GoAlert on GKE Autopilot

GoAlert on GKE Autopilot

GoAlert is an open-source, Apache 2.0-licensed on-call scheduling and incident alert-escalation platform, originally built by Target and run in production at scale. It lets teams define escalation policies, on-call rotations and schedules, and dispatch outbound notifications by email, webhook, or (optionally) Twilio SMS/voice. This module deploys GoAlert on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services GoAlert uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

1. Overview​

GoAlert runs as a single Go binary pod on GKE Autopilot. The deployment wires together a focused set of Google Cloud services:

CapabilityGoogle Cloud serviceNotes
ComputeGKE AutopilotGo binary pod, 1 vCPU / 512 MiB by default, min_instance_count = 1, max_instance_count = 1
DatabaseCloud SQL for PostgreSQL (POSTGRES_17)Required — GoAlert does not support MySQL or other engines; pgcrypto extension installed automatically
SecretsSecret ManagerAuto-generated admin password and a data-encryption key; database password managed by the foundation
IngressCloud Load BalancingExternal LoadBalancer Service by default, optional custom domain + managed certificate

There is no object storage row in this table — GoAlert_Common's storage_buckets output is always []. GoAlert has no file-upload/attachment feature; every piece of application state (escalation policies, schedules, alerts, notification history, users) lives in PostgreSQL.

Sensible defaults worth knowing up front:

  • PostgreSQL is mandatory. database_type = "POSTGRES_17" is fixed by GoAlert_Common; selecting any other engine breaks startup.
  • application_database_name / application_database_user default to "admin", not "goalert". This variant wires db_name/db_user in GoAlert_Common from the generic App_GKE-level application_database_name / application_database_user variables, whose module-level defaults are "admin" — inconsistent with the Cloud Run variant's db_name/db_user variables (default "goalert"). Cosmetic, but worth knowing before you go looking in Cloud SQL for a database named goalert.
  • A single, always-warm pod. min_instance_count = 1, max_instance_count = 1 — GoAlert runs a continuous in-process "engine" loop that evaluates escalation-policy timing, rotation state, and outbound notification dispatch; there is no scale-to-zero concept on GKE in this module, and a single instance matches GoAlert's own recommendation against running multiple default-mode engine instances without a --api-only topology this module doesn't wire.
  • No Redis, no object storage. GoAlert's state lives entirely in PostgreSQL; it needs no external cache, queue, or file storage.
  • GOALERT_DB_URL is assembled at container start, not at plan time. GoAlert accepts only a single Postgres connection-string env var, and the runtime Secret-Manager-sourced DB_PASSWORD can't be URL-encoded until the container actually starts — entrypoint.sh (and each init-job script) builds it from the discrete DB_* values the Foundation injects, branching on whether the resolved host is the cloud-sql-proxy loopback (127.0.0.1, no TLS) or a real socket/IP.
  • public_url has no auto-computed default on GKE. Unlike GoAlert_CloudRun, this module passes public_url = var.public_url straight through with no fallback computation — leave it empty and GOALERT_PUBLIC_URL falls back to GoAlert's own http://localhost:8081, breaking OIDC callbacks and links in outgoing notifications. Set it explicitly once the external LoadBalancer IP or custom domain is known.

2. Google Cloud Services & How to Explore Them​

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the GoAlert workload​

GoAlert runs as a single always-on pod on Autopilot (min = max = 1), which bills for the CPU/memory the pod actually requests.

  • Console: Kubernetes Engine → Workloads → select the GoAlert workload to see pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
  • CLI:
    kubectl get pods,svc -n "$NAMESPACE"
    kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100

See App_GKE for how Autopilot and the workload type (Deployment vs StatefulSet) are managed.

B. Cloud SQL for PostgreSQL​

GoAlert stores all application data — escalation policies, schedules, rotations, alerts, notification history, and users — in a managed Cloud SQL PostgreSQL instance. Pods reach it privately through the Cloud SQL Auth Proxy sidecar over a loopback TCP connection (127.0.0.1); entrypoint.sh detects this and skips the Unix-socket branch used on Cloud Run.

  • Console: SQL → select the instance for connections, backups, flags, and metrics.
  • CLI:
    gcloud sql instances list --project "$PROJECT"
    gcloud sql instances describe <instance-name> --project "$PROJECT"
    gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"

The instance name, database name, user, and the Secret Manager secret holding the password are all surfaced in the Outputs. See App_GKE for the connection model, automated backups, and password rotation.

C. Secret Manager​

Two secrets are generated automatically by GoAlert_Common and stored in Secret Manager: the admin password (consumed by the admin-bootstrap init job) and a data-encryption key (recommended by upstream GoAlert docs). The database password is managed separately by the foundation.

  • Console: Security → Secret Manager.
  • CLI:
    gcloud secrets list --project "$PROJECT" --filter="name~goalert"
    gcloud secrets versions access latest --secret=<admin-password-secret-id> --project "$PROJECT"

D. Networking & ingress​

By default the workload is exposed through an external Cloud Load Balancing IP (service_type = LoadBalancer). A custom domain with a Google-managed certificate can be enabled, and a static IP can be reserved so the address survives redeploys.

  • Console: Network services → Load balancing; VPC network → IP addresses.
  • CLI:
    kubectl get svc -n "$NAMESPACE"
    gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

E. Cloud Logging & Monitoring​

Pod stdout/stderr flow to Cloud Logging; GKE and Cloud SQL metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.

  • Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
  • CLI:
    gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
      --project "$PROJECT" --limit 50

3. GoAlert Application Behaviour​

  • The 3-stage initialization job chain is load-bearing. GoAlert_Common defines three ordered Kubernetes Jobs, each depending on the one before it, all with execute_on_apply = true:

    1. db-init (postgres:15-alpine) — creates the PostgreSQL role and database.
    2. db-migrate (goalert/goalert:<version>, depends_on_jobs = ["db-init"]) — runs goalert migrate --db-url=..., applying GoAlert's own schema. This must run before admin-bootstrap: goalert add-user has no migration logic of its own, and on a fresh database it fails with relation "auth_basic_users" does not exist.
    3. admin-bootstrap (goalert/goalert:<version>, depends_on_jobs = ["db-migrate"]) — runs goalert add-user --admin directly against Postgres to create the first admin login.

    On GKE, execute_on_apply = false only stops Terraform from waiting for a job to finish — the underlying Kubernetes Job/pod is still created and scheduled immediately either way. Correctness here relies on depends_on_jobs (App_GKE's 3-tier job dependency system), not on apply-time sequencing. All three scripts also retry internally (up to 10 attempts, 5s apart) to absorb Cloud SQL/scheduling latency.

  • No first-visit setup wizard. GoAlert has no web-based initial-admin flow — the admin-bootstrap job is the only way an admin account gets created. Retrieve the generated password:

    gcloud secrets versions access latest --secret=<admin_password_secret_id output>

  • Health endpoint. /health is GoAlert's documented public, unauthenticated endpoint (200 once the app lifecycle leaves the "Starting" state). This module's startup and liveness probes default to a TCP port check rather than an HTTP path check — Kubernetes supports tcpSocket for both probe types (unlike Cloud Run, which forbids a TCP liveness probe) — and both proved correct on live verification (HTTP 200 on /health with real "listening and serving HTTP" log lines).

  • Inspect job execution:

    kubectl get jobs -n "$NAMESPACE"
    kubectl logs -n "$NAMESPACE" job/<job-name>

4. Configuration Variables​

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for GoAlert are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 1 — Project & Identity​

VariableDefaultDescription
project_id(required)Target Google Cloud project.
regionus-central1Region for the workload and regional resources.

Group 2 — Deployment Environment​

VariableDefaultDescription
tenant_deployment_iddemoShort suffix that makes resource names unique per environment. Use a distinct value (e.g. gke) from any co-deployed GoAlert_CloudRun (cr) to avoid a naming collision.
support_users[]Emails granted project access and monitoring alerts.
resource_labels{}Labels applied to all resources.

Group 3 — Application & Database Identity​

VariableDefaultDescription
application_namegoalertBase name for resources. Do not change after first deploy.
application_display_nameGoAlertHuman-readable name shown in the Console.
application_versionlatestImage tag. "latest" maps to a pinned Dockerfile build arg (GOALERT_VERSION = v0.34.1).
admin_usernameadminUsername created by the admin-bootstrap init job.
admin_emailadmin@techequity.cloudEmail for the initial admin account.
public_url""No auto-computed default on GKE. Set explicitly once the external LoadBalancer IP or custom domain is known.

Group 4 — Runtime & Scaling​

VariableDefaultDescription
deploy_applicationtrueSet false to provision infrastructure only.
container_resources{ cpu_limit="1000m", memory_limit="512Mi" }CPU/memory requests and limits.
container_port8081GoAlert's native HTTP port.
min_instance_count1Minimum pod replicas.
max_instance_count1Single default-mode engine instance; multi-instance needs a --api-only topology this module doesn't wire.
enable_cloudsql_volumetrueCloud SQL Auth Proxy sidecar.
enable_image_mirroringtrueMirrors the GoAlert base image into Artifact Registry.

Group 9 — GKE Backend Configuration​

VariableDefaultDescription
service_typeLoadBalancerHow the Kubernetes Service is exposed.
workload_typenull (resolves to Deployment)"Deployment" or "StatefulSet".
session_affinityClientIPSession affinity for the Kubernetes Service.
namespace_name"" (auto-generated)Kubernetes namespace.

Group 16/17 — Database Configuration​

VariableDefaultDescription
database_typePOSTGRES_17Cloud SQL engine. GoAlert requires PostgreSQL.
application_database_nameadminPostgreSQL database name — see the naming-inconsistency note in Overview.
application_database_useradminPostgreSQL application user.
database_password_length32Generated password length (16–64).

Group 11/12 — Workload Automation​

VariableDefaultDescription
initialization_jobs[]Leave empty for GoAlert_Common's default 3-job chain (db-init → db-migrate → admin-bootstrap).
cron_jobs[]GoAlert has no platform-scheduled recurring tasks by default.

Group 22 — Observability & Health​

VariableDefaultDescription
startup_probe_configTCP, 30s delay, 30 retriesAccommodates first-boot migration latency (db-migrate).
health_check_configTCP, 30s delay, 3 retriesKubernetes liveness probe.
uptime_check_config{ enabled=false, path="/health" }Cloud Monitoring uptime check.

Group 15 — Redis​

VariableDefaultDescription
enable_redisfalseNot required by GoAlert; present for platform compatibility.

Group 19 — Custom Domain, Static IP & Networking​

VariableDefaultDescription
enable_custom_domaintrueProvision Ingress for custom hostnames.
reserve_static_iptrueReserve a stable global static IP for the load balancer — recommended so public_url doesn't need to change after every redeploy.

Every other input (Module Metadata, Environment Variables & Secrets, CI/CD & GitHub Integration, Custom SQL, Storage & Filesystem, IAP & Cloud Armor, StatefulSet Configuration, VPC Service Controls, Reliability Policies) is inherited from App_GKE with its standard behaviour — see App_GKE for the full, group-organized list.

5. Outputs​

Returned on a successful deployment — the quickest way to locate and explore the running resources.

OutputDescription
service_nameKubernetes Service name.
namespaceNamespace the workload runs in.
service_cluster_ip / service_external_ipIn-cluster ClusterIP / external LoadBalancer IP.
service_urlURL to reach GoAlert.
database_instance_nameCloud SQL instance name.
database_name / database_userApplication database name / user.
database_password_secretSecret Manager secret holding the DB password.
database_host / database_portDB endpoint (127.0.0.1 via the Auth Proxy sidecar) / port.
storage_bucketsAlways [] — GoAlert provisions no storage buckets.
container_imageDeployed image.
initialization_jobsNames of the created init jobs (db-init, db-migrate, admin-bootstrap).
kubernetes_readyWhether the cluster endpoint is available and all workload resources are deployed. false on the first apply of a new inline cluster — a re-run completes the deployment.
deployment_id / tenant_id / resource_prefixNaming identifiers.
project_id / project_numberProject identifiers.

6. Configuration Pitfalls & Sensible Defaults​

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time. Invalid configuration fails the plan with a clear, named error before any resource is created.

SettingSensible valueRiskConsequence if wrong
database_typePOSTGRES_17CriticalAny other engine breaks GoAlert's schema and startup entirely — pgcrypto and the whole goalert migrate flow are Postgres-specific.
initialization_jobs order (db-init → db-migrate → admin-bootstrap)Leave [] unless you fully understand the dependency chainCriticalRunning admin-bootstrap before db-migrate fails with relation "auth_basic_users" does not exist on a fresh database — goalert add-user has no migration logic of its own. On GKE, execute_on_apply=false does NOT delay pod scheduling, only Terraform's wait — the ordering guarantee comes entirely from depends_on_jobs.
public_urlSet explicitly once the LoadBalancer IP/domain is knownHighThis module does not auto-compute a service URL (unlike the Cloud Run variant) — an unset public_url falls back to GoAlert's own http://localhost:8081, breaking OIDC auth callbacks and every link in outgoing notification emails.
min_instance_count1HighGoAlert's escalation-timing engine is a continuous in-process loop — at zero replicas, escalations for real alerts are silently missed entirely.
application_database_name / application_database_userConfirm actual values (admin/admin by default, not goalert)MediumLooking for a database literally named goalert in Cloud SQL will not find it under this variant's defaults.
enable_cloudsql_volumetrueHighThe Auth Proxy sidecar is required for PostgreSQL connectivity on GKE.
reserve_static_iptrueMediumWithout a reserved static IP, the external LoadBalancer address can change across redeploys, breaking any public_url you've configured.
admin_username / admin_emailSet once, retrieve password from Secret ManagerMediumGoAlert has no self-service password reset flow visible from Terraform; losing track of the bootstrapped admin credential means using the goalert CLI directly against the database to create a new one.
max_instance_count1 unless you wire a --api-only topologyMediumGoAlert supports multiple engine instances safely (not a double-fire bug per upstream docs), but this module has no built-in mechanism to designate --api-only replicas.

For the foundation behaviour referenced throughout — Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. GoAlert-specific application configuration shared with the Cloud Run variant is described in GoAlert_Common.
