ActualBudget on GKE Autopilot

Actual Budget is a privacy-first, local-first personal finance application built around zero-based envelope budgeting. The actual-server component is a lightweight Node.js sync server that stores each budget as a SQLite file and synchronises it across the web UI, desktop, and mobile clients. This module deploys ActualBudget on GKE Autopilot as a StatefulSet with a per-pod block PVC, on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services ActualBudget uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

1. Overview

ActualBudget runs as a single Node.js actual-server workload. Because it manages its own SQLite storage, the deployment wires together a deliberately small set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	actual-server pods, 1 vCPU / 1 GiB by default, single replica (min = max = 1) run as a StatefulSet
Database	None	Budgets are SQLite files under /data — database_type = "NONE" is fixed by ActualBudget_Common; no Cloud SQL instance is created
Persistent storage	Kubernetes PVC (per-pod block volume)	stateful_pvc_enabled = true by default — a 20Gi standard-rwo PVC mounted at /data (SQLite needs block storage, not GCS FUSE)
Object storage	Cloud Storage	A storage bucket is always declared by ActualBudget_Common; it only mounts at /data (via GCS FUSE) when the block PVC is disabled
Secrets	Secret Manager	Optional — a 32-character API token (enable_api_key, default false) injected as ACTUAL_TOKEN via a native Kubernetes Secret
Ingress	Kubernetes Service / Gateway API	Defaults to service_type = ClusterIP with enable_custom_domain = true but no domains configured — internal-only until you add a LoadBalancer or a domain

Sensible defaults worth knowing up front:

• StatefulSet + block PVC by default. stateful_pvc_enabled = true auto-resolves workload_type to StatefulSet (no need to set both) and mounts a 20Gi standard-rwo PVC at /data with fsGroup = 3000, matching the ActualBudget Helm chart's convention so the container (UID 1000/GID 2000) can write to the volume. This is deliberately preferred over GCS FUSE because SQLite does not tolerate a FUSE-mounted directory well.
• No database at all. database_type is fixed to NONE by ActualBudget_Common; there is no Cloud SQL instance, no db-init job, and enable_cloudsql_volume defaults false (no Cloud SQL Auth Proxy sidecar).
• Redis is hard-disabled, not just off by default. The variant's main.tf passes enable_redis = false to the App_GKE foundation unconditionally — it does not forward var.enable_redis — so ActualBudget never receives a REDIS_HOST on GKE regardless of how that variable is set.
• Single replica by design. min_instance_count = 1 and max_instance_count = 1 — the server assumes exclusive access to its SQLite files on the shared PVC.
• container_port is fixed at 5006 by ActualBudget_Common regardless of the container_port variable's own value — that variable is inert (its description/validation text references a stale 6333, a harmless copy-paste artifact from another module).
• No admin/secret generation. The server password is set interactively on the first-run onboarding screen — there is no pre-seeded credential to retrieve unless enable_api_key = true generates an ACTUAL_TOKEN.
• Health probes target / — HTTP GET / returns 200 as soon as the Node server is listening, no authentication required.
• Out-of-the-box exposure is internal-only. service_type defaults to ClusterIP (not LoadBalancer, unlike most GKE app modules) and enable_custom_domain defaults to true but application_domains defaults to [] — so a fresh deploy has no reachable external endpoint until you set service_type = LoadBalancer or supply application_domains (plus DNS).

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the ActualBudget StatefulSet

ActualBudget runs as a single-replica StatefulSet, which gives its pod a stable identity (<statefulset-name>-0) and rebinds the same PVC across restarts and updates.

• Console: Kubernetes Engine → Workloads → select the ActualBudget workload for pods, revisions, and events.
• CLI:

  kubectl get statefulset,pods,svc -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" statefulset/<service-name> --tail=100
  kubectl describe pod -n "$NAMESPACE" -l app=<service-name>

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. Persistent Volumes — the /data block PVC

With stateful_pvc_enabled = true (the default), a per-pod PersistentVolumeClaim is provisioned and mounted at /data, where actual-server writes its budget SQLite databases, server files, and user files. The default standard-rwo StorageClass is SSD-backed (Balanced PD) and draws the (often tight) SSD_TOTAL_GB regional quota.

• Console: Kubernetes Engine → Storage → PersistentVolumeClaims.
• CLI:

  kubectl get pvc -n "$NAMESPACE"
  kubectl describe pvc -n "$NAMESPACE"
  kubectl exec -n "$NAMESPACE" statefulset/<service-name> -- df -h /data

C. Cloud Storage — the storage bucket (GCS FUSE fallback)

ActualBudget_Common always declares a Cloud Storage bucket (storage), but it is only mounted at /data via GCS FUSE when the block PVC is disabled (stateful_pvc_enabled = false). With the default StatefulSet PVC in place, this bucket exists but is not mounted.

• Console: Cloud Storage → Buckets.
• CLI:

  gcloud storage buckets list --project "$PROJECT" --filter="name~actualbudget"

See App_GKE for GCS Fuse mount behaviour and CMEK options.

D. Secret Manager — optional API token

By default no secrets are created. When enable_api_key = true, a 32-character random token is generated, stored in Secret Manager as secret-<prefix>-<app>-api-key, and injected into the pod as the ACTUAL_TOKEN environment variable via a native Kubernetes Secret — useful for automations that must call the server before the UI is configured.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~api-key"
  gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"

See App_GKE for the Secret Store CSI integration and rotation.

E. Networking & ingress

The workload defaults to service_type = ClusterIP — no external IP is created out of the box. enable_custom_domain = true provisions a Kubernetes Gateway API resource, but with application_domains = [] by default there are no hostnames to route. Set service_type = LoadBalancer for a direct external IP, or populate application_domains (with DNS pointed at the resulting IP) for a custom-domain Gateway with a managed certificate.

• Console: Kubernetes Engine → Services & Ingress; Network services → Load balancing.
• CLI:

  kubectl get svc,gateway -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

F. Cloud Logging & Monitoring

Pod stdout/stderr flow to Cloud Logging; GKE metrics flow to Cloud Monitoring. An optional uptime check (uptime_check_config, disabled by default) requires a publicly reachable endpoint, which the ClusterIP default does not provide.

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. ActualBudget Application Behaviour

• No initialization job. There is no database to bootstrap; the server creates its SQLite files under /data on first boot. Custom initialization_jobs are accepted for data loading or migration tasks but none is provided by default.
• First-run setup. On first access the web UI shows an onboarding screen where you set the server password — there are no pre-seeded credentials to retrieve. Do this immediately after making the service reachable; until a password is set, anyone who can reach the URL can claim the server.
• Data layout. ACTUAL_SERVER_FILES = /data/server-files (server metadata and the account database) and ACTUAL_USER_FILES = /data/user-files (per-budget sync data), both on the persistent /data mount (PVC by default).
• Local-first sync model. Clients (web, desktop, mobile) keep a full local copy of the budget and use the server only to synchronise encrypted changes between devices — brief server unavailability does not block working in a client.
• Single-writer constraint, safe StatefulSet updates. The server assumes exclusive access to its SQLite files; keep max_instance_count = 1. Because the workload is a StatefulSet with a stable per-pod identity bound to the same PVC, the default RollingUpdate strategy replaces the single pod in place rather than surging a second pod against the shared volume — unlike the Deployment+NFS combinations used by other modules in this repo, there is no double-mount deadlock risk here.
• Probe precedence. startup_probe_config and health_check_config (the generic top-level App_GKE probe variables) are inert for ActualBudget — the effective probe configuration always comes from ActualBudget's own startup_probe / liveness_probe variables (forwarded through ActualBudget_Common's config output), both of which target unauthenticated HTTP GET /.
• Version updates. Change application_version and re-apply — Cloud Build produces a new image and the StatefulSet rolls the new revision. latest builds the pinned 25.7.1 via the app-specific ACTUALBUDGET_VERSION build ARG (not the generic APP_VERSION the foundation injects).
• Health path. Startup probe: HTTP GET /, 15s initial delay, 10s timeout, 10s period, 10 failures allowed. Liveness probe: HTTP GET /, 30s initial delay, 5s timeout, 30s period, 3 failures allowed. Both return 200 unauthenticated as soon as the HTTP server is listening.
• Verification:

  kubectl get statefulset,pods,svc -n "$NAMESPACE"
  POD=$(kubectl get pods -n "$NAMESPACE" -l app=<service-name> -o jsonpath='{.items[0].metadata.name}')
  kubectl port-forward -n "$NAMESPACE" "$POD" 5006:5006 &
  curl -s -o /dev/null -w "%{http_code}\n" http://localhost:5006/   # expect 200

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for ActualBudget are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 3 — Application Identity

Variable	Default	Description
application_name	actualbudget	Base name for resources. Do not change after first deploy.
application_version	latest	Image version tag; latest builds the pinned 25.7.1.
enable_api_key	false	Generate a 32-char API token in Secret Manager and inject it as ACTUAL_TOKEN. Recommended for any deployment reachable outside the pod/namespace.

Group 4 — Runtime & Scaling

Variable	Default	Description
cpu_limit	1000m	actual-server is a lightweight Node.js process; 1 vCPU suffices.
memory_limit	1Gi	Modest memory is enough for typical budget files.
min_instance_count	1	Keeps the single instance warm and avoids cold starts.
max_instance_count	1	Keep at 1 — one shared SQLite volume, one writer.
container_port	5006	Inert — ActualBudget_Common always sets the container port to 5006.
enable_cloudsql_volume	false	No Cloud SQL — leave false.
enable_image_mirroring	true	Mirrors actualbudget/actual-server into Artifact Registry to avoid Docker Hub rate limits.

Group 6 — GKE Backend & Cluster

Variable	Default	Description
service_type	ClusterIP	Internal-only by default — unlike most GKE app modules, which default to LoadBalancer.
workload_type	null → StatefulSet	Auto-resolves because stateful_pvc_enabled = true by default.
session_affinity	None	No sticky routing configured (single replica makes this largely moot).

Group 7 — StatefulSet Configuration

Variable	Default	Description
stateful_pvc_enabled	true	Enabled by default — actual-server's SQLite budget DB and user files need block storage, not GCS FUSE.
stateful_pvc_size	20Gi	Per-pod PVC size; size for the budget databases and files plus overhead.
stateful_pvc_mount_path	/data	Where actual-server persists its SQLite DB, server files, and user files.
stateful_pvc_storage_class	standard-rwo	SSD-backed Balanced PD; draws the SSD_TOTAL_GB quota — override to standard (HDD) if that quota is tight.
stateful_fs_group	3000	Matches the ActualBudget Helm chart's fsGroup convention so the container (UID 1000/GID 2000) can write to the PVC.

Group 9 — Reliability Policies

Variable	Default	Description
enable_pod_disruption_budget	true	On by default (unlike most modules) — protects the single StatefulSet replica during voluntary node disruption.
pdb_min_available	1	Minimum pods available during voluntary disruptions.

Group 10 — Observability & Health

Variable	Default	Description
startup_probe	HTTP /, 15s initial delay, 10 failures	The effective startup probe (see §3 "Probe precedence").
liveness_probe	HTTP /, 30s initial delay, 3 failures	The effective liveness probe.
startup_probe_config / health_check_config	HTTP /	Declared for foundation-variable mirroring but inert for ActualBudget — use startup_probe / liveness_probe above instead.
uptime_check_config	disabled	Enable only once the endpoint is publicly reachable (LoadBalancer or a custom domain).

Group 14 — Cloud Storage & Artifact Registry

Variable	Default	Description
create_cloud_storage	true	Always creates the storage bucket ActualBudget_Common declares.
gcs_volumes	[]	Additional GCS FUSE mounts; the storage bucket only auto-mounts at /data when stateful_pvc_enabled = false.

Group 15 — Redis Cache

Variable	Default	Description
enable_redis	true (variable default)	Has no effect — main.tf hardcodes enable_redis = false to the foundation regardless of this variable's value.
redis_host / redis_port / redis_auth	inert	Not applicable — ActualBudget has no Redis integration on GKE.

Group 16 — Database Backend

Variable	Default	Description
database_type	NONE (fixed)	ActualBudget_Common fixes this to NONE; no Cloud SQL instance is created regardless of this variable.
application_database_name / application_database_user	actualbudgetdb / actualbudgetuser	Forwarded for foundation compatibility only — not referenced (no database exists).

Group 19 — Custom Domain, Static IP & Networking

Variable	Default	Description
enable_custom_domain	true	On by default, but with application_domains = [] the Gateway has no hostnames to route until you supply one.
application_domains	[]	Populate to expose ActualBudget via a custom domain + managed certificate.
reserve_static_ip	true	Reserves a static IP even though service_type defaults to ClusterIP (no LoadBalancer IP is allocated by default).

All other inputs follow standard App_GKE behaviour.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip	In-cluster ClusterIP.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific services.
service_external_ip	External LoadBalancer IP (when service_type = LoadBalancer and a static IP is reserved).
service_url	URL to reach ActualBudget.
actualbudget_api_key_secret_id	Secret Manager secret ID for the API key. Empty when enable_api_key = false.
statefulset_name	Name of the StatefulSet.
storage_buckets	Created Cloud Storage buckets (includes the storage bucket).
network_name / network_exists / regions	VPC network, presence, available regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
initialization_jobs	Names of any custom setup jobs (empty by default).
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / cicd_configuration	CI/CD status and details (repo, trigger, registry).
github_repository_url / github_repository_owner / github_repository_name	CI/CD GitHub details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time — a StatefulSet forced alongside a stateless setting, IAP with no authorized identities, quota_memory_* given as bare integers, an out-of-range container_port/backup_retention_days. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime.

Setting	Sensible value	Risk	Consequence if wrong
max_instance_count	1	Critical	Multiple pods writing the same SQLite files on one shared volume risks corruption/write conflicts.
First-run server password	set immediately	Critical	Until a password is set, anyone who can reach the service can claim the server and its budget data.
/data PVC contents	never delete manually	Critical	The block PVC is the only copy of the budget databases; deleting it erases all budgets.
stateful_pvc_enabled	true	Critical	Disabling it falls back to GCS FUSE at /data, which does not tolerate SQLite under heavy concurrent write.
quota_memory_requests / _limits	binary units (4Gi, 8192Mi)	Critical	Bare integers are treated as bytes and block all pod scheduling.
service_type / application_domains	set one to expose externally	High	With the defaults (ClusterIP + no domains), the service is reachable only from inside the cluster.
stateful_pvc_storage_class	standard-rwo (SSD)	Medium	Draws the tight SSD_TOTAL_GB quota; override to standard (HDD) on a quota-constrained project — SQLite does not need SSD IOPS.
enable_redis	any value — inert	Low	Attempting to enable Redis via this variable has no effect on GKE; main.tf always forces it off.
container_port	5006 (fixed)	Low	The variable is inert; its own description/validation text references a stale, unrelated port number.
startup_probe_config / health_check_config	any value — inert	Low	Use startup_probe / liveness_probe instead to change probe timing; these two are ignored for ActualBudget.
enable_api_key	true for automation on a reachable endpoint	Medium	Without ACTUAL_TOKEN, programmatic API access relies solely on the server password.
backup_retention_days	7 (raise for prod)	Medium	Too short for compliance retention.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. ActualBudget-specific application configuration shared with the Cloud Run variant is described in ActualBudget_Common.
