InvenTree on Google Cloud Run

InvenTree is a free, open-source inventory management system: it tracks parts and components, stock locations and movements, suppliers, bills of materials, and purchase and sales orders, and is used by hardware teams, makerspaces and small manufacturers. This module deploys InvenTree on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure.

This guide focuses on the cloud services InvenTree uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.

---

1. Overview

InvenTree runs as a Python/Django application served by gunicorn on Cloud Run v2. Each revision runs two containers built from the same image: the web container and a django-q qcluster background-worker sidecar. The deployment wires together a focused set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	Cloud Run v2	Web container (1 vCPU / 2 GiB) plus a qcluster sidecar (1 vCPU / 1 GiB); CPU always allocated; scale-to-zero by default
Database	Cloud SQL for MySQL 8.0	Schema created by Django migrations in a dedicated migrate init job
Shared filesystem	NFS (Services_GCP NFS server)	Optional (enable_nfs = false by default) — needed to persist InvenTree's data directory
Object storage	Cloud Storage	A data bucket (Foundation default) and a storage bucket (from InvenTree_Common) are created; neither is mounted into the container
Secrets	Secret Manager	Database password only — the module generates no application secrets
Ingress	Cloud Run URL / Cloud Load Balancing	Project-number run.app URL; optional external HTTPS load balancer + custom domain

Sensible defaults worth knowing up front:

• Use the project-number URL. InvenTree checks every request's host against INVENTREE_SITE_URL, which the Foundation injects from the predicted https://<service>-<project-number>.<region>.run.app URL. The hash-form *.a.run.app URL that Cloud Run also advertises returns HTTP 500 (INVE-E7). The service_url output is the project-number form.
• The data directory is ephemeral unless you enable NFS. InvenTree keeps config.yaml, its generated secret_key.txt, uploaded media, collected static files and plugins under /home/inventree/data. With the default enable_nfs = false, that is the container's own filesystem and is lost on every cold start. Set enable_nfs = true and nfs_mount_path = "/home/inventree/data" for any deployment you intend to keep.
• Migrations are a job, not a startup step. INVENTREE_AUTO_UPDATE is "false"; the migrate init job owns the schema.
• The background worker needs CPU outside requests. cpu_always_allocated = true (instance-based billing) so the qcluster sidecar keeps polling between requests.
• Scale-to-zero is enabled by default (min_instance_count = 0, max_instance_count = 1). While no instance exists, the worker does not run either; set min_instance_count = 1 if scheduled work matters.
• No administrator account is provisioned. The module creates no admin user and no admin secret (see §3).

---

2. Google Cloud Services & How to Explore Them

All commands assume PROJECT and REGION are set. Service and resource names are reported in the deployment Outputs.

A. Cloud Run — the InvenTree service

InvenTree runs as a Cloud Run v2 service with two containers per revision: the ingress container (gunicorn on port 8000) and the qcluster sidecar (no HTTP). Each deployment creates an immutable revision; traffic can be split across revisions for safe rollouts.

• Console: Cloud Run → select the service for revisions, containers, traffic, logs, and metrics.
• CLI:

  gcloud run services list --project "$PROJECT" --region "$REGION"
  gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
  gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"

See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.

B. Cloud SQL for MySQL 8.0

InvenTree stores all of its records — parts, stock, orders, users — in a managed Cloud SQL for MySQL 8.0 instance. The service connects over the instance's private IP via TCP (enable_cloudsql_volume = false): the wrapper entrypoint sets INVENTREE_DB_HOST from the Foundation's DB_IP. On first deploy the db-init job creates the database and user, then the migrate job creates the schema.

• Console: SQL → select the instance for connections, backups, flags, metrics.
• CLI:

  gcloud sql instances list --project "$PROJECT"
  gcloud sql instances describe <instance-name> --project "$PROJECT"
  gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"

The instance name, database, user, and password secret are in the Outputs. See App_CloudRun for the connection model, backups, and password rotation.

C. NFS — InvenTree's data directory

When enable_nfs = true, the Services_GCP NFS share is mounted into the web container and the init jobs at nfs_mount_path, and into the qcluster sidecar at /home/inventree/data. Point nfs_mount_path at /home/inventree/data so all three see the same directory; the default /var/lib/inventree is not a path InvenTree reads or writes.

• Console: Compute Engine → VM instances (the Services_GCP NFS server).
• CLI:

  gcloud compute instances list --project "$PROJECT" --filter="name~nfs"

D. Cloud Storage

Two buckets are provisioned by default: the Foundation's data bucket (from storage_buckets) and a storage bucket contributed by InvenTree_Common. Neither is mounted into the container (gcs_volumes is empty), and InvenTree does not read or write them. The storage bucket is a convenient place to stage files for enable_custom_sql_scripts.

• Console: Cloud Storage → Buckets.
• CLI:

  gcloud storage buckets list --project "$PROJECT"

E. Secret Manager

InvenTree_Common generates no application secrets. The only secret is the database password, managed by the foundation. Any credential-named key you put in environment_variables is moved into Secret Manager automatically while protect_sensitive_environment_variables = true.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT"

See App_CloudRun for injection and rotation details.

F. Networking & ingress

The service is reachable at its project-number run.app URL by default. An external HTTPS load balancer with a custom domain, Cloud CDN, and Cloud Armor can be layered on; a custom domain also sidesteps the two-hostname issue above.

• Console: Cloud Run (service URL); Network services → Load balancing.
• CLI:

  PROJECT_NUMBER=$(gcloud projects describe "$PROJECT" --format='value(projectNumber)')
  echo "https://<service-name>-${PROJECT_NUMBER}.${REGION}.run.app"
  gcloud compute addresses list --project "$PROJECT"

See App_CloudRun.

G. Cloud Logging & Monitoring

Logs from both containers flow to Cloud Logging; Cloud Run and Cloud SQL metrics flow to Cloud Monitoring. The uptime check is off by default (uptime_check_config.enabled = false).

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50

---

3. InvenTree Application Behaviour

• Two-stage init chain. db-init (mysql:8.0-debian, 3 retries, 600 s) creates the MySQL user and database and verifies the user can connect. migrate (the app image, 2 vCPU / 2 GiB, 1800 s, depends on db-init) runs python3 manage.py migrate --noinput and then counts the tables; it fails if fewer than 10 exist, because migrate can exit 0 having applied nothing.
• Why not INVENTREE_AUTO_UPDATE. Upstream's in-process migration runs in the gunicorn master before the port binds (so the startup probe kills the revision mid-migration), its empty-database branch is unreachable, and the web and worker containers would race on the same schema. Both containers run with INVENTREE_AUTO_UPDATE = "false".
• Required environment. The wrapper entrypoint refuses to start without INVENTREE_SITE_URL (or CLOUDRUN_SERVICE_URL as a fallback) and the Foundation's DB_IP, DB_NAME, DB_USER and DB_PASSWORD. The module also sets INVENTREE_USE_X_FORWARDED_PROTO = "true" and INVENTREE_SESSION_COOKIE_SECURE = "true", so absolute links are https:// and cookies are secure behind Cloud Run's TLS termination.
• Static files. The web container runs collectstatic on every start (the vendor init.sh does not). A failure there is logged as a warning and the container still starts — the UI may then render unstyled.
• Background worker. The qcluster sidecar runs /cloud-entrypoint.sh invoke worker with the app's infrastructure env and secrets (inherit_app_env = true), and with INVENTREE_AUTO_UPDATE and INVENTREE_COLLECTSTATIC set to false. Turning off enable_background_worker removes it: the UI and API still work, but no scheduled tasks, notifications or label generation run.
• Health checks. Startup and liveness probes are HTTP GET / on port 8000. The root path answers with a redirect to the web UI.

  curl -s -o /dev/null -w "%{http_code}\n" "$SERVICE_URL/"   # expect 302

• First administrator. The module creates no InvenTree user, and the admin_email input is not used. Create the first superuser yourself — for example with InvenTree's own INVENTREE_ADMIN_USER, INVENTREE_ADMIN_EMAIL and INVENTREE_ADMIN_PASSWORD settings (see the InvenTree documentation), supplied through environment_variables / secret_environment_variables.
• Inspect job execution:

  gcloud run jobs list --project "$PROJECT" --region "$REGION"
  gcloud run jobs executions list --job <job-name> --project "$PROJECT" --region "$REGION"

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for InvenTree are listed; every other input is inherited from App_CloudRun with its standard behaviour.

Group 1 — Project & Identity

Variable	Default	Description
project_id	(required)	Target Google Cloud project.
tenant_id	demo	Short suffix that makes resource names unique per environment.
region	us-central1	Region for the service and regional resources.

Group 2 — Deployment Environment

Variable	Default	Description
support_users	[]	Emails granted project access and monitoring alerts.
resource_labels	{}	Labels applied to all resources.

Group 3 — Application Identity

Variable	Default	Description
application_name	inventree	Base name for resources. Do not change after first deploy.
display_name	InvenTree	Human-readable name shown in the Console.
application_version	1.5.4	inventree/inventree tag, passed as the INVENTREE_VERSION build ARG. Pin an exact version — this variant's value is the one that takes effect.
php_memory_limit	512M	Not used — InvenTree is a Python application.
admin_email	admin@example.com	Not used — no administrator account is created.
enable_gcs_storage_volume	true	Not used — no bucket is mounted by this setting.

Group 4 — Runtime & Scaling

Variable	Default	Description
deploy_application	true	Set false to provision infrastructure only.
container_image_source	custom	Builds the wrapper image via Cloud Build. "prebuilt" skips the wrapper entrypoint and its DB_* → INVENTREE_DB_* mapping.
cpu_limit	1000m	CPU for the web container.
memory_limit	2Gi	Memory for the web container.
min_instance_count	0	0 enables scale-to-zero.
max_instance_count	1	Autoscaling upper bound.
container_port	8000	gunicorn's port.
execution_environment	gen2	Cloud Run execution environment.
timeout_seconds	300	Maximum request duration.
enable_cloudsql_volume	false	Connect over private-IP TCP instead of the Auth Proxy socket.
container_protocol	http1	HTTP/1.1.
cpu_always_allocated	true	Required for the qcluster sidecar.
enable_background_worker	true	Run the qcluster sidecar.
worker_cpu_limit / worker_memory_limit	1000m / 1Gi	Sidecar resources.

Group 5 — Access & Ingress Control

Variable	Default	Description
ingress_settings	all	Public ingress by default.
vpc_egress_setting	PRIVATE_RANGES_ONLY	Route only RFC 1918 traffic via VPC.
enable_iap	false	Require Google sign-in.
iap_authorized_users / iap_authorized_groups	[]	Who may access through IAP.

Group 6 — Environment Variables & Secrets

Variable	Default	Description
environment_variables	{}	Extra InvenTree settings (INVENTREE_*). Merged over the module's defaults, so a key here wins — do not override INVENTREE_AUTO_UPDATE, INVENTREE_DATA_DIR or INVENTREE_DB_ENGINE.
secret_environment_variables	{}	Map of env var → Secret Manager secret name.
protect_sensitive_environment_variables	true	Moves credential-named keys from environment_variables into Secret Manager.
secret_propagation_delay	30	Seconds to wait after secret creation before proceeding.
secret_rotation_period	2592000s	Secret Manager rotation notification frequency.

Group 7 — Backup & Restore

Variable	Default	Description
backup_schedule	0 2 * * *	Automated backup cron (UTC).
backup_retention_days	7	Retention; raise for production.
enable_backup_import / backup_source / backup_uri / backup_format	restore options	Restore from a backup on deploy.

Group 8 — CI/CD & Binary Authorization

Standard App_CloudRun Cloud Build / Cloud Deploy integration — see App_CloudRun. Key inputs: enable_cicd_trigger, github_repository_url, github_token, enable_cloud_deploy, enable_binary_authorization.

Group 9 — Custom SQL Scripts & NFS Naming

enable_custom_sql_scripts, custom_sql_scripts_bucket, custom_sql_scripts_path, custom_sql_scripts_use_root — run SQL from a GCS bucket after provisioning (verified end to end on this module, executed as the application user). nfs_instance_name / nfs_instance_base_name select the NFS server; leave them at their defaults to use the Services_GCP server. See App_CloudRun.

Group 10 — Load Balancer, CDN & Image Retention

Variable	Default	Description
enable_cloud_armor	false	Provision Global HTTPS LB + Cloud Armor WAF.
application_domains	[]	Custom domain names for the HTTPS LB.
enable_cdn	false	Enable Cloud CDN on the HTTPS LB backend (requires Cloud Armor).
max_images_to_retain	7	Revision/image pruning.
delete_untagged_images / image_retention_days	true / 30	No effect in a Services_GCP deployment — the shared registry's own policy applies.

Group 11 — Storage & Filesystem

Variable	Default	Description
create_cloud_storage	true	Create the buckets in storage_buckets.
storage_buckets	[{ name_suffix = "data" }]	Setting this replaces the list — adding a bucket destroys the default data bucket.
enable_nfs	false	Mount NFS into the service, jobs and sidecar. Set true to persist the data directory.
nfs_mount_path	/var/lib/inventree	Set to /home/inventree/data when enable_nfs = true.
gcs_volumes	[]	GCS Fuse volume mounts (requires gen2).
manage_storage_kms_iam / enable_artifact_registry_cmek	false	CMEK options.

Group 12 — Database Backend

Variable	Default	Description
database_type	MYSQL_8_0	InvenTree is configured for MySQL.
db_name / db_user	inventree	Tenant-prefixed at deploy time. Immutable after first deploy.
database_password_length	32	Generated password length (16–64). Do not change on a running deployment.
enable_auto_password_rotation	false	Automated password rotation.
db_host_env_var_name	DB_IP	Extra name for the DB private IP; redundant, since DB_IP is always injected.

Group 13 — Jobs & Scheduled Tasks

Variable	Default	Description
initialization_jobs	[]	Leave empty to use the built-in db-init → migrate chain. A non-empty list replaces it entirely.
cron_jobs	[]	No platform-scheduled recurring tasks by default — InvenTree's own scheduling runs in the qcluster sidecar.

Group 14 — Observability & Health

Variable	Default	Description
startup_probe	HTTP GET /, 30 s delay, 15 s period, 60 retries	A long window for a cold first start.
liveness_probe	HTTP GET /, 60 s delay, 30 s period, 3 retries	Matches the vendor image's health check (the document root).
uptime_check_config	{ enabled = false, path = "/" }	Cloud Monitoring uptime check — off by default.
alert_policies	[]	Metric alert policies.

Group 21 — Redis

Variable	Default	Description
enable_redis	false	InvenTree is not wired to Redis by this module.
redis_host / redis_port	"" / 6379	Redis endpoint.

Group 22 — VPC Service Controls & Audit Logging

Variable	Default	Description
enable_vpc_sc	false	Enforce a VPC-SC perimeter (requires organization_id).
enable_audit_logging	false	Detailed Cloud Audit Logs.

---

5. Outputs

Returned on a successful deployment — the quickest way to locate and explore the running resources.

Output	Description
service_name	Cloud Run service name.
service_url	Project-number run.app URL of the service — the one InvenTree accepts.
service_location	Region the service runs in.
load_balancer_ip / load_balancer_url	External HTTPS load balancer IP / URL (when enabled).
database_instance_name	Cloud SQL instance name.
database_name / database_user	Application database name / user.
database_password_secret	Secret Manager secret holding the DB password.
database_host / database_port	DB endpoint (sensitive) / port.
storage_buckets	Created Cloud Storage buckets.
network_name / network_exists / regions	VPC network, presence, regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels / uptime_check_names	Monitoring status, channels, uptime checks.
initialization_jobs	Names of the setup jobs (db-init, migrate).
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / github_repository_url / cicd_configuration	CI/CD status and details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_CloudRun foundation engine, which validates values and combinations at plan time. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Setting	Sensible value	Risk	Consequence if wrong
enable_nfs / nfs_mount_path	true / /home/inventree/data	Critical	With the defaults (false / /var/lib/inventree) the data directory is ephemeral: uploaded media, plugins, config.yaml and the generated secret key are lost on every cold start, and a new secret key invalidates all sessions and password-reset tokens. Enabling NFS at the default path mounts a directory InvenTree never uses.
Service URL used by people	the project-number URL (service_url output) or a custom domain	High	The hash-form *.a.run.app URL returns HTTP 500 (INVE-E7), because the host does not match INVENTREE_SITE_URL.
db_name / db_user	Set once	Critical	Immutable after first deploy; renaming recreates the DB/user and loses all inventory data.
storage_buckets	leave at default unless you mean to replace it	High	The list replaces the default — adding one bucket destroys the data bucket and anything in it.
environment_variables	do not set INVENTREE_AUTO_UPDATE=true	Critical	Re-enables in-process migrations in both containers: a race on one schema and a probe kill mid-migration. A half-migrated database cannot be repaired by re-running migrate (it fails with Duplicate column name) — it has to be dropped and recreated.
initialization_jobs	[]	High	Any non-empty list replaces db-init → migrate; without them the schema is never created and the app exits on start.
container_image_source	custom	Critical	prebuilt deploys the stock image without the wrapper entrypoint — no INVENTREE_DB_* mapping, so InvenTree cannot reach MySQL.
application_version	an exact tag	Medium	Pin it on this variant; a pin set only in InvenTree_Common is overridden.
cpu_always_allocated / enable_background_worker	true / true	Medium	With request-based CPU the worker is frozen between requests; without the sidecar no background tasks run. Both fail silently.
min_instance_count	1 for production	Medium	At 0 there is no instance, and so no background worker, while idle; the first request after idle waits for a cold start.
database_password_length	Set once	High	Changing it on a running deployment rotates the password without updating the database user; every connection then fails until db-init is re-run.
enable_cloud_armor	enable for production	Medium	The service is publicly reachable without WAF protection by default.

---

For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_CloudRun. InvenTree-specific application configuration is described in InvenTree_Common.

Related guides

• Hands-on lab: InvenTree on Cloud Run — deploy it step by step, with the console screens and commands at each stage.
• InvenTree Common — Shared Application Configuration — the application layer this module builds on.
