Medusa on GKE Autopilot

1. Introduction

The single most important thing to know about this module: Medusa has no official Docker image, so Medusa_GKE builds one from source on every deploy. Every other application module in this catalogue wraps a prebuilt upstream image; this one instead has Cloud Build clone the medusajs/dtc-starter monorepo template (only apps/backend — the Medusa server plus its built-in Admin UI, same process and port — is built; the separate Next.js apps/storefront is explicitly out of scope) and run medusa build inside a multi-stage Dockerfile. Expect a real git clone + pnpm install + medusa build on every image build — budget roughly 10 minutes for the build step alone, separate from Cloud SQL provisioning and Kubernetes Job execution time.

Medusa itself is an open-source, headless e-commerce platform — an API-first alternative to Shopify Plus/Saleor with full programmatic control over products, carts, orders, customers, and payments, plus a built-in Admin UI served by the same server process. This module deploys Medusa on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.

This guide focuses on the cloud services Medusa uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.

---

2. Overview

Capability	Google Cloud service	Notes
Compute	GKE Autopilot	Node.js pods (built from source), 1 vCPU / 1 GiB by default, horizontally autoscaled
Database	Cloud SQL for PostgreSQL 15	Required — Medusa does not support MySQL or other engines
Cache & background workflows	Redis (required)	Session/cache/event-bus/workflow-engine/locking; no supported production fallback
Object storage (optional)	Cloud Storage	Off by default (enable_gcs_storage = false); when enabled, a bucket + dedicated service account + auto-generated HMAC key are provisioned
Secrets	Secret Manager	Auto-generated JWT_SECRET, COOKIE_SECRET, admin password; database password
Ingress	Cloud Load Balancing	service_type = LoadBalancer by default
Build	Cloud Build	Clones medusajs/dtc-starter, runs medusa build — no prebuilt image exists to pull instead

Sensible defaults worth knowing up front:

• PostgreSQL 15 is mandatory. The database engine is fixed by the shared application layer; selecting any other engine breaks startup.
• Redis is required, not optional, in production. enable_redis = true by default. Medusa logs "redisUrl not found. A fake redis instance will be used." and boots anyway if Redis is unreachable — that is a dev/test fallback, not a supported production mode.
• container_port = 9000 — Medusa's documented default port, serving both the REST API and the Admin UI.
• container_image_source = "custom" cannot be changed to "prebuilt" meaningfully — there is no prebuilt Medusa image to deploy instead.
• Build time is real and separate from deploy time. The Cloud Build step is allotted up to 30 minutes (timeout: 1800s in the reference cloudbuild.yaml) though a typical build — clone, pnpm install, medusa build — completes in roughly 10 minutes. This is on top of normal Cloud SQL provisioning (20–35 minutes on a first deploy) and the four init-job (Kubernetes Job) executions that follow.
• A four-stage initialization chain runs before the workload is considered ready: db-init → medusa-migrate → medusa-verify → medusa-admin-create, each depending on the previous.
• MEDUSA_WORKER_MODE = "shared" — a single pod handles both API requests and Medusa's background jobs/subscribers/workflows, since Medusa's officially-recommended split server/worker topology doesn't map onto a single GKE workload.
• enable_gcs_storage = false by default. Medusa falls back to local, ephemeral container filesystem storage for uploaded files until you opt in.
• application_version does not pin what gets built. The Dockerfile has no ARG consuming it — only MEDUSA_STARTER_REF (hardcoded to main in Medusa_Common) controls which dtc-starter branch is cloned.

---

3. Google Cloud Services & How to Explore Them

All commands assume you have run gcloud container clusters get-credentials <cluster> --region <region> --project <project> and that PROJECT, REGION, and NAMESPACE are set. The namespace and other identifiers are reported in the deployment Outputs.

A. GKE Autopilot — the Medusa workload

kubectl get pods,svc -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" deploy/<service-name> --tail=100

See App_GKE for how Autopilot, scaling, and the workload type (Deployment vs StatefulSet) are managed.

B. Cloud Build — the from-source image build

Every deploy (and every rebuild triggered by an edit to the Application module's build config) runs a real build: git clone --depth 1 --branch main https://github.com/medusajs/dtc-starter.git, pnpm install, pnpm build inside apps/backend, then a second pnpm install --prod outside the pnpm workspace before the runtime image is assembled.

gcloud builds list --project "$PROJECT" --limit 5
gcloud builds log <build-id> --project "$PROJECT"

C. Cloud SQL for PostgreSQL 15

Medusa stores all application data (products, orders, customers, carts, inventory) in a managed Cloud SQL for PostgreSQL 15 instance. Pods reach it privately through the Cloud SQL Auth Proxy sidecar over a Unix socket by default.

gcloud sql instances list --project "$PROJECT"
gcloud sql instances describe <instance-name> --project "$PROJECT"
gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"

The instance name, database, user, and password secret are in the Outputs. See App_GKE for the connection model, backups, and password rotation.

D. Redis

Redis is enabled by default. When redis_host is left empty, the platform NFS VM's IP is used as the Redis host fallback (requires enable_nfs = true or a discovered Services_GCP-managed NFS server); otherwise set redis_host explicitly.

redis-cli -h <redis-host> ping
# Confirm the resolved REDIS_URL constructed by entrypoint.sh at boot:
kubectl exec -n "$NAMESPACE" deploy/<service-name> -- env | grep -i redis

E. Cloud Storage (optional)

Only provisioned when enable_gcs_storage = true. No manual HMAC key setup is required — Medusa_Common generates a dedicated service account and access-key/secret-key pair automatically.

gcloud storage buckets list --project "$PROJECT"
gcloud storage ls gs://gcs-<service-name>-storage/

F. Secret Manager

JWT_SECRET, COOKIE_SECRET, and the bootstrapped admin password are generated automatically. The database password is managed separately by the foundation.

gcloud secrets list --project "$PROJECT" --filter="name~medusa"
gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"

G. Networking & ingress

kubectl get svc -n "$NAMESPACE"
gcloud compute addresses list --project "$PROJECT"

See App_GKE for custom domains, Cloud CDN, and static IP details.

H. Cloud Logging & Monitoring

gcloud logging read 'resource.type="k8s_container" AND resource.labels.namespace_name="'"$NAMESPACE"'"' \
  --project "$PROJECT" --limit 50

---

4. Medusa Application Behaviour

The four-stage initialization chain

1. db-init (postgres:15-alpine) — waits for the database, creates the application role and database, grants privileges on public, and best-effort installs the uuid-ossp/postgis extensions.
2. medusa-migrate — runs npx medusa db:migrate on the built image (2 vCPU / 2Gi, up to 30 minutes, 3 retries).
3. medusa-verify — a guard job that connects after medusa-migrate and fails the apply if the public schema has zero tables. This exists because App_GKE's execute_on_apply setting only gates whether Terraform waits for a job, not whether the underlying Kubernetes pod is scheduled before the main workload boots — and an init-job failure does not fail the apply by default. Without medusa-verify, a raced or failed migration could silently ship a healthy-looking pod pointed at an empty database. Live-verified: logged "public schema has 146 table(s)" on a successful deploy.
4. medusa-admin-create — runs npx medusa user -e <email> -p <password> to create the first admin login, using admin_email (default admin@techequity.cloud) and the auto-generated admin-password secret. Live-verified: logged "User created successfully.".

kubectl get jobs -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" job/<job-name>

Health endpoint

/health is unauthenticated and used by both the startup probe (120-second initial delay, 40 × 15-second retries — roughly 12 minutes total) and the liveness probe (30-second initial delay, 3 retries). Live-verified: curl /health returns OK with HTTP 200.

kubectl get pods -n "$NAMESPACE" -o wide
curl -s -o /dev/null -w "%{http_code}\n" "http://<external-ip>/health"

MEDUSA_WORKER_MODE = "shared"

A single pod runs both the API server and Medusa's background jobs/subscribers/workflows — Medusa's officially-recommended split server/worker topology doesn't map onto a single GKE workload, so this module always runs shared mode. Practically: every running replica is doing both request handling and whatever background work Medusa's workflow engine schedules. Unlike Cloud Run, GKE has no request-based CPU throttling concept — each pod's CPU limit is available continuously.

Retrieving the first-run admin credentials

ADMIN_SECRET=$(gcloud secrets list --project "$PROJECT" --filter="name~medusa-admin-password" --format="value(name)")
gcloud secrets versions access latest --secret="$ADMIN_SECRET" --project "$PROJECT"

The admin email is whatever admin_email was set to at deploy time (default admin@techequity.cloud).

Accessing the built-in Admin UI

Medusa serves its Admin UI from the same process and port as the API — open http://<external-ip>/app in a browser and sign in with the email/password retrieved above.

---

5. Configuration Variables

Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Medusa are listed; every other input is inherited from App_GKE with its standard behaviour and defaults.

Group 3 — Application Identity

Variable	Default	Description
application_name	medusa	Base name for resources. Do not change after first deploy.
admin_email	admin@techequity.cloud	Email for the first admin user created by medusa-admin-create.
application_version	latest	Deployment-tracking tag only. Does not select what's built — the Dockerfile has no ARG consuming it; only MEDUSA_STARTER_REF (fixed to main) determines the cloned code.

Group 4 — Runtime & Scaling

Variable	Default	Description
container_resources	{ cpu_limit = "1000m", memory_limit = "1Gi" }	Per-pod resource limits — lower memory default than the CloudRun variant's 2Gi; raise it under combined API + background-workflow load.
min_instance_count / max_instance_count	1 / 3	Replica bounds.
container_port	9000	Medusa's documented default port.
container_image_source	custom	Always builds from source — there is no "prebuilt" Medusa image.
enable_cloudsql_volume	true	Cloud SQL Auth Proxy sidecar.

Group 6 — GKE Backend Configuration

Variable	Default	Description
service_type	LoadBalancer	Exposes the Admin UI and API externally by default.
workload_type	null (resolves to Deployment)	StatefulSet auto-selected only if stateful_pvc_enabled = true.

Group 15 — Database

Variable	Default	Description
database_type	POSTGRES_15	Fixed by Medusa_Common; MySQL is not supported.
application_database_name / application_database_user	medusa / medusa	Database name / application user.

Group 11 — Storage & Filesystem

Variable	Default	Description
enable_gcs_storage	false	Provisions a GCS bucket + auto-generated HMAC key for Medusa's S3-compatible file provider. When false, uploads use local, ephemeral container storage.

Group 21 — Redis & Cloud Armor

Variable	Default	Description
enable_redis	true	Required in production.
redis_host	""	Empty uses the platform NFS VM IP as a fallback (requires enable_nfs = true); otherwise set explicitly.
redis_port / redis_auth	"6379" / ""	Redis port / auth password (sensitive).

Group 14 — Observability & Health

Variable	Default	Description
startup_probe_config	HTTP /health, 120s delay, 40-failure threshold	~12-minute total window.
health_check_config	HTTP /health, 30s delay, 3-failure threshold

For every other group (CI/CD, backup, IAM, VPC-SC, load balancer/CDN, resource quota, stateful workload, etc.), see App_GKE — Medusa inherits the Foundation's standard behaviour with no application-specific override.

---

6. Outputs

Output	Description
service_name	Kubernetes Service name.
namespace	Namespace the workload runs in.
service_external_ip / service_url	External LoadBalancer IP / URL to reach Medusa.
database_instance_name / database_name / database_user	Cloud SQL identifiers.
database_password_secret	Secret Manager secret holding the DB password.
database_host / database_port	DB endpoint (127.0.0.1 via the Auth Proxy) / port.
storage_buckets	Created Cloud Storage buckets — empty unless enable_gcs_storage = true.
container_image / container_registry	The Cloud-Build-produced Medusa image and its Artifact Registry repo.
initialization_jobs	Names of the four created init jobs.
kubernetes_ready	Whether the cluster/workload is ready.
deployment_id / tenant_id / resource_prefix	Naming identifiers.
project_id / project_number	Project identifiers.
cicd_enabled / cicd_configuration / artifact_registry_repository	CI/CD status and details.
vpc_sc_enabled / audit_logging_enabled / artifact_registry_cmek_enabled	Security posture flags.

---

7. Configuration Pitfalls & Sensible Defaults

Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).

Inherited plan-time validation. This module passes its configuration through the App_GKE foundation engine, which validates values and combinations at plan time. Invalid configuration fails the plan with a clear, named error before any resource is created — see also the module-level Validation Guards section of modules/Medusa_GKE/README.md.

Setting	Sensible value	Risk	Consequence if wrong
From-source build (container_image_source = "custom")	No action needed — it's the only valid mode	High	Any change to the Dockerfile, entrypoint.sh, or build args in Medusa_Common requires a real Cloud Build rebuild (~10 minutes for the build step alone) before it takes effect. Force a rebuild with tofu taint 'module.medusa_app.module.app_build.null_resource.build_and_push_application_image[0]' if the content-hash trigger misses an edit.
enable_redis	true	Critical	Medusa logs "redisUrl not found. A fake redis instance will be used." and boots anyway — this graceful-looking log message is a dev/test fallback, not a supported production mode. Cache/session/event-bus/workflow-engine/locking all depend on Redis; disabling it in a long-running production deployment is unsupported.
medusa-verify init job	Leave in the default chain	Critical	This job exists specifically because an init-job failure does not fail the module apply, and execute_on_apply on GKE only gates waiting, not scheduling order against the main workload's boot. Removing medusa-verify (by overriding initialization_jobs) reopens the exact silent-empty-database risk it was added to close.
pnpm workspace-isolation (lesson for extending this Dockerfile pattern)	N/A — informational	High	If you clone this from-source pattern for another pnpm/npm-workspace-based application, remember that build output produced inside a cloned monorepo is still nested under that monorepo's pnpm-workspace.yaml. Running pnpm install --prod directly on that output silently reinstalls it as part of the outer workspace and can write zero node_modules — confirmed here as sh: medusa: not found at runtime. Always copy standalone build output to a directory with no ancestor pnpm-workspace.yaml before installing its production dependencies.
admin_email / bootstrapped admin password	Retrieve from Secret Manager after deploy	High	There is no pre-seeded admin credential visible anywhere except Secret Manager (admin_password_secret_id output) — losing track of it means recovering access via npx medusa user manually against the running database.
container_resources.memory_limit	1Gi default	Medium	Lower than the CloudRun variant's 2Gi default despite running the same shared-worker-mode process; raise it if pods show memory pressure under combined API + background-workflow load.
application_version	Understand it's metadata-only	Low	Changing it does not pin or change what code is built; only MEDUSA_STARTER_REF (fixed to main) controls the cloned dtc-starter branch. A fully reproducible pinned build requires overriding container_build_config.build_args.
enable_gcs_storage = false (default)	Enable it for any persistent-upload use case	Medium	Local storage is ephemeral container filesystem — uploaded product images/files do not survive a pod restart or redeploy.

---

For the foundation behaviour referenced throughout — IAM and Workload Identity, autoscaling, ingress and certificates, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Medusa-specific application configuration shared with the Cloud Run variant is described in Medusa_Common.
