Superset on Google Cloud Run

This document provides a comprehensive reference for the modules/Superset_CloudRun Terraform module. It covers architecture, IAM, configuration variables, Superset-specific behaviours, and operational patterns for deploying Apache Superset on Google Cloud Run (v2).

---

1. Module Overview

Apache Superset is an open-source data visualisation and exploration platform. Superset CloudRun is a wrapper module built on top of App CloudRun. It uses App CloudRun for all GCP infrastructure provisioning and injects Superset-specific application configuration, a two-phase database initialisation pipeline, and a SECRET_KEY secret via Superset Common.

Key Capabilities:

• Compute: Cloud Run v2 (Gen2), 2 vCPU / 2 Gi by default, up to 5 instances.
• Data Persistence: Cloud SQL PostgreSQL 15 (default). GCS superset-data bucket auto-provisioned by Superset Common.
• Security: SUPERSET_SECRET_KEY (50-char random) auto-generated by Superset Common and stored in Secret Manager.
• Caching: Redis optional but recommended for production (enable_redis = false by default).
• Initialisation: Two-phase init — db-init (database schema) followed by app-init (Superset bootstrap: database upgrade + admin user creation). Both run automatically on first deploy.
• CI/CD: Cloud Build custom image pipeline; psycopg2-binary is pre-installed in the bundled Dockerfile for PostgreSQL connectivity.

Project & Application Identity

Variable	Group	Type	Default	Description
project_id	1	string	—	GCP project ID. Required.
tenant_deployment_id	1	string	'demo'	Short suffix appended to all resource names.
support_users	1	list(string)	[]	Email recipients for monitoring alerts.
resource_labels	1	map(string)	{}	Labels applied to all provisioned resources.
application_name	2	string	'superset'	Base resource name. Do not change after initial deployment.
display_name	2	string	'Superset'	Human-readable name shown in the GCP Console.
description	2	string	'Apache Superset data visualisation platform'	Cloud Run service description.
application_version	2	string	'latest'	Superset image version tag.

Two-phase init: Superset Common provisions two sequential Cloud Run Jobs by default:

1. db-init — creates the PostgreSQL database and user using postgres:15-alpine.
2. app-init — runs as the Superset container image, executes db upgrade (schema migrations) and fab create-admin (admin user creation). app-init depends on db-init completing successfully.

---

2. IAM & Access Control

Superset_CloudRun delegates all IAM provisioning to App_CloudRun. The Cloud Run SA, Cloud Build SA, IAP service agent, and password rotation role sets are identical to those in App_CloudRun §2.

SUPERSET_SECRET_KEY: Superset Common auto-generates a 50-character random password (no special characters) and stores it in Secret Manager as {prefix}-secret-key. This key is used by Superset for Flask session signing and is injected as SUPERSET_SECRET_KEY.

App-init identity: The app-init Cloud Run Job runs as the Superset application container. It has access to the database credentials and SUPERSET_SECRET_KEY from Secret Manager to perform schema migration and admin user creation.

For the complete role tables, see App_CloudRun §2.

---

3. Core Service Configuration

A. Compute (Cloud Run)

Superset is a Python/React application with substantial resource requirements due to query execution and visualisation rendering.

Variable	Group	Default	Description
deploy_application	3	true	Set false for infrastructure-only deployment.
container_image_source	3	'custom'	'custom' builds via Cloud Build. 'prebuilt' deploys an existing image URI.
container_image	3	""	Override image URI. Leave empty for Cloud Build.
cpu_limit	3	'2000m'	CPU per instance. 2 vCPU recommended for query execution.
memory_limit	3	'2Gi'	Memory per instance.
container_port	3	8088	Superset's Gunicorn HTTP port.
execution_environment	3	'gen2'	Gen2 execution environment.
timeout_seconds	3	600	Max request duration. Extended to 600s for long-running queries and dashboard rendering.
enable_cloudsql_volume	3	true	Connects via Unix socket.
min_instance_count	3	1	Minimum Cloud Run instances.
max_instance_count	3	5	Maximum Cloud Run instances.
traffic_split	3	[]	Canary/blue-green traffic allocation.

Differences from App CloudRun defaults:

Variable	App CloudRun	Superset CloudRun	Reason
container_port	8080	8088	Superset's Gunicorn port.
cpu_limit	'1000m'	'2000m'	Query execution and rendering require 2 vCPU.
memory_limit	'512Mi'	'2Gi'	Python-based query engine and caching require more memory.
timeout_seconds	300	600	Long-running queries and dashboard loads can exceed 5 minutes.
min_instance_count	0	1	Dashboard users benefit from a warm instance.
max_instance_count	1	5	Multiple concurrent dashboard users require more instances.

B. Database (Cloud SQL — PostgreSQL 15)

Superset uses PostgreSQL 15 as its metadata database (storing dashboards, charts, datasets, and user settings).

Variable	Group	Default	Description
db_name	11	'superset_db'	PostgreSQL database name. Do not change after deployment.
db_user	11	'superset_user'	PostgreSQL application user.
database_password_length	11	32	Auto-generated password length.
enable_auto_password_rotation	11	false	Automated zero-downtime password rotation.

Note: application_database_name = 'superset_db' and application_database_user = 'superset_user' are the defaults in Superset CloudRun. These differ from the App CloudRun defaults (gkeappdb / gkeappuser).

C. Storage (GCS)

Variable	Group	Default	Description
create_cloud_storage	10	true	Set false to skip GCS bucket creation.
storage_buckets	10	[{ name_suffix = "data" }]	Additional GCS buckets.
gcs_volumes	10	[]	GCS Fuse volume mounts.

D. Networking

Variable	Group	Default	Description
ingress_settings	4	'all'	'all', 'internal', or 'internal-and-cloud-load-balancing'.
vpc_egress_setting	4	'PRIVATE_RANGES_ONLY'	VPC egress routing.

E. Initialization & Bootstrap

Superset Common provides a two-phase initialisation pipeline by default:

Phase 1 — db-init:

• Image: postgres:15-alpine
• Creates the superset_db database and superset_user via db-init.sh
• execute_on_apply = true

Phase 2 — app-init:

• Image: null (uses the Superset application image)
• Executes app-init.sh: runs superset db upgrade and superset fab create-admin
• depends_on_jobs = ["db-init"]
• execute_on_apply = true
• Timeout: 1800s (30 minutes for migrations on first run)

Variable	Group	Default	Description
initialization_jobs	12	[]	One-shot Cloud Run Jobs. Leave empty for Superset Common to supply the default two-job pipeline. Non-empty list replaces it entirely.
cron_jobs	12	[]	Recurring scheduled jobs.

---

4. Advanced Security

A. Secret Key

Superset Common auto-generates a 50-character SUPERSET_SECRET_KEY and stores it in Secret Manager. This key is critical — changing it invalidates all existing user sessions.

Variable	Group	Default	Description
secret_environment_variables	5	{}	Additional Secret Manager references. SUPERSET_SECRET_KEY is auto-injected.

B. Cloud Armor WAF

Variable	Group	Default	Description
enable_cloud_armor	9	false	Provisions Global HTTPS LB + Cloud Armor WAF.
admin_ip_ranges	9	[]	CIDR ranges exempted from WAF rules.

C. Identity-Aware Proxy (IAP)

Variable	Group	Default	Description
enable_iap	4	false	Enables IAP on the Cloud Run service. Useful for restricting Superset to internal users.
iap_authorized_users	4	[]	Users/service accounts granted access.
iap_authorized_groups	4	[]	Google Groups granted access.

---

5. Traffic & Ingress

Variable	Group	Default	Description
enable_cloud_armor	9	false	Provisions Global HTTPS LB + Cloud Armor WAF.
enable_cdn	9	false	Enables Cloud CDN. Superset serves dynamic content; CDN is appropriate for static assets only.
application_domains	9	[]	Custom domain names.

---

6. CI/CD & Delivery

Variable	Group	Default	Description
enable_cicd_trigger	7	false	Provisions a Cloud Build GitHub trigger.
github_repository_url	7	""	GitHub repository URL.
github_token	7	""	GitHub PAT. Sensitive.
enable_cloud_deploy	7	false	Provisions a Cloud Deploy pipeline.
enable_binary_authorization	7	false	Image attestation enforcement.

---

7. Reliability & Scheduling

A. Health Probes

Superset exposes /health as its health endpoint.

Variable	Group	Default	Description
startup_probe	13	{ enabled=true, type="HTTP", path="/health", initial_delay_seconds=60, timeout_seconds=5, period_seconds=10, failure_threshold=12 }	Long startup probe — allows up to 180s for Superset initialisation.
liveness_probe	13	{ enabled=true, type="HTTP", path="/health", initial_delay_seconds=30, timeout_seconds=5, period_seconds=30, failure_threshold=3 }	Liveness probe.
uptime_check_config	13	{ enabled=true, path="/health" }	Cloud Monitoring uptime check.

Note on startup probe: initial_delay_seconds=60 and failure_threshold=12 give Superset up to 180 seconds of total startup tolerance. This accommodates the Gunicorn worker pool initialisation and first database connection setup.

---

8. Integrations

A. Redis Cache

Redis is disabled by default (enable_redis = false). For production deployments with multiple users, enabling Redis as the Celery broker and result backend is recommended.

Variable	Group	Default	Description
enable_redis	21	false	Enables Redis. Recommended for production multi-user deployments.
redis_host	21	""	Redis server hostname or IP.
redis_port	21	6379	Redis TCP port (number, not string in CloudRun variant).

Note: redis_port in Superset CloudRun is a number type (default 6379), unlike the string type in Superset GKE (default "6379").

B. Email (SMTP)

Configure SMTP for alert and report notifications via environment_variables.

---

9. Platform-Managed Behaviours

Behaviour	Implementation	Detail
50-char secret key	Auto-generated by Superset Common	SUPERSET_SECRET_KEY is a 50-char random string (special=false). Changing it invalidates all sessions.
Two-phase init	db-init + app-init jobs	db-init creates the database; app-init runs migrations and creates admin. Both run automatically.
psycopg2-binary in Dockerfile	Superset Common Dockerfile	The bundled Dockerfile pre-installs psycopg2-binary for PostgreSQL connectivity, which requires native library build at image creation time.
PostgreSQL 15	database_type = "POSTGRES_15" fixed in Superset Common	PostgreSQL is the supported metadata database.
Port 8088	container_port = 8088	Superset's Gunicorn default port.
Extended timeout	timeout_seconds = 600	Long-running SQL queries and dashboard renders can exceed 5 minutes.
superset-data bucket	Superset Common provisions automatically	GCS bucket for chart exports and report outputs.
Unix socket default	enable_cloudsql_volume = true	Connects to Cloud SQL via the Auth Proxy Unix socket.

---

10. Variable Reference

Variable	Group	Default	Description
module_description	0	(Superset platform text)	Platform metadata.
credit_cost	0	50	Deployment credit cost.
enable_purge	0	true	Permits full deletion on destroy.
project_id	1	—	GCP project ID. Required.
tenant_deployment_id	1	'demo'	Resource name suffix.
support_users	1	[]	Monitoring alert email addresses.
resource_labels	1	{}	Labels for all resources.
application_name	2	'superset'	Base resource name.
display_name	2	'Superset'	Human-readable name.
description	2	'Apache Superset data visualisation platform'	Service description.
application_version	2	'latest'	Superset image tag.
deploy_application	3	true	Infrastructure-only when false.
container_image_source	3	'custom'	'custom' or 'prebuilt'.
container_image	3	""	Image URI override.
cpu_limit	3	'2000m'	CPU per instance.
memory_limit	3	'2Gi'	Memory per instance.
container_port	3	8088	Superset's Gunicorn port.
execution_environment	3	'gen2'	Cloud Run execution environment.
timeout_seconds	3	600	Max request duration (600s for long queries).
enable_cloudsql_volume	3	true	Cloud SQL Auth Proxy sidecar.
min_instance_count	3	1	Minimum Cloud Run instances.
max_instance_count	3	5	Maximum Cloud Run instances.
traffic_split	3	[]	Traffic allocation.
ingress_settings	4	'all'	Traffic source restrictions.
vpc_egress_setting	4	'PRIVATE_RANGES_ONLY'	VPC egress.
enable_iap	4	false	Identity-Aware Proxy.
iap_authorized_users	4	[]	IAP access list.
iap_authorized_groups	4	[]	IAP group access.
environment_variables	5	{}	Additional env vars.
secret_environment_variables	5	{}	Additional Secret Manager references. SUPERSET_SECRET_KEY is auto-injected.
backup_schedule	6	'0 2 * * *'	Backup cron schedule.
backup_retention_days	6	7	Backup retention days.
enable_backup_import	6	false	One-time restore on apply.
enable_cicd_trigger	7	false	Cloud Build GitHub trigger.
github_repository_url	7	""	GitHub repository URL.
github_token	7	""	GitHub PAT. Sensitive.
enable_cloud_deploy	7	false	Cloud Deploy pipeline.
enable_binary_authorization	7	false	Image attestation.
enable_cloud_armor	9	false	Cloud Armor WAF.
admin_ip_ranges	9	[]	WAF-exempt CIDR ranges.
application_domains	9	[]	Custom domains.
enable_cdn	9	false	Cloud CDN.
storage_buckets	10	[{ name_suffix = "data" }]	Additional GCS buckets.
gcs_volumes	10	[]	GCS Fuse mounts.
db_name	11	'superset_db'	PostgreSQL database name.
db_user	11	'superset_user'	PostgreSQL user.
database_password_length	11	32	Password length.
enable_auto_password_rotation	11	false	Automated password rotation.
initialization_jobs	12	[]	Init jobs. Empty uses default two-phase pipeline.
cron_jobs	12	[]	Recurring scheduled jobs.
startup_probe	13	{ path="/health", initial_delay_seconds=60, failure_threshold=12, ... }	Startup probe.
liveness_probe	13	{ path="/health", initial_delay_seconds=30, ... }	Liveness probe.
uptime_check_config	13	{ enabled=true, path="/health" }	Uptime check.
enable_redis	21	false	Redis. Recommended for production.
redis_host	21	""	Redis hostname/IP.
redis_port	21	6379	Redis port (number).
enable_vpc_sc	22	false	VPC Service Controls.
enable_audit_logging	22	false	Cloud Audit Logs.

---

11. Outputs

Output	Description
service_name	Name of the Cloud Run service.
service_url	Public URL of the Cloud Run service.
service_location	GCP region.
project_id	GCP project ID.
deployment_id	Deployment ID suffix.
database_instance_name	Name of the Cloud SQL PostgreSQL 15 instance.
database_name	Application database name.
database_user	Application database user.
database_password_secret	Secret Manager secret name for the database password.
storage_buckets	Created GCS storage buckets.
container_image	Container image used.
cicd_enabled	Whether the CI/CD pipeline is enabled.

Configuration Pitfalls & Sensible Defaults

Risk levels: Critical (data loss, full outage, security breach) — High (service unavailable or significant degradation) — Medium (degraded function or increased cost) — Low (minor impact).

Variable	Sensible Default	Risk	Consequence of Incorrect Value
SUPERSET_SECRET_KEY (via Secret Manager)	Auto-generated 50-char random string	Critical	The module auto-generates a secret key and injects it as SUPERSET_SECRET_KEY. If this value is changed or the secret is rotated, all existing user sessions are immediately invalidated and all encrypted database credentials stored in Superset (connected data sources) become permanently unreadable. Treat as immutable after first deploy.
container_resources.cpu_limit	"2000m"	High	Superset's Python/Flask stack is CPU-intensive at startup. Under 1000m the superset db upgrade migration step (run by the app-init job) times out, leaving the database in a partially migrated state.
container_resources.memory_limit	"2Gi"	High	Under 1 Gi the gunicorn workers are OOM-killed during heavy query execution. "2Gi" is the minimum; "4Gi" is recommended for production with many concurrent users.
SUPERSET_PORT	"8088" (injected in superset.tf)	High	Hardcoded by the module to match container_port. Overriding to a different value without also changing container_port causes health checks and routing to fail entirely.
container_port	8088	High	Must match SUPERSET_PORT. Changing one without the other causes a port mismatch between the Cloud Run health check target and the gunicorn bind address.
enable_redis	false	High	Without Redis, async query execution (Celery workers), dashboard cache warming, and result backend are all disabled. Superset falls back to synchronous execution, which blocks gunicorn workers on long-running queries and can cause a full service hang under moderate load. Always set enable_redis = true for production.
redis_host	null	High	Required when enable_redis = true. Injected as REDIS_HOST and REDIS_PORT into the runtime environment. An empty value causes all Celery workers to fail to connect on startup.
SUPERSET_LOAD_EXAMPLES	"no" (injected in superset.tf)	Medium	If overridden to "yes", Superset loads example dashboards and datasets into the database on every startup, increasing init time significantly and polluting the workspace with demo data.
application_database_name	"superset"	High	Changing after the database is initialised orphans the Superset application schema including all dashboards, charts, and database connections. Immutable after first apply.
application_database_user	"superset"	High	The database user is created in the db-init job. Renaming requires manual Cloud SQL intervention. Immutable after first apply.
application_version	"latest"	Medium	Pinning to a specific version is strongly recommended for production. "latest" triggers uncontrolled upgrades on every container rebuild, which may introduce breaking changes to the Superset config API or require new migration steps that the app-init job must handle.
min_instance_count	1	High	Scale-to-zero causes Celery workers to shut down; any async queries scheduled while the container is cold will be lost. Superset itself has a 30–60 s startup time.
max_instance_count	1 (check your setting)	Medium	Multiple Superset instances share PostgreSQL but need Redis as a shared result backend for Celery. Without Redis, running max_instance_count > 1 causes async query results to be unavailable to the instance that did not execute the query.
enable_cloudsql_volume	true	Critical	Required for the Cloud SQL Auth Proxy sidecar. Disabling causes all PostgreSQL connections to fail.
ingress_settings	"all"	High	Leaves the Superset UI accessible from the public internet. For internal BI tools, set to "internal-and-cloud-load-balancing".
enable_iap	false	High	Without IAP, Superset's login form is publicly reachable. Always enable IAP or restrict ingress for production deployments.
timeout_seconds	300	Medium	Superset complex SQL queries can run for several minutes. Reducing below 120 s causes long-running analytical queries to be aborted mid-execution.
backup_schedule	"0 2 * * *"	Medium	Disabling automated backups leaves all dashboards, charts, database connection configs, and RLS rules unprotected.
enable_auto_password_rotation	false	Medium	Enabling without sufficient rotation_propagation_delay_sec causes brief intervals of DB connectivity failures during the rotation window.
startup_probe.failure_threshold	30	High	Reducing below 15 causes Cloud Run to kill the container before the app-init job migrations complete and Superset first boots.
db_tier	"db-f1-micro" (Common default)	Medium	The Common module defaults to "db-f1-micro" for Cloud SQL. This is insufficient for production Superset workloads with concurrent users. Override to at least "db-custom-2-7680" in production.

Destroying Resources

When destroying a Cloud Run deployment, you may encounter:

Error: Error waiting for Subnetwork to be deleted: The following serverless IPv4 address(es) on subnet ... are still in use.

Resolution: Wait 20–30 minutes and re-run tofu destroy. GCP holds serverless IPv4 addresses asynchronously after Cloud Run service deletion.
