup probe (startup_probe: initial_delay=15s, timeout=5s, period=10s, failure_threshold=10) and liveness probe (liveness_probe: initial_delay=30s, timeout=5s, period=30s, failure_threshold=3) are both HTTP GET /api/v1/info, unauthenticated. The same path is the default for the foundation-level health_check_config, startup_probe_config, and uptime_check_config variables.
• Single-instance scaling. min_instance_count = 1 / max_instance_count = 1 by default — the metrics database on the PVC is written by one process; do not scale beyond 1 without verifying Netdata's distributed/streaming configuration.
• Image version pinning. application_version = "latest" resolves to the pinned Dockerfile default v2.2.6 at build time (the app-specific NETDATA_VERSION build ARG, not the generic APP_VERSION the foundation injects) — set an explicit version to track a different release.
• Verify the running workload:

  kubectl get pods,pvc -n "$NAMESPACE"
  kubectl exec -n "$NAMESPACE" <pod-name> -- wget -qO- http://127.0.0.1:19999/api/v1/info
  kubectl port-forward -n "$NAMESPACE" svc/<service-name> 19999:19999
  # then browse http://127.0.0.1:19999

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Netdata are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 3 — Application Identity

Variable	Default	Description
application_name	netdata	Base name for resources. Do not change after first deploy.
application_version	latest	netdata/netdata image tag used as the custom-build base; latest is pinned to a known-good tag (v2.2.6) at build time.
enable_admin_password	false	Generates a Secret Manager credential for an operator-side auth layer. Netdata's own dashboard remains unauthenticated regardless of this setting.

Group 4 — Runtime & Scaling

Variable	Default	Description
cpu_limit	1000m	1 vCPU.
memory_limit	1Gi	Raise for larger collection counts / longer retention.
min_instance_count	1	Keep at 1 to avoid cold starts.
max_instance_count	1	Keep at 1 — one PVC, one writer.
container_port	19999	Fixed by Netdata_Common; this variable is informational only and is not forwarded to App_GKE.
enable_cloudsql_volume	false	Netdata has no Cloud SQL database — keep false.

Group 6 — GKE Backend & Cluster

Variable	Default	Description
service_type	ClusterIP	Internal-only by default; set LoadBalancer for a public IP.
workload_type	null → StatefulSet	Auto-resolves to StatefulSet because stateful_pvc_enabled = true.
session_affinity	None	No sticky routing needed with a single replica.

Group 7 — StatefulSet Configuration

Variable	Default	Description
stateful_pvc_enabled	true	Provisions a per-pod block PVC — required so Netdata's dbengine files get real block-device semantics (GCS FUSE corrupts them).
stateful_pvc_size	20Gi	Size to hold your collection retention window plus overhead.
stateful_pvc_mount_path	/var/lib/netdata	Where Netdata persists its metrics DB, alarm log, and config.
stateful_pvc_storage_class	standard-rwo (SSD)	Balanced-PD, SSD-backed. Draws the SSD_TOTAL_GB quota — override to standard (HDD) if quota-constrained; Netdata's write pattern does not require SSD IOPS.
stateful_fs_group	3000	Makes the PVC group-writable; Netdata runs as UID 1000 / GID 2000.

Group 10 — Observability & Health

Variable	Default	Description
startup_probe / liveness_probe	HTTP GET /api/v1/info	Container-level probes wired through Netdata_Common.
health_check_config / startup_probe_config	HTTP GET /api/v1/info	Foundation-level probe configuration (same endpoint).
uptime_check_config	disabled, path /api/v1/info	Enable for an external google_monitoring_uptime_check_config, only useful once the Service is publicly reachable.

Group 13 — Filesystem (NFS)

Variable	Default	Description
enable_nfs	false	Off by default — persistence is handled by the StatefulSet block PVC instead. Enable only if you need a shared NFS mount for a purpose other than Netdata's own dbengine data.
nfs_mount_path	/mnt/nfs	Not the same path as the PVC mount (/var/lib/netdata) — avoid pointing NFS at the PVC's path.

Group 15 — Redis (not used)

Netdata does not use Redis. enable_redis defaults true at the variable level, but Netdata_GKE's main.tf unconditionally forwards enable_redis = false to App_GKE, so the variable's default is inert for this module — no Redis connection is ever injected.

Group 16 — Database Backend (not used)

database_type is fixed to NONE by Netdata_Common; no Cloud SQL instance, database, or user is created. The application_database_name (netdatadb) / application_database_user (netdatauser) and related db_* variables are declared for foundation-variable-mirroring compatibility only and have no effect.

Group 19 — Custom Domain, Static IP & Networking

Variable	Default	Description
enable_custom_domain	true	Enables Gateway-based routing, but has no effect until application_domains is populated.
application_domains	[]	Custom hostnames + managed certificate.
reserve_static_ip	true	Stable external IP across redeploys, once service_type = LoadBalancer or a Gateway is in use.

All other inputs follow standard App_GKE behaviour.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip	In-cluster ClusterIP.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific services.
service_external_ip	External LoadBalancer IP (when service_type = LoadBalancer and a static IP is reserved).
service_url	URL to reach Netdata.
netdata_admin_password_secret_id	Secret Manager secret ID for the admin-password credential; empty when enable_admin_password = false.
storage_buckets	Created Cloud Storage buckets.
network_name / network_exists / regions	VPC network, presence, available regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
initialization_jobs	Names of any user-supplied initialization jobs (none by default).
statefulset_name	Name of the StatefulSet (when stateful_pvc_enabled = true).
cicd_enabled / cicd_configuration	CI/CD status and details (repo, trigger, registry).
github_repository_url / github_repository_owner / github_repository_name	CI/CD GitHub details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time — a StatefulSet forced alongside a stateless setting, IAP with no authorized identities, quota_memory_* given as bare integers, an out-of-range container_port/ backup_retention_days. Netdata_GKE additionally guards min_instance_count <= max_instance_count and IAP-enabled-without-OAuth- credentials at plan time (see validation.tf). Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Setting	Sensible value	Risk	Consequence if wrong
service_type (default ClusterIP) + enable_admin_password	Leave enable_admin_password=false internal-only, or add a reverse-proxy/auth layer before exposing externally	Critical	Netdata's dashboard has no built-in login; exposing it externally (LoadBalancer, or a configured custom domain) with no operator-added auth layer publishes all collected host/container metrics.
stateful_pvc_enabled	true	Critical	Disabling it falls back to GCS FUSE, which corrupts Netdata's dbengine metrics files — data loss / crash-looping.
max_instance_count	1	High	Netdata's dbengine is written by a single process against one PVC; scaling beyond 1 risks file corruption/lock contention.
stateful_pvc_storage_class	standard-rwo (SSD)	Medium	Draws the tight SSD_TOTAL_GB regional quota; switch to standard (HDD) on quota-constrained projects — Netdata's write pattern does not need SSD IOPS.
enable_nfs	false (keep off)	Medium	NFS is not the supported path for Netdata's own data files (/var/lib/netdata); only enable it for an unrelated shared mount at a different path.
application_version	latest (→ pinned v2.2.6)	Medium	Pinning to an arbitrary tag that doesn't exist upstream fails the Cloud Build image mirror/build step.
memory_limit	1Gi (raise for large collection counts)	Medium	Netdata holds recent metrics in memory; undersizing causes OOM restarts under heavy collection load.
quota_memory_requests / _limits	binary units (4Gi, 8192Mi)	Critical	Bare integers are treated as bytes and block all pod scheduling in the namespace.
enable_custom_domain (default true) with empty application_domains	Populate application_domains or leave both alone	Low	enable_custom_domain=true alone has no effect until a domain is listed — not a functional risk, but can be confusing when auditing exposure.
backup_retention_days	7 (raise for prod)	Medium	Too short for compliance retention.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Netdata-specific application configuration shared with the Cloud Run variant is described in Netdata_Common.
