Mattermost GKE Module — Configuration Guide

This guide describes every configuration variable available in the Mattermost_GKE module. Mattermost_GKE is a wrapper module that combines the generic App_GKE infrastructure module with the Mattermost_Common shared application configuration to deploy Mattermost — an open-source, self-hostable team messaging and collaboration platform — on Google Kubernetes Engine (GKE) Autopilot.

Most configuration options in Mattermost GKE map directly to the same options in App GKE. Where a variable is identical in behaviour, this guide references the App GKE guide rather than repeating the same documentation. Only the variables and defaults that are specific to Mattermost are described in full here.

Note: Variables marked as platform-managed are set and maintained by the platform. You do not normally need to change them.

GKE vs Cloud Run: Mattermost maintains persistent WebSocket connections for real-time message delivery. GKE Autopilot is better suited to production Mattermost deployments than Cloud Run because it supports long-lived connections without the per-request timeout constraints of Cloud Run. Use Mattermost GKE for any team-size deployment where real-time reliability is important.

---

Standard Configuration Reference

The following configuration areas are provided by the underlying App_GKE module. Consult the linked sections of the App_GKE Configuration Guide for full documentation.

Configuration Area	App GKE.md Section	Mattermost-Specific Notes
Project & Identity	§2 IAM & Access Control	Identical.
Application Identity	§3.A Compute (GKE Autopilot)	Mattermost-specific defaults; see Group 2: Application Identity.
Runtime & Scaling	§3.A Compute (GKE Autopilot)	Mattermost-specific defaults for container_port, container_resources, and min_instance_count; see Group 3: Runtime & Scaling.
Environment Variables & Secrets	§3 Core Service Configuration	No pre-populated environment variables — Mattermost is configured via site_url and edition; see Group 5: Environment Variables & Secrets.
Networking & Network Policies	§3.D Networking & Network Policies	Identical.
Initialization Jobs & CronJobs	§3.E Initialization Jobs & CronJobs	db-init PostgreSQL job supplied automatically by Mattermost Common; see Group 8: Jobs & Scheduled Tasks.
Additional Services	§3.F Additional Services	Identical.
Storage — NFS	§3.C Storage (NFS / GCS / GCS Fuse)	enable_nfs defaults to false; see Group 9: Storage & Filesystem — NFS.
Storage — GCS	§3.C Storage (NFS / GCS / GCS Fuse)	GCS Fuse volumes preferred for /mattermost/data; see Group 10: Storage & Filesystem — GCS.
Database Configuration	§3.B Database (Cloud SQL)	PostgreSQL 15 required; see Group 11: Database Configuration.
Backup Schedule & Retention	§3.B Database (Cloud SQL)	Identical.
Custom SQL Scripts	§3.E Initialization Jobs & CronJobs	Identical.
Observability & Health Checks	§3.A Compute (GKE Autopilot)	Mattermost exposes /api/v4/system/ping; see Group 13: Observability & Health.
Cloud Armor WAF	§4.A Cloud Armor WAF	Identical.
Identity-Aware Proxy	§4.B Identity-Aware Proxy (IAP)	Identical.
Binary Authorization	§4.C Binary Authorization	Identical.
VPC Service Controls	§4.D VPC Service Controls	Identical.
Secrets Store CSI Driver	§4.E Secrets Store CSI Driver	Always enabled — no configuration required.
Traffic & Ingress	§5 Traffic & Ingress	Identical.
CDN	§5.B CDN	Identical.
Custom Domain & Static IP	§5.C Static IP Reservation	Mattermost site_url must match; see Group 16: Custom Domain & Static IP.
Cloud Build Triggers	§6.A Cloud Build Triggers	Identical.
Cloud Deploy Pipeline	§6.B Cloud Deploy Pipeline	Identical.
Image Mirroring	§6.C Image Mirroring	Identical.
Pod Disruption Budgets	§7.A Pod Disruption Budgets	Identical.
Topology Spread Constraints	§7.B Topology Spread Constraints	Identical.
Resource Quotas	§7.C Resource Quotas	Identical.
Auto Password Rotation	§7.D Auto Password Rotation	See Group 11: Database Configuration.
Redis Cache	§8.A Redis / Memorystore	enable_redis defaults to false; recommended for multi-replica; see Group 15: Redis Cache.
Backup Import	§8.B Backup Import	Exposes both backup_uri (full GCS URI or Drive ID) and backup_file (filename in module backup bucket); see Group 6: Backup & Maintenance.
Service Mesh (ASM)	§8.C Service Mesh (ASM via Fleet)	Identical.
Multi-Cluster Services	§8.D Multi-Cluster Services (MCS)	Identical.

---

How Mattermost GKE Relates to App GKE

Mattermost GKE passes all variables through to App GKE and adds a Mattermost Common sub-module that supplies Mattermost-specific defaults and application configuration. The main effects are:

1. PostgreSQL 15 is required. Mattermost requires PostgreSQL 13 or later. The database_type default is set to "POSTGRES_15".
2. A db-init job runs on first deployment. Mattermost Common supplies a default db-init Kubernetes Job that creates the Mattermost PostgreSQL database and user. Mattermost then runs its own schema migrations on first startup — no manual schema setup is needed.
3. No pre-populated environment variables. Unlike Ghost, Mattermost does not require SMTP defaults injected by the module. Key settings — site URL, edition, Redis — are controlled by dedicated top-level variables (site_url, edition, enable_redis).
4. Edition selection controls the container image. Setting edition = "enterprise" automatically switches the container image to mattermost/mattermost-enterprise-edition. The default ("team") uses mattermost/mattermost-team-edition. Enterprise Edition requires a paid licence key provided via environment_variables.
5. GCS Fuse is preferred over NFS for file storage. enable_nfs defaults to false. Mattermost file uploads and attachments are stored on GCS volumes mounted via the CSI GCS Fuse driver at /mattermost/data. This provides durable, multi-replica-safe storage without provisioning a Filestore instance.
6. Resource defaults are sized for Mattermost. The default cpu_limit (2 vCPU) and memory_limit (4 Gi) accommodate Mattermost's concurrent WebSocket handling, channel caching, and message indexing.
7. Redis is optional but recommended for multi-replica deployments. enable_redis defaults to false. Enabling Redis provides distributed session and cache storage, which is required for correct behaviour across more than one pod replica.
8. Health probes use Mattermost's dedicated ping endpoint. Both startup_probe and liveness_probe default to path = "/api/v4/system/ping" — Mattermost's built-in health endpoint that returns HTTP 200 when the server is ready to accept connections.
9. site_url must be set for correct link generation. Mattermost uses MM_SERVICESETTINGS_SITEURL for notification emails, in-app link generation, and OAuth redirects. The site_url variable sets this automatically.

---

Group 1: Project & Identity

Identical to App_GKE. See App_GKE.

Mattermost GKE-specific additions in this group:

Variable	Default	Description
region	"us-central1"	GCP region for resource deployment. Used as a fallback when VPC subnet discovery cannot determine the region. Also used as the default location for GCS buckets provisioned for Mattermost file storage.
site_url	""	The public URL where Mattermost is accessible (e.g., "https://chat.example.com"). Sets MM_SERVICESETTINGS_SITEURL. Required for correct link generation in notification emails, OAuth redirects, and in-app deep links. Leave empty only for initial infrastructure provisioning before a domain is assigned.
edition	"team"	Mattermost edition. "team" deploys the free Team Edition. "enterprise" deploys Enterprise Edition and requires a licence key supplied via environment_variables. Changing this value after initial deployment replaces the container image on the next apply.

---

Group 2: Application Identity

These variables behave identically to App_GKE. See App_GKE for descriptions.

Mattermost-specific defaults:

Variable	Mattermost GKE Default	App GKE Default	Notes
application_name	"mattermost"	"gkeapp"	Used as the base name for all GCP and Kubernetes resources. Do not change after deployment.
application_display_name	"Mattermost"	"App GKE Application"	Shown in the platform UI and dashboards. Can be changed freely.
application_description	"Mattermost - Open-source team messaging on GKE Autopilot"	"App GKE Custom Application…"	Descriptive label. Can be changed freely.
application_version	"9.11.2"	"1.0.0"	The Mattermost release version to build and deploy. Incrementing this value triggers a new Cloud Build run.

---

Group 3: Runtime & Scaling

Most variables behave identically to App_GKE. See App_GKE Group 3.

Mattermost-specific defaults and behaviour:

Variable	Mattermost GKE Default	App GKE Default	Notes
container_port	8065	8080	Mattermost's native HTTP port. Do not change unless your custom Dockerfile binds Mattermost to a different port.
container_resources	{ cpu_limit = "2000m", memory_limit = "4Gi" }	{ cpu_limit = "1000m", memory_limit = "512Mi" }	Mattermost handles concurrent WebSocket connections, channel caching, and message indexing. 2 vCPU and 4 Gi are the recommended production minimums.
min_instance_count	1	0	Mattermost maintains persistent WebSocket connections. Scale-to-zero drops active user sessions. Keep at 1 or higher for any deployment with active users.
max_instance_count	5	3	Higher ceiling to accommodate traffic spikes during large team communication bursts.
container_image_source	"custom"	"custom"	Mattermost Common supplies a Dockerfile-based build by default. Set to "prebuilt" to deploy a pre-built image URI directly.
enable_cloudsql_volume	false	true	Mattermost GKE connects to Cloud SQL over a private TCP connection rather than via a Unix socket sidecar by default. Set to true to inject the Cloud SQL Auth Proxy sidecar.
timeout_seconds	300	300	For WebSocket-heavy deployments, increase to 3600 to prevent active WebSocket connections from being severed by the backend timeout.
container_protocol	"http1"	"http1"	Mattermost uses HTTP/1.1 for its WebSocket upgrade path. Do not change to "h2c" unless your Mattermost configuration explicitly supports HTTP/2.

The remaining runtime variables (deploy_application, container_image, container_build_config, enable_image_mirroring, enable_vertical_pod_autoscaling, service_annotations, service_labels, cloudsql_volume_mount_path) behave as described in App_GKE Group 3.

---

Group 4: Access & Networking

These variables behave identically to App_GKE. See App_GKE, App_GKE, and App_GKE.

Note: The ingress_settings and vpc_egress_setting variables appear in Mattermost GKE's variable definitions but are not passed through to App GKE. Setting these variables has no effect on the deployed infrastructure in the current implementation.

The following networking variables are available in Mattermost GKE:

Variable	Default	Description
enable_iap	false	Enables Identity-Aware Proxy authentication on the load balancer.
iap_authorized_users	[]	Individual users or service accounts granted IAP access.
iap_authorized_groups	[]	Google Groups granted IAP access.
iap_oauth_client_id	""	OAuth client ID for IAP configuration.
iap_oauth_client_secret	""	OAuth client secret for IAP configuration.
iap_support_email	""	Support email shown on the Google OAuth consent screen.
enable_custom_domain	true	Configures Ingress/Gateway for custom domain routing with managed SSL certificates.
application_domains	[]	Custom domain names (e.g. ["chat.example.com"]).
reserve_static_ip	true	Reserves a Global Static IP for the load balancer.
static_ip_name	""	Name for the reserved IP; auto-generated if blank.
network_tags	["nfsserver"]	Firewall tags applied to GKE cluster nodes.
enable_cloud_armor	false	Enables a Cloud Armor WAF security policy.
admin_ip_ranges	[]	Admin CIDR ranges permitted through Cloud Armor.
cloud_armor_policy_name	"default-waf-policy"	Name of the Cloud Armor security policy to attach.
enable_vpc_sc	false	Enables VPC Service Controls perimeter enforcement.

---

Group 5: Environment Variables & Secrets

These variables behave identically to App_GKE. See App_GKE.

Mattermost-specific behaviour:

Mattermost GKE does not pre-populate environment_variables with Mattermost settings. Mattermost configuration is controlled via three mechanisms:

1. site_url sets MM_SERVICESETTINGS_SITEURL automatically via Mattermost Common.
2. edition selects the container image (team or enterprise) automatically.
3. environment_variables accepts any additional Mattermost environment variables (using the MM_ prefix convention).

Enterprise Edition licence key:

When edition = "enterprise", supply the licence key via environment_variables:

environment_variables = {
  MM_LICENSE = "your-mattermost-enterprise-licence-key"
}

Common Mattermost environment variable overrides:

Variable	Purpose
MM_EMAILSETTINGS_SMTPSERVER	SMTP server for email notifications.
MM_EMAILSETTINGS_SMTPPORT	SMTP port (e.g., "587").
MM_EMAILSETTINGS_SMTPUSERNAME	SMTP authentication username.
MM_EMAILSETTINGS_SMTPPASSWORD	SMTP authentication password.
MM_EMAILSETTINGS_ENABLESMTPAUTH	"true" to enable SMTP authentication.
MM_EMAILSETTINGS_FEEDBACKEMAIL	From address for notification emails.
MM_SERVICESETTINGS_ENABLEDEVELOPER	"false" for production (disables developer mode).

The remaining secrets variables (secret_environment_variables, secret_rotation_period, secret_propagation_delay, manage_storage_kms_iam) behave as described in App_GKE.

---

Group 6: Backup & Maintenance

These variables behave identically to App_GKE. See App_GKE.

Mattermost-specific defaults:

Variable	Default	Notes
backup_schedule	"0 2 * * *"	Daily at 02:00 UTC. Adjust to match your Recovery Point Objective and traffic patterns.
backup_retention_days	7	7-day retention. Increase for production deployments (30–90 days recommended).

Backup Import — Mattermost GKE supports importing an existing backup on first deployment:

Variable	Default	Description
enable_backup_import	false	When true, runs a one-time import job during deployment to restore the backup specified by backup_uri. Configure backup_source, backup_uri, and backup_format before enabling.
backup_source	"gcs"	Source system for the backup file. "gcs" imports from a Cloud Storage URI; "gdrive" imports from a Google Drive file ID.
backup_uri	""	Full GCS URI ("gs://my-bucket/backups/mattermost.sql") or Google Drive file ID.
backup_file	"backup.sql"	Filename of a backup stored in the module's automatically created backups GCS bucket. An alternative to backup_uri for backups already placed in the module-managed bucket.
backup_format	"sql"	Format of the backup file. Supported values: sql, tar, gz, tgz, tar.gz, zip, auto.

---

Group 7: CI/CD & GitHub Integration

Identical to App_GKE. See App_GKE.

The following CI/CD variables are available: enable_cicd_trigger, github_repository_url, github_token, github_app_installation_id, cicd_trigger_config, enable_cloud_deploy, cloud_deploy_stages, enable_binary_authorization, binauthz_evaluation_mode (default "ALWAYS_ALLOW"; options: ALWAYS_ALLOW, REQUIRE_ATTESTATION, ALWAYS_DENY).

---

Group 8: Jobs & Scheduled Tasks

These variables behave as described in App_GKE, with one important Mattermost-specific behaviour.

Mattermost default db-init job:

When initialization_jobs is left as the default (empty list []), Mattermost Common automatically supplies a db-init job:

Field	Value
Job name	db-init
Image	PostgreSQL client image
Purpose	Creates the Mattermost PostgreSQL database and user; Mattermost then runs its own schema migrations on first startup
CPU / Memory	1000m / 512Mi

Override initialization_jobs with a non-empty list to replace this default with your own jobs. Each custom job must specify at least one of command, args, or script_path.

CronJobs and Additional Services:

The cron_jobs and additional_services variables are available and behave identically to App_GKE. See App_GKE for full documentation.

Note: The cron_jobs schema in Mattermost GKE uses Kubernetes CronJob fields — restart_policy, concurrency_policy, failed_jobs_history_limit, successful_jobs_history_limit, starting_deadline_seconds, suspend — rather than the Cloud Run–style fields used in Mattermost CloudRun. The secret_env_vars field is not available in GKE cron jobs; secrets are managed via secret_environment_variables at the module level.

---

Group 9: Storage & Filesystem — NFS

These variables behave identically to App_GKE. See App_GKE.

Mattermost-specific defaults:

Variable	Default	Notes
enable_nfs	false	NFS storage is disabled by default for Mattermost. GCS Fuse volumes are the preferred storage backend for /mattermost/data because they are durable and multi-replica-safe without the overhead of a Filestore instance. Enable NFS if your deployment requires POSIX filesystem semantics not supported by GCS Fuse (e.g., file locking).
nfs_mount_path	"/mattermost/data"	The path where the NFS volume is mounted inside the Mattermost container. Matches Mattermost's default data directory.

---

Group 10: Storage & Filesystem — GCS

These variables behave identically to App_GKE. See App_GKE Group 9.

Mattermost-specific behaviour:

Mattermost stores team uploads, file attachments, and plugin data under /mattermost/data. The recommended approach for Mattermost GKE is to provision a GCS bucket and mount it via the GCS Fuse CSI driver:

create_cloud_storage = true

storage_buckets = [
  {
    name_suffix    = "mattermost-data"
    storage_class  = "STANDARD"
    force_destroy  = false
    versioning_enabled = true
  }
]

gcs_volumes = [
  {
    name       = "mattermost-data"
    mount_path = "/mattermost/data"
    readonly   = false
    mount_options = ["implicit-dirs", "stat-cache-ttl=60s", "type-cache-ttl=60s"]
  }
]

Unlike Ghost GKE, Mattermost Common does not automatically provision a GCS bucket. You must define storage_buckets and gcs_volumes explicitly if you want GCS-backed file storage.

The create_cloud_storage, storage_buckets, and gcs_volumes variables behave as described in App_GKE Group 9.

---

Group 11: Database Configuration

These variables behave identically to App_GKE. See App_GKE.

Mattermost-specific defaults and restrictions:

Variable	Mattermost GKE Default	App GKE Default	Notes
database_type	"POSTGRES_15"	"POSTGRES"	Mattermost requires PostgreSQL 13 or later. Do not change to MySQL or SQL Server — Mattermost will not start.
application_database_name	"mattermost"	"gkeappdb"	PostgreSQL database name for Mattermost. Do not change after deployment — this is passed directly to Mattermost Common as db_name.
application_database_user	"mattermost"	"gkeappuser"	PostgreSQL user for Mattermost. Do not change after deployment — passed to Mattermost Common as db_user.

Important: application_database_name and application_database_user are passed through to Mattermost Common as db_name and db_user. Unlike Ghost GKE, there are no separate db_name/db_user shorthand variables in Mattermost GKE — application_database_name and application_database_user serve both purposes.

Cloud SQL instance discovery:

Variable	Default	Description
sql_instance_name	""	Name of an existing Cloud SQL instance to use. Leave empty to auto-discover a Services GCP-managed instance or create an inline instance.
sql_instance_base_name	"app-sql"	Base name for the inline Cloud SQL instance when no existing instance is found. Deployment ID is appended.

PostgreSQL extensions:

Mattermost does not require custom PostgreSQL extensions by default, but the module exposes extension management variables for advanced deployments:

Variable	Default	Description
enable_postgres_extensions	false	Enables installation of PostgreSQL extensions after provisioning.
postgres_extensions	[]	List of PostgreSQL extensions to install (e.g., ["pg_trgm", "btree_gin"]).

Automatic password rotation is also supported:

Variable	Default	Description
enable_auto_password_rotation	false	Deploys an automated database password rotation job. When true, the database password is rotated on the schedule defined by secret_rotation_period and GKE pods are restarted to pick up the new credential.
rotation_propagation_delay_sec	90	Seconds to wait after rotation before restarting pods, to allow Secret Manager replication to complete.

---

Group 12: Custom SQL Scripts

Identical to App_GKE. See App_GKE.

---

Group 13: Observability & Health

These variables behave identically to App_GKE. See App_GKE.

Mattermost-specific defaults:

Mattermost exposes a dedicated health endpoint at /api/v4/system/ping that returns HTTP 200 and a JSON status body when the server is fully initialised and ready to accept connections. Both probe variable sets default to this path.

Health probe routing

Mattermost GKE exposes two parallel sets of probe variables:

Variable set	Passed to	Configures
startup_probe, liveness_probe	Mattermost Common sub-module	The application container's Kubernetes probe spec
startup_probe_config, health_check_config	App GKE directly	The App GKE-standard probe configuration for load balancer health checks

These are parallel paths, not aliases. Changing startup_probe does not affect startup_probe_config.

Startup probe (startup_probe → Mattermost Common):

Field	Mattermost Default	App GKE Default	Notes
path	"/api/v4/system/ping"	"/healthz"	Mattermost's built-in readiness endpoint.
initial_delay_seconds	60	10	Mattermost runs PostgreSQL migrations on first startup, which may take 30–60 seconds for large databases.
failure_threshold	30	3	Allows up to 7.5 minutes of startup time (30 × 15s). Sufficient for fresh deployments with schema migration.
period_seconds	15	10	—

Liveness probe (liveness_probe → Mattermost Common):

Field	Mattermost Default	App GKE Default	Notes
path	"/api/v4/system/ping"	"/healthz"	Same as startup probe.
initial_delay_seconds	60	15	Gives Mattermost additional time to stabilise after the startup probe passes.
period_seconds	30	30	—
failure_threshold	3	3	—

App GKE-standard probes (startup_probe_config, health_check_config → App GKE):

Variable	Mattermost Default	Notes
startup_probe_config	{ enabled = true, path = "/", initial_delay_seconds = 120, failure_threshold = 15 }	Override path to "/api/v4/system/ping" for accurate Mattermost health checking.
health_check_config	{ enabled = true, path = "/" }	Override path to "/api/v4/system/ping" for accurate Mattermost health checking.

uptime_check_config: Defaults to { enabled = false, path = "/" } — uptime checks are disabled by default. Enable and set path = "/api/v4/system/ping" for production monitoring.

Prometheus metrics: Mattermost exposes Prometheus metrics on port 8067. These are not scraped automatically by this module but can be consumed by Cloud Monitoring using a custom metrics exporter or a Prometheus-to-Cloud-Monitoring integration.

---

Group 14: Reliability Policies

Identical to App_GKE. See App_GKE.

Available variables: enable_pod_disruption_budget, pdb_min_available, enable_topology_spread, topology_spread_strict.

Note: enable_pod_disruption_budget defaults to false in Mattermost GKE. Enable it for production deployments where rolling node upgrades must not take all Mattermost pods offline simultaneously.

---

Group 15: Redis Cache

These variables configure Mattermost's optional Redis integration. The underlying Redis infrastructure support is provided by App_GKE (see App_GKE); the variables below are Mattermost-specific. Mattermost uses Redis as a distributed cache and session backend — required for correct behaviour across more than one pod replica.

Note: enable_redis defaults to false in Mattermost GKE. This is safe for single-replica deployments. For any deployment with min_instance_count > 1 or horizontal scaling, Redis must be enabled.

Variable	Default	Options / Format	Description & Implications
enable_redis	false	true / false	Enables Redis as Mattermost's distributed cache and session backend. When false, Mattermost uses an in-process cache — requests routed to different pod replicas will not share session state, causing intermittent authentication failures under load. Required for multi-replica deployments.
redis_host	""	Hostname or IP address	The hostname or IP address of the Redis server. Leave blank to use the automatically discovered NFS server IP (the platform's default co-hosted Redis). Override with an explicit IP or hostname when using a dedicated Redis instance such as Google Cloud Memorystore. Example: "10.128.0.10".
redis_port	"6379"	Port number string	TCP port for the Redis server. The default 6379 is the standard Redis port. Change only if your Redis instance is configured to listen on a non-standard port.
redis_auth	""	String (sensitive)	Authentication password for the Redis server. Leave empty if the Redis instance does not require authentication. For Memorystore instances with AUTH enabled, set this to the instance's AUTH string. Treated as sensitive — not stored in Terraform state in plaintext.

Validating Group 15 Settings

Google Cloud Console:

• Memorystore instance (if used): Navigate to Memorystore → Redis to confirm the instance exists, its IP address, port, and AUTH status.
• Mattermost Redis status: Once deployed, navigate to the Mattermost System Console (Environment → Cache) or review container logs for cache initialisation messages.

gcloud CLI / kubectl:

# List Memorystore Redis instances in the project (if using Memorystore)
gcloud redis instances list \
  --region=REGION \
  --project=PROJECT_ID \
  --format="table(name,host,port,state,memorySizeGb,authEnabled)"

# Confirm Redis environment variables are set in the Mattermost pod
kubectl exec -n NAMESPACE POD_NAME -- env | grep -i redis

# Test Redis connectivity from inside the Mattermost pod
kubectl exec -n NAMESPACE POD_NAME -- \
  nc -zv REDIS_HOST 6379

---

Group 16: Custom Domain & Static IP

Identical to App_GKE. See App_GKE.

Mattermost site_url configuration: Mattermost must know its public URL at startup. When using a custom domain, set site_url to match the domain in application_domains (e.g., site_url = "https://chat.example.com"). Mattermost uses this URL for notification emails, OAuth provider redirects, and in-app link generation — an incorrect site_url causes broken notification links, failed OAuth logins, and incorrect mobile app deep links.

---

Group 17: GKE Backend Configuration

Identical to App_GKE. See App_GKE.

Available variables: gke_cluster_name, namespace_name, workload_type, service_type, session_affinity, enable_multi_cluster_service, configure_service_mesh, enable_network_segmentation, termination_grace_period_seconds, deployment_timeout, gke_cluster_selection_mode (default "primary"), network_name (default ""; auto-discovered when empty), prereq_gke_subnet_cidr (default "10.201.0.0/24").

Session affinity note: session_affinity defaults to "ClientIP". Mattermost uses server-side session tokens. Without session affinity, users can experience intermittent authentication errors when requests are routed to different pod replicas that do not share an in-memory session cache. Keep "ClientIP" unless Redis is enabled with a shared session backend.

Service type: service_type defaults to "LoadBalancer". This provisions an external load balancer. For internal-only Mattermost deployments, change to "ClusterIP" and configure an Ingress separately.

---

Group 18: Stateful Workloads

Identical to App_GKE. See the StatefulSet configuration described in App_GKE.

Setting stateful_pvc_enabled = true automatically resolves workload_type to "StatefulSet". This provides each Mattermost pod with its own dedicated PVC for local storage, as an alternative to GCS Fuse volumes. For most Mattermost deployments, GCS Fuse is preferred over StatefulSet PVCs because GCS provides durability and cross-pod access without size constraints.

Available variables: stateful_pvc_enabled, stateful_pvc_size (default "10Gi"), stateful_pvc_mount_path (default "/data"), stateful_pvc_storage_class (default "standard-rwo"), stateful_headless_service, stateful_pod_management_policy, stateful_update_strategy, stateful_fs_group.

---

Group 19: Resource Quota

Identical to App_GKE. See App_GKE.

Available variables: enable_resource_quota, quota_cpu_requests, quota_cpu_limits, quota_memory_requests, quota_memory_limits, quota_max_pods, quota_max_services, quota_max_pvcs.

Memory quota suffix requirement: quota_memory_requests and quota_memory_limits must use binary unit suffixes (e.g., "8Gi", "4096Mi"). Bare integers are treated as bytes by Kubernetes and will block all pod scheduling.

---

Exploring the Deployment

Google Cloud Console

Workloads: Navigate to Kubernetes Engine → Workloads and filter by namespace (the namespace name is derived from application_name and tenant_deployment_id). The Mattermost Deployment or StatefulSet, the db-init Job, and any configured CronJobs appear here.

Services & Ingress: Navigate to Kubernetes Engine → Services & Ingress to find the Mattermost Service, its external IP address, and any configured Ingress resources. If reserve_static_ip = true, the reserved IP appears under VPC Network → IP Addresses.

Storage: Navigate to Cloud Storage → Buckets and search for buckets prefixed with app and your application_name to find the Mattermost data bucket and the automated backup bucket.

Database: Navigate to SQL to find the Cloud SQL PostgreSQL 15 instance. The instance name follows the pattern app<name><tenant><id>-sql. Click the instance to view connections, query insights, and backup history.

Secrets: Navigate to Security → Secret Manager to view the DB_PASSWORD and other secrets provisioned by the module. Secret names follow the app<name><tenant><id>-* pattern.

Monitoring: Navigate to Monitoring → Dashboards and Monitoring → Alerting to view the uptime checks (if uptime_check_config.enabled = true) and any alert policies configured via alert_policies.

gcloud CLI and kubectl

# Get the GKE cluster credentials
gcloud container clusters get-credentials CLUSTER_NAME \
  --region=REGION \
  --project=PROJECT_ID

# List pods in the Mattermost namespace
kubectl get pods -n NAMESPACE

# Tail Mattermost application logs
kubectl logs -n NAMESPACE -l app=mattermost -f

# Check the db-init job status
kubectl get jobs -n NAMESPACE

# Describe the Mattermost Deployment (or StatefulSet)
kubectl describe deployment mattermost -n NAMESPACE

# Check the external IP assigned to the Service
kubectl get service -n NAMESPACE

# View environment variables injected into the Mattermost pod
kubectl exec -n NAMESPACE POD_NAME -- env | grep MM_

# Check Mattermost health endpoint directly from inside the pod
kubectl exec -n NAMESPACE POD_NAME -- \
  curl -s http://localhost:8065/api/v4/system/ping

# View Cloud SQL instance details
gcloud sql instances describe INSTANCE_NAME \
  --project=PROJECT_ID \
  --format="table(name,databaseVersion,state,ipAddresses)"

# List GCS buckets for this deployment
gcloud storage buckets list \
  --project=PROJECT_ID \
  --filter="name~mattermost"

# View Secret Manager secrets for this deployment
gcloud secrets list \
  --project=PROJECT_ID \
  --filter="name~mattermost"

---

Module Outputs

Mattermost GKE exposes the following Terraform outputs:

Output	Description
service_name	Name of the Kubernetes service
service_url	Service URL
service_external_ip	External IP address of the load balancer
project_id	GCP project ID
deployment_id	Deployment ID suffix
namespace	Kubernetes namespace
database_instance_name	Name of the Cloud SQL instance
database_name	Name of the application database
database_user	Name of the application database user
database_password_secret	Secret Manager secret name for the database password
storage_buckets	Created GCS storage buckets
container_image	Container image used for the deployment
cicd_enabled	Whether the CI/CD pipeline is enabled
github_repository_url	GitHub repository URL connected for CI/CD
kubernetes_ready	true when the GKE cluster endpoint is reachable and all Kubernetes workload resources are deployed. false on the first apply of a new inline cluster — the cluster is created but the endpoint is not yet readable, so Kubernetes resources are skipped. The CI/CD pipeline must re-run apply to complete the deployment.

---

Configuration Pitfalls & Sensible Defaults

Risk levels: Critical (data loss, full outage, security breach) — High (service unavailable or significant degradation) — Medium (degraded function or increased cost) — Low (minor impact).

Variable	Sensible Default	Risk	Consequence of Incorrect Value
project_id	(required)	Critical	No default — deployment fails immediately.
database_type	"POSTGRES_15"	Critical	Mattermost only supports PostgreSQL. Setting to MYSQL_8_0 or NONE causes the db-init job to fail and Mattermost to crash at startup.
application_database_name	"mattermost"	Critical	Immutable after deployment — changing this recreates the database and destroys all Mattermost data (channels, messages, users).
application_database_user	"mattermost"	Critical	Immutable after deployment — changing this recreates the user, invalidates credentials, and breaks Mattermost's database connection.
site_url	""	High	An empty site_url prevents Mattermost from generating correct notification email links, OAuth redirects, and mobile deep links. Configure before inviting users.
edition	"team"	High	Setting "enterprise" without a valid licence key causes Mattermost to start in an unlicensed state and disables enterprise features silently. Provide the key via environment_variables.
enable_redis	false	High	Safe for single-replica deployments. For min_instance_count > 1, in-process session caching causes intermittent authentication failures when requests are load-balanced across pods. Enable Redis for any multi-replica deployment.
min_instance_count	1	High	Setting 0 allows scale-to-zero. Cold starts drop active WebSocket connections, causing users to see disconnection banners and miss real-time messages until reconnection. Keep at 1 for production.
container_resources.memory_limit	"4Gi"	High	Mattermost caches active channels and user sessions in memory. Under-provisioning (below 2Gi) causes OOM kills under moderate team load, especially during bulk message exports or plugin execution.
session_affinity	"ClientIP"	High	Without Redis and without session affinity, admin and user sessions are not shared across pods. Users are effectively logged out on every request that routes to a different replica.
container_port	8065	Critical	Mattermost listens on 8065. Changing this without matching the container's bound port causes all health probes to fail and the pod to enter a restart loop.
timeout_seconds	300	Medium	Mattermost WebSocket connections are long-lived. A 300-second backend timeout causes active connections to be severed regularly. Set to 3600 for WebSocket-heavy deployments.
enable_nfs	false	Medium	NFS is off by default. If gcs_volumes is also not configured, Mattermost file uploads are stored inside the container's ephemeral filesystem and lost on pod restart. Configure GCS Fuse volumes for durable file storage.
create_cloud_storage	false	Medium	No GCS bucket is provisioned automatically by this module. Without create_cloud_storage = true and a gcs_volumes entry, uploaded files are not durable across pod restarts.
stateful_pvc_size	"10Gi"	Medium	For teams actively sharing files and media, 10Gi fills quickly. Provision 50–100 Gi for active teams. PVC size can be expanded but not reduced.
quota_memory_requests / quota_memory_limits	""	Critical (GKE-specific)	Must use binary suffixes (Gi, Mi) when set. Bare integers are treated as bytes and prevent all pods from being scheduled.
backup_retention_days	7	Medium	Too short for active teams. Increase to 30+ days to provide a meaningful recovery window.
enable_cloud_armor	false	Medium	Without Cloud Armor, Mattermost's login page and API endpoints are exposed to brute-force and credential-stuffing attacks. Enable for any publicly reachable deployment.
enable_pod_disruption_budget	false	Medium	Disabled by default. Without a PDB, GKE node upgrades can terminate all Mattermost pods simultaneously, causing a full outage. Enable for production.
startup_probe.failure_threshold	30	High	Mattermost runs PostgreSQL schema migrations on first startup. Reducing failure_threshold below 20 on fresh deployments with large databases can cause Kubernetes to restart the pod before migrations complete, creating a restart loop.
