PSE Certification Preparation Guide: Section 3 — Ensuring data protection (~23% of the exam)

📚 Official exam guide: Professional Cloud Security Engineer certification — always confirm section weightings against the current Google Cloud exam guide.

This guide covers Section 3 of the Professional Cloud Security Engineer exam. The relevant foundation modules: App_Common (Secret Manager lifecycle and the zero-downtime rotation pipeline), Services_GCP and App_Common (customer-managed encryption keys with plan-time key recovery), and the TLS/storage controls spread across App_CloudRun, App_GKE, and the platform's object-storage layer. Deploy the secure-platform profile with enable_cmek = true plus guarded-edge with enable_auto_password_rotation = true before starting.

---

3.1 Protecting sensitive data and preventing data loss

⏱ ~2 h · 💰 low — Secret Manager versions and one rotation job · ⚙️ Requires: guarded-edge (enable_auto_password_rotation = true); any database-backed deployment

Why the exam cares — The exam tests secret hygiene end to end: never in code/env-var plaintext/Terraform state, least-privilege access per secret, automated rotation with zero downtime, and a defensible audit trail. It also tests restricting access to data services (BigQuery, Cloud Storage, Cloud SQL), protecting compute instance metadata, and Sensitive Data Protection (formerly Cloud DLP) for PII discovery and de-identification — which the modules do not implement.

How RAD implements it — the platform's Secret Manager layer:

• The database password is generated randomly (database_password_length, default 32, range 16–64) and stored as secret-{instance}-{service}. Workload access is per-secret roles/secretmanager.secretAccessor. Apps consume secrets by reference: secret_environment_variables on Cloud Run resolves at runtime via a secret key reference; App_GKE uses the Secret Manager add-on — a SecretProviderClass plus a SecretSync custom resource materializes Secret Manager values into the Kubernetes Secret the pods reference, with secret_propagation_delay (default 30 s) absorbing replication lag.
• The GitHub CI/CD token is written with gcloud secrets versions add inside a provisioner specifically so the plaintext never enters Terraform state — a state-hygiene pattern worth quoting in exam answers about IaC secret handling.
• secret_rotation_period (default 2592000s = 30 days) creates the Pub/Sub topic secret-{service}-rotation and grants the Secret Manager service identity roles/pubsub.publisher so Secret Manager itself emits rotation notifications on schedule.
• enable_auto_password_rotation (default false; plan-time validation requires a database) deploys the full handler: Eventarc trigger → pw-rotator-dispatcher Cloud Run service → {prefix}-pw-rotator Cloud Run job. The job's zero-downtime dual-version flow: record current ENABLED version → generate a new random password → ALTER USER on Cloud SQL (effective immediately) → add a new secret version (so latest serves the new value) → sleep rotation_propagation_delay_sec (default 90) → disable (not destroy) the old version, keeping it for rollback and audit.

Datastore-side protection: Cloud SQL is private-IP-only with encrypted-only SSL mode; Redis has AUTH enabled with the AUTH string stored in Secret Manager.

Instance metadata: the one Compute Engine VM the platform runs, the NFS server (create_network_filesystem in Services_GCP, enable_nfs in App_CloudRun), is built from an instance template that sets the enable-oslogin = true metadata key (so SSH access is governed by IAM rather than by SSH keys pasted into metadata), enables Shielded VM (Secure Boot, vTPM, integrity monitoring), and has no external IP. On GKE, workloads reach Google credentials through the Workload Identity metadata server rather than the node's metadata.

Try it

1. Deploy with rotation enabled. In Console > Security > Secret Manager, open secret-{instance}-{service} → Versions: note the version history and the rotation settings (next rotation time, topic).
2. Trigger and observe a rotation without waiting 30 days:

gcloud run jobs execute <prefix>-pw-rotator --region us-central1 --wait
gcloud secrets versions list secret-<instance>-<service> \
  --format="table(name, state, createTime)"

3. You should see a new ENABLED version and the previous one DISABLED. Confirm the app still serves traffic during the swap (the dual-version window plus the propagation sleep covers in-flight connections).
4. Audit who touched the secret (requires enable_audit_logging = true):

gcloud logging read 'protoPayload.serviceName="secretmanager.googleapis.com" AND protoPayload.methodName:"AccessSecretVersion"' \
  --limit=10 --format="table(timestamp, protoPayload.authenticationInfo.principalEmail)"

5. You know it worked when the version table shows the dual-version history and the data-access log names the workload SA as the only payload reader.

Check yourself

Q1: Scenario — during password rotation, users must see zero failed logins. Order the steps correctly and explain the critical ordering decision.

A: Generate new password → update the database user (ALTER USER) → add the new Secret Manager version → wait a propagation delay → disable the old version. The critical choice: the DB is updated before the secret version, and the old version is disabled only after propagation — during the window both old (cached) and new credentials authenticate, so no client fails. Disabling (not destroying) the old version preserves rollback.

Q2: Why does Secret Manager's rotation feature alone not rotate anything?

A: rotation on a secret only publishes a Pub/Sub notification on schedule. Something must consume it and perform the change — here, Eventarc fires the dispatcher, which executes the rotator job. The exam loves this distinction: rotation schedule = notification; rotation handler = your code.

Q3: A teammate proposes declaring Secret Manager secret versions directly in Terraform for API tokens. What is the risk and the deployed alternative?

A: That resource stores the plaintext payload in Terraform state — anyone with state access (or a committed state file) reads the secret. The module instead pushes the value with gcloud secrets versions add in a provisioner, so only a non-reversible hash is kept in state and workloads read the secret by ID at runtime.

Beyond the modules — Sensitive Data Protection (Cloud DLP) is not implemented: study infoType inspection of Cloud Storage/BigQuery, de-identification (redaction, CryptoDeterministicConfig tokenization, format-preserving encryption with CryptoReplaceFfxFpeConfig), and routing findings to SCC. Scratch command: gcloud dlp inspect-templates create or inspect a string via the API: gcloud alpha dlp text inspect --content="My SSN is 123-45-6789" --info-types=US_SOCIAL_SECURITY_NUMBER (or use the Security > Sensitive Data Protection console). Also study BigQuery column-level security and dynamic data masking — no BigQuery exists in the platform — and instance metadata protection: block-project-ssh-keys, why OS Login beats metadata SSH keys, the Metadata-Flavor: Google header requirement, and never storing secrets in metadata or startup scripts.

⚠️ Exam trap — DISABLED secret versions can be re-enabled; DESTROYED versions are gone forever. Rotation handlers should disable, not destroy, the previous version until the new one is proven — exactly what the rotator job does.

---

3.2 Managing encryption at rest, in transit, and in use

⏱ ~2 h · 💰 low — a few KMS key versions per month · ⚙️ Requires: secure-platform (enable_cmek = true)

Why the exam cares — You must choose the right key-management tier (Google default → CMEK → Cloud HSM → Cloud EKM/Hold-Your-Own-Key) for a compliance requirement, understand rotation semantics (new versions encrypt; old versions still decrypt), key state transitions (ENABLED/DISABLED/DESTROY_SCHEDULED/DESTROYED), and crypto-shredding.

How RAD implements it —

• At rest, CMEK (enable_cmek default false): keyring cmek-{prefix} (created idempotently because keyrings are indestructible) with three symmetric-encryption keys — cloudsql-{prefix}-key, artifactregistry-{prefix}-key, storage-{prefix}-key — each rotating on cmek_key_rotation_period (default 7776000s, 90 days). Each service identity (Cloud SQL, AlloyDB, Artifact Registry; the GCS service agent) is granted roles/cloudkms.cryptoKeyEncrypterDecrypter on the individual key, not the project.
• App-layer CMEK: discovers the Services_GCP keyring or creates {project_id}-cmek-keyring, manages well-known keys storage-key and artifact-registry-key, and waits ~60 s for IAM propagation before encrypting buckets/repos.
• Key recovery at plan time (a key-recovery script runs on every plan): if the named key version is scheduled for destruction it is restored, if disabled it is re-enabled, if missing it is created — returning a key status of enabled|restored|created|skipped. A companion check re-asserts the GCS service agent's KMS grant. The Binary Authorization signing key gets the same restore-and-enable treatment.
• In transit: Certificate Manager Google-managed certificates terminate TLS at the global HTTPS LB with permanent HTTP→HTTPS redirects; Cloud SQL enforces encrypted-only SSL mode (PostgreSQL); the Cloud SQL Auth Proxy sidecar gives mTLS-wrapped database connections on GKE.
• In use: not implemented (no Confidential VMs / Confidential GKE Nodes).
• Object lifecycle policies: the backup bucket carries a Cloud Storage lifecycle rule that deletes objects older than backup_retention_days (App_CloudRun and App_GKE), and each entry in storage_buckets accepts lifecycle_rules (delete or change storage class by age, version count, and similar conditions).

Try it

1. In Console > Security > Key Management, open keyring cmek-{prefix}; check each key's rotation period and next rotation date, and the per-key IAM grants on the Permissions pane.

gcloud kms keys list --keyring=cmek-<prefix> --location=us-central1 \
  --format="table(name, purpose, rotationPeriod, primary.state)"
gcloud kms keys get-iam-policy cloudsql-<prefix>-key \
  --keyring=cmek-<prefix> --location=us-central1
gcloud sql instances describe <instance> --format="value(diskEncryptionConfiguration.kmsKeyName)"

2. Exercise the recovery path: disable the storage key version (gcloud kms keys versions disable 1 --key=storage-key --keyring=<keyring> --location=us-central1), then run a plan/redeploy from the portal — the platform's plan-time key-recovery check re-enables it before any bucket operation; check the plan log for a key status of restored/enabled.
3. You know it worked when the Cloud SQL instance reports your CMEK key name and the disabled key version is ENABLED again after the next plan.

Check yourself

Q1: Scenario — a regulator requires that you can render all customer data unrecoverable on demand ("crypto-shredding"). How does the deployed CMEK design satisfy this, and what is the irreversible step?

A: All Cloud SQL/GCS/AR data is encrypted under customer-managed keys. Disabling the key versions makes data immediately inaccessible but reversible; scheduling destruction (gcloud kms keys versions destroy) and letting the 24-hour-plus pending window elapse destroys the key material, making every byte encrypted under it permanently unrecoverable — including backups. Destruction of the key version is the irreversible step.

Q2: After automatic rotation creates key version 5, can data encrypted under version 2 still be read?

A: Yes. Rotation changes the primary version used for new encryption; existing ciphertext stays decryptable by its original version as long as that version remains enabled. This is why disabling/destroying old versions, not rotation itself, is what cuts access to old data.

Q3: Cloud SQL instance creation fails with "Cloud KMS key is disabled, destroyed, or scheduled to be destroyed." What does the platform do about this class of failure, and what would you answer on the exam?

A: The platform's plan-time data "external" probe restores DESTROY_SCHEDULED versions and re-enables DISABLED ones before dependent resources are touched. The exam answer: restore the key version (possible only during the scheduled-destruction window) or re-enable it, and verify the service agent still holds roles/cloudkms.cryptoKeyEncrypterDecrypter on the key.

Beyond the modules — Not implemented: choosing software versus hardware keys (Cloud KMS software keys versus the Cloud HSM protection level, FIPS 140-2 Level 3 — --protection-level=hsm at key creation), Cloud EKM (keys held outside Google entirely), customer-supplied encryption keys (CSEK), key import (import jobs for bringing your own key material), explicit key revocation by disabling or destroying versions, Confidential Computing (AMD SEV Confidential VMs / Confidential GKE Nodes), and client-side/application-layer encryption (e.g., Tink). Scratch commands: gcloud kms keys create hsm-key --keyring=KR --location=L --purpose=encryption --protection-level=hsm and gcloud compute instances create cvm --confidential-compute --maintenance-policy=TERMINATE.

⚠️ Exam trap — CMEK does not mean Google "can't see" your data (the key still lives in Cloud KMS and Google infrastructure performs the cryptography); it means you control the key lifecycle and IAM. Only Cloud EKM (external key manager) keeps key material outside Google — pick EKM for "provider must never hold the key" scenarios.

---

3.3 Securing AI workloads

⏱ ~30 min (reading) · 💰 n/a · ⚙️ Requires: nothing deployable — concept-only

Why the exam cares — The current PSE exam includes securing AI/ML systems: threats unique to models (prompt injection, training-data poisoning, model inversion/extraction), guardrail services (Model Armor), de-identifying training data, the IaaS-vs-PaaS responsibility split for training infrastructure, and security controls for Gemini Enterprise Agent Platform.

How RAD implements it — No AI-specific control (Model Armor, Gemini Enterprise Agent Platform, Vertex AI) is implemented by the modules. The catalogue does deploy self-hosted AI applications on the foundation modules — for example Ollama_CloudRun (CPU-only) and Ollama_GKE (optional NVIDIA L4 GPU node pool) for model serving, with model weights on a Cloud Storage bucket, and AI gateways and front-ends such as LiteLLM_CloudRun, OpenWebUI_CloudRun and AnythingLLM_CloudRun — and they inherit the generic controls below; the Cloud Run versus GKE choice is a small-scale version of the PaaS-versus-IaaS responsibility question. The nearest adjacency: every generic control here also protects an AI workload's serving path — Artifact Registry vulnerability scanning for model-server images, Binary Authorization for attested inference containers, VPC-SC around storage/APIs holding training data, CMEK on the buckets that would hold model artifacts, and IAP/Cloud Armor in front of inference endpoints.

Try it

1. The modules add no AI-specific controls; instead, rehearse the perimeter pattern you would reuse (in a project of your own, since VPC-SC is not offered in a RAD-managed one): confirm storage.googleapis.com (training data) and artifactregistry.googleapis.com (model images) are in the deployed perimeter's restricted-services list.

POLICY=$(gcloud access-context-manager policies list --organization=ORG_ID --format="value(name)")
gcloud access-context-manager perimeters dry-run describe vpcsc_<prefix>_perimeter \
  --policy=$POLICY --format="yaml(spec.restrictedServices)"

2. You know you've internalized the mapping when you can state which deployed control would cover aiplatform.googleapis.com if it were added to a perimeter (the same access-level + restricted-service mechanism).

Check yourself

Q1: Scenario — a fine-tuned internal LLM occasionally outputs employee phone numbers from its training data. Which two Google Cloud controls address this, at which stage?

A: Sensitive Data Protection de-identification of the training corpus before fine-tuning (prevents memorization of PII), and Model Armor response filters on the serving path to detect and block PII leakage in outputs. IAM/VPC-SC don't help — the leak is via legitimate model responses.

Q2: What changes in your security responsibilities between training on Compute Engine GPUs (IaaS) versus Vertex AI Training (PaaS)?

A: IaaS: you own OS hardening (Shielded VM), patching, inter-node lateral-movement controls (no external IPs, firewall rules), plus data/IAM controls. PaaS: Google runs the nodes; your scope narrows to Vertex AI IAM roles, CMEK on artifacts, VPC-SC on the Vertex AI API, and private endpoints. Same shared-responsibility narrowing logic as GKE Standard vs Autopilot.

Beyond the modules — Study: Model Armor templates (prompt-injection/jailbreak/PII filters for Gemini and Vertex endpoints); security controls for Gemini Enterprise Agent Platform (identity and IAM for agents and the people who use them, what data connectors let an agent reach, VPC-SC, CMEK and audit logging — check the current product documentation, as the naming is recent); Vertex AI security controls (CMEK, VPC-SC support, Private Service Connect endpoints, granular roles such as roles/aiplatform.user), and the OWASP Top 10 for LLM Applications. Scratch commands: gcloud ai models list --region=us-central1, and review the Model Armor page in the console.

⚠️ Exam trap — Prompt injection is an input-validation problem at the model boundary; WAFs like Cloud Armor cannot parse prompts semantically. Answers that bolt a WAF onto an LLM endpoint to stop jailbreaks are distractors — Model Armor (or equivalent guardrails) is the control.
