Gatus on GKE Autopilot

Gatus is an open-source, Apache 2.0-licensed developer-oriented status page and health-check monitor written in Go. It polls configured HTTP, TCP, DNS, ICMP, and other endpoints on independent per-endpoint schedules, evaluates simple result conditions (status code, response time, response body content, TLS certificate expiry), and serves a live public status page plus alerting — no external database required. This module deploys Gatus on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services Gatus uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

1. Overview

Gatus runs as a single Go web workload. The deployment wires together a deliberately small set of Google Cloud services — Gatus has no database, cache, or object-storage dependency of its own:

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	Single Go Deployment, 1 vCPU / 512 MiB by default
Database	None	database_type = "NONE"; optional history store is a local SQLite file, no Cloud SQL provisioned
Persistence	Ephemeral disk (default), NFS, or block PVC (StatefulSet)	SQLite history at /data/data.db; block PVC is the only option verified safe for Gatus's WAL-mode SQLite (see below)
Object storage	None	Gatus stores nothing in Cloud Storage
Cache / queue	None	No Redis; Gatus has no cache or queue dependency
Secrets	Secret Manager	No auto-generated secrets; only user-supplied secret_environment_variables
Ingress	Cloud Load Balancing	External LoadBalancer Service; optional custom domain + managed certificate

Sensible defaults worth knowing up front:

• No database is provisioned. database_type = "NONE" — Gatus's optional history store is a local SQLite file. The database-related variables exist for completeness but are inert unless you deliberately opt in to an external database.
• Configuration is entirely file-based. Every monitored endpoint, alert integration, and storage setting lives in one YAML file baked into the image at build time — there is no per-setting environment variable convention and no runtime config-reload API. Change monitored endpoints by editing modules/Gatus_Common/scripts/config.yaml and redeploying.
• Stateless Deployment by default, with the ONE genuinely safe durability option in this catalogue. workload_type = "Deployment" with an ephemeral SQLite history store at /data/data.db. Gatus hardcodes SQLite WAL journal mode (confirmed live: no config option disables it), and SQLite's own documentation states WAL is unsupported on network filesystems — so NFS carries a real corruption risk here. GKE's stateful_pvc_enabled = true (a real block device, not gcsfuse) is the recommended path for durable history: pair it with stateful_pvc_storage_class = "standard" (HDD; Gatus's history needs no SSD IOPS, and HDD avoids the tight regional SSD_TOTAL_GB quota).
• Single replica by default (min_instance_count = 1, max_instance_count = 1). Multiple replicas would each independently poll every endpoint and duplicate alerts — there is no shared coordination between Gatus instances.
• Exposed via a LoadBalancer Service (service_type = "LoadBalancer") so the status page is reachable from outside the cluster; reserve_static_ip and enable_custom_domain both default to false since Gatus bakes no self-referencing URL into its config at boot — enable either only if you need a stable IP or a custom hostname.
• The health endpoint is /health, which returns HTTP 200 as soon as the server binds its port.
• To run alongside Gatus_CloudRun on the same tenant, set tenant_deployment_id = "gke" (and "cr" on the Cloud Run variant) — see the recommendation in config/deploy.tfvars. This avoids a naming collision on shared secret names, GCS bucket names, and rotation topics.
• Access control, if any, is configured in config.yaml. Gatus ships with an open status page by default; optional basic-auth or OIDC protection is configured in the security block of config.yaml and requires a rebuild.

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the Gatus workload

Gatus pods are scheduled on Autopilot, which bills for the CPU/memory the pods actually request. By default the workload is a stateless Deployment with a single replica; switching to a StatefulSet provisions a per-pod block PVC for durable check history.

• Console: Kubernetes Engine → Workloads → select the Gatus workload to see pods and events. Kubernetes Engine → Services & Ingress shows the external IP.
• CLI:

  kubectl get pods,svc -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100
  kubectl get statefulset -n "$NAMESPACE"          # when stateful_pvc_enabled = true

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. Persistence — the SQLite history store

Gatus has no Cloud SQL instance. Its optional history store is a local SQLite file at /data/data.db, baked into the image's directory structure. With the default stateless Deployment this directory is ephemeral — history does not survive a pod restart.

• StatefulSet block PVC (recommended for durable history): stateful_pvc_enabled = true with stateful_pvc_mount_path = "/data" and stateful_pvc_storage_class = "standard" — a per-pod real block device holds the history database. This is the only persistence option in this catalogue verified safe for Gatus's WAL-mode SQLite file.

• NFS (Filestore) — use with caution: enable_nfs = true mounts at /data, but carries the WAL-on-network-filesystem risk described in §1.

• Console: Filestore → Instances (NFS); Kubernetes Engine → Storage → PersistentVolumeClaims (block PVC).

• CLI:

  kubectl get pvc -n "$NAMESPACE"                             # StatefulSet PVCs
  kubectl exec -n "$NAMESPACE" <pod> -- ls -l /data           # history store location

See App_GKE for the NFS and StatefulSet PVC models.

C. Secret Manager

Gatus generates no secrets at deploy time — there is no database password or encryption key to manage. Secret Manager is used only if you supply your own via secret_environment_variables (for example a ${VAR} referenced inside config.yaml's alerting configuration).

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT"
  gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"

See App_GKE for the Secret Store CSI integration and rotation.

D. Networking & ingress

By default the workload is exposed through an external Cloud Load Balancing IP via a LoadBalancer Service. A custom domain with a Google-managed certificate and a reserved static IP can both be enabled if needed, but neither is required for correctness since Gatus's config bakes no self-referencing URL.

• Console: Network services → Load balancing; VPC network → IP addresses.
• CLI:

  kubectl get ingress,svc -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

E. Cloud Logging & Monitoring

Pod stdout/stderr flow to Cloud Logging; GKE metrics flow to Cloud Monitoring. Optional uptime checks and alert policies are available. Gatus logs each endpoint check's result (success/failure, duration) as it runs.

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. Gatus Application Behaviour

• No first-deploy database setup. Gatus has no external database and no migration step. It reads config.yaml, initialises its SQLite history store (if configured), and starts serving immediately. There is no init job by default.
• Persistence depends on the workload type. A stateless Deployment uses an ephemeral history store; a StatefulSet with a block PVC makes it durable across pod restarts.
• imagePullPolicy = Always for the custom image. App_GKE sets this for custom-built/mirrored images so a rebuild-and-redeploy under an unchanged tag pulls the new layers rather than serving a stale node cache.
• Health path. Startup and liveness probes target /health, which returns HTTP 200 as soon as the server binds port 8080. Verify from inside the cluster:

  kubectl run curl --rm -it --image=curlimages/curl -n "$NAMESPACE" -- \
    curl -s -o /dev/null -w '%{http_code}\n' http://<service-name>.$NAMESPACE.svc.cluster.local/health

• View the status page (against the external IP):

  EXTERNAL_IP=$(kubectl get svc <service-name> -n "$NAMESPACE" \
    -o jsonpath='{.status.loadBalancer.ingress[0].ip}')
  curl -s "http://$EXTERNAL_IP/" | head -20

• Configuration changes require a rebuild. Gatus has no admin UI or API for editing monitored endpoints. Edit modules/Gatus_Common/scripts/config.yaml (add, remove, or modify endpoints entries) and redeploy to apply changes.
• Access is open until you configure it. By default the status page has no authentication. Configure basic-auth or OIDC in config.yaml's security block and redeploy to restrict viewing.

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Gatus are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 1 — Project & Identity

Variable	Default	Description
project_id	(required)	Target Google Cloud project.
region	us-central1	Region for the workload and regional resources.

Group 2 / 3 — Deployment Environment & Application Identity

Variable	Default	Description
tenant_deployment_id	demo	Short suffix; set "gke" to coexist with a Gatus_CloudRun deployment on the same tenant (see config/deploy.tfvars).
application_name	gatus	Base name for resources. Do not change after first deploy.
application_version	latest	Image version tag; latest maps to a pinned v5.36.0 base. Pin v5.x.y in production.

Group 4 — Runtime & Scaling

Variable	Default	Description
deploy_application	true	Set false to provision infrastructure only.
container_image_source	custom	custom builds the wrapper image via Cloud Build; prebuilt deploys an image directly.
min_instance_count	1	Minimum replicas (GKE has no scale-to-zero).
max_instance_count	1	Keep at 1 — replicas would each independently poll every endpoint and duplicate alerts.
container_resources	{ cpu_limit="1000m", memory_limit="512Mi" }	Per-pod CPU/memory.
container_port	8080	Gatus listens on port 8080.
container_protocol	http1	HTTP/1.1 by default.
workload_type	Deployment	Stateless default; StatefulSet for a durable per-pod PVC.
enable_cloudsql_volume	false	Off — Gatus has no database.
enable_image_mirroring	true	Mirror the Gatus image into Artifact Registry.

Group 5 — Identity-Aware Proxy (IAP)

Variable	Default	Description
enable_iap	false	Require Google sign-in. Blocks unauthenticated viewing. Needs iap_oauth_client_id / _secret.

Group 6 — Environment Variables & Secrets

Variable	Default	Description
environment_variables	{}	Substitutions for ${VAR}-style references inside config.yaml, not per-setting overrides.
secret_environment_variables	{}	Map of env var → Secret Manager secret name (optional; none required).

Group 6 — GKE Cluster

Variable	Default	Description
gke_cluster_name	""	Leave empty to auto-discover the Services_GCP cluster.
service_type	LoadBalancer	Gatus is a public status page, so this defaults to LoadBalancer.
session_affinity	None	Set ClientIP if you scale replicas and want a client pinned.

Group 7 — StatefulSet (durable check history)

Variable	Default	Description
stateful_pvc_enabled	null	Set true for a per-pod block PVC — the only durable option verified safe for Gatus's WAL-mode SQLite history.
stateful_pvc_size	10Gi	Per-pod PVC storage size.
stateful_pvc_mount_path	/data	Mount path; matches the storage.path directory baked into config.yaml.
stateful_pvc_storage_class	standard	HDD by default — Gatus's history store needs no SSD IOPS; avoids the tight SSD_TOTAL_GB quota.

Group 9 — Reliability Policies

Variable	Default	Description
enable_pod_disruption_budget	true	Protect availability during node upgrades.
pdb_min_available	1	Minimum pods available during voluntary disruptions.

Group 10 — Observability & Health

Variable	Default	Description
startup_probe_config	HTTP /health	Startup probe. Gatus becomes healthy within seconds.
health_check_config	HTTP /health	Liveness probe.
uptime_check_config	disabled	Optional Cloud Monitoring uptime check.

Group 13 / 14 — Filesystem & Cloud Storage

Variable	Default	Description
enable_nfs	false	Optional durable history mount. Caution: carries a WAL-on-network-filesystem risk — prefer stateful_pvc_enabled.
nfs_mount_path	/data	NFS mount path; matches Gatus's baked-in storage.path.
storage_buckets	[]	Not required — Gatus uses no object storage.

Group 16 — Database Backend

Variable	Default	Description
database_type	NONE	Gatus has no external database; leave NONE.
application_database_name / application_database_user	gatus	Inert unless an external database is deliberately enabled.

Group 15 — Redis Cache

Variable	Default	Description
enable_redis	false	Not required — Gatus has no Redis dependency.

Group 19 — Custom Domain, Static IP & Networking

Variable	Default	Description
enable_custom_domain	false	Provision an Ingress for a custom hostname + managed certificate. Off by default — the LoadBalancer Service already gives external reachability.
application_domains	[]	Hostnames to serve.
reserve_static_ip	false	Off by default — Gatus bakes no self-referencing URL, so there is no correctness reason to reserve a stable IP.

All other inputs follow standard App_GKE behaviour.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip	In-cluster ClusterIP.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific services.
service_external_ip	External LoadBalancer IP.
service_url	URL to reach Gatus.
database_instance_name / database_name / database_user	Database identifiers — empty for the default NONE engine.
database_password_secret / database_host / database_port	Database endpoint fields — unused for NONE.
storage_buckets	Created Cloud Storage buckets (none by default).
network_name / network_exists / regions	VPC network, presence, available regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
initialization_jobs / db_import_job	Names of any setup and import jobs (none by default).
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / cicd_configuration	CI/CD status and details (repo, trigger, registry).
github_repository_url / github_repository_owner / github_repository_name	CI/CD GitHub details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time — IAP with no OAuth credentials, enable_cloudsql_volume = true with database_type = "NONE", min_instance_count > max_instance_count, quota_memory_* without binary units. The GKE variant's own validation.tf enforces these guards. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Setting	Sensible value	Risk	Consequence if wrong
enable_nfs (for durable history)	Prefer stateful_pvc_enabled instead	Critical	Gatus hardcodes SQLite WAL journal mode, which SQLite's own documentation states is unsupported on network filesystems — NFS-backed history risks silent corruption over time.
stateful_pvc_mount_path	/data	High	Mounting the PVC anywhere other than Gatus's baked-in storage.path directory persists the wrong path and history stays ephemeral.
stateful_pvc_storage_class	standard (HDD)	Medium	The SSD-backed default (standard-rwo) draws down the tight regional SSD_TOTAL_GB quota for a workload that needs no SSD IOPS.
max_instance_count	1	High	Scaling beyond 1 has every replica independently poll every endpoint, duplicating alert notifications with no coordination between instances.
enable_cloudsql_volume	false	High	Setting true with database_type = "NONE" starts an Auth Proxy sidecar with no instance to reach — rejected by the plan-time guard.
enable_iap	only when auth-gated	High	IAP requires Google sign-in for every request, blocking unauthenticated status-page viewing.
min_instance_count	1	High	GKE requires min ≥ 1; the validation guard rejects invalid values, and 0 would leave no pod to serve the status page.
Gatus security block in config.yaml	Configure if the page has sensitive endpoint names	Medium	Left default, the status page (including all configured endpoint names and their up/down history) is publicly visible to anyone with the external IP.
quota_memory_requests / _limits	binary units (4Gi, 8192Mi)	Critical	Bare integers are bytes and block all pod scheduling in the namespace.
enable_pod_disruption_budget	true	Medium	Disabling allows GKE to evict all pods simultaneously during maintenance.
application_version	Pin v5.x.y in prod	Low	latest maps to a pinned base (v5.36.0); pin explicitly to control upgrades.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Gatus-specific application configuration shared with the Cloud Run variant is described in Gatus_Common.
