AdGuard Home on Google Cloud Run
⚠️ CRITICAL — read before deploying. AdGuard Home's core value is network-wide DNS ad/tracker blocking, which requires clients to query it over DNS on port 53 (TCP+UDP). Cloud Run is HTTP(S)-only ingress and cannot expose raw port 53 under any configuration. This module deploys AdGuard Home's web admin console only (port 3000) for filter-list, custom-rule, and client-settings configuration management. The deployed instance is NOT reachable as a public DNS resolver on Cloud Run. If you need AdGuard Home to actually resolve DNS queries for real clients, this module (as currently scoped) cannot do that — see §6 Configuration Pitfalls for the full explanation and the (out-of-scope) workaround this module does not implement.
AdGuard Home is an open-source, GPL-3.0-licensed, network-wide DNS server that blocks ads and trackers at the DNS level and includes parental controls. It is a Go static binary with no external database — all configuration lives in a flat YAML file written by its own first-run setup wizard. This module deploys AdGuard Home's web admin console on Cloud Run v2 on top of the App_CloudRun foundation, which provisions and manages the shared Google Cloud infrastructure.
This guide focuses on the cloud services AdGuard Home uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics common to every Cloud Run application — service identity, ingress and load balancing, scaling and concurrency, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, and the deployment lifecycle — refer to the App_CloudRun foundation guide rather than repeating them here.
1. Overview
AdGuard Home runs as a single Go static-binary container on Cloud Run v2. The deployment wires together a focused set of Google Cloud services:
| Capability | Google Cloud service | Notes |
|---|---|---|
| Compute | Cloud Run v2 | Single Go binary, 1 vCPU / 512 MiB by default, serverless autoscaling; scale-to-zero by default |
| Database | None | AdGuard Home has no external database — configuration is a flat YAML file |
| Object storage | Cloud Storage (×2, GCS Fuse) | conf bucket (config) and work bucket (query log/stats), both mounted as filesystem volumes |
| Secrets | Secret Manager | None generated — the admin credential is set through AdGuard Home's own first-run web wizard |
| Ingress | Cloud Run URL / Cloud Load Balancing | Default run.app URL (web admin console only — see the CRITICAL note above); optional external HTTPS load balancer + custom domain |
Sensible defaults worth knowing up front:
- This deployment is a configuration-management console, not a DNS resolver. Cloud Run cannot expose raw DNS (port 53 TCP/UDP). Do not point real DNS clients at this deployment's URL or IP.
- No external database.
database_type = "NONE"and must not be changed. - Two GCS Fuse volumes are pre-wired and provisioned automatically —
confat/opt/adguardhome/confandworkat/opt/adguardhome/work— so configuration and query-log/stats persist across restarts and cold starts. You do not need to setgcs_volumesyourself. container_port = 3000— AdGuard Home's setup wizard is hardcoded to listen on port 3000 untilAdGuardHome.yamlexists. If you change the web UI's own port during the setup wizard, keep it at 3000 or the platform's health probe and public URL will stop matching what the container listens on.- Scale-to-zero by default (
cpu_always_allocated = false,min_instance_count = 0). This is a plain request/response admin console in this deployment shape, so idle cost is minimal. - No pre-seeded admin credential. AdGuard Home's own first-run setup wizard, served at the deployment URL, is where you set the admin username/password — nothing is injected by the platform.
2. Google Cloud Services & How to Explore Them
All commands assume PROJECT and REGION are set. Service and resource names
are reported in the deployment Outputs.
A. Cloud Run — the AdGuard Home web admin console
AdGuard Home runs as a Cloud Run v2 service that autoscales by request load between the minimum and maximum instance counts.
- Console: Cloud Run → select the service for revisions, traffic, logs, and metrics.
- CLI:
gcloud run services list --project "$PROJECT" --region "$REGION"
gcloud run services describe <service-name> --project "$PROJECT" --region "$REGION"
gcloud run revisions list --service <service-name> --project "$PROJECT" --region "$REGION"
See App_CloudRun for scaling, concurrency, execution environment, and traffic splitting.
B. Cloud Storage (GCS Fuse) — config and query-log/stats
AdGuard Home stores its entire configuration in a flat YAML file
(AdGuardHome.yaml) and its query log / stats database under a separate
directory. Both are backed by dedicated Cloud Storage buckets mounted as GCS
Fuse filesystem volumes — conf and work — provisioned automatically.
- Console: Cloud Storage → Buckets.
- CLI:
gcloud storage buckets list --project "$PROJECT" --filter="name~adguardhome"
gcloud storage ls gs://<conf-bucket>/ # bucket names are in the Outputs
gcloud storage cat gs://<conf-bucket>/AdGuardHome.yaml # inspect the live config
See App_CloudRun for GCS Fuse and CMEK options.
C. Networking & ingress
The service is reachable at its run.app URL by default. This is the web
admin console URL only — it is not a DNS server address. An external HTTPS
load balancer with a custom domain, Cloud CDN, and Cloud Armor can be layered
on for the admin console.
- Console: Cloud Run (service URL); Network services → Load balancing.
- CLI:
gcloud run services describe <service-name> --region "$REGION" --format='value(status.url)'
See App_CloudRun.
D. Cloud Logging & Monitoring
Container logs flow to Cloud Logging; Cloud Run metrics flow to Cloud Monitoring, with optional uptime checks and alert policies.
- Console: Logging → Logs Explorer; Monitoring → Dashboards / Alerting.
- CLI:
gcloud run services logs read <service-name> --project "$PROJECT" --region "$REGION" --limit 50
The entrypoint logs a DNS-scope reminder banner on every boot — visible in the first lines of a fresh revision's log.
3. AdGuard Home Application Behaviour
- No database bootstrap. AdGuard Home has no external database, so there
is no
initialization_jobsdefault — the list is available for operator-supplied custom jobs only. - First-run setup wizard. On first visit to the service URL (before
AdGuardHome.yamlexists), AdGuard Home serves its own setup wizard on port 3000: choose the admin web UI port (keep it 3000), set the admin username/password, and select upstream DNS servers. Nothing here is pre-seeded by the platform. - Health path. Startup and liveness probes target
/— there is no dedicated health endpoint; the root returns200both before and after initial setup. - DNS resolution is not reachable. The container's own internal DNS listener may start, but nothing outside the revision can reach port 53 on Cloud Run. Only the web admin console (the container's exposed HTTP port) is reachable.
- Inspect job execution (if any custom init jobs were added):
gcloud run jobs list --project "$PROJECT" --region "$REGION"
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for AdGuard Home are listed; every other input is inherited from App_CloudRun with its standard behaviour.
Group 1 — Project & Identity
| Variable | Default | Description |
|---|---|---|
project_id | (required) | Target Google Cloud project. |
region | us-central1 | Region for the service and regional resources. |
Group 2 — Deployment Environment
| Variable | Default | Description |
|---|---|---|
tenant_deployment_id | demo | Short suffix that makes resource names unique per environment. |
Group 3 — Application Identity
| Variable | Default | Description |
|---|---|---|
application_name | adguardhome | Base name for resources. Do not change after first deploy. |
application_display_name | AdGuard Home | Human-readable name shown in the Console. |
application_version | latest | Deployment-tracking tag. Maps to the app-specific ADGUARDHOME_VERSION build ARG in the Dockerfile (not the generic APP_VERSION). |
Group 4 — Runtime & Scaling
| Variable | Default | Description |
|---|---|---|
deploy_application | true | Set false to provision infrastructure only. |
cpu_limit | 1000m | CPU per instance. |
memory_limit | 512Mi | Memory per instance. |
min_instance_count | 0 | Scale-to-zero by default. |
max_instance_count | 1 | Single instance — AdGuard Home has no multi-instance coordination concern for its own admin console, but do not scale beyond 1 unless you understand your GCS Fuse write pattern. |
container_port | 3000 | The setup wizard's fixed port. Not DNS port 53. |
cpu_always_allocated | false | Request-based billing — a plain admin-console app needs no background CPU. |
enable_cloudsql_volume | false | Not used — no database. |
Group 5 — Access & Ingress Control
| Variable | Default | Description |
|---|---|---|
ingress_settings | all | Public by default; the admin console has its own login. |
enable_iap | false | Recommended to enable — puts Google identity auth in front of the DNS-filtering policy console. |
Group 6 — Environment Variables & Secrets
| Variable | Default | Description |
|---|---|---|
environment_variables | {} | Rarely needed — AdGuard Home reads config from its own YAML file. |
secret_environment_variables | {} | No platform secrets exist for this app. |
Group 11 — Storage & Filesystem
| Variable | Default | Description |
|---|---|---|
create_cloud_storage | true | Creates the always-provisioned conf/work buckets plus any in storage_buckets. |
gcs_volumes | [] | Leave empty to use the module's own conf/work mounts. |
enable_nfs | false | Not used — persistence is via GCS Fuse. |
Group 12 — Database Backend
| Variable | Default | Description |
|---|---|---|
database_type | NONE | Fixed — must not be changed. |
Group 13 — Jobs & Scheduled Tasks
| Variable | Default | Description |
|---|---|---|
initialization_jobs | [] | No default job — AdGuard Home needs no database bootstrap. |
Group 14 — Observability & Health
| Variable | Default | Description |
|---|---|---|
startup_probe / liveness_probe | HTTP / | No dedicated health endpoint; root returns 200 before and after setup. |
uptime_check_config | disabled | Optional Cloud Monitoring uptime check. |
Group 16 — Redis Cache
Not applicable — AdGuard Home does not use Redis. enable_redis defaults false.
Group 22 — VPC Service Controls & Audit Logging
| Variable | Default | Description |
|---|---|---|
enable_vpc_sc | false | Enforce a VPC-SC perimeter (requires organization_id). |
5. Outputs
Returned on a successful deployment — the quickest way to locate and explore the running resources.
| Output | Description |
|---|---|
service_name | Cloud Run service name. |
service_url | Default run.app URL of the web admin console (not a DNS resolver address). |
service_location | Region the service runs in. |
load_balancer_ip / load_balancer_url | External HTTPS load balancer IP / URL (when enabled). |
storage_buckets | Created Cloud Storage buckets (conf, work). |
network_name / network_exists / regions | VPC network, presence, regions. |
container_image / container_registry | Deployed image and Artifact Registry repo. |
monitoring_enabled / monitoring_notification_channels / uptime_check_names | Monitoring status, channels, uptime checks. |
deployment_id / tenant_id / resource_prefix | Naming identifiers. |
project_id / project_number | Project identifiers. |
vpc_sc_enabled / vpc_sc_perimeter_name / vpc_sc_dry_run_mode | VPC-SC status. |
6. Configuration Pitfalls & Sensible Defaults
Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).
Inherited plan-time validation. This module passes its configuration through the App_CloudRun foundation engine, which validates values and combinations at plan time. Invalid configuration fails the plan with a clear, named error before any resource is created.
| Setting | Sensible value | Risk | Consequence if wrong |
|---|---|---|---|
| Expecting real DNS resolution from this deployment | Do not rely on it | Critical | Cloud Run cannot expose raw port 53 TCP/UDP under any configuration — clients pointed at this deployment's IP/hostname for DNS will get no response. This module is scoped as a configuration-management console only. |
container_port changed without also changing the setup wizard's own web UI port | Keep both at 3000 | Critical | AdGuard Home's runtime web-UI port comes from AdGuardHome.yaml (set during setup) — if it diverges from container_port, the platform's health probe and public URL stop matching what the container actually listens on, and the revision never becomes Ready after the first restart. |
database_type | NONE (do not change) | Critical | AdGuard Home has no database integration; setting a real engine here has no effect but signals a misunderstanding of the module. |
gcs_volumes | Leave empty (module default) | Critical | Overriding it without also mounting conf/work loses AdGuard Home's configuration and query history on every cold start / restart. |
| Admin console left with no IAP / open sign-up-equivalent | Enable enable_iap or restrict ingress_settings | High | The admin console controls DNS filtering policy; an open, unauthenticated console lets anyone reconfigure filtering or read query logs. |
min_instance_count = 0 (scale-to-zero) | Acceptable default | Low | Cold starts add a few seconds of latency to the first request after idle — fine for an admin console, unlike a real-time DNS resolver. |
memory_limit below 512Mi | Keep at 512Mi (gen2 floor) | Medium | Cloud Run's gen2 execution environment rejects memory_limit < 512Mi outright at plan time. |
For the foundation behaviour referenced throughout — service identity, scaling and concurrency, ingress and load balancing, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, and image mirroring — see App_CloudRun. AdGuard-Home-specific application configuration shared with the GKE variant is described in AdGuardHome_Common.
