Apache Superset on GKE Autopilot

Apache Superset is an open-source data exploration and visualisation platform trusted by organisations worldwide. This module deploys Superset on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services Superset uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

1. Overview

Superset runs as a Python/Gunicorn web workload. The deployment wires together a focused set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	Python/Gunicorn pods, 2 vCPU / 2 GiB by default, horizontally autoscaled
Database	Cloud SQL for PostgreSQL 15	Required — stores dashboards, charts, datasets, and user settings
Object storage	Cloud Storage	A dedicated data bucket provisioned automatically
Cache & async queries	Redis	Disabled by default; strongly recommended for production multi-user deployments
Secrets	Secret Manager	Auto-generated SUPERSET_SECRET_KEY and database password
Ingress	Cloud Load Balancing	External LoadBalancer, optional custom domain + managed certificate

Sensible defaults worth knowing up front:

• PostgreSQL 15 is required. Superset uses it as its metadata database for all dashboards, charts, datasets, and role definitions. MySQL is not supported.
• SUPERSET_SECRET_KEY is auto-generated. A 50-character random key is generated and stored in Secret Manager. It signs Flask sessions — rotating it invalidates all active user sessions. Treat it as immutable after the first deploy.
• Two-phase initialisation runs automatically. A db-init job creates the PostgreSQL database and user; then an app-init job runs schema migrations and creates the admin user. Both run on every deploy but are idempotent.
• Session affinity is ClientIP. Superset's Flask sessions benefit from sticky routing so requests from the same browser reach the same pod.
• Redis is disabled by default. Without Redis, Celery workers have no broker; async query execution and dashboard caching are unavailable. Enable for production.
• The health probe targets /health — Superset's Gunicorn readiness endpoint.

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the Superset workload

Superset pods are scheduled on Autopilot, which bills for the CPU/memory the pods actually request. Horizontal Pod Autoscaling sizes the deployment between the minimum and maximum replica counts.

• Console: Kubernetes Engine → Workloads → select the Superset workload to see pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
• CLI:

  kubectl get pods,svc,hpa -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100
  kubectl describe hpa -n "$NAMESPACE"          # current vs target utilisation

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. Cloud SQL for PostgreSQL 15

Superset stores all metadata (dashboards, charts, datasets, users, roles, database connections) in a managed Cloud SQL for PostgreSQL 15 instance. Pods connect privately through the Cloud SQL Auth Proxy sidecar over a Unix socket, so no public IP is exposed. On first deploy the db-init job creates the application database and user, and the app-init job runs superset db upgrade to apply the schema.

• Console: SQL → select the instance for connections, backups, flags, and metrics.
• CLI:

  gcloud sql instances list --project "$PROJECT"
  gcloud sql instances describe <instance-name> --project "$PROJECT"
  # Open an interactive shell to inspect schema/data:
  gcloud sql connect <instance-name> --user=<db-user> --project "$PROJECT"

The instance name, database name, user, and the Secret Manager secret holding the password are all surfaced in the Outputs. For the connection model, automated backups, and password rotation, see App_GKE.

C. Cloud Storage

A dedicated Cloud Storage bucket is provisioned automatically for Superset data exports, chart outputs, and report files. The workload service account is granted access automatically.

• Console: Cloud Storage → Buckets.
• CLI:

  gcloud storage buckets list --project "$PROJECT"
  gcloud storage ls gs://<data-bucket>/          # bucket name is in the Outputs

See App_GKE for GCS Fuse mounts and CMEK options.

D. Redis cache and async query engine

Redis serves as Superset's caching backend and Celery broker. When enabled, it powers async SQL execution, dashboard cache warming, and scheduled reports. Without Redis, all queries run synchronously and block Gunicorn workers.

• Console: Memorystore → Redis (if using a managed instance).
• CLI:

  redis-cli -h <redis-host> ping
  redis-cli -h <redis-host> info keyspace

E. Secret Manager

The SUPERSET_SECRET_KEY and the database password are stored as Secret Manager secrets and injected into pods at runtime; plaintext never appears in configuration.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT"
  gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"

The database password secret name is in the Outputs. See App_GKE for the Secret Store CSI integration and rotation.

F. Networking & ingress

By default the workload is exposed through an external Cloud Load Balancing IP. A custom domain with a Google-managed certificate can be enabled, and a static IP can be reserved so the address survives redeploys.

• Console: Network services → Load balancing; VPC network → IP addresses.
• CLI:

  kubectl get ingress,svc -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

G. Cloud Logging & Monitoring

Pod stdout/stderr flows to Cloud Logging; GKE and Cloud SQL metrics flow to Cloud Monitoring. An optional uptime check against /health and optional alert policies are available (disabled by default).

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. Superset Application Behaviour

• First-deploy database setup. The db-init job creates the Superset database and user idempotently before the application starts. It runs with postgres:15-alpine and shuts down the Cloud SQL Auth Proxy sidecar via quitquitquit on completion.
• Schema migrations on every deploy. The app-init job runs superset db upgrade on each deploy, applying any pending Flask-AppBuilder and Superset schema changes automatically. This job then creates or updates the admin user with superset fab create-admin, and finally runs superset init to load default roles and permissions.
• Startup sequence. The app-init job depends on db-init completing successfully. Its 30-minute timeout accommodates slow first-run migrations on large or complex schemas. The startup probe allows up to 180 seconds (60 s initial delay, 12 failure thresholds at 10 s intervals) for the Gunicorn worker pool to come up.
• Flask secret key. SUPERSET_SECRET_KEY signs Flask sessions and encrypts database connection credentials stored in Superset's metadata. Changing it after the first deploy invalidates all sessions and makes stored credentials unreadable. The key is auto-generated as a 50-character random string in Secret Manager.
• Async queries and scheduled reports. Superset's Celery workers use Redis as the broker and result backend. Without Redis, async queries and scheduled reports are unavailable. Configure enable_redis = true and supply redis_host for production.
• Health path. Readiness/liveness probes target /health, which returns HTTP 200 when the Gunicorn worker pool is ready.
• Admin login. The admin credentials are set through the environment variables SUPERSET_ADMIN_USERNAME, SUPERSET_ADMIN_EMAIL, and SUPERSET_ADMIN_PASSWORD. The password defaults to the value of SUPERSET_SECRET_KEY when not explicitly set.

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Superset are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 1 — Project & Identity

Variable	Default	Description
project_id	(required)	Target Google Cloud project.
region	us-central1	Region for the workload and regional resources.

Group 2 — Deployment Environment

Variable	Default	Description
tenant_deployment_id	demo	Short suffix that makes resource names unique per environment.
support_users	[]	Emails granted project access and monitoring alerts.
resource_labels	{}	Labels applied to all resources for cost/ownership tracking.

Group 3 — Application Identity

Variable	Default	Description
application_name	superset	Base name for resources. Do not change after first deploy.
application_display_name	Apache Superset	Friendly name shown in the Console.
application_description	(set)	Workload description annotation.
application_version	latest	Superset image version tag; pin to a specific release for production.

Group 4 — Runtime & Scaling

Variable	Default	Description
deploy_application	true	Set false to provision infrastructure only.
container_resources	{ cpu_limit = "2000m", memory_limit = "2Gi" }	CPU and memory per pod; 2 vCPU / 2 GiB minimum for Superset.
container_port	8088	Superset/Gunicorn listens on port 8088.
container_image_source	custom	custom builds the bundled Dockerfile (required for psycopg2); prebuilt uses an existing image.
min_instance_count	1	Minimum replicas. Keep ≥ 1 to avoid cold-start delays.
max_instance_count	5	Maximum replicas (autoscaler ceiling).
timeout_seconds	600	Request timeout; extended for long-running SQL queries.
enable_cloudsql_volume	true	Cloud SQL Auth Proxy sidecar for socket connections.
enable_vertical_pod_autoscaling	false	Let Autopilot tune resource requests automatically.

Group 5 — Environment Variables & Secrets

Variable	Default	Description
environment_variables	{}	Extra non-secret settings. SUPERSET_SECRET_KEY is injected automatically.
secret_environment_variables	{}	Map of env var → Secret Manager secret name.

Group 6 — GKE Backend & Cluster

Variable	Default	Description
service_type	LoadBalancer	How the Service is exposed.
session_affinity	ClientIP	Sticky routing recommended for Superset Flask sessions.
workload_type	null	Auto-resolves to StatefulSet when per-pod storage is enabled.
network_tags	['nfsserver']	Node/pod tags for firewall rules.

Group 7 — StatefulSet

Variable	Default	Description
stateful_pvc_enabled	null	Enable PVC templates in a StatefulSet. Superset does not require per-pod storage.
stateful_pvc_size	10Gi	Storage size for each PVC when enabled.
stateful_pvc_mount_path	/data	Container mount path for the PVC.
stateful_pvc_storage_class	standard-rwo	Kubernetes StorageClass for PVCs.

Group 8 — Resource Quota

Variable	Default	Description
enable_resource_quota	false	Cap namespace CPU/memory/object counts.
quota_memory_requests / quota_memory_limits	""	Must use binary units (4Gi, 8192Mi) — bare integers are read as bytes and block all scheduling.

Group 9 — Reliability Policies

Variable	Default	Description
enable_pod_disruption_budget	false	Protect availability during node upgrades.
pdb_min_available	1	Raise min_instance_count above 1 if you need eviction headroom.

Group 10 — Observability & Health

Variable	Default	Description
startup_probe_config	HTTP /health, 60 s delay, 12 failures	Allows up to 180 s for the Gunicorn worker pool to initialise.
health_check_config	HTTP /health, 60 s delay	Liveness probe.
uptime_check_config	disabled, /health	Cloud Monitoring uptime check.
alert_policies	[]	Optional metric alert policies.

Group 11 — Jobs & Scheduled Tasks

Variable	Default	Description
initialization_jobs	[]	Leave empty to use the built-in two-phase db-init + app-init pipeline.
cron_jobs	[]	Recurring CronJobs — useful for cache warmup or report generation.
additional_services	[]	Sidecar or helper GKE services (e.g. Celery workers).

Group 12 — CI/CD & GitHub Integration

Standard App_GKE Cloud Build / Cloud Deploy integration — see App_GKE. Key inputs: enable_cicd_trigger, github_repository_url, github_token, enable_cloud_deploy.

Group 13 — Filesystem (NFS)

Variable	Default	Description
enable_nfs	false	Shared Filestore volume. Superset does not require NFS — state lives in PostgreSQL.
nfs_mount_path	/mnt/nfs	Mount path inside the container if NFS is enabled.

Group 14 — Cloud Storage & Artifact Registry

Variable	Default	Description
create_cloud_storage	true	Provision the data bucket.
storage_buckets / gcs_volumes	(set)	Additional buckets / GCS Fuse mounts.
manage_storage_kms_iam / enable_artifact_registry_cmek	false	CMEK options.

Group 15 — Redis Cache

Variable	Default	Description
enable_redis	false	Enable Redis for Celery and caching. Strongly recommended for production.
redis_host	""	Redis hostname or IP. Required when enable_redis = true.
redis_port	"6379"	Redis port (string in the GKE variant).
redis_auth	""	Optional Redis authentication password (sensitive).

Group 16 — Database Backend

Variable	Default	Description
database_type	POSTGRES_15	Fixed — do not change. Superset requires PostgreSQL.
application_database_name	superset_db	Database name. Immutable after first deploy.
application_database_user	superset_user	Application user. Immutable after first deploy.
database_password_length	32	Generated password length (16–64).
enable_auto_password_rotation	false	Zero-downtime DB password rotation.

Group 17 — Backup & Maintenance

Variable	Default	Description
backup_schedule	0 2 * * *	Automated backup cron (UTC).
backup_retention_days	7	Retention; raise to 30–90 for production/compliance.
enable_backup_import / backup_source / backup_uri	restore options	Restore from a backup on deploy.

Group 18 — Custom SQL Scripts

enable_custom_sql_scripts, custom_sql_scripts_bucket, custom_sql_scripts_path, custom_sql_scripts_use_root — run SQL from a GCS bucket after provisioning. See App_GKE.

Group 19 — Custom Domain, Static IP & Networking

Variable	Default	Description
enable_custom_domain	true	Provision Ingress for custom hostnames + managed certificate.
application_domains	[]	Hostnames to serve.
reserve_static_ip	true	Stable external IP across redeploys.

Group 20 — Identity-Aware Proxy (IAP)

Variable	Default	Description
enable_iap	false	Require Google sign-in in front of Superset.
iap_authorized_users / iap_authorized_groups	[]	Who may access.
iap_oauth_client_id / iap_oauth_client_secret	""	Required when IAP is enabled (sensitive).
iap_support_email	""	Shown on the OAuth consent screen.

Group 21 — Cloud Armor

Variable	Default	Description
enable_cloud_armor	false	Attach a Cloud Armor (WAF) policy to the Ingress backend.
admin_ip_ranges	[]	CIDRs allowed privileged access.
cloud_armor_policy_name	(set)	Policy name.

Group 22 — VPC Service Controls & Audit Logging

Variable	Default	Description
enable_vpc_sc	false	Enforce a VPC-SC perimeter (requires organization_id).
vpc_cidr_ranges / vpc_sc_dry_run	(set)	Access level CIDRs / dry-run mode.
enable_audit_logging	false	Detailed Cloud Audit Logs.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip	In-cluster ClusterIP.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific services.
service_external_ip	External LoadBalancer IP (when a static IP is reserved).
service_url	URL to reach Superset.
database_instance_name	Cloud SQL instance name.
database_name	Application database name.
database_user	Application database user.
database_password_secret	Secret Manager secret holding the DB password.
database_host / database_port	DB endpoint (127.0.0.1 via the Auth Proxy) / port.
storage_buckets	Created Cloud Storage buckets.
network_name / network_exists / regions	VPC network, presence, available regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
initialization_jobs / db_import_job	Names of the setup and (optional) import jobs.
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / cicd_configuration	CI/CD status and details.
github_repository_url / github_repository_owner / github_repository_name	GitHub repo details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Setting	Sensible value	Risk	Consequence if wrong
SUPERSET_SECRET_KEY (auto-generated)	immutable after first deploy	Critical	Changing the key invalidates all active sessions and makes stored database connection credentials in Superset's metadata permanently unreadable.
database_type	POSTGRES_15	Critical	Superset requires PostgreSQL; changing breaks startup.
enable_cloudsql_volume	true	Critical	Disabling removes the Auth Proxy sidecar; all PostgreSQL connections fail.
application_database_name / _user	set once	Critical	Immutable after first deploy; renaming recreates the DB/user and destroys all dashboards and metadata.
enable_backup_import	false unless restoring	Critical	Enabling without a valid backup_uri fails the import job.
quota_memory_requests / _limits	binary units	Critical	Bare integers are bytes and block all pod scheduling.
enable_redis	true for production	High	Without Redis, Celery workers have no broker; async queries and scheduled reports are unavailable.
redis_host	set explicitly	High	Required when enable_redis = true; empty causes Celery workers to fail on startup.
container_resources.memory_limit	2Gi minimum	High	Under 1 GiB Gunicorn workers are OOM-killed during query execution.
container_resources.cpu_limit	2000m	High	Under 1000m the app-init migration job may time out in its 30-minute window.
min_instance_count	1	High	0 causes scale-to-zero; async queries submitted during cold-start are lost.
session_affinity	ClientIP	High	Without stickiness, Flask session state is lost between requests on multi-replica deployments.
startup_probe_config.failure_threshold	12 or higher	High	Reducing too far causes GKE to kill pods before Superset finishes database migrations.
application_version	pin to a specific release	Medium	latest triggers uncontrolled upgrades that may introduce breaking API changes.
enable_iap / enable_cloud_armor	enable for production	Medium	Without them, the Superset login form is publicly reachable.
backup_retention_days	7 (raise for prod)	Medium	Too short for compliance retention.
pdb_min_available vs min_instance_count	leave headroom	Medium	1/1 can stall node upgrades.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Superset-specific application configuration shared with the Cloud Run variant is described in Superset_Common.
