Maybe Finance on GKE Autopilot

Maybe (Maybe Finance) is an open-source, self-hosted alternative to Mint/Monarch for personal finance and wealth management — budgeting, net-worth tracking, transaction categorization, and multi-account aggregation, built on Ruby on Rails. This module deploys Maybe on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services Maybe uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

1. Overview

Maybe runs as a single Rails/Puma web workload with a Sidekiq background-job process co-located in the same container. The deployment wires together a focused set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	Rails/Puma pods on port 3000, 2 vCPU / 4 GiB by default; Sidekiq runs as a background process inside the same container
Database	Cloud SQL for PostgreSQL 15	Required — a plan-time guard accepts only POSTGRES_13/14/15 (or NONE); MySQL is rejected
Background jobs & real-time UI	Redis (via the shared NFS VM, or an explicit host)	Mandatory — a plan-time guard fails if disabled; powers Sidekiq (account syncing, import processing, notifications) and ActionCable
File persistence	Cloud Filestore (NFS)	Attachments persist under /opt/maybefinance/storage, shared across pods; also the default source for the Redis host IP
Object storage	Cloud Storage	A storage bucket is auto-provisioned by MaybeFinance_Common; not mounted into pods unless gcs_volumes is set
Secrets	Secret Manager	Auto-generated SECRET_KEY_BASE (Rails session/encryption key); database password
Ingress	Cloud Load Balancing	External LoadBalancer with a reserved static IP; custom domain + managed certificate enabled by default

Sensible defaults worth knowing up front:

• PostgreSQL 15 is mandatory. database_type defaults to POSTGRES_15 and a plan-time guard (validation.tf) rejects anything other than POSTGRES_13/14/15/NONE — MySQL is not supported.
• Redis is mandatory, not optional. A plan-time precondition fails the plan outright if enable_redis = false. When redis_host is left blank, enable_nfs must stay true so the shared NFS server's IP is used as the Redis host (the NFS VM co-hosts Redis in this repo's convention).
• Cloud SQL is reached via the Auth Proxy sidecar on loopback. enable_cloudsql_volume = true injects a cloud-sql-proxy sidecar listening on 127.0.0.1:5432. Rails cannot parse the Cloud SQL Unix-socket DSN, so the cloud entrypoint never builds a URL-style DSN — it maps the Foundation's DB_HOST/DB_PORT/DB_NAME/DB_USER/DB_PASSWORD onto Maybe's discrete DB_HOST/DB_PORT/POSTGRES_DB/POSTGRES_USER/ POSTGRES_PASSWORD env vars and sets PGSSLMODE=disable on loopback (require on a real private IP).
• min_instance_count = 1 / max_instance_count = 5. At least one pod stays up so the in-process Sidekiq worker keeps draining the job queue; scaling to zero stops background jobs entirely.
• Combined web + worker container, not a sidecar. The cloud entrypoint starts bundle exec sidekiq in the background and then execs the Rails web server in the foreground of the same container — Maybe is not deployed with a separate additional_services worker.
• SECRET_KEY_BASE is generated once by MaybeFinance_Common and stored in Secret Manager, shared identically by the web and Sidekiq processes. Rails uses it to sign sessions/cookies and to derive the key that encrypts ActiveRecord-encrypted columns.
• Schema is created by an init job, not on boot. The maybefinance-migrate job runs rails db:prepare during apply; the runtime entrypoint never runs migrations.
• Session affinity is ClientIP so a client's requests reach the same pod.
• container_image_source = "custom". Cloud Build builds a thin wrapper image FROM ghcr.io/maybe-finance/maybe:<version>. application_version defaults to "stable"; a "latest" request is mapped to the pinned stable channel via the app-specific MAYBE_VERSION build ARG (the Foundation's generic APP_VERSION build arg is intentionally not used).

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region "$REGION" --project "$PROJECT" and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the Maybe workload (web + Sidekiq)

Maybe pods are scheduled on Autopilot, which bills for the CPU/memory the pods actually request. The Rails/Puma web server and the Sidekiq worker run as two processes inside the same container, sharing SECRET_KEY_BASE and the Redis connection.

• Console: Kubernetes Engine → Workloads → select the Maybe workload for pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
• CLI:

  kubectl get pods,svc -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100
  kubectl exec -n "$NAMESPACE" deploy/<service-name> -- ps aux | grep -E 'puma|sidekiq'

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. Cloud SQL for PostgreSQL 15

Maybe stores all application data (accounts, transactions, budgets, users) in a managed Cloud SQL for PostgreSQL 15 instance. Pods reach it through the Cloud SQL Auth Proxy sidecar on 127.0.0.1:5432; no public IP is exposed. On first deploy the db-init job creates the application database and user, grants the app role cloudsqlsuperuser (so Maybe's migrations can create Postgres extensions without superuser access), and pre-creates the pgcrypto extension; maybefinance-migrate then runs rails db:prepare.

• Console: SQL → select the instance for connections, backups, flags, metrics.
• CLI:

  gcloud sql instances list --project "$PROJECT"
  gcloud sql instances describe <instance-name> --project "$PROJECT"
  gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"

The instance name, database, user, and the Secret Manager secret holding the password are all in the Outputs. See App_GKE for the connection model, automated backups, and password rotation.

C. NFS (Cloud Filestore) & Redis

Cloud Filestore (NFS) is mounted at /opt/maybefinance/storage so uploaded attachments persist and are shared across pods. Maybe also requires Redis for Sidekiq (background account syncing, import processing, notifications) and ActionCable (real-time UI updates); when redis_host is left blank, the injected REDIS_HOST resolves to the shared NFS server's IP (the NFS VM co-hosts Redis in this repo's platform convention).

• Console: Filestore → Instances; Compute Engine → VM instances (the NFS VM, if it also runs Redis).
• CLI:

  gcloud filestore instances list --project "$PROJECT"
  kubectl get pvc -n "$NAMESPACE"
  kubectl exec -n "$NAMESPACE" deploy/<service-name> -- env | grep -E 'REDIS_URL|REDIS_HOST'

See App_GKE for NFS discovery/provisioning behaviour and the Redis injection mechanics.

D. Cloud Storage

A Cloud Storage bucket (suffix storage) is provisioned automatically by MaybeFinance_Common, and the default storage_buckets variable adds a second bucket (suffix data). Neither is mounted into the pod filesystem by default — gcs_volumes is empty out of the box — so they exist as provisioned storage but are inert until explicitly wired up.

• Console: Cloud Storage → Buckets.
• CLI:

  gcloud storage buckets list --project "$PROJECT" --filter="name~maybefinance"

See App_GKE for CMEK options and GCS Fuse mounts.

E. Secret Manager

One Maybe-specific secret is generated automatically and stored in Secret Manager: SECRET_KEY_BASE (secret-<prefix>-maybefinance-secret-key-base), a 64-character random value shared by the Rails web process and the Sidekiq worker. The database password is managed separately by the foundation. On GKE, secrets are projected into pods via the Secret Store CSI driver.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~maybefinance"
  gcloud secrets versions access latest --secret=<secret-key-base-name> --project "$PROJECT"

See App_GKE for the Secret Store CSI integration and rotation.

F. Networking & ingress

By default the workload is exposed through an external Cloud Load Balancing IP (service_type = LoadBalancer, reserve_static_ip = true so the address survives redeploys) with enable_custom_domain = true provisioning a Kubernetes Ingress. network_tags defaults to ["nfsserver"], required for the NFS/Redis discovery path.

• Console: Network services → Load balancing; VPC network → IP addresses.
• CLI:

  kubectl get svc,ingress -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

G. Cloud Logging & Monitoring

Pod stdout/stderr flow to Cloud Logging (RAILS_LOG_TO_STDOUT = "true"); GKE and Cloud SQL metrics flow to Cloud Monitoring. Optional uptime checks and alert policies are available.

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. Maybe Finance Application Behaviour

• First-deploy database setup. The db-init job runs db-init.sh using postgres:15-alpine. It connects to Cloud SQL, idempotently creates the application database and user, grants privileges, grants the app role cloudsqlsuperuser (Cloud SQL's app users aren't real superusers, so this lets Maybe's own migration create Postgres extensions), and pre-creates pgcrypto as a belt-and-suspenders step. The job is safe to re-run (execute_on_apply = true, max_retries = 1).
• Schema migration is a separate init job. maybefinance-migrate runs bundle exec rails db:prepare against the image built for the app (image = null in its job spec, so it reuses the built Maybe image and toolchain), depends on db-init completing first, and retries up to 3 times (max_retries = 3, timeout_seconds = 1200, memory_limit = 2Gi).
• First-run admin registration, not an auto-created secret. SELF_HOSTED = "true" enables Maybe's self-host UI, which lets the first visitor register the initial admin account through the web UI — unlike some other modules in this repo, there is no auto-generated admin password secret to retrieve.
• SECRET_KEY_BASE is immutable in practice. It is generated once by MaybeFinance_Common and shared by the web and Sidekiq processes. Rotating it after first boot invalidates existing sessions and makes ActiveRecord-encrypted columns unreadable.
• DB env-var mapping happens in the cloud entrypoint, not a URL DSN. The platform injects DB_HOST (loopback via the proxy sidecar on GKE), DB_PORT, DB_NAME, DB_USER, DB_PASSWORD; the entrypoint maps these onto POSTGRES_DB/POSTGRES_USER/POSTGRES_PASSWORD (Maybe's Rails config/database.yml convention) and sets PGSSLMODE based on whether the resolved host is loopback.
• Redis wiring. REDIS_URL is built from the injected REDIS_HOST/ REDIS_PORT/REDIS_AUTH if not already set. If REDIS_URL ends up empty (Redis unreachable), the entrypoint skips starting Sidekiq entirely — background jobs silently stop running rather than crashing the pod.
• Health path. Startup probe is HTTP GET /up with a generous allowance for a slow first boot (initial_delay_seconds = 60, period_seconds = 15, failure_threshold = 30 — roughly 8 minutes of headroom). Liveness probe is also HTTP GET /up (initial_delay_seconds = 60, period_seconds = 30, failure_threshold = 3).
• Inspect the init jobs and running config:

  kubectl get jobs -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" job/<db-init-job-name>
  kubectl logs -n "$NAMESPACE" job/<maybefinance-migrate-job-name>
  kubectl exec -n "$NAMESPACE" deploy/<service-name> -- env | grep -E 'RAILS_ENV|POSTGRES_|REDIS_URL'

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform (the {{UIMeta group=N}} tag in each variable's description in variables.tf). Only settings specific to or notable for Maybe are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 3 — Application Identity

Variable	Default	Description
application_name	maybefinance	Base name for resources. Do not change after first deploy.
application_version	stable	ghcr.io/maybe-finance/maybe image tag used as the custom-build base; latest is mapped to the pinned stable release channel via MAYBE_VERSION.

Group 4 — Runtime & Scaling

Variable	Default	Description
container_port	3000	Maybe's native Rails/Puma port.
container_resources	cpu_limit=2000m, memory_limit=4Gi	2 vCPU / 4 GiB for the combined Rails + Sidekiq container.
min_instance_count	1	Keep at 1 so the co-located Sidekiq worker always has a pod to run in.
max_instance_count	5	HPA ceiling.
enable_cloudsql_volume	true	Auth Proxy sidecar (loopback) — required on GKE.
container_image_source	custom	Thin wrapper image built FROM the upstream GHCR image.

Group 6 — GKE Backend & Cluster

Variable	Default	Description
service_type	LoadBalancer	External IP for the Maybe UI.
workload_type	null → Deployment	Deployment (combined web + Sidekiq pod).
session_affinity	ClientIP	Sticky routing so a client reaches the same pod.

Group 9 — Reliability Policies

Variable	Default	Description
enable_pod_disruption_budget	true	Keeps at least one pod available during voluntary node disruptions.
pdb_min_available	"1"	Minimum pods available during disruptions.

Group 13 — NFS

Variable	Default	Description
enable_nfs	true	Attachments persist and are shared across pods; also the default source for the Redis host IP.
nfs_mount_path	/opt/maybefinance/storage	Where Maybe stores uploaded attachments.

Group 15 — Redis

Variable	Default	Description
enable_redis	true	Mandatory — a plan-time guard fails the plan if set to false.
redis_host	""	Leave blank to use the NFS server IP (requires enable_nfs = true).
redis_port	6379	Redis server port.

Group 16 — Database Backend

Variable	Default	Description
database_type	POSTGRES_15	Guard restricts this to POSTGRES_13/14/15/NONE; MySQL is rejected.
application_database_name	maybefinance	Database name. Immutable after first deploy.
application_database_user	maybefinance	Application database user; password auto-generated in Secret Manager.

Group 19 — Custom Domain, Static IP & Networking

Variable	Default	Description
enable_custom_domain	true	Provisions a Kubernetes Ingress for custom domain routing.
reserve_static_ip	true	Stable external IP across redeploys.
network_tags	["nfsserver"]	Required tag for NFS/Redis-host discovery.

All other inputs follow standard App_GKE behaviour.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip	In-cluster ClusterIP.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific services.
service_external_ip	External LoadBalancer IP (when a static IP is reserved).
service_url	URL to reach Maybe.
database_instance_name	Cloud SQL instance name.
database_name / database_user	Application database name / user.
database_password_secret	Secret Manager secret holding the DB password.
database_host / database_port	DB endpoint (127.0.0.1 via the Auth Proxy) / port.
storage_buckets	Created Cloud Storage buckets.
network_name / network_exists / regions	VPC network, presence, available regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
initialization_jobs / db_import_job	Names of the setup (db-init, maybefinance-migrate) and (optional) import jobs.
cicd_enabled / cicd_configuration	CI/CD status and details (repo, trigger, registry).
github_repository_url / github_repository_owner / github_repository_name	CI/CD GitHub details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time — plus MaybeFinance's own validation.tf guards (Redis mandatory, PostgreSQL-only, min ≤ max, IAP credentials required when enabled, no Auth Proxy without a real database). Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Setting	Sensible value	Risk	Consequence if wrong
database_type	POSTGRES_15 (or 13/14)	Critical	A non-PostgreSQL engine is rejected at plan time; forcing one around the guard breaks the installer and every query.
enable_redis	true	Critical	The plan-time guard blocks false outright — Maybe has no functioning background-job queue or real-time UI without Redis.
application_database_name / application_database_user	Set once	Critical	Immutable after first deploy; renaming recreates the DB/user and orphans all data.
SECRET_KEY_BASE (auto-generated)	Never change	Critical	Rotating it after first boot invalidates all sessions and makes ActiveRecord-encrypted columns unreadable.
quota_memory_requests / _limits	binary units (4Gi, 8192Mi)	Critical	Bare integers are treated as bytes and block all pod scheduling in the namespace.
min_instance_count	1	High	Scaling to 0 stops the co-located Sidekiq worker — account syncing, import processing, and notifications silently stop firing.
enable_cloudsql_volume	true	High	The Auth Proxy sidecar on 127.0.0.1:5432 is required for DB connectivity on GKE.
enable_nfs	true (unless redis_host is set explicitly)	High	If left false with redis_host empty, the plan-time guard fails; if disabled after a working deploy with an explicit redis_host, uploaded attachments become ephemeral.
redis_host	"" (use NFS IP) or a real, reachable host	High	An unreachable Redis host makes REDIS_URL resolve but fail to connect — Sidekiq starts but jobs never process; the entrypoint only skips Sidekiq when REDIS_URL is entirely empty.
container_resources.memory_limit	4Gi (default)	High	The combined Rails + Sidekiq process is memory-hungry under import/sync workloads; shrinking it risks OOM.
session_affinity	ClientIP	High	Without stickiness, requests bounce between pods and can disrupt authenticated sessions.
reserve_static_ip	true	Medium	Without it, the external IP can change across redeploys, breaking DNS and any configured custom domain.
backup_retention_days	7 (raise for prod)	Medium	Too short for compliance retention.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Maybe-specific application configuration shared with the Cloud Run variant lives in the MaybeFinance_Common module (its own docs/modules/MaybeFinance_Common.md guide has not been published yet).
