Plausible Analytics on GKE Autopilot

Plausible Analytics Community Edition is the leading open-source, AGPL-3.0-licensed, privacy-first web analytics platform — a lightweight, cookie-free, GDPR/CCPA/PECR-compliant alternative to Google Analytics that you fully own and self-host. This module deploys Plausible CE on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

Plausible is an Elixir/Phoenix application with two datastores: Cloud SQL PostgreSQL 15 holds accounts and site configuration only, and ClickHouse holds all analytics events. ClickHouse is provided by the separate ClickHouse_GKE module and is mandatory — deploy it first. There is deliberately no Plausible_CloudRun variant: ClickHouse cannot run on Cloud Run, so this pair follows the GKE-only pattern (like Supabase and Temporal).

This guide focuses on the cloud services Plausible uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

1. Overview

Plausible runs as an Elixir/Phoenix (BEAM) web workload on port 8000. The deployment wires together a focused set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	Plausible pods, 1 vCPU by default, horizontally autoscaled 1–10 replicas
Config database	Cloud SQL for PostgreSQL 15	Accounts, sites, and settings ONLY — no analytics events
Event store	ClickHouse (ClickHouse_GKE)	Mandatory — every pageview/event lands here; deploy it first
Secrets	Secret Manager	Auto-generated SECRET_KEY_BASE and TOTP_VAULT_KEY; DB password; the ClickHouse password (owned by ClickHouse_GKE)
Image build	Cloud Build + Artifact Registry	Thin custom build FROM ghcr.io/plausible/community-edition
Ingress	Cloud Load Balancing	External LoadBalancer, optional custom domain + managed certificate

Sensible defaults worth knowing up front:

• ClickHouse is not optional. A plan-time validation guard blocks the apply when clickhouse_url is empty, and module_dependency defaults to ["Services_GCP", "ClickHouse_GKE"]. Wire the ClickHouse_GKE outputs in: clickhouse_url = clickhouse_internal_endpoint (same cluster, preferred) or clickhouse_endpoint; clickhouse_db = clickhouse_database; clickhouse_user = clickhouse_username; clickhouse_password_secret = clickhouse_password_secret_id.
• The ClickHouse password crosses module boundaries safely. Plausible references the Secret Manager secret created by ClickHouse_GKE; the foundation grants Plausible's workload SA secretAccessor on it and injects it as CLICKHOUSE_PASSWORD. No password ever appears in Terraform variables.
• application_version = "latest" is a pin, not a tag. CE publishes no latest tag on ghcr.io/plausible/community-edition; the build pins the known-good release v3.2.1 via the app-specific PLAUSIBLE_VERSION build ARG (the Foundation injects APP_VERSION and wins that merge, hence the app-specific ARG name).
• SECRET_KEY_BASE and TOTP_VAULT_KEY are generated automatically and stored in Secret Manager. Both must remain stable: rotating SECRET_KEY_BASE invalidates all sessions and logs every user out; rotating TOTP_VAULT_KEY breaks every enrolled 2FA device.
• Registration is open by default. Create the first account at <service URL>/register, then set DISABLE_REGISTRATION = "true" (or "invite_only") via environment_variables.
• Port 8000; probes on /api/health. The health endpoint responds without authentication, so startup/liveness probes never see a 401/403.
• 1Gi memory is the reliable floor for the BEAM runtime plus the in-process Oban job queue (the shared-layer default).
• No NFS, no GCS buckets. All state lives in PostgreSQL and ClickHouse.

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the Plausible workload

Plausible pods are scheduled on Autopilot, which bills for the CPU/memory the pods actually request. Horizontal Pod Autoscaling sizes the Deployment between the minimum and maximum replica counts.

• Console: Kubernetes Engine → Workloads → select the Plausible workload to see pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
• CLI:

  kubectl get pods -A | grep plausible          # find the namespace and pods
  kubectl get pods,svc,hpa -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" deploy/"$(kubectl get deploy -n "$NAMESPACE" -o jsonpath='{.items[0].metadata.name}')" --tail=100

The entrypoint logs its composed configuration at startup — look for the [plausible-entrypoint] lines showing the DATABASE_URL host, ClickHouse host, and BASE_URL.

B. Cloud SQL for PostgreSQL 15 — accounts and configuration

Plausible stores accounts, sites, goals, and settings in a managed Cloud SQL for PostgreSQL 15 instance. Pods reach it privately through the Cloud SQL Auth Proxy sidecar — the entrypoint always connects over TCP 127.0.0.1:5432 (socket-path hosts are coerced to 127.0.0.1, because postgresql:// URLs cannot carry socket paths). On first deploy a db-init Job (postgres:15-alpine) creates the application role and database; Plausible's own migrations run at container startup.

• Console: SQL → select the instance for connections, backups, flags, metrics.
• CLI:

  gcloud sql instances list --project "$PROJECT"
  gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"

Analytics events are NOT here. If you query PostgreSQL looking for pageviews you will find nothing — events live in ClickHouse.

C. ClickHouse — the event store (via ClickHouse_GKE)

Every pageview and custom event is written to ClickHouse, deployed and owned by the separate ClickHouse_GKE module (a StatefulSet with a persistent volume). Plausible connects using the composed CLICKHOUSE_DATABASE_URL; on first boot, CE's db createdb creates the events database if missing and db migrate applies the ClickHouse schema.

• CLI:

  kubectl get pods -A | grep clickhouse                 # the ClickHouse workload
  # Ping ClickHouse from inside the cluster (endpoint = the clickhouse_url you wired in):
  kubectl run ch-ping --rm -it --restart=Never --image=curlimages/curl -- \
    curl -s "<clickhouse_url>/ping"                     # expect: Ok.
  # Confirm the composed wiring inside the Plausible pod:
  kubectl exec -n "$NAMESPACE" deploy/<deploy-name> -- env | grep PLATFORM_CLICKHOUSE

D. Secret Manager

Four secrets matter to a running Plausible:

Secret	Owner	Purpose
secret-<prefix>-plausible-secret-key-base	Plausible_Common	Phoenix session signing — never rotate (logs everyone out)
secret-<prefix>-plausible-totp-vault-key	Plausible_Common	Encrypts 2FA TOTP secrets at rest — never rotate (breaks all 2FA)
DB password secret	App_GKE foundation	Cloud SQL application-user password
ClickHouse password secret	ClickHouse_GKE	Injected as CLICKHOUSE_PASSWORD; Plausible's SA is granted secretAccessor

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~plausible"
  gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"

E. Cloud Build & Artifact Registry — the custom image

The image is a thin wrapper: FROM ghcr.io/plausible/community-edition:<tag> plus the cloud entrypoint (plausible-entrypoint.sh, pure POSIX sh — the image has no bash/node/python). The entrypoint URL-encodes credentials with a pure-shell percent-encoder, composes DATABASE_URL and CLICKHOUSE_DATABASE_URL, falls back BASE_URL to the platform-predicted service URL, then runs CE's db createdb + db migrate (advisory-locked) before exec-ing the server.

• CLI:

  gcloud builds list --project "$PROJECT" --limit 5
  gcloud artifacts docker images list <region>-docker.pkg.dev/$PROJECT/<repo> --include-tags | grep plausible

Entrypoint edits are baked into the image — they need a rebuild + redeploy. Job scripts (create-db-and-user.sh) are mounted at apply time — no rebuild needed.

F. Networking & ingress

By default the workload is exposed through an external Cloud Load Balancing IP with a reserved static address. A custom domain with a Google-managed certificate can be enabled.

On projects capped on global external static IP quota, set reserve_static_ip = false and enable_custom_domain = false. The default enable_custom_domain = true activates the per-app HTTPS Gateway (zero-config nip.io HTTPS) even without a custom domain, and the Gateway reserves a global static IP; with both disabled, the Service falls back to an ephemeral LoadBalancer IP and consumes no static address. The companion ClickHouse_GKE — whose only consumer is in-cluster Plausible — can additionally set service_type = "ClusterIP" to need no external IP at all.

• CLI:

  kubectl get ingress,svc -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT" --filter="name~plausible"

Set base_url (or leave it empty for the platform-predicted URL) — it drives the tracking-script snippet Plausible shows for each site and the links in its emails.

G. Cloud Logging & Monitoring

Pod stdout/stderr flow to Cloud Logging; GKE and Cloud SQL metrics flow to Cloud Monitoring. An optional uptime check targets /api/health.

• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. Plausible Application Behaviour

• Two-phase database bootstrap. The db-init Job creates the PostgreSQL role and database (idempotent, safe to re-run). Then, at every container start, the entrypoint runs CE's db createdb (creates the ClickHouse events database if missing) and db migrate (PostgreSQL + ClickHouse migrations, advisory-locked so concurrent replicas don't race), before exec /entrypoint.sh run.
• Hard fail on missing ClickHouse. If PLATFORM_CLICKHOUSE_URL is empty at runtime the entrypoint exits 1 with an explicit error naming the fix (deploy ClickHouse_GKE and set clickhouse_url). In practice you never see this because the plan-time validation catches it first.
• First account via /register. There are no seeded credentials. Open <service URL>/register, create the first account, add your site, and Plausible shows the tracking snippet (<script defer data-domain="yourdomain.com" src=".../js/script.js"></script>). After that, close registration with DISABLE_REGISTRATION = "true" (or "invite_only") in environment_variables and apply via Update.
• BASE_URL matters for correctness. It drives the snippet URL and email links. The entrypoint defaults it to the platform-predicted service URL (GKE_SERVICE_URL); set base_url explicitly when serving behind a custom domain.
• Health path. Startup and liveness probes target GET /api/health, which is unauthenticated by design and returns a JSON status body such as {"sessions":"ok","postgres":"ok","clickhouse":"ok",...} — a quick end-to-end check that both datastores are reachable. Do not repoint probes at authenticated pages (they would 401/403 and the pod would never become Ready).
• Version upgrades. Set application_version to an explicit CE tag (e.g. v3.2.1) and apply; a new image builds and migrations run on the next start.

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Plausible are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 1 — Project, Identity & ClickHouse

Variable	Default	Description
project_id	(required)	Target Google Cloud project.
region	us-central1	Region for the workload and regional resources.
clickhouse_url	""	Effectively required — the plan blocks when empty. Bare http(s)://host[:port] base endpoint, no credentials or path: ClickHouse_GKE's clickhouse_internal_endpoint (preferred) or clickhouse_endpoint.
clickhouse_password_secret	""	ClickHouse_GKE's clickhouse_password_secret_id output. The foundation grants the workload SA access and injects CLICKHOUSE_PASSWORD.
clickhouse_db	plausible_events_db	ClickHouse_GKE's clickhouse_database output.
clickhouse_user	plausible	ClickHouse_GKE's clickhouse_username output.
base_url	""	Public BASE_URL — drives the tracking snippet and email links. Empty uses the platform-predicted service URL.

Group 2 — Deployment Environment

Variable	Default	Description
tenant_deployment_id	demo	Short suffix that makes resource names unique per environment.
support_users	[]	Emails granted project access and monitoring alerts.
resource_labels	{}	Labels applied to all resources.

Group 3 — Application Identity

Variable	Default	Description
application_name	plausible	Base name for resources. Do not change after first deploy.
application_version	latest	CE image tag. latest pins to v3.2.1 at build time (CE has no latest tag); set an explicit tag to upgrade.

Group 4 — Runtime & Scaling

Variable	Default	Description
deploy_application	true	Set false to provision infrastructure only.
container_image_source	custom	Keep custom — the wrapper image's entrypoint composes both database URLs.
container_port	8000	Plausible CE's HTTP_PORT.
container_resources	1000m / 512Mi	Per-pod CPU/memory. Raise memory toward the 1Gi BEAM+Oban floor for production.
min_instance_count / max_instance_count	1 / 10	HPA bounds.
enable_cloudsql_volume	true	Cloud SQL Auth Proxy sidecar; the entrypoint uses its TCP listener on 127.0.0.1:5432.
enable_image_mirroring	true	Mirror the base image into Artifact Registry before building.
workload_type	Deployment	Plausible is stateless (state lives in Cloud SQL + ClickHouse).

Group 6 — GKE Cluster, Environment Variables & Secrets

Variable	Default	Description
environment_variables	{}	Extra settings — e.g. { DISABLE_REGISTRATION = "true" } after the first account. Do not set DATABASE_URL, CLICKHOUSE_DATABASE_URL, SECRET_KEY_BASE, or TOTP_VAULT_KEY here.
secret_environment_variables	{}	Map of env var → Secret Manager secret name.
gke_cluster_name / namespace_name	""	Empty auto-discovers the Services_GCP cluster / auto-generates the namespace.
service_type	LoadBalancer	How the Kubernetes Service is exposed.
session_affinity	None	Stateless — any pod can serve any request.

Group 10 — Observability & Health

Variable	Default	Description
startup_probe_config	HTTP /api/health, 30s delay, threshold 30	Generous window for first-boot migrations.
health_check_config	HTTP /api/health, 30s period, threshold 3	Liveness probe.
uptime_check_config	disabled, /api/health	Optional Cloud Monitoring uptime check.

Group 11 — Jobs & Scheduled Tasks

Variable	Default	Description
initialization_jobs	[]	Leave empty to use the built-in db-init job (postgres:15-alpine + create-db-and-user.sh).
cron_jobs / additional_services	[]	Scheduled CronJobs / helper services.

Group 15 — Redis

enable_redis, redis_host, redis_port, redis_auth are inert convention mirrors of the Foundation variables — Plausible does not use Redis.

Group 16 — Database Backend

Variable	Default	Description
application_database_name	plausible	PostgreSQL database name (tenant-prefixed by the foundation). Immutable after first deploy.
application_database_user	plausible	Application database role. Immutable after first deploy.
database_password_length	32	Generated password length (16–64).

Groups 5 (IAP), 7 (backup/StatefulSet), 8 (ResourceQuota), 9 (custom SQL/PDB), 12 (CI/CD), 13 (NFS — off), 14 (storage/registry), 17 (backup import), 19 (custom domain/static IP), 21 (Cloud Armor/CDN), and 22 (VPC-SC/audit logging) are standard App_GKE inputs — see App_GKE.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip / stage_service_cluster_ips	In-cluster ClusterIP(s).
service_external_ip	External LoadBalancer IP (when a static IP is reserved).
service_url	URL to reach Plausible (open /register here first).
database_instance_name	Cloud SQL instance name.
database_name / database_user	Application database name / user (config store only).
database_password_secret	Secret Manager secret holding the DB password.
database_host / database_port	DB endpoint (127.0.0.1 via the Auth Proxy) / port.
storage_buckets	Created Cloud Storage buckets (empty for Plausible).
network_name / network_exists / regions	VPC network, presence, available regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
initialization_jobs / db_import_job	Names of the setup and (optional) import jobs.
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / cicd_configuration	CI/CD status and details.
github_repository_url / github_repository_owner / github_repository_name	CI/CD GitHub details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready (re-run apply if false on a new inline cluster).
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time. In addition, Plausible_GKE's own validation guard rejects an empty clickhouse_url, min > max instance counts, IAP without OAuth credentials, and a Cloud SQL sidecar with database_type = "NONE" — all before any resource is created.

Setting	Sensible value	Risk	Consequence if wrong
ClickHouse_GKE application_version	Keep the pinned 24.12-alpine	Critical	Overriding the ClickHouse pin with an untested version has broken Plausible upstream (plausible/analytics#3855) — migrations or queries fail against an incompatible ClickHouse. Plausible version-pins ClickHouse for a reason.
SECRET_KEY_BASE (auto-generated)	Never rotate	Critical	Rotation invalidates every Phoenix session — all users are logged out at once.
TOTP_VAULT_KEY (auto-generated)	Never rotate	Critical	Rotation makes every enrolled 2FA device unusable; affected users are locked out of 2FA login.
clickhouse_url	ClickHouse_GKE's clickhouse_internal_endpoint	High (blocked)	Left empty, the deploy is blocked at plan time by the validation guard — deploy ClickHouse_GKE first and paste its output. A wrong-but-nonempty URL fails at runtime (entrypoint/migrations cannot reach the event store).
clickhouse_password_secret	ClickHouse_GKE's clickhouse_password_secret_id	High	Missing or wrong secret → CLICKHOUSE_PASSWORD is absent and ClickHouse authentication fails; pods crash-loop on migrate.
DISABLE_REGISTRATION	"true" (or "invite_only") after the first account	Medium	Registration stays open by default — anyone who finds the URL can create an account on your analytics instance.
application_version	latest (pins v3.2.1) or an explicit CE tag	High	CE publishes no latest tag; without the pin the build would fail MANIFEST_UNKNOWN. Pin explicit versions in production.
application_database_name / application_database_user	Set once	Critical	Immutable after first deploy; renaming recreates the DB/role and orphans account/site config.
container_resources.memory_limit	1Gi	High	Below the BEAM + in-process Oban floor, pods OOM under load or during migrations.
base_url	Custom-domain URL when using one	High	A wrong BASE_URL puts the wrong script src in every tracking snippet and breaks email links.
Probe path	/api/health	High	Repointing probes at an authenticated page returns 401/403 — the pod never becomes Ready even though the app booted fine.
enable_cloudsql_volume	true	High	The entrypoint connects to 127.0.0.1:5432 via the Auth Proxy sidecar; disabling it breaks the PostgreSQL path (and is blocked when database_type = "NONE").
enable_iap	false for public analytics	High	IAP in front of Plausible blocks the tracking script on your websites — visitors' browsers cannot POST events through a Google login wall.
quota_memory_requests / _limits	binary units (4Gi, 8192Mi)	Critical	Bare integers are bytes and block all pod scheduling in the namespace.
Teardown order	Plausible first, then ClickHouse	Medium	Destroying ClickHouse while Plausible still runs leaves pods crash-looping against a vanished event store (and the secret grant dangling).
enable_pod_disruption_budget	true	Medium	Disabling allows GKE to evict all pods simultaneously during maintenance.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Plausible-specific application configuration (secrets, entrypoint, database bootstrap) is described in Plausible_Common, and the event store in ClickHouse_GKE.
