Wallos on Google Cloud Run

Wallos is an open-source, self-hosted subscription and recurring-expense tracker built on plain PHP 8.3 + php-fpm (no MVC framework). It tracks recurring subscriptions, converts prices across currencies, sends renewal notifications, and supports a household multi-user mode. This module deploys Wallos on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure.

This guide focuses on the cloud services Wallos uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.

---

1. Overview

Wallos runs as a single PHP container on Cloud Run v2. It is deliberately minimal — no SQL database, no cache, no queue — but it DOES run a real, always-on cron daemon, which drives several of the defaults below:

Capability	Google Cloud service	Notes
Compute	Cloud Run v2	Single PHP/php-fpm service, 1 vCPU / 1 GiB by default; min = max = 1, cpu_always_allocated = true
Persistent state	Cloud Storage (GCS FUSE)	Two buckets: db mounted at /var/www/html/db (SQLite file), uploads mounted at /var/www/html/images/uploads/logos (custom provider logos)
Database	None (embedded SQLite)	database_type = NONE; no Cloud SQL is provisioned; confirmed no MySQL/Postgres support exists anywhere in the app
Cache & queue	None	Wallos uses no Redis
Secrets	Secret Manager	No app secrets generated; users live in the SQLite DB
Ingress	Cloud Run URL / Cloud Load Balancing	Default ingress is all — the service is publicly reachable out of the box
Background jobs	In-container cron daemon	8 baked-in scheduled tasks (exchange-rate refresh, renewal notifications, an email-verification poll every 2 minutes, etc.) — not modeled as a Cloud Run Job; it runs continuously inside the main container

Sensible defaults worth knowing up front:

• State lives in two SQLite/logo files on GCS, each in its own bucket. Wallos has no Cloud SQL database. Its subscriptions, categories, settings, and users are stored in /var/www/html/db/wallos.db (bucket db); user-uploaded custom provider logos live in /var/www/html/images/uploads/logos (bucket uploads). Both paths are fixed — no environment variable relocates either one. Losing or wiping either bucket loses that state.
• CRITICAL — single always-on instance, not just cold-start tuning. min_instance_count = max_instance_count = 1 and cpu_always_allocated = true. This is a harder constraint than the usual "avoid cold starts" pattern: Wallos's SQLite database has no multi-writer support (so max = 1 is required), and its baked-in cron daemon only fires scheduled tasks while an instance is actually running with allocated CPU (so min = 1 and cpu_always_allocated = true are both required). Scaling to zero silently stops every scheduled task with no error — renewal notifications simply stop arriving.
• Default login is admin / admin. Wallos seeds this credential on first boot. Change it in the web UI immediately after deploy.
• Ingress defaults to all (public). The service is reachable from the public internet out of the box. To restrict it, set ingress_settings = "internal" (VPC-only) or internal-and-cloud-load-balancing, or front it with the HTTPS load balancer (enable_cloud_armor = true + application_domains).
• No Redis, no init job. enable_redis = false and no db-init job runs; the app is ready as soon as the container starts.
• Container port 80. Wallos serves plain HTTP/1.1 on port 80 (container_protocol = http1).
• Prebuilt image. bellamy/wallos is a genuine, third-party-maintained "latest"-tagged image (there is no official Wallos-project image); no Dockerfile or Cloud Build step is used.

---

2. Google Cloud Services & How to Explore Them

All commands assume PROJECT and REGION are set. Service and resource names are reported in the deployment Outputs.

A. Cloud Run — the Wallos service

Wallos runs as a Cloud Run v2 service pinned to a single, always-allocated instance. Each deployment creates an immutable revision; traffic can be split across revisions for safe rollouts.

• Console: Cloud Run → select the service for revisions, traffic, logs, and metrics.
• CLI:

  gcloud run services list --project "$PROJECT" --region "$REGION" \
    --filter="metadata.name~wallos"
  gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
  gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"

See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.

B. Cloud Storage — persistent state (GCS FUSE)

Wallos has no Cloud SQL database. Its embedded SQLite database (/var/www/html/db/wallos.db) and its user-uploaded provider logos (/var/www/html/images/uploads/logos) live in two separate Cloud Storage buckets, each mounted into the container via GCS FUSE (requires the gen2 execution environment).

• Console: Cloud Storage → Buckets.
• CLI:

  gcloud storage buckets list --project "$PROJECT" --filter="name~wallos"
  gcloud storage ls gs://<db-bucket>/               # bucket name is in the Outputs
  gcloud storage ls gs://<db-bucket>/wallos.db      # the SQLite DB object
  gcloud storage ls gs://<uploads-bucket>/          # user-uploaded logo files

See App_CloudRun for GCS FUSE and CMEK options.

C. Secret Manager

Wallos generates no application secrets — there is no encryption key or JWT secret to manage, because all identity state lives in the SQLite database. Secret Manager is still used by the foundation for platform-managed secrets (e.g. CI/CD tokens if configured).

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~wallos"

See App_CloudRun for injection and rotation details.

D. Networking & ingress

The service's ingress defaults to all — reachable from the public internet out of the box. To restrict it, set ingress_settings = "internal" (VPC-only), or layer an external HTTPS load balancer with a custom domain, Cloud CDN, and Cloud Armor.

• Console: Cloud Run (service URL); Network services → Load balancing.
• CLI:

  gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'
  gcloud compute addresses list --project "$PROJECT"

See App_CloudRun.

E. Cloud Logging & Monitoring

Container logs flow to Cloud Logging; Cloud Run metrics flow to Cloud Monitoring, with optional uptime checks and alert policies. Since Wallos's cron daemon runs in-process, its scheduled-task activity (or failures) is visible only in the container logs — there is no separate Cloud Run Job to inspect.

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50

---

3. Wallos Application Behaviour

• No first-deploy database setup. There is no db-init job and no Cloud SQL instance. On first start Wallos creates its SQLite database at /var/www/html/db/wallos.db (on the GCS FUSE mount) if it does not already exist and seeds the default admin/admin user.
• State persistence. Subscriptions, categories, settings, and users live entirely in /var/www/html/db/wallos.db. Because that file is on the persistent db GCS bucket, it survives restarts and redeploys. Custom provider logos persist separately on the uploads bucket.
• Default credentials must be changed. The seeded admin/admin login is well-known. Log in and change the password (and ideally the username) in the web UI immediately after the first deploy.
• Single-writer constraint. The embedded SQLite database does not support concurrent writers across instances on a GCS FUSE mount. Keep max_instance_count = 1; scaling out risks corrupting the database.
• Always-on cron daemon — not request-triggered. Wallos's 8 baked-in scheduled tasks (exchange-rate refresh, renewal notifications, an email-verification poll every 2 minutes, etc.) run inside the same container continuously. This is why min_instance_count = 1 and cpu_always_allocated = true are both required — under request-based (throttled) billing or scale-to-zero, these tasks would either stall or never run.
• Health path. Startup and liveness probes target / — Wallos's unauthenticated login page. bellamy/wallos documents no dedicated /health endpoint, so this is a coarse readiness signal (verify at first deploy):

  curl -s -o /dev/null -w '%{http_code}\n' "$SERVICE_URL/"    # 200 once the server is up

• No Redis. enable_redis = false; Wallos is a self-contained app with no queue or cache beyond its own cron daemon.
• Inspect the running revision's env and mounts:

  gcloud run services describe <service-name> \
    --region "$REGION" --project "$PROJECT" \
    --format='value(spec.template.spec.containers[0].env)'

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Wallos are listed; every other input is inherited from App_CloudRun with its standard behaviour.

Group 1 — Project & Identity

Variable	Default	Description
project_id	(required)	Target Google Cloud project.
region	us-central1	Region for the service and regional resources.

Group 3 — Application Identity

Variable	Default	Description
application_name	wallos	Base name for resources. Do not change after first deploy.
application_display_name	Wallos	Human-readable name shown in the Console.
application_version	latest	Wallos image tag — bellamy/wallos:latest is a genuine "latest" release, not a pinned build artifact.

Group 4 — Runtime & Scaling

Variable	Default	Description
deploy_application	true	Set false to provision supporting infrastructure only.
cpu_limit	1000m	CPU per instance.
memory_limit	1Gi	Memory per instance; covers php-fpm workers plus the always-running cron daemon.
min_instance_count	1	CRITICAL — must stay 1. The cron daemon only fires while an instance is running.
max_instance_count	1	CRITICAL — must stay 1. SQLite on GCS FUSE cannot take concurrent writers.
container_port	80	Wallos's HTTP/1.1 listener.
container_protocol	http1	Wallos serves plain HTTP/1.1.
execution_environment	gen2	Required for the GCS FUSE mounts.
enable_cloudsql_volume	false	Wallos has no Cloud SQL; leave false.
enable_image_mirroring	true	Mirror the Wallos image into Artifact Registry (avoids Docker Hub rate limits).
container_image_source	prebuilt	Must stay forwarded to the foundation — bellamy/wallos needs no build step; App_CloudRun's own default (custom) would otherwise silently win.
cpu_always_allocated	true	CRITICAL — must stay true. The cron daemon needs CPU between requests to actually execute its scheduled tasks.

Group 5 — Access & Ingress Control

Variable	Default	Description
ingress_settings	all	Default is public. Set internal to restrict to VPC-only access, or internal-and-cloud-load-balancing behind a Load Balancer.
vpc_egress_setting	PRIVATE_RANGES_ONLY	Route only RFC 1918 traffic via VPC.
enable_iap	false	Require Google sign-in in front of Wallos.
iap_authorized_users / iap_authorized_groups	[]	Who may access through IAP.

Group 6 — Environment Variables & Secrets

Variable	Default	Description
environment_variables	{}	Extra non-secret settings.
secret_environment_variables	{}	Map of env var → Secret Manager secret name. Wallos uses none by default.
secret_propagation_delay	30	Seconds to wait after secret creation before proceeding.

Group 9 — Custom SQL Scripts

enable_custom_sql_scripts, custom_sql_scripts_bucket, custom_sql_scripts_path, custom_sql_scripts_use_root — not applicable to Wallos (no SQL database). Leave at defaults.

Group 11 — Storage & Filesystem

Variable	Default	Description
create_cloud_storage	true	Create the Wallos db and uploads buckets (and any extra storage_buckets).
storage_buckets	[]	Additional GCS buckets beyond the auto-provisioned db/uploads buckets.
enable_nfs	false	NFS is off by default; not needed for Wallos.
gcs_volumes	[]	Extra GCS FUSE mounts. The db and uploads buckets are added automatically.
manage_storage_kms_iam / enable_artifact_registry_cmek	false	CMEK options.

Group 12 — Database Backend

Not applicable — Wallos has no SQL database. database_type is fixed to NONE by Wallos_Common, and database_password_length, the db_*_env_var_name inputs, and password rotation are forwarded only for foundation compatibility.

Group 13 — Jobs & Scheduled Tasks

Variable	Default	Description
initialization_jobs	[]	No default init job. Provide jobs only for custom data loading/migration.
cron_jobs	[]	Additional Cloud Scheduler + Cloud Run jobs — separate from Wallos's own 8 in-container scheduled tasks.

Group 14 — Observability & Health

Variable	Default	Description
startup_probe	HTTP / 15s delay	Startup probe; no dedicated /health endpoint is documented for this image.
liveness_probe	HTTP / 30s delay	Liveness probe on the unauthenticated login page.
uptime_check_config	disabled, path /health	Cloud Monitoring uptime check; disabled by default.
alert_policies	[]	Metric alert policies.

Group 23 — VPC Service Controls & Audit Logging

Variable	Default	Description
enable_vpc_sc	false	Enforce a VPC-SC perimeter (requires organization_id).
vpc_cidr_ranges / vpc_sc_dry_run	(set)	Access level CIDRs / dry-run mode.
enable_audit_logging	false	Detailed Cloud Audit Logs.

All other inputs follow standard App_CloudRun behaviour.

---

5. Outputs

Returned on a successful deployment — the quickest way to locate and explore the running resources.

Output	Description
service_name	Cloud Run service name.
wallos_url	URL of the Wallos web UI (port 80). VPC-internal when ingress_settings = internal.
service_location	Region the service runs in.
stage_services	Stage-specific service details (Cloud Deploy).
load_balancer_ip / load_balancer_url	External HTTPS load balancer IP / URL (when enabled).
storage_buckets	Created Cloud Storage buckets (db and uploads).
network_name / network_exists / regions	VPC network, presence, regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels / uptime_check_names	Monitoring status, channels, uptime checks.
initialization_jobs	Names of any init jobs (empty by default).
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / github_repository_url / github_repository_owner / github_repository_name / cicd_configuration	CI/CD status and details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_CloudRun foundation engine, which validates values and combinations at plan time — IAP with no authorized identities, a gen1 runtime with GCS FUSE mounts, min_instance_count > max_instance_count, out-of-range timeouts. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Setting	Sensible value	Risk	Consequence if wrong
min_instance_count	1	Critical	Scaling to zero silently stops Wallos's cron daemon — renewal notifications and every other scheduled task stop firing, with no error anywhere.
max_instance_count	1	Critical	>1 puts concurrent writers on SQLite over GCS FUSE, corrupting the database.
cpu_always_allocated	true	Critical	false throttles CPU to near-zero between requests, starving the cron daemon of the CPU cycles it needs to run scheduled tasks.
db / uploads GCS buckets	Never delete	Critical	The embedded SQLite DB and custom logos live here; deleting either bucket destroys that state permanently.
admin / admin (seeded login)	Change on first login	Critical	Leaving the default credential lets anyone who can reach the service take full control.
ingress_settings	all (or internal to restrict)	High	Default all exposes the service to the public internet — pair with IAP or Cloud Armor if that's not desired; set internal for VPC-only access.
container_port	80	High	Wallos listens on 80; a different port makes the startup probe fail and the revision never becomes Ready.
startup_probe / liveness_probe path	/	Medium	No dedicated /health endpoint is documented for bellamy/wallos — if the app ever gates its root path behind auth, the probe path needs adjusting.
container_image_source	prebuilt (forwarded)	High	If not forwarded, App_CloudRun's own default (custom) silently wins and triggers a from-source Kaniko build against an image with no Dockerfile — the deploy fails.
enable_cloudsql_volume	false	Medium	Wallos has no Cloud SQL; enabling adds a useless Auth Proxy sidecar.
execution_environment	gen2	High	gen1 cannot mount the GCS FUSE volumes, so state is not persisted.
db/uploads volume-shadowing	Verify at first deploy	High	If bellamy/wallos seeds any default assets inside /var/www/html/db or /var/www/html/images/uploads/logos, mounting a fresh empty bucket over that exact path hides them on first boot — this was not confirmed either way during research.

---

For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_CloudRun. Wallos-specific application configuration shared with the GKE variant is described in Wallos_Common.
