Ghostfolio on GKE Autopilot
Ghostfolio is an open-source, AGPL-licensed wealth management application for tracking net worth, investment portfolios, and asset allocation across multiple brokerage accounts and platforms — a privacy-first alternative to commercial portfolio trackers. This module deploys Ghostfolio on GKE Autopilot on top of the App_GKE foundation, which provisions and manages the shared Google Cloud and Kubernetes infrastructure.
This guide focuses on the cloud services Ghostfolio uses and how to explore and operate them from the Google Cloud Console and the command line. For the mechanics that are common to every GKE application — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC Service Controls, backups, and the deployment lifecycle — refer to the App_GKE foundation guide rather than repeating them here.
1. Overview
Ghostfolio runs as a NestJS (Prisma ORM) web workload. The deployment wires together a focused set of Google Cloud services:
| Capability | Google Cloud service | Notes |
|---|---|---|
| Compute | GKE Autopilot | NestJS API + Angular frontend, 1 vCPU / 1 GiB by default, horizontally autoscaled |
| Database | Cloud SQL for PostgreSQL 15 | Required — Ghostfolio's Prisma ORM does not support MySQL |
| Cache & queue | Redis (required, not optional) | Market-data caching, sessions, and Bull queue/job management |
| Secrets | Secret Manager | Auto-generated ACCESS_TOKEN_SALT and JWT_SECRET_KEY; database password |
| Ingress | Cloud Load Balancing | External LoadBalancer Service by default; optional custom domain + managed certificate |
Sensible defaults worth knowing up front:
- PostgreSQL 15 is mandatory. The database engine is fixed by the shared application layer; Ghostfolio's Prisma ORM does not support other engines.
- Redis is mandatory, not optional. Ghostfolio's own health endpoint checks Redis connectivity directly, so the app never reports healthy without it.
ACCESS_TOKEN_SALTandJWT_SECRET_KEYare generated automatically and stored in Secret Manager. Both are boot-blocking. RotatingACCESS_TOKEN_SALTafter first boot invalidates every previously issued anonymous Security Token.- No seeded admin account. The first visitor to the deployed URL clicks "Get Started" and the app mints a random Security Token as the account owner — there is no email/password form or first-run wizard to complete.
service_type = "LoadBalancer"by default. Ghostfolio is a browser-facing web UI, so unlike internal-only apps (databases, admin tools) it needs a publicly reachable Service.- No bulk file/media storage is provisioned.
enable_nfsdefaultsfalseandstorage_bucketsis always empty. DATABASE_URLis composed at runtime. Ghostfolio's Prisma connection string is a URL-authority DSN; on GKE the cloud entrypoint uses the cloud-sql-proxy sidecar's127.0.0.1loopback withsslmode=disablewhenenable_cloudsql_volume = true(the default).
2. Google Cloud Services & How to Explore Them
All commands assume you have run
gcloud container clusters get-credentials <cluster> --region <region> --project <project>
and that PROJECT, REGION, and NAMESPACE are set. Resource names are reported
in the deployment Outputs.
A. GKE Autopilot — the Ghostfolio workload
Ghostfolio runs as a Kubernetes Deployment behind a Service. Autopilot manages node provisioning and bin-packing automatically.
- Console: Kubernetes Engine → Workloads → select the Deployment.
- CLI:
kubectl get deployment -n "$NAMESPACE"
kubectl get pods -n "$NAMESPACE" -o wide
kubectl describe deployment <deployment-name> -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" -l app=<app-label> --tail=100
See App_GKE for scaling, rollout strategy, and pod disruption budgets.
B. Cloud SQL for PostgreSQL 15
Ghostfolio stores all application data in a managed Cloud SQL for PostgreSQL 15
instance, reached via a cloud-sql-proxy sidecar listening on 127.0.0.1. On first
deploy an initialization Job creates the application database and role.
- Console: SQL → select the instance for connections, backups, flags, metrics.
- CLI:
gcloud sql instances list --project "$PROJECT"
gcloud sql instances describe <instance-name> --project "$PROJECT"
gcloud sql connect <instance-name> --user=<db-user> --database=<db-name> --project "$PROJECT"
C. Redis (required)
Redis backs market-data caching, sessions, and Bull queue/job management.
- CLI:
kubectl exec -it -n "$NAMESPACE" <pod-name> -- sh -c 'echo -e "PING\r" | nc $REDIS_HOST $REDIS_PORT'
# Confirm the pod's injected Redis env vars:
kubectl exec -n "$NAMESPACE" <pod-name> -- env | grep REDIS
D. Secret Manager
Two cryptographic secrets are generated automatically: ACCESS_TOKEN_SALT and
JWT_SECRET_KEY. The database password is managed separately by the foundation and
synced into the cluster via SecretSync.
- Console: Security → Secret Manager.
- CLI:
gcloud secrets list --project "$PROJECT"
gcloud secrets versions access latest --secret=<secret-name> --project "$PROJECT"
E. Networking & ingress
The default LoadBalancer Service exposes an external IP. A Kubernetes Ingress
with a custom domain and managed certificate can be layered on via
enable_custom_domain.
- CLI:
kubectl get svc -n "$NAMESPACE"
kubectl get ingress -n "$NAMESPACE"
F. Cloud Logging & Monitoring
Container logs flow to Cloud Logging automatically via the GKE logging agent; metrics flow to Cloud Monitoring.
- CLI:
gcloud logging read 'resource.type="k8s_container" resource.labels.namespace_name="'"$NAMESPACE"'"' --project "$PROJECT" --limit 50
3. Ghostfolio Application Behaviour
- First-deploy database setup. An initialization Job runs
db-init.shusingpostgres:15-alpine, idempotently creating the application role, database, and grants. - Migrations and seeding run on EVERY container boot, inside the same process
as the server. The upstream
docker/entrypoint.shrunsprisma migrate deploy, thenprisma db seed, then starts the server — a failed migration crashes the container loudly instead of shipping a healthy pod against an empty database. ACCESS_TOKEN_SALTandJWT_SECRET_KEYare immutable after first boot. RotatingACCESS_TOKEN_SALTinvalidates every previously issued Security Token. RotatingJWT_SECRET_KEYlogs everyone out.- No first-run form to fill in. The first visitor mints their own Security Token via "Get Started" — no admin bootstrap step is required.
- Health path. Startup and liveness probes target
GET /api/v1/health, which checks BOTH the database AND Redis connections and returns503until both are healthy. - Inspect job execution:
kubectl get jobs -n "$NAMESPACE"
kubectl logs -n "$NAMESPACE" job/<job-name>
4. Configuration Variables
Variables are grouped exactly as they appear on the deployment platform. Only settings specific to or notable for Ghostfolio are listed; every other input is inherited from App_GKE with its standard behaviour.
Group 3 — Application Identity
| Variable | Default | Description |
|---|---|---|
application_name | ghostfolio | Base name for resources. Do not change after first deploy. |
application_version | latest | Docker Hub's ghostfolio/ghostfolio publishes a real latest tag — pin for reproducible builds. |
Group 4 — Runtime & Scaling
| Variable | Default | Description |
|---|---|---|
container_resources | { cpu_limit="1000m", memory_limit="1Gi" } | 1 vCPU / 1 GiB is sufficient for typical usage. |
container_port | 3333 | Ghostfolio's DEFAULT_PORT. |
enable_cloudsql_volume | true | Runs the cloud-sql-proxy sidecar; DB_IP resolves to 127.0.0.1 and the cloud entrypoint uses sslmode=disable. |
container_image_source | custom | Cloud Build wraps the prebuilt ghostfolio/ghostfolio image with a thin cloud entrypoint. |
Group 6 — Kubernetes Placement & Networking
| Variable | Default | Description |
|---|---|---|
service_type | LoadBalancer | Ghostfolio is a browser-facing web UI — do not switch to ClusterIP without a separate ingress path. |
namespace_name | (auto-generated) | Kubernetes namespace. |
Group 15 — Database
| Variable | Default | Description |
|---|---|---|
application_database_name | ghostfolio | PostgreSQL database name. Immutable after first deploy. |
application_database_user | ghostfolio | Application database user. Password auto-generated in Secret Manager. |
Group 13 — Jobs & NFS
| Variable | Default | Description |
|---|---|---|
initialization_jobs | [] | Leave empty to use the built-in db-init job. No separate migrate job — migrations run inside the app container on every boot. |
enable_nfs | false | Not required — Ghostfolio has no bulk file/media storage. |
Group 14 — Observability & Health
| Variable | Default | Description |
|---|---|---|
startup_probe_config | HTTP /api/v1/health, 30s delay, 12-failure threshold | Checks BOTH database AND Redis connectivity. |
health_check_config | HTTP /api/v1/health, 30s delay, 3-failure threshold | Same endpoint as the startup probe. |
Group 21 — Redis
| Variable | Default | Description |
|---|---|---|
enable_redis | true | REQUIRED — always forward unconditionally, never gate on redis_host != "". |
redis_host | "" | Redis endpoint. Leave empty to use the NFS server IP. |
redis_auth | "" | Redis auth password (sensitive). Aliased at runtime onto Ghostfolio's own REDIS_PASSWORD env var. |
5. Outputs
Returned on a successful deployment — the quickest way to locate and explore the running resources.
| Output | Description |
|---|---|
service_name | Kubernetes Service name. |
service_url | URL of the deployed application (LoadBalancer IP, custom domain, or internal DNS). |
namespace | Kubernetes namespace. |
database_instance_name | Cloud SQL instance name. |
database_name / database_user | Application database name / user. |
database_password_secret | Secret Manager secret holding the DB password. |
storage_buckets | Always empty — Ghostfolio needs no bulk file/media storage. |
container_image / container_registry | Deployed image and Artifact Registry repo. |
initialization_jobs | Names of the setup jobs. |
deployment_id / tenant_id / resource_prefix | Naming identifiers. |
project_id / project_number | Project identifiers. |
6. Configuration Pitfalls & Sensible Defaults
Risk: Critical (data loss / outage / security) — High (service degraded) — Medium (cost or partial degradation) — Low (minor).
| Setting | Sensible value | Risk | Consequence if wrong |
|---|---|---|---|
ACCESS_TOKEN_SALT (auto-generated) | Never rotate after first boot | Critical | Rotating it invalidates every previously issued Security Token. |
JWT_SECRET_KEY (auto-generated) | Only rotate in a maintenance window | Critical | Rotating it invalidates all active sessions. |
application_database_name / application_database_user | Set once | Critical | Immutable after first deploy; renaming recreates the DB/user and destroys all data. |
enable_redis | true, always forwarded unconditionally | Critical | Without it, Ghostfolio's health endpoint never reports healthy. |
service_type | LoadBalancer | High | Switching to ClusterIP without a separate ingress path makes the app unreachable from outside the cluster. |
enable_cloudsql_volume | true | High | Disabling it removes the proxy sidecar, so DB_IP falls back to the raw private IP and the cloud entrypoint's sslmode branching no longer matches a loopback connection. |
enable_backup_import | false unless restoring | Critical | Enabling without a valid backup_uri fails the import job. |
For the foundation behaviour referenced throughout — Workload Identity, ingress, autoscaling, CI/CD, Cloud Armor, IAP, Binary Authorization, VPC-SC, backups, and image mirroring — see App_GKE. Ghostfolio-specific application configuration shared with the Cloud Run variant is described in Ghostfolio_Common.
