ClassicPress on GKE Autopilot

ClassicPress is a free, open-source, business-focused CMS — a lightweight fork of WordPress 4.9.x that preserves the classic (pre-Gutenberg) editing experience, with plugins, themes, a media library, and a REST API. This module deploys ClassicPress on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services ClassicPress uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

1. Overview

ClassicPress runs as a single PHP/Apache web workload built from a thin custom image FROM classicpress/classicpress. The deployment wires together a focused set of Google Cloud services:

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	PHP/Apache pod on port 80, 1 vCPU / 2 GiB by default
Workload shape	Kubernetes StatefulSet + block PVC	stateful_pvc_enabled = true auto-resolves workload_type to StatefulSet; a 10Gi standard-rwo (SSD) PVC is mounted at /var/www/html — the whole ClassicPress install (code, plugins, themes, wp-content/uploads) lives on this per-pod volume
Database	Cloud SQL for MySQL 8.0	Fixed — ClassicPress_Common hardcodes database_type = "MYSQL_8_0"
File persistence (secondary)	Cloud Filestore (NFS)	Mounted at /var/lib/classicpress by default (enable_nfs = true) — see the note in Section 3 on what this path is actually used for
Object storage	Cloud Storage	A classicpress-uploads bucket is provisioned automatically but is not mounted into the pod by default
Secrets	Secret Manager	Auto-generated CLASSICPRESS_SALT_SEED (derives the 8 WordPress-style auth keys/salts); database password
Ingress	Cloud Load Balancing	External LoadBalancer with a reserved static IP; custom domain + managed certificate enabled by default

Sensible defaults worth knowing up front:

• MySQL 8.0 is mandatory and hardcoded. ClassicPress_Common's config sets database_type = "MYSQL_8_0" directly; the variant's database_type variable (default null) only takes effect if explicitly overridden, and doing so breaks the MySQL-specific db-init job and entrypoint. Leave it null.
• Custom build, not prebuilt. container_image_source defaults to "custom" — Cloud Build produces a thin image FROM classicpress/classicpress that grafts an entrypoint shim aliasing the Foundation's injected DB_* vars onto ClassicPress's CLASSICPRESS_DB_* and deriving stable auth salts. The stock upstream image is never deployed directly.
• Cloud SQL is reached via the Auth Proxy sidecar on loopback. The variant sets DB_HOST = 127.0.0.1; a cloud-sql-proxy sidecar (enable_cloudsql_volume = true) listens on 127.0.0.1:3306, and the entrypoint aliases the injected DB_* values onto CLASSICPRESS_DB_* (TCP, no SSL needed for MySQL).
• Single replica, StatefulSet by default. min_instance_count = 1, max_instance_count = 1. Each pod gets its own PVC via stateful_pvc_enabled = true (default), so scaling beyond 1 replica would give each pod a separate, unsynced copy of the install rather than a shared one.
• NFS is also enabled by default (enable_nfs = true, mounted at /var/lib/classicpress), but the grafted entrypoint and Dockerfile never reference that path — the actual persistent install lives on the StatefulSet PVC at /var/www/html. See the pitfalls table.
• No auto-install — first login is manual. ClassicPress_Common generates no admin-password secret and sets no auto-install flag. ClassicPress creates its schema and admin account through its own first-run web installer once db-init has provisioned the empty database.
• CLASSICPRESS_SALT_SEED is generated automatically and stored in Secret Manager; the entrypoint derives all 8 WordPress-style AUTH_KEY/SALT values from it deterministically, so cookies and sessions survive pod restarts.
• Startup probe is generous (TCP, 20 retries) to allow time for the upstream image's own entrypoint to populate the empty /var/www/html PVC on first boot.

---

2. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region "$REGION" --project "$PROJECT" and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the ClassicPress workload

ClassicPress runs as a StatefulSet (auto-selected because stateful_pvc_enabled defaults to true), scheduled on Autopilot, which bills for the CPU/memory the pod actually requests. The single replica owns a dedicated standard-rwo (SSD) PVC.

• Console: Kubernetes Engine → Workloads → select the ClassicPress workload for pods, revisions, and events. Kubernetes Engine → Services & Ingress shows the external IP.
• CLI:

  kubectl get statefulset,pods,svc -n "$NAMESPACE" --selector 'app~classicpress' 2>/dev/null || \
    kubectl get statefulset,pods,svc -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" statefulset/<service-name> --tail=100
  kubectl describe pod -n "$NAMESPACE" -l app=<service-name>

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed, and Group 7 for StatefulSet/PVC mechanics.

B. Cloud SQL for MySQL 8.0

ClassicPress stores all application data (posts, pages, users, options, plugin/theme settings) in a managed Cloud SQL for MySQL 8.0 instance. Pods reach it through the Cloud SQL Auth Proxy sidecar on 127.0.0.1:3306; no public IP is exposed. On first deploy the db-init job creates the application database, user, and grants, verifies the app user can connect, then shuts the sidecar down.

• Console: SQL → select the instance for connections, backups, flags, metrics.
• CLI:

  gcloud sql instances list --project "$PROJECT"
  gcloud sql instances describe <instance-name> --project "$PROJECT"
  gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"

The instance name, database, user, and the Secret Manager secret holding the password are all in the Outputs. See App_GKE for the connection model, automated backups, and password rotation.

C. Storage — StatefulSet PVC, NFS, and Cloud Storage

Three distinct storage mechanisms are present. The StatefulSet PVC (10Gi, standard-rwo, mounted at /var/www/html) is the primary and only confirmed persistence path — it holds the entire ClassicPress install, including uploaded media. NFS (Cloud Filestore) is separately mounted at /var/lib/classicpress (enable_nfs = true), but neither the Dockerfile nor the entrypoint shim reference that path — see the pitfalls table. A Cloud Storage bucket (suffix classicpress-uploads) is also provisioned but not wired into the pod as a gcs_volumes mount by default; add an entry to gcs_volumes to use it.

• Console: Kubernetes Engine → Storage → PersistentVolumeClaims; Filestore → Instances; Cloud Storage → Buckets.
• CLI:

  kubectl get pvc -n "$NAMESPACE"
  gcloud filestore instances list --project "$PROJECT"
  gcloud storage buckets list --project "$PROJECT" --filter="name~classicpress-uploads"

See App_GKE Groups 7, 13, and 14 for PVC lifecycle, NFS discovery, and GCS Fuse mount mechanics.

D. Secret Manager

One ClassicPress-specific secret is generated automatically and stored in Secret Manager: CLASSICPRESS_SALT_SEED, a 64-character random seed from which the entrypoint derives all 8 WordPress-style AUTH_KEY/SECURE_AUTH_KEY/ LOGGED_IN_KEY/NONCE_KEY and their matching SALT values (SHA-256 of the seed plus a fixed per-key suffix). The database password is managed separately by the foundation. On GKE, secrets are projected into pods via the Secret Store CSI driver.

• Console: Security → Secret Manager.
• CLI:

  gcloud secrets list --project "$PROJECT" --filter="name~classicpress"
  gcloud secrets versions access latest --secret=<db-password-secret-name> --project "$PROJECT"

See App_GKE for the Secret Store CSI integration and rotation.

E. Networking & ingress

By default the workload is exposed through an external Cloud Load Balancing IP (service_type = LoadBalancer, reserve_static_ip = true so the address survives redeploys), and enable_custom_domain = true provisions an Ingress resource ready for a Google-managed certificate once application_domains is populated.

• Console: Network services → Load balancing; VPC network → IP addresses.
• CLI:

  kubectl get svc,ingress -n "$NAMESPACE"
  gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

F. Cloud Logging & Monitoring

Pod stdout/stderr flow to Cloud Logging; GKE and Cloud SQL metrics flow to Cloud Monitoring. Optional uptime checks and alert policies are available.

• Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
• CLI:

  gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
    --project "$PROJECT" --limit 50

---

3. ClassicPress Application Behaviour

• First-deploy database setup. The db-init job runs db-init.sh using mysql:8.0-debian. It waits for TCP connectivity (or a Cloud SQL socket), idempotently creates the application database, user, and grants, verifies the app user can connect, then gracefully shuts down the Cloud SQL Auth Proxy sidecar (POST /quitquitquit, falling back to SIGKILL). The job is safe to re-run (execute_on_apply = true, max_retries = 3).
• No separate migration job — manual first-run install. There is no auto-install flag for ClassicPress. Once db-init has provisioned the empty database, ClassicPress creates its own schema and admin account through the first-run web installer (/wp-admin/install.php in the upstream image). Visit the service URL after first deploy and complete the installer to set the admin username, password, and email — there is no generated admin-password secret.
• DB env-var aliasing on loopback. The Foundation injects DB_HOST = 127.0.0.1 (the proxy sidecar), DB_PORT, DB_NAME, DB_USER, DB_PASSWORD; ClassicPress reads CLASSICPRESS_DB_*. The grafted entrypoint.sh builds CLASSICPRESS_DB_HOST as host:port (or a localhost:<socket> form if a Cloud SQL socket directory is found) and aliases the rest, before handing off to the upstream docker-entrypoint.sh.
• Auth keys/salts are derived, not stored individually. CLASSICPRESS_SALT_SEED is the only generated secret; the entrypoint computes all 8 CLASSICPRESS_AUTH_KEY / ..._SALT values as sha256(seed-<key-name>), so every restart and every pod (if you ever scale out) agrees on the same values without persisting wp-config.php state.
• The install itself lives on the StatefulSet PVC. The upstream docker-entrypoint.sh writes wp-config.php and copies the ClassicPress application into /var/www/html on first boot — which on this module is a 10Gi standard-rwo block PVC, not ephemeral container storage, so the install (plugins, themes, and wp-content/uploads) survives pod restarts and rescheduling.
• NFS mount path is not referenced by the image or entrypoint.
• Redis is optional and off by default. When enable_redis = true, leaving redis_host empty lets the Foundation's own REDIS_HOST injection (the shared NFS-VM Redis IP when enable_nfs = true) take effect; setting redis_host explicitly points ClassicPress at an external Redis/Memorystore instance instead.
• Health paths. Startup probe is TCP on port 80 with a generous failure_threshold = 20 (first boot copies the whole application onto the empty PVC, which can take time); liveness probe is HTTP GET / with a 300-second initial delay — a 200 (installed site) or a 302 redirect to the installer (fresh site) both count as healthy.
• Inspect the init job and running config:

  kubectl get jobs -n "$NAMESPACE"
  kubectl logs -n "$NAMESPACE" job/<db-init-job-name>
  kubectl exec -n "$NAMESPACE" statefulset/<service-name> -- env | grep CLASSICPRESS_DB

---

4. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform (by their {{UIMeta group=N}} tag, not by the .tf file's section comments, which are occasionally out of sync with the tags). Only settings specific to or notable for ClassicPress are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 3 — Application Identity

Variable	Default	Description
application_name	classicpress	Base name for resources. Do not change after first deploy.
application_version	latest	Maps to the classicpress/classicpress image tag. Tags are PHP-qualified (php8.3-apache, php8.4-apache), not version-qualified; latest resolves to a pinned PHP-qualified tag at build time via the app-specific CLASSICPRESS_VERSION build arg (the generic APP_VERSION build arg the Foundation injects would otherwise silently overwrite it with the literal, non-existent tag "latest").

Group 4 — Runtime & Scaling

Variable	Default	Description
container_image_source	custom	Builds the thin FROM classicpress/classicpress image with the grafted entrypoint shim; required — the stock image cannot alias DB_* on its own.
cpu_limit	1000m	CPU limit for the ClassicPress container. Increase for high-traffic sites or heavy plugins.
memory_limit	2Gi	Memory limit. WordPress-family apps typically need ≥512Mi; more for large media libraries.
min_instance_count / max_instance_count	1 / 1	Keep both at 1 — the StatefulSet PVC is per-pod and not shared.
container_port	80	ClassicPress runs on Apache, port 80.
php_memory_limit	512M	PHP memory limit; must be ≤ memory_limit.
upload_max_filesize / post_max_size	64M	Max upload / POST size; keep post_max_size ≥ upload_max_filesize.
enable_cloudsql_volume	true	Auth Proxy sidecar (loopback) — required on GKE.

Group 6 — GKE Backend & Cluster

Variable	Default	Description
service_type	LoadBalancer	External IP for the ClassicPress UI.
workload_type	null → StatefulSet	Auto-resolved because stateful_pvc_enabled = true.
session_affinity	ClientIP	Sticky routing so a client reaches the same pod.

Group 7 — StatefulSet / PVC

Variable	Default	Description
stateful_pvc_enabled	true	ClassicPress stores its whole install under /var/www/html; enabling this auto-resolves workload_type to StatefulSet.
stateful_pvc_size	10Gi	Per-pod PVC size. Raise for large media libraries.
stateful_pvc_mount_path	/var/www/html	Where the ClassicPress install (code + wp-content/uploads) lives.
stateful_pvc_storage_class	standard-rwo	SSD-backed Balanced PD; draws the SSD_TOTAL_GB regional quota. Override to standard (HDD) if quota-constrained.

Group 10 — Observability & Health

Variable	Default	Description
startup_probe	{ type: TCP, path: "/", failure_threshold: 20, period_seconds: 15 }	Generous threshold — first boot populates the empty PVC with the full application.
liveness_probe	{ type: HTTP, path: "/", initial_delay_seconds: 300 }	A 200 or a 302-to-installer both count as healthy.

Group 13 — Filesystem (NFS)

Variable	Default	Description
enable_nfs	true	Provisions Filestore-backed shared storage; not currently referenced by the entrypoint or Dockerfile — see Section 3.
nfs_mount_path	/var/lib/classicpress	Container mount path for the (currently unused) NFS share.

Group 15 — Redis Cache

Variable	Default	Description
enable_redis	false	Enables ClassicPress's WordPress-style object cache backend.
redis_host	""	Leave empty to fall back to the Foundation's own REDIS_HOST (the NFS-VM Redis IP when enable_nfs = true); set explicitly to use an external Redis/Memorystore instance.

Group 16 — Database Backend

Variable	Default	Description
database_type	null → MYSQL_8_0	Hardcoded in ClassicPress_Common; leave null. Overriding it breaks the MySQL-specific db-init job and entrypoint.
application_database_name	classicpress	Database name. Immutable after first deploy.
application_database_user	classicpress	Application database user; password auto-generated in Secret Manager.

Group 19 — Custom Domain, Static IP & Networking

Variable	Default	Description
enable_custom_domain	true	Provisions an Ingress ready for a managed certificate once application_domains is set.
reserve_static_ip	true	Stable external IP across redeploys.
application_domains	[]	Custom hostnames — empty by default; add one to activate the managed certificate.

All other inputs follow standard App_GKE behaviour.

---

5. Outputs

These values are returned on a successful deployment and are the quickest way to locate and explore the running resources.

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_cluster_ip	In-cluster ClusterIP.
stage_service_cluster_ips	Map of ClusterIPs for stage-specific services.
service_external_ip	External LoadBalancer IP (when a static IP is reserved).
service_url	URL to reach ClassicPress.
database_instance_name	Cloud SQL instance name.
database_name / database_user	Application database name / user.
database_password_secret	Secret Manager secret holding the DB password.
database_host / database_port	DB endpoint (127.0.0.1 via the Auth Proxy) / port.
storage_buckets	Created Cloud Storage buckets (including classicpress-uploads).
network_name / network_exists / regions	VPC network, presence, available regions.
container_image / container_registry	Deployed image and Artifact Registry repo.
monitoring_enabled / monitoring_notification_channels	Monitoring status and channels.
initialization_jobs / db_import_job	Names of the setup (db-init) and (optional) import jobs.
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / cicd_configuration	CI/CD status and details (repo, trigger, registry).
github_repository_url / github_repository_owner / github_repository_name	CI/CD GitHub details.
artifact_registry_repository / cloudbuild_trigger_name / cloudbuild_trigger_id	Registry and build trigger.
kubernetes_ready	Whether the cluster/workload is ready.
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode	VPC-SC status.
audit_logging_enabled / artifact_registry_cmek_enabled	Audit logging and CMEK status.

---

6. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time — a StatefulSet forced alongside a stateless setting, IAP with no authorized identities, quota_memory_* given as bare integers, an out-of-range container_port/backup_retention_days. Invalid configuration fails the plan with a clear, named error before any resource is created, so most mistakes below are caught up front rather than at apply or runtime. ClassicPress also runs its own preconditions (validation.tf) for upload_max_filesize ≤ post_max_size, min_instance_count ≤ max_instance_count, Redis without a host source, IAP without OAuth credentials, and enable_cloudsql_volume with database_type = "NONE".

Setting	Sensible value	Risk	Consequence if wrong
database_type	null (→ MYSQL_8_0)	Critical	ClassicPress_Common's db-init job and entrypoint are MySQL-specific; overriding to a Postgres/SQL Server engine breaks both.
application_database_name / application_database_user	Set once	Critical	Immutable after first deploy; renaming recreates the DB/user and orphans all data.
CLASSICPRESS_SALT_SEED (auto-generated)	Never change	Critical	Changing the seed after first boot invalidates all signed cookies and logged-in sessions.
stateful_pvc_size / stateful_pvc_mount_path	10Gi / /var/www/html	Critical	This PVC holds the entire install (code + uploads) — resizing down or losing the PVC destroys the site; the mount path must match where ClassicPress's entrypoint writes.
max_instance_count	1	High	Each StatefulSet pod gets its own PVC; scaling beyond 1 gives every replica a separate, diverging copy of the site rather than a shared one.
enable_cloudsql_volume	true	High	The Auth Proxy sidecar on 127.0.0.1:3306 is required for DB connectivity on GKE.
enable_nfs	true (but currently unused by the app)	Medium	Provisions and pays for a Filestore instance that the current entrypoint/Dockerfile never mount data onto — see Section 3. Disabling it does not remove any confirmed persistence, but confirm against a live deployment before relying on this.
stateful_pvc_storage_class	standard-rwo (SSD)	Medium	Draws the tight regional SSD_TOTAL_GB quota. Override to standard (HDD pd-standard) on quota-constrained projects — fine for a low-IOPS PHP/MySQL workload.
First-run admin setup	Complete /wp-admin/install.php promptly after deploy	Medium	Until the installer runs, the site has no schema and no admin account — there is no generated admin-password secret to recover with.
memory_limit	2Gi	Medium	Below ~512Mi the PHP/Apache pod risks OOM under load or with heavier plugins.
quota_memory_requests / _limits	binary units (4Gi, 8192Mi)	Critical	Bare integers are treated as bytes and block all pod scheduling in the namespace.
reserve_static_ip	true	Medium	Without it, the external IP can change across redeploys, breaking DNS and any hardcoded site URL.
backup_retention_days	7 (raise for prod)	Medium	Too short for compliance retention.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. ClassicPress-specific application configuration shared with the Cloud Run variant is described in the ClassicPress_Common module (no standalone ClassicPress_Common.md guide exists yet in this docs set).
