Loki on GKE Autopilot

Loki on GKE Autopilot

Grafana Loki is a horizontally-scalable, highly-available log aggregation system — often described as "Prometheus for logs." Unlike full-text log indexers, Loki indexes only a small set of labels per log stream rather than the full text of every line, which keeps storage and operating costs low. It is normally queried with LogQL through Grafana (as a datasource) or the LogCLI tool, with an agent such as Promtail or Grafana Alloy shipping logs into it. This module deploys Loki itself, not Grafana, on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services Loki uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

1. Overview​

Loki runs as a single Go binary pod, in monolithic mode (-target=all, Loki's default, which runs every internal component — distributor, ingester, querier, compactor — in one process). The deployment wires together a narrow, GCS-centric set of Google Cloud services:

CapabilityGoogle Cloud serviceNotes
ComputeGKE AutopilotGo binary pod, 1 vCPU / 512Mi by default, Deployment workload type
Object storageCloud StorageA single storage bucket — Loki's actual object-storage backend for chunks and the shipped TSDB index, not incidental file storage
SecretsSecret ManagerNone generated — Loki_Common declares secret_ids = {}
IngressCloud Load Balancingservice_type = "LoadBalancer" by default; optional custom domain + static IP

Sensible defaults worth knowing up front:

  • No database, no Redis. Loki's durable state (chunks, TSDB index) lives entirely in a GCS bucket. database_type = "NONE" and enable_redis has no effect on Loki's own config.
  • max_instance_count is effectively pinned to 1. Loki_Common overrides max_instance_count = 1 in the config it hands to App_GKE, regardless of the value passed in. Loki's compactor (retention/deletion) is a true singleton and the baked config uses an in-memory ring (common.ring.kvstore.store: inmemory) with replication_factor: 1, which cannot coordinate across multiple replicas.
  • Single-tenant, no auth. The baked config sets auth_enabled: false. There is no per-tenant isolation and no built-in authentication — Loki's HTTP API is reachable by anyone who can reach the LoadBalancer IP, subject to service_type/ingress configuration.
  • workload_type = "Deployment", not "StatefulSet". Loki's durable state is GCS, not local disk, so a per-pod block PVC is not required for correctness (a StatefulSet option exists via stateful_pvc_enabled for local index-cache durability, but is not the default).
  • service_type = "LoadBalancer" exposes Loki externally by default, so log-shipping clients outside the cluster (or even outside the project) can reach it. Set reserve_static_ip = true (the default) for a stable address across redeploys.
  • Config-file driven, not env-var driven. Loki's storage/schema settings live entirely in a config file baked into the image; only the GCS bucket name is templated in at pod start via the LOKI_GCS_BUCKET environment variable.
  • No init jobs. initialization_jobs defaults to [] — Loki has nothing to bootstrap.
  • Custom-built, distroless-based image. See §4 and §7 for why the Dockerfile in this module looks unusual.

2. Google Cloud Services & How to Explore Them​

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the Loki workload​

Loki runs as a single pod on Autopilot, deployed as a Deployment by default. Because max_instance_count is effectively pinned to 1, this workload does not horizontally fan out — its "scaling" is really about resource sizing (cpu_limit, memory_limit), not replica count.

  • Console: Kubernetes Engine → Workloads → select the Loki workload for pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
  • CLI:
    kubectl get pods,svc -n "$NAMESPACE"
    kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. Cloud Storage — Loki's object storage backend​

A dedicated storage GCS bucket is Loki's actual storage backend, not an optional extra. Loki writes compressed log chunks and the shipped TSDB index shards into it directly via its native gcs storage client (Application Default Credentials — the GKE Workload Identity SA is granted roles/storage.objectAdmin on the bucket).

  • Console: Cloud Storage → Buckets → select the storage bucket.
  • CLI:
    gcloud storage buckets list --project "$PROJECT" --filter="name~storage"
    gcloud storage ls gs://<storage-bucket>/                 # top-level layout
    gcloud storage ls gs://<storage-bucket>/index_*/          # TSDB index shards (schema prefix "index_")
    gcloud storage du -s gs://<storage-bucket>/                # total bytes stored
    Chunk objects and index shards accumulate under the bucket root and index_* prefixes respectively, per the schema_config baked into the image (schema: v13, index.prefix: index_, index.period: 24h).

See App_GKE for CMEK options and GCS Fuse mounts (not used by Loki's own storage path, which is native GCS API access, not a mounted filesystem).

C. Secret Manager​

No secrets are generated for Loki — Loki_Common declares secret_ids = {} and secret_values = {}. Any secrets you add via secret_environment_variables are your own operator-supplied values (e.g. if you front Loki with a reverse-proxy auth layer).

  • Console: Security → Secret Manager.
  • CLI:
    gcloud secrets list --project "$PROJECT"

D. Networking & ingress​

By default the workload is exposed through an external LoadBalancer Service IP (service_type = "LoadBalancer"), so log-shipping clients outside the cluster can push logs in. A custom domain with a Google-managed certificate can be enabled, and reserve_static_ip = true (the default) keeps the address stable across redeploys.

  • Console: Network services → Load balancing; VPC network → IP addresses.
  • CLI:
    kubectl get svc -n "$NAMESPACE"
    gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

E. Cloud Logging & Monitoring​

Pod stdout/stderr (Loki's own process logs, not the logs it ingests) flow to Cloud Logging; GKE metrics flow to Cloud Monitoring.

  • Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
  • CLI:
    gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
      --project "$PROJECT" --limit 50

3. Querying Loki​

This module deploys Loki with no built-in web UI — Loki is a headend for logs, queried through LogQL. Two common ways to query it once deployed:

  • logcli (Grafana's official CLI), pointed at the external service address:
    export LOKI_ADDR="http://<external-ip>:3100"
    logcli labels                                             # discover available labels
    logcli query '{job="myapp"}' --limit=50                   # LogQL query
  • Direct HTTP against the query API:
    curl -s "http://<external-ip>:3100/loki/api/v1/query?query=%7Bjob%3D%22myapp%22%7D" | jq .
  • As a Grafana datasource — add a Loki datasource in Grafana pointing at the external LoadBalancer address; this is the normal production pattern for exploring and dashboarding ingested logs.

4. Loki Application Behaviour​

  • Config templating at pod start, not database migrations. Loki_Common bakes a config template into the image with a single placeholder, __LOKI_GCS_BUCKET__. The container entrypoint substitutes the real bucket name (injected as the LOKI_GCS_BUCKET env var) with sed and writes the result to /etc/loki/local-config.yaml before Loki starts — there is no first-boot schema step to wait on.
  • No init jobs needed. Loki has no database to bootstrap, so initialization_jobs is empty by default and this module never injects one.
  • Health path is /ready. Both the startup and liveness probes target Loki's built-in, unauthenticated readiness endpoint, which returns HTTP 200 once the server is listening — typically within seconds.
  • Monolithic mode. -target=all runs every Loki component in the single process — the right shape for a small/medium single-tenant deployment.
  • Single-instance scaling constraint. The in-memory ring and singleton compactor mean Loki here is not designed to run more than one instance concurrently. Loki_Common enforces this by pinning max_instance_count = 1 in the config it passes to the Foundation, regardless of what the platform input is set to.
  • workload_type and durability. Deployment is the default and is sufficient — Loki's durable state is GCS, not local disk. A StatefulSet with stateful_pvc_enabled = true (mounted at /var/cache/loki) exists as an option for local index-cache/compactor-scratch durability across pod restarts, but is not required for correctness.
  • Retention. The baked config sets limits_config.retention_period: 720h (30 days) with the compactor performing deletion (retention_enabled: true, delete_request_store: gcs).
  • Inspect the running pod's environment (e.g. to confirm the bucket actually injected):
    kubectl exec -n "$NAMESPACE" deploy/<service-name> -- env | grep LOKI_GCS_BUCKET

5. Configuration Variables​

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Loki are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 1 — Project & Identity​

VariableDefaultDescription
project_id(required)Target Google Cloud project.
regionus-central1Region for the workload and regional resources.

Group 3 — Application Identity​

VariableDefaultDescription
application_namelokiBase name for resources. Do not change after first deploy.
application_versionlatest"latest" resolves to the pinned LOKI_VERSION build ARG (3.6.12) — not the generic APP_VERSION, which the Foundation would otherwise force to a non-existent latest Loki tag.

Group 4 — Runtime & Scaling​

VariableDefaultDescription
min_instance_count / max_instance_count1 / 1max_instance_count is overridden to 1 by Loki_Common regardless of this value — see §1.
container_port3100Loki's HTTP listener port — fixed by the baked config (server.http_listen_port). Changing this without also changing the config template will break the deployment.
container_resources{ cpu_limit="1000m", memory_limit="512Mi" }Raise memory for high-cardinality label sets or heavy query load.
enable_cloudsql_volumefalseOff — Loki has no database.

Group 6 — GKE Cluster​

VariableDefaultDescription
service_typeLoadBalancerExternal exposure is the default — required for log-shipping clients outside the cluster.
workload_typeDeploymentSufficient since Loki's durable state is GCS, not local disk.
session_affinityNoneNo pod stickiness needed at the single-replica default scale.

Group 7 — StatefulSet​

VariableDefaultDescription
stateful_pvc_enablednull (off)Optional: switch to a per-pod block PVC (mount at /var/cache/loki) for local index-cache durability across restarts. Not required — Loki's durable state is GCS.

Group 11 — Workload Automation​

VariableDefaultDescription
initialization_jobs[]Loki needs no init job.

Group 14 — Cloud Storage​

VariableDefaultDescription
storage_buckets[]Additional buckets beyond the auto-provisioned storage bucket Loki actually uses for chunks/index.

Group 15 — Redis Cache​

VariableDefaultDescription
enable_redisfalseLoki has no built-in use for Redis; this exists only for Foundation-mirroring completeness.

Group 16 — Database Configuration​

VariableDefaultDescription
database_typeNONEFixed — Loki's durable storage is the GCS bucket, not Cloud SQL. All other Group 16 database variables are inert.

Group 19 — Custom Domain & Networking​

VariableDefaultDescription
reserve_static_iptrueKeeps the LoadBalancer address stable across redeploys — recommended when external clients hard-code the Loki push endpoint.

All other inputs follow standard App_GKE behaviour.

6. Outputs​

Returned on a successful deployment — the quickest way to locate and explore the running resources.

OutputDescription
service_nameKubernetes Service name.
namespaceNamespace the workload runs in.
service_external_ipExternal LoadBalancer IP (when a static IP is reserved).
service_urlURL to reach Loki.
storage_bucketsCreated storage buckets — includes the storage bucket Loki uses for chunks and the TSDB index.
database_instance_name / database_name / database_user / database_password_secretAlways empty — database_type = "NONE".
container_image / container_registryDeployed image and Artifact Registry repo.
network_name / network_exists / regionsVPC network, presence, available regions.
monitoring_enabled / monitoring_notification_channelsMonitoring status and channels.
initialization_jobsAlways empty — Loki needs no init job.
deployment_id / tenant_id / resource_prefixNaming identifiers.
project_id / project_numberProject identifiers.
kubernetes_readyWhether the cluster/workload is ready.
cicd_enabled / cicd_configurationCI/CD status and details.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_modeVPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabledAudit logging and CMEK status.

7. Configuration Pitfalls & Sensible Defaults​

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Note for operators/maintainers: why the Dockerfile in this module looks unusual. The official grafana/loki image is genuinely distroless — inspecting its filesystem shows only /usr/bin/loki, with no shell, no coreutils, and no dynamic linker at all. A standard Dockerfile pattern (RUN chmod +x /entrypoint.sh) fails outright at build time (exec: /bin/sh: no such file or directory) because RUN needs a shell. The first fix attempt — grafting a busybox binary from the default busybox:stable tag via a multi-stage COPY — also failed, with the more confusing error exec /bin/busybox: no such file or directory, because busybox:stable's binary is dynamically linked and the distroless target has no dynamic linker to satisfy it. The fix was to switch to busybox:musl, verified via file to be genuinely statically linked (no interpreter needed): FROM busybox:musl AS busybox in a build-only stage, COPY --from=busybox /bin/busybox /bin/busybox into the final distroless-based image, and ENTRYPOINT ["/bin/busybox", "sh", "/entrypoint.sh"] (busybox invoked directly by absolute path — no applet symlinks exist, so even the entrypoint script itself calls /bin/busybox sed ... rather than a bare sed). If you ever touch this Dockerfile, or clone it for another distroless-based application on GKE, remember: verify a grafted busybox tag is genuinely static (file <binary> should show no interpreter / dynamically linked) before assuming it will run inside a distroless target.

SettingSensible valueRiskConsequence if wrong
max_instance_countLeave at default (effectively pinned to 1)CriticalEven though Loki_Common overrides this to 1 in the config it passes to the Foundation, don't rely on scaling Loki horizontally in this deployment shape — the in-memory ring and singleton compactor are not designed for concurrent replicas.
container_port3100 (do not change without also editing the config template)CriticalLoki's server.http_listen_port is baked into the config file, not read from container_port at runtime — mismatching them breaks routing between the Kubernetes Service and the pod.
service_typeLoadBalancer for external log-shippingHighSetting ClusterIP makes Loki reachable only from inside the cluster, blocking Promtail/Alloy agents running elsewhere.
Access controlNone by default (auth_enabled: false)HighLoki's HTTP API (push and query) has no built-in authentication. Anyone who can reach the external IP can push or query logs. Front it with Cloud Armor, IAP, or a reverse-proxy auth layer if this matters for your deployment.
application_versionPin an explicit tag (e.g. 3.6.12) for productionMedium"latest" silently resolves to whatever tag Loki_Common's Dockerfile currently pins, which changes only when the module source changes.
container_resources.memory_limitRaise above 512Mi for high-cardinality labels or heavy query loadMediumLoki's query engine and in-memory index cache can OOM under load with the conservative default.
reserve_static_iptrueMediumWith false, the external IP can change on redeploy and (per the fleet-wide GKE finding documented for other modules) GKE_SERVICE_URL-style self-referencing values can fall back to an unreachable internal DNS name if computed before the ephemeral LoadBalancer IP is known.
database_typeLeave at NONELowSetting anything else has no effect — Loki_Common never wires a database connection into Loki's config regardless.

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Loki-specific application configuration shared with the Cloud Run variant is described in Loki_Common.
