Grafana on Google Cloud Run
This document provides a comprehensive reference for the modules/Grafana_CloudRun Terraform module. It covers architecture, IAM, configuration variables, Grafana-specific behaviours, and operational patterns for deploying Grafana on Google Cloud Run (v2).
1. Module Overview
Grafana is the world's leading open-source observability and analytics platform, used by 10M+ users at organizations such as NASA, CERN, and Goldman Sachs. It provides unified dashboards, alerting, and visualization for metrics, logs, and traces from over 100 data sources including Prometheus, BigQuery, Cloud SQL, Elasticsearch, and more.
Grafana CloudRun is a wrapper module built on top of App CloudRun. It uses App CloudRun for all GCP infrastructure provisioning and injects Grafana-specific application configuration, probe tuning, and storage configuration via Grafana Common.
Key Capabilities:
- Compute: Cloud Run v2 (Gen2), 1 vCPU / 2 Gi by default, configurable scaling with
min_instance_countandmax_instance_count. - Data Persistence: Cloud SQL PostgreSQL 15 as the Grafana application database. SQLite is not safe for multi-instance Cloud Run deployments — the module automatically injects
GF_DATABASE_TYPE=postgres. - Storage: A
grafana-dataGCS bucket is automatically provisioned byGrafana Common. GCS Fuse volumes and optional NFS mounts are supported for sharing dashboards and plugins across instances. - Security: Inherits Cloud Armor WAF, IAP, Binary Authorization, and VPC Service Controls from
App CloudRun. - Caching: Optional Redis support (
enable_redis = falseby default) for Grafana session storage or caching. - CI/CD: Cloud Build custom image pipeline by default; Cloud Deploy progressive delivery optional.
- Reliability: Health probes target
/api/health— Grafana's dedicated health endpoint.
Wrapper architecture: Grafana CloudRun calls Grafana Common to build an application_config object containing Grafana-specific environment variables and probe configuration. grafana.tf hardcodes GF_DATABASE_TYPE = "postgres" into the merged environment so that Grafana uses the provisioned Cloud SQL PostgreSQL instance rather than falling back to SQLite. module_storage_buckets carries the grafana-data bucket provisioned by Grafana Common. scripts_dir is resolved to Grafana_Common/scripts at apply time.
2. IAM & Access Control
Grafana CloudRun delegates all IAM provisioning to App CloudRun. The Cloud Run SA, Cloud Build SA, IAP service agent, and password rotation role sets are identical to those in App CloudRun.
Database initialisation: Unlike Ghost or Metabase, Grafana does not ship a db-init Cloud Run Job by default. Grafana auto-migrates its database schema on startup when it connects to a PostgreSQL instance. The provisioned PostgreSQL database and user are passed to the Grafana container via DB_HOST, DB_NAME, DB_USER, and DB_PASSWORD environment variables injected by App CloudRun.
GF_DATABASE_TYPE injection: grafana.tf merges { GF_DATABASE_TYPE = "postgres" } into the environment_variables map. This is a required override — without it, Grafana defaults to SQLite regardless of the other GF_DATABASE_* variables present.
For the complete role tables and IAP, password rotation, and public access details, see the App CloudRun documentation.
3. Core Service Configuration
A. Compute (Cloud Run)
Grafana is a Go application with moderate resource requirements. The default 1 vCPU / 2 Gi configuration is sufficient for most dashboard and alerting workloads. Production deployments serving many concurrent users should increase both limits.
Scale configuration: min_instance_count defaults to 1 (no scale-to-zero). Cold starts are relatively fast for Grafana (5–15 seconds), but keeping a warm instance eliminates latency for monitoring dashboards. max_instance_count defaults to 5.
| Variable | Group | Default | Description |
|---|---|---|---|
deploy_application | 4 | true | Set false for infrastructure-only deployment (SQL, storage, secrets). |
container_image_source | 4 | 'custom' | 'custom' builds via Cloud Build; 'prebuilt' deploys an existing image URI. |
container_image | 4 | "" | Override image URI. Leave empty for Cloud Build to manage. |
cpu_limit | 4 | '1000m' | CPU per instance. Increase for large dashboard query loads. |
memory_limit | 4 | '2Gi' | Memory per instance. |
min_instance_count | 4 | 1 | Minimum running instances. Set 0 for scale-to-zero. |
max_instance_count | 4 | 5 | Maximum running instances. |
container_port | 4 | 3000 | Grafana's default HTTP port. |
execution_environment | 4 | 'gen2' | Gen2 required for NFS mounts and GCS Fuse. |
timeout_seconds | 4 | 300 | Max request duration. |
enable_cloudsql_volume | 4 | true | Injects the Cloud SQL Auth Proxy sidecar. |
container_protocol | 4 | 'http1' | HTTP protocol version. |
enable_image_mirroring | 4 | true | Mirrors the Grafana image into Artifact Registry. |
traffic_split | 4 | [] | Canary/blue-green traffic allocation. |
service_annotations | 4 | {} | Advanced Cloud Run annotations. |
service_labels | 4 | {} | Labels applied to the Cloud Run service. |
B. Database (Cloud SQL — PostgreSQL 15)
Grafana requires a relational database for persisting dashboards, users, organisations, alerts, and plugin state. The module uses PostgreSQL 15 by default.
SQLite is not safe for multi-instance deployments. SQLite uses file locking, which fails when multiple Cloud Run instances attempt concurrent writes. The module hardcodes GF_DATABASE_TYPE = "postgres" in grafana.tf to ensure PostgreSQL is used regardless of other settings.
Unix socket connection: enable_cloudsql_volume defaults to true. App CloudRun injects the Auth Proxy sidecar and sets DB_HOST to the socket path under /cloudsql.
| Variable | Group | Default | Description |
|---|---|---|---|
database_type | 12 | 'POSTGRES_15' | Cloud SQL engine. Must be a PostgreSQL variant for Grafana. |
db_name | 12 | 'grafana' | PostgreSQL database name. Do not change after initial deployment. |
db_user | 12 | 'grafana' | PostgreSQL application user. Password auto-generated and stored in Secret Manager. |
database_password_length | 12 | 32 | Auto-generated password length. Range: 16–64. |
enable_auto_password_rotation | 12 | false | Automated zero-downtime password rotation. |
rotation_propagation_delay_sec | 12 | 90 | Seconds to wait after rotation before restarting the service. |
C. Storage (NFS & GCS)
NFS is disabled by default (enable_nfs = false). Enable it when multiple Cloud Run instances need to share Grafana plugins or custom dashboards stored on a shared filesystem. Requires execution_environment = 'gen2'.
GCS data bucket: Grafana Common automatically provisions a grafana-data GCS bucket. GCS Fuse volumes can be mounted into the container for direct filesystem access to GCS objects.
| Variable | Group | Default | Description |
|---|---|---|---|
create_cloud_storage | 11 | true | Set false to skip GCS bucket creation. |
storage_buckets | 11 | [{ name_suffix = "data" }] | Additional GCS buckets to provision. |
enable_nfs | 11 | false | Provisions NFS shared storage. Requires gen2. |
nfs_mount_path | 11 | '/mnt/nfs' | Container path where NFS is mounted. |
gcs_volumes | 11 | [] | GCS buckets to mount via GCS Fuse (requires gen2). |
manage_storage_kms_iam | 11 | false | Creates a CMEK KMS keyring and enables CMEK on storage buckets. |
enable_artifact_registry_cmek | 11 | false | Enables at-rest CMEK encryption for container images in Artifact Registry. |
D. Networking
| Variable | Group | Default | Description |
|---|---|---|---|
ingress_settings | 5 | 'all' | 'all' — public internet; 'internal' — VPC only; 'internal-and-cloud-load-balancing' — forces traffic through the HTTPS Load Balancer. |
vpc_egress_setting | 5 | 'PRIVATE_RANGES_ONLY' | 'PRIVATE_RANGES_ONLY' routes only RFC 1918 traffic via VPC. 'ALL_TRAFFIC' routes all egress via VPC. |
E. Initialization & Bootstrap
Unlike Metabase or Ghost, Grafana does not require a db-init job. Grafana auto-creates and migrates its database schema on first startup. If a pre-existing Grafana database needs to be imported, use enable_backup_import.
| Variable | Group | Default | Description |
|---|---|---|---|
initialization_jobs | 13 | [] | One-shot Cloud Run Jobs run during deployment. Grafana does not require a default job — leave empty unless custom initialization is needed. |
cron_jobs | 13 | [] | Recurring scheduled Cloud Run Jobs triggered by Cloud Scheduler. |
4. Advanced Security
A. Cloud Armor WAF
When enable_cloud_armor = true, a Global HTTPS Load Balancer with a Cloud Armor WAF policy is provisioned in front of Cloud Run.
| Variable | Group | Default | Description |
|---|---|---|---|
enable_cloud_armor | 10 | false | Provisions Global HTTPS LB + Cloud Armor WAF. Required for custom domains, CDN, and DDoS protection. |
admin_ip_ranges | 10 | [] | CIDR ranges exempted from WAF rules. |
B. Identity-Aware Proxy (IAP)
When enable_iap = true, Cloud Run's native IAP integration is enabled. Google identity authentication is required before requests reach Grafana. This is recommended for internal monitoring dashboards.
| Variable | Group | Default | Description |
|---|---|---|---|
enable_iap | 5 | false | Enables IAP natively on the Cloud Run service. |
iap_authorized_users | 5 | [] | Users granted IAP access. Format: 'user:email'. |
iap_authorized_groups | 5 | [] | Google Groups granted IAP access. Format: 'group:name@example.com'. |
C. Binary Authorization
| Variable | Group | Default | Description |
|---|---|---|---|
enable_binary_authorization | 8 | false | Enforces image attestation. Requires a Binary Authorization policy pre-configured in the project. |
D. VPC Service Controls
| Variable | Group | Default | Description |
|---|---|---|---|
enable_vpc_sc | 22 | false | Registers module API calls within the project's VPC-SC perimeter. |
vpc_cidr_ranges | 22 | [] | VPC subnet CIDR ranges for VPC-SC network access level. |
vpc_sc_dry_run | 22 | true | Logs VPC-SC violations without blocking. Set false to enforce. |
organization_id | 22 | "" | GCP Organization ID for VPC-SC. Required — auto-discovery is disabled to prevent unintended perimeter activation. |
enable_audit_logging | 22 | false | Enables detailed Cloud Audit Logs. |
E. Secret Manager Integration
| Variable | Group | Default | Description |
|---|---|---|---|
secret_environment_variables | 6 | {} | Secret Manager references injected as env vars. (e.g., { GF_SECURITY_ADMIN_PASSWORD = "grafana-admin-password" }) |
secret_rotation_period | 6 | '2592000s' | Secret rotation notification frequency. Default: 30 days. |
secret_propagation_delay | 6 | 30 | Seconds to wait after secret creation before dependent resources proceed. |
5. Traffic & Ingress
A. HTTPS Load Balancer
When enable_cloud_armor = true, a Global HTTPS Load Balancer backed by a Serverless NEG is provisioned. Traffic flows: Internet → Cloud Armor → Global HTTPS LB → Serverless NEG → Cloud Run.
B. Cloud CDN
When enable_cdn = true (requires enable_cloud_armor = true), Cloud CDN is attached to the HTTPS Load Balancer backend.
| Variable | Group | Default | Description |
|---|---|---|---|
enable_cdn | 10 | false | Enables Cloud CDN on the HTTPS LB backend. |
max_images_to_retain | 10 | 7 | Maximum recent container images to keep in Artifact Registry. |
delete_untagged_images | 10 | true | Automatically deletes untagged images from Artifact Registry. |
image_retention_days | 10 | 30 | Days after which images are eligible for deletion. |
C. Custom Domains
| Variable | Group | Default | Description |
|---|---|---|---|
application_domains | 10 | [] | Custom domain names for the HTTPS LB. Google-managed SSL certificates provisioned per domain. |
6. CI/CD & Delivery
A. Cloud Build Triggers
| Variable | Group | Default | Description |
|---|---|---|---|
enable_cicd_trigger | 8 | false | Provisions a Cloud Build GitHub trigger. Requires github_repository_url and credentials. |
github_repository_url | 8 | "" | Full HTTPS URL of the GitHub repository. |
github_token | 8 | "" | GitHub PAT. Required on first apply. Sensitive. |
github_app_installation_id | 8 | "" | GitHub App installation ID (preferred for org repos). |
cicd_trigger_config | 8 | { branch_pattern = "^main$" } | Advanced trigger config: branch_pattern, included_files, ignored_files, trigger_name, substitutions. |
B. Cloud Deploy Pipeline
| Variable | Group | Default | Description |
|---|---|---|---|
enable_cloud_deploy | 8 | false | Provisions a Cloud Deploy pipeline. Requires enable_cicd_trigger = true. |
cloud_deploy_stages | 8 | [dev, staging, prod(approval)] | Ordered promotion stages. |
7. Reliability & Scheduling
A. Health Probes & Uptime Monitoring
Grafana exposes a dedicated /api/health endpoint that returns HTTP 200 when the application and database connection are healthy. Both probes target this endpoint.
| Variable | Group | Default | Description |
|---|---|---|---|
startup_probe | 14 | { path="/api/health", initial_delay_seconds=30, failure_threshold=12 } | Startup probe. Allows 30 seconds initial delay plus 12 × 10s = total 150 seconds startup tolerance. |
liveness_probe | 14 | { path="/api/health", initial_delay_seconds=60, failure_threshold=3 } | Liveness probe. Restarts the container after 3 consecutive failures. |
uptime_check_config | 14 | { enabled=true, path="/api/health" } | Cloud Monitoring uptime check. |
alert_policies | 14 | [] | Cloud Monitoring metric alert policies. |
B. Backup
| Variable | Group | Default | Description |
|---|---|---|---|
backup_schedule | 7 | '0 2 * * *' | Cron expression (UTC) for automated daily backups. |
backup_retention_days | 7 | 7 | Days to retain backup files in GCS. |
enable_backup_import | 7 | false | Triggers a one-time database restore on apply. |
backup_source | 7 | 'gcs' | 'gcs' (full URI) or 'gdrive' (file ID). |
backup_uri | 7 | "" | Full GCS URI (e.g., 'gs://my-bucket/grafana-2024-01.sql') or Google Drive file ID. |
backup_format | 7 | 'sql' | Backup format. Options: sql, tar, gz, tgz, tar.gz, zip. |
C. Auto Password Rotation
| Variable | Group | Default | Description |
|---|---|---|---|
enable_auto_password_rotation | 12 | false | Enables automated zero-downtime password rotation. |
rotation_propagation_delay_sec | 12 | 90 | Seconds to wait after writing the new secret before restarting the service. |
secret_rotation_period | 6 | '2592000s' | Rotation frequency. Default: 30 days. |
8. Integrations
A. Redis
Redis support is available but disabled by default (enable_redis = false). When enabled, Redis can be used for Grafana session storage. For production, point redis_host at a dedicated Google Cloud Memorystore for Redis instance.
| Variable | Group | Default | Description |
|---|---|---|---|
enable_redis | 21 | false | Enables Redis configuration. |
redis_host | 21 | "" | Redis hostname or IP. Leave blank to use the NFS server IP when enable_redis = true. |
redis_port | 21 | '6379' | Redis TCP port (string). |
redis_auth | 21 | "" | Redis AUTH password. Sensitive. |
B. Data Sources
Grafana supports 100+ data sources. Configure them through the Grafana UI after deployment. Common GCP-native sources:
- Cloud Monitoring — uses the Cloud Run service account's Workload Identity for authentication.
- BigQuery — requires the Cloud Run SA to have
roles/bigquery.dataViewer. - Cloud SQL — configure via the PostgreSQL or MySQL data source plugin pointing at the provisioned Cloud SQL instance.
- Prometheus — connect to any Prometheus endpoint reachable from the VPC.
C. Environment Variables
Use environment_variables for non-sensitive Grafana configuration using GF_* environment variable names:
environment_variables = {
GF_SERVER_ROOT_URL = "https://grafana.example.com"
GF_SMTP_ENABLED = "true"
GF_SMTP_HOST = "smtp.sendgrid.net:587"
GF_AUTH_ANONYMOUS_ENABLED = "false"
GF_SECURITY_ALLOW_EMBEDDING = "true"
}
Note:
GF_DATABASE_TYPE = "postgres"is injected automatically — do not set it manually.
D. Backup Import & Recovery
| Variable | Group | Default | Description |
|---|---|---|---|
enable_custom_sql_scripts | 9 | false | Runs SQL scripts from GCS after provisioning. |
custom_sql_scripts_bucket | 9 | "" | GCS bucket containing SQL scripts. |
custom_sql_scripts_path | 9 | "" | Path prefix within the bucket. |
custom_sql_scripts_use_root | 9 | false | Run scripts as the root DB user. |
9. Platform-Managed Behaviours
| Behaviour | Implementation | Detail |
|---|---|---|
| PostgreSQL 15 required | database_type = "POSTGRES_15" fixed by Grafana Common | SQLite is not safe for multi-instance deployments. |
| PostgreSQL client forced | GF_DATABASE_TYPE = "postgres" injected in grafana.tf | Without this, Grafana falls back to SQLite even when all other GF_DATABASE_* variables are set. |
| GCS data bucket | grafana-data bucket provisioned by Grafana Common via module_storage_buckets | A dedicated GCS bucket for Grafana data is provisioned automatically. |
| Unix socket by default | enable_cloudsql_volume = true default | Grafana connects to Cloud SQL via the Auth Proxy Unix socket. |
| Custom image by default | container_image_source = 'custom' | Cloud Build compiles a custom image using Grafana_Common's Dockerfile extending the official grafana/grafana image. |
| No default db-init job | initialization_jobs = [] | Grafana auto-migrates its schema on startup. No explicit database initialization job is needed. |
| Health endpoint | /api/health | Grafana exposes a dedicated health endpoint. Both startup and liveness probes target this path. |
| Scripts directory | scripts_dir = abspath("${path.module}/../Grafana_Common/scripts") | Initialization scripts are sourced from Grafana_Common. |
10. Variable Reference
All user-configurable variables, sorted by UI group then order. Group 0 variables are reserved for platform metadata.
| Variable | Group | Default | Description |
|---|---|---|---|
module_description | 0 | (Grafana platform text) | Platform metadata: module description. |
module_documentation | 0 | https://docs.radmodules.dev/docs/modules/Grafana_CloudRun | Platform metadata: documentation URL. |
module_dependency | 0 | ['Services GCP'] | Platform metadata: required modules. |
module_services | 0 | (GCP service list) | Platform metadata: GCP services consumed. |
credit_cost | 0 | 50 | Platform metadata: deployment credit cost. |
require_credit_purchases | 0 | false | Platform metadata: enforces credit balance check. |
enable_purge | 0 | true | Permits full deletion of module resources on destroy. |
public_access | 0 | true | Platform catalogue visibility. |
deployment_id | 0 | "" | Deployment ID suffix. Auto-generated if empty. |
resource_creator_identity | 0 | (platform SA) | Service account used by Terraform to manage resources. |
project_id | 1 | — | GCP project ID. Required. |
region | 1 | 'us-central1' | GCP region for Cloud Run and Cloud SQL. |
tenant_deployment_id | 2 | 'demo' | Short suffix appended to all resource names. |
support_users | 2 | [] | Email addresses for monitoring alerts. |
resource_labels | 2 | {} | Labels applied to all provisioned resources. |
application_name | 3 | 'grafana' | Base resource name. |
display_name | 3 | 'Grafana Dashboards' | Human-readable name in the GCP Console. |
description | 3 | 'Grafana - Open-source observability and analytics platform' | Cloud Run service description. |
application_version | 3 | '11.4.0' | Grafana image version tag. |
deploy_application | 4 | true | Set false for infrastructure-only deployment. |
container_image_source | 4 | 'custom' | 'custom' (Cloud Build) or 'prebuilt' (existing image). |
container_image | 4 | "" | Container image URI override. |
cpu_limit | 4 | '1000m' | CPU per instance. |
memory_limit | 4 | '2Gi' | Memory per instance. |
min_instance_count | 4 | 1 | Minimum running instances. |
max_instance_count | 4 | 5 | Maximum running instances. |
container_port | 4 | 3000 | Grafana's native HTTP port. |
execution_environment | 4 | 'gen2' | Gen2 required for NFS mounts and GCS Fuse. |
timeout_seconds | 4 | 300 | Max request duration. |
enable_cloudsql_volume | 4 | true | Injects Cloud SQL Auth Proxy sidecar. |
container_protocol | 4 | 'http1' | 'http1' or 'h2c'. |
enable_image_mirroring | 4 | true | Mirrors the Grafana image into Artifact Registry. |
traffic_split | 4 | [] | Canary/blue-green traffic allocation. |
max_revisions_to_retain | 4 | 7 | Maximum Cloud Run revisions to keep. |
cloudsql_volume_mount_path | 4 | '/cloudsql' | Container path for the Auth Proxy Unix socket. |
service_annotations | 4 | {} | Advanced Cloud Run annotations. |
service_labels | 4 | {} | Labels applied to the Cloud Run service. |
ingress_settings | 5 | 'all' | 'all', 'internal', or 'internal-and-cloud-load-balancing'. |
vpc_egress_setting | 5 | 'PRIVATE_RANGES_ONLY' | 'PRIVATE_RANGES_ONLY' or 'ALL_TRAFFIC'. |
enable_iap | 5 | false | Enables IAP natively on the Cloud Run service. |
iap_authorized_users | 5 | [] | Users granted IAP access. |
iap_authorized_groups | 5 | [] | Google Groups granted IAP access. |
environment_variables | 6 | {} | Plain-text env vars. GF_DATABASE_TYPE is injected automatically — do not override. |
secret_environment_variables | 6 | {} | Secret Manager references (e.g., { GF_SECURITY_ADMIN_PASSWORD = "grafana-admin-password" }). |
secret_propagation_delay | 6 | 30 | Seconds to wait after secret creation. |
secret_rotation_period | 6 | '2592000s' | Secret Manager rotation notification frequency. |
backup_schedule | 7 | '0 2 * * *' | Cron expression (UTC) for automated backups. |
backup_retention_days | 7 | 7 | Days to retain backup files in GCS. |
enable_backup_import | 7 | false | Triggers a one-time restore on apply. |
backup_source | 7 | 'gcs' | 'gcs' or 'gdrive'. |
backup_uri | 7 | "" | Full GCS URI or Google Drive file ID. |
backup_format | 7 | 'sql' | Backup format. |
enable_cicd_trigger | 8 | false | Provisions a Cloud Build GitHub trigger. |
github_repository_url | 8 | "" | Full HTTPS URL of the GitHub repository. |
github_token | 8 | "" | GitHub PAT. Required on first apply. Sensitive. |
github_app_installation_id | 8 | "" | GitHub App installation ID. |
cicd_trigger_config | 8 | { branch_pattern = "^main$" } | Advanced Cloud Build trigger config. |
enable_cloud_deploy | 8 | false | Provisions a Cloud Deploy progressive delivery pipeline. |
cloud_deploy_stages | 8 | [dev, staging, prod(approval)] | Ordered Cloud Deploy promotion stages. |
enable_binary_authorization | 8 | false | Enforces image attestation on deployment. |
binauthz_evaluation_mode | 8 | 'ALWAYS_ALLOW' | Binary Authorization evaluation mode. Not referenced in this module. |
enable_custom_sql_scripts | 9 | false | Runs SQL scripts from GCS after provisioning. |
custom_sql_scripts_bucket | 9 | "" | GCS bucket containing SQL scripts. |
custom_sql_scripts_path | 9 | "" | Path prefix within the bucket. |
custom_sql_scripts_use_root | 9 | false | Run scripts as the root DB user. |
enable_cloud_armor | 10 | false | Provisions Global HTTPS LB + Cloud Armor WAF. |
admin_ip_ranges | 10 | [] | CIDR ranges exempted from WAF rules. |
application_domains | 10 | [] | Custom domains with Google-managed SSL certificates. |
enable_cdn | 10 | false | Enables Cloud CDN on the HTTPS LB backend. |
max_images_to_retain | 10 | 7 | Maximum recent container images to keep in Artifact Registry. |
delete_untagged_images | 10 | true | Automatically deletes untagged images from Artifact Registry. |
image_retention_days | 10 | 30 | Days after which images are eligible for deletion. |
create_cloud_storage | 11 | true | Set false to skip GCS bucket creation. |
storage_buckets | 11 | [{ name_suffix = "data" }] | Additional GCS buckets to provision. |
enable_nfs | 11 | false | Provisions NFS shared storage. Requires gen2. |
nfs_mount_path | 11 | '/mnt/nfs' | Container path where NFS is mounted. |
gcs_volumes | 11 | [] | GCS buckets to mount via GCS Fuse (requires gen2). |
manage_storage_kms_iam | 11 | false | Creates CMEK KMS key and enables CMEK on all storage buckets. |
enable_artifact_registry_cmek | 11 | false | Creates Artifact Registry KMS key for at-rest image encryption. |
database_type | 12 | 'POSTGRES_15' | Cloud SQL engine. PostgreSQL required for Grafana. |
db_name | 12 | 'grafana' | PostgreSQL database name. |
db_user | 12 | 'grafana' | PostgreSQL application user. |
database_password_length | 12 | 32 | Auto-generated password length. Range: 16–64. |
enable_auto_password_rotation | 12 | false | Automated zero-downtime password rotation. |
rotation_propagation_delay_sec | 12 | 90 | Seconds to wait after rotation before restarting the service. |
initialization_jobs | 13 | [] | One-shot Cloud Run Jobs. Leave empty — Grafana auto-migrates its schema. |
cron_jobs | 13 | [] | Recurring scheduled Cloud Run Jobs. |
startup_probe | 14 | { path="/api/health", initial_delay_seconds=30, failure_threshold=12 } | Startup probe. |
liveness_probe | 14 | { path="/api/health", initial_delay_seconds=60, failure_threshold=3 } | Liveness probe. |
uptime_check_config | 14 | { enabled=true, path="/api/health" } | Cloud Monitoring uptime check. |
alert_policies | 14 | [] | Cloud Monitoring metric alert policies. |
enable_redis | 21 | false | Enables Redis for Grafana session storage or caching. |
redis_host | 21 | "" | Redis hostname/IP. |
redis_port | 21 | '6379' | Redis TCP port (string). |
redis_auth | 21 | "" | Redis AUTH password. Sensitive. |
enable_vpc_sc | 22 | false | Enables VPC-SC perimeter enforcement. |
vpc_cidr_ranges | 22 | [] | VPC subnet CIDR ranges for VPC-SC network access level. |
vpc_sc_dry_run | 22 | true | Logs VPC-SC violations without blocking. |
organization_id | 22 | "" | GCP Organization ID for VPC-SC. |
enable_audit_logging | 22 | false | Enables detailed Cloud Audit Logs. |
11. Outputs
| Output | Description |
|---|---|
service_name | Name of the Cloud Run service. |
service_url | Public URL of the Cloud Run service. |
service_location | GCP region where the Cloud Run service is deployed. |
project_id | GCP project ID. |
deployment_id | Deployment ID suffix used in resource names. |
database_instance_name | Name of the Cloud SQL PostgreSQL instance. |
database_name | Name of the application database. |
database_user | Name of the application database user. |
database_password_secret | Secret Manager secret name for the database password. |
storage_buckets | Created GCS storage buckets. |
container_image | Container image used for the deployment. |
cicd_enabled | Whether the CI/CD pipeline is enabled. |
Configuration Pitfalls & Sensible Defaults
Risk levels: Critical (data loss, full outage, security breach) — High (service unavailable or significant degradation) — Medium (degraded function or increased cost) — Low (minor impact).
| Variable | Sensible Default | Risk | Consequence of Incorrect Value |
|---|---|---|---|
GF_SECURITY_ADMIN_PASSWORD (via secret_environment_variables) | Grafana default "admin" | Critical | Grafana ships with user admin / password admin. This module does not auto-rotate it. Always inject a strong password via Secret Manager using secret_environment_variables = { GF_SECURITY_ADMIN_PASSWORD = "your-secret-name" } before the first deployment. |
GF_SECURITY_ADMIN_USER (via environment_variables) | "admin" | High | The well-known default admin username is a brute-force target. Set to a non-obvious value via environment_variables. |
GF_DATABASE_TYPE | "postgres" (hardcoded in grafana.tf) | Critical | Always injected as "postgres" by the module. Overriding to "sqlite3" via environment_variables causes data loss: SQLite is stored on the container ephemeral disk and lost on every new Cloud Run revision. |
GF_SERVER_ROOT_URL | Not set (Grafana default) | High | Must exactly match the public URL of the deployment (e.g., https://grafana.example.com). Without it, OAuth redirects, email notification links, and embed iframe src attributes all point to the wrong origin and break. |
GF_SERVER_DOMAIN | Not set (Grafana default) | High | Used for cookie domain and SMTP sender identity. Must match the domain part of GF_SERVER_ROOT_URL or cookie-based auth will fail across subdomains. |
GF_SMTP_ENABLED | Not set | Medium | Alerting notifications and user invitation emails are silently dropped when SMTP is not configured. Must be set alongside GF_SMTP_HOST, GF_SMTP_USER, GF_SMTP_PASSWORD, and GF_SMTP_FROM_ADDRESS — omitting any one of the five makes the entire SMTP stack non-functional. |
GF_SMTP_HOST | Not set | Medium | Required when GF_SMTP_ENABLED = "true". Must include port, e.g., smtp.gmail.com:587. |
GF_AUTH_ANONYMOUS_ENABLED | Not set (defaults to false) | Critical | Setting to "true" exposes all dashboards to unauthenticated users. Only set if the Grafana instance is intentionally public. Always combine with ingress_settings restrictions. |
db_name | "grafana" | High | Changing after the database is initialised orphans the existing schema. Immutable after first apply. |
db_user | "grafana" | High | Changing after the db-init job has run requires manual Cloud SQL re-provisioning. Immutable after first apply. |
memory_limit | "2Gi" | High | Grafana loads all dashboard JSON into memory. Under 512Mi the container exits with OOM errors. Default "2Gi" is safe for up to ~100 dashboards; reduce with caution. |
min_instance_count | 1 | High | Scale-to-zero (0) causes cold starts where Grafana must reconnect to PostgreSQL and re-read all dashboards — typically 10–20 s. Alert channels will miss notifications fired during this window. |
max_instance_count | 3 | Medium | Grafana Cloud Run instances share a PostgreSQL backend but not in-memory state. Alerting can fire duplicate notifications if multiple instances evaluate the same rule simultaneously. Use 1 for simple deployments or configure a shared alerting backend. |
enable_iap | false | High | Without IAP, the Grafana login page is publicly accessible. Combine with GF_AUTH_DISABLE_LOGIN_FORM = "true" only if OAuth is fully configured; otherwise keep IAP enabled or set ingress_settings = "internal-and-cloud-load-balancing". |
GF_AUTH_GOOGLE_CLIENT_ID / GF_AUTH_GOOGLE_CLIENT_SECRET | Not set | High | Google OAuth for Grafana requires both values to be set together. Providing only one results in a failed OAuth exchange and a login error page. |
GF_FEATURE_TOGGLES_ENABLE | Not set | Low | Enabling experimental feature toggles in production may cause unexpected dashboard rendering failures after Grafana upgrades. |
application_version | "11.4.0" | Medium | Pinning to a specific version is recommended for production. Leaving as "latest" causes uncontrolled upgrades on every container rebuild, which may introduce breaking dashboard API changes. |
enable_redis | false | Low | Grafana does not require Redis for its core function. Enabling it without providing redis_host raises a validation error. |
ingress_settings | "all" | High | The Cloud Run default allows traffic from any source. For internal-only deployments set to "internal-and-cloud-load-balancing" to restrict. |
backup_schedule | "0 2 * * *" | Medium | Disabling scheduled backups leaves dashboard configurations and user definitions unprotected against accidental deletion or Cloud SQL corruption. |
enable_auto_password_rotation | false | Low | If enabled, ensure rotation_propagation_delay_sec is large enough for all running Cloud Run instances to pick up the new DB password before the old version expires, otherwise services will intermittently lose DB connectivity. |
Destroying Resources
Known Deletion Issue: Serverless IPv4 Address Release
When destroying a Cloud Run deployment, you may encounter an error similar to:
Error: Error waiting for Subnetwork to be deleted: The following serverless IPv4 address(es) on subnet ... are still in use.
Cause: GCP holds serverless IPv4 addresses on the VPC subnet asynchronously after a Cloud Run service is deleted. These addresses are released by GCP approximately 20–30 minutes after the Cloud Run service is removed.
Resolution: Wait 20–30 minutes after the initial destroy attempt, then re-run:
tofu destroy
